Haier HRF-349NAA User manual

(1) Four temperature zones
Four temperature zones for satisfaction of varied storage needs
(2) 0°C zone
Temperature ranges between -2°C and +3°C for storage of fresh and uncooked
food with an ideal outcome of nutrient contents preservation.
(3) -7°C storage
Food stored in the wide-temp zone (-7°C) requires no preservice defrosting and
additional labor on processing but well keeps the nutrient value.
(4) Automatic temperature control
In Fuzzy mode, the appliance adjusts inside temperature automatically according
to variation of ambient temperature conditions for an optimized cooling
performance.
(5) Over temp alarm
The alarm function is activated when temperature exceeds the set temperature
value.
(6) Holiday mode
The appliance keeps operation but consumes the least energy while ensuring
that no unwanted odor in refrigerator and remaining food in good condition.
(7) Fresh food basket
The basket is designed for storage of fresh vegetables in an extended period.
(8) Deodorizer
The deodorizer incorporates advanced biological sterilization technology to
exterminate most bacteria and bacillus and remove bad odors in the air.
(9) VFD flashing display
Application of vacuum fluorescence technology for display of the refrigerator
operation status.
(10) 007 mode
The wide temp zone can be set for super freeze 007 mode for nutrient value
preservation.
(11) Ice cube tray
An ice cube tray is installed inside the freezer door to avoid odor contact.
(12) Touch control
The appliance uses a touch control panel with sensitive performance and elegant
design.
Primary features

Technical data in this manual may vary from that of the refrigerator you have just
purchased due to technical improvement.
Parts and features
Lights
Food shelf
Crisper
0°C zone
Wide temp drawer
Freezer drawer
Power plug
Bottle holder cover
Short bottle holder
Small bottle holder cover
Small bottle holder
Vegetable basket
Deodorizer
Large bottle holder
Ice cube box
Wine rack
Warning: The plug should be accessible after the appliance positioned.
If the supply cord is damaged, it must be replaced by the manufacture or its
service agent or a similary qualified person in order to avoid a hazard.
Warning: The appliance is not intended for use by young children or infirm persons without
supervision.
Warning: Young children should be supervised to ensure that they do not play with the
appliance.
Warning: Keep ventilation openings in the appliance enclosure or in the built-in structure;
clear of obstruction.
Warning: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufaturer.
Warning: Do not damage the refrigerant circuit (applicable only for appliances with
refrigeration circuits which are accessible to the user).
Warning: Do not use electrical appliances indide the food storage compartments, unless
they are of the type recommended by the manufacturer.

Safety precautions
This refrigerator requires a 220-240V
/50Hz supply
Failure in operation and damage to the
control panel, thermostat or the
compressor will occur if voltage is outside
the range 187-242V unless a regulator
with a capacity of over 750W or higher is
installed.
A separate earthed socket is required.
Care for external cable
* Hold the plug, not the electric cable,
when unplugging the appliance.
* Ensure that the electric cable is not
trapped by the appliance.
* Do not step on the cable. Avoid damage
to the electric cable when moving the
appliance.
Damaged electric cable
When the electrical cable is damaged or
worn, turn off the appliance and consult to
an authorized service agent for
replacement.
If inflammable gas leaks in the vicinity
of the appliance
* Turn off any leaking valve;
* Open the doors and windows;
* Do not, under any circumstances,
unplug electrical appliances in the vicinity
of the leak.
Unplug the appliance for the following:
* Cleaning or maintenance;
* Replacement of lamp

Never store inflammable, explosive or
corrosive materials in the appliance.
This appliance should only be used for
household purpose and cannot be used
for storage of blood, pharmaceuticals and
microbiological products.
Do not install the appliance near gasoline
or other inflammable articles.
Don't place electrical plugs, regulators or
microwaves on top of the appliance. Don't
use electric appliances (Except those
allowed by manufacturer) inside the
appliance.
Do not swing on or apply excessive
pressure to the appliance door.
Don't place heavy or unstable articles or
water containers on top of the appliance.
Mousse Spray Gas Acid Alkali
Vaccine
Chemical Agent
Bacterin
Safety precautions

Remove the appliance door and door seal
if the appliance is discarded to prevent
accidental entrapment in the appliance.
Do not touch inside surface of freezer
compartment in operation, especially with
wet hands as hands may freeze onto the
surface.
Do not spray or splash the appliance
when cleaning the appliance, nor place
the appliance in a damp area.
Disassembly, renovation or cooling
system maintenance of appliance must be
authorized.
Unplug the appliance in the event of a
power interruption or during cleaning.
Allow at least 5 minutes lapse before
restarting the appliance.
Never store bottled beer or beverages in
the freezer compartment.
Safety precautions

Location
The appliance should be placed on a flat and solid surface. If the appliance is placed on
a plinth, flat, strong and fire-resistant materials must be used. The front black foot of the
appliance can be adjusted clockwise or anti-clockwise to lift or lower the appliance if it is
placed on an uneven surface.
Adjustable Foot
The appliance shall be placed away from
heat sources or direct sunlight.
The appliance should be placed in a well-
ventilated area, and a space of 10cm or
more should be allowed around the
appliance.
Never place the appliance near to a water
source. Clean and dry any water splashes
and stains with soft cloth.
Never operate the appliance in low
ambient temperature (below 5°C) or
outdoors.
Clockwise Anti-clockwise
Space
>10cm
>10cm
>10cm

Preparation
Unpacking
Remove all packing materials.
Check attached accessories
and materials.
Check if all accessories specified in the
Packing List are available. Contact the
local distributor if shortage is found.
Ensure that the appliance is
properly located.
(See section “Location”)
Clean the appliance before
using.
(See section “Cleaning”)
Time lapse before power supply
Connect the appliance to power source at
least 30 minutes after the appliance is sited
and cleaned.
Operation
Manual
Warranty
Certificate
Caution: After unpacking, write down the model and manufacture number of
the appliance on the Warranty Certificate which will be required if technical
services are applied for.

Operation
Connection to power supply
When the appliance is connected to a power supply, the Fuzzy mode is set,
icon of the mode goes on, and temperature in wide temp and freezer zones
are displayed, default time is 12:00 and icon of freezer coruscates.
Setting of operation mode
Either of the following operation modes can be selected.
(1) Fuzzy mode: If no special requirement is intended, it is recommended that fuzzy mode
be used. Hold Fuzzy button pressed for 3 seconds until the icon appears. The appliance
is then operational automatically. (Refer to section “Functions”).
(2) Manual mode: In lock-off mode, press temperature button for temperature adjustment.
(See section “Functions”)
Suggestion
Regardless of irrespective fluctuations in ambient
temperature, selection of the Fuzzy Operation Mode
will guarantee the most efficient and energy-saving
operation of the appliance.
Loading the appliance with food
Load the appliance with food when the over temp
alarm icon disappears, indicating that the set
temperature of the appliance compartments has
been reached.
Caution: Some time is required before reset temperature is reached. The
length of this period depends on the extent of the temperature change,
ambient temperature, frequency of door opening and amount of food in
storage.

Functions
A. Refrigerator/(pressed for 3 seconds in lock-on mode) Refrigerator ON/OFF
B. Wide temp zone / (pressed for 3 seconds in lock-on mode) wide temp zone ON/OFF/
pressed for 3 seconds, 007 super freeze mode ON/OFF
C. Freezer / (pressed for 3 seconds in lock-on mode) super freeze
D. Fuzzy mode / (pressed for 3 seconds in lock-on mode) holiday mode
C+D Lock-on and Lock-off E. Refrigerator average temperature display
F. Wide temp zone average temperature display
G. Freezer average temperature display H. Fuzzy mode icon
I. Super freeze mode icon J. Holiday mode icon
K. Lock-on mode icon L. Ambient temperature display icon M. Clock icon
Note: These block English letters in front of the phrases above listed will be used
hereinafter to represent the phrases thereof.
Control panel
Lock-on and lock-off mode
In lock-off mode, if button C and button D are held pressed simultaneously, icon K appears;
In lock-on mode, if button C and button D are pressed simultaneously, icon K disappears
and lock-on mode is inactivated and the following modes can be adjusted.

Caution
The following functions 3, 4, 5 and 6 can be
operated under Lock-off mode. (icon K
disappears)
Fuzzy mode (This section can be skipped if Manual Mode is set.)
* This mode is designed to ensure normal operation of the appliance under
variable ambient temperature.
* Temperature in refrigerator is automatically adjusted according to variations of
ambient temperature.
Hold button D pressed for 3 seconds then icon H will appear on the display screen and the
fuzzy operation mode is set. Pressing button D again for 3 seconds until icon H disappears
can inactivate the fuzzy operation mode.
Caution: In fuzzy mode, temperature of the refrigerator and freezer cannot
be adjusted and super freeze mode cannot be set, but temperature in the
wide temp zone can be reset.
Refrigerator setup and adjusting (This section can be skipped if
Fuzzy mode is set.)
Press button A, E icon of current temperature value coruscates. Every press of button A
will result in increase of refrigerator temperature by 1°C in a cycle from 2°C to 10°C. The
current temperature icon will not coruscate and icon E will again display refrigerator
average temperature screen 5 seconds later after last press of the button.
Functions

Wide temp zone adjusting
The wide temp zone can be adjusted between -3°C and -18°C. If button B is pressed, icon
F of current temperature will blink. Every press of button B will result in decrease of
current temperature by 1 degree until -18°C. The cycle starts from -3°C. 5 seconds later
after the latest press of any button, the indication of current temperature will cease
blinking and icon F will display fridge average temperature.
Freezer adjusting (This section can be skipped if Fuzzy mode is set.)
Press button C, icon G will coruscate. Every press of button C will result in decrease of
current temperature by 1 degree until -26°C. The cycle starts from -16°C. 5 seconds later
after the latest press of any button, the indication of current temperature will cease
blinking and icon G will display freezer average temperature.
Super freeze (Super freeze mode cannot be set under Fuzzy mode.)
* Super freeze function is designed to preserve the nutritional value of food,
as the food will freeze completely in the shortest period possible.
Functions

In lock-on mode (icon K appears), hold button C pressed for 3 seconds, then the super
freeze mode can be set and icon I appears. The super freeze mode can be inactivated
manually by holding button C pressed for 3 seconds in lock-on mode, then icon I
disappears. This mode will cease automatically when preset operating period of the
compressor finishes.
Display function control
30 seconds after the latest setup, VFD brightness becomes weakened. 3 minutes later,
VFD become black automatically. If temperature in freezer is too high and the over-temp
alarm is activated, VFD will not become black.
Refrigerator On/Off
In lock-on mode (icon K appears), hold button A pressed for 3 seconds, icon E disappears
and operation of refrigerator ceases; If button A is again held pressed for 3 seconds in
lock-on mode, icon E will appear and operation of refrigerator will be resumed.
Functions
Caution: If super freeze mode is set, freezer temperature cannot be adjusted.
Temperature of wide-temp zone and refrigerator can be adjusted if lock on mode is
inactivated by pressing buttons C and D.

Wide temp zone ON/OFF
In lock-on mode (icon K appears), hold button B pressed for 3 seconds, icon F disappears
and wide temp zone ceases operation. If button B is again held pressed for 3 seconds in
lock-on mode, icon F will appear and operation of wide temp zone will be resumed.
Time setup
When lock-on mode is set (icon K appears), hold button B and C pressed and then icon M
blinks for time setup. Press of button B adjusts the digits of hour. (Every press will result in
a digit increase until “23” appears. The cycle starts from “00”.) Press of button C adjusts
the digits of minute. (Every press will result in a digit increase until “59” appears. The cycle
starts from “00”.) 5 seconds later after the latest press, digits of time will cease blinking.
Holiday mode
When lock-on mode is set (icon K appears), hold button D pressed for 3 seconds and icon
J appears and the refrigerator, wide-temp zone and freezer will approach to the
temperature of 17°C, -7°C and -18°C, respectively. The holiday mode can be manually
inactivated by holding button D pressed for 3 seconds in lock on mode, then icon J will
disappear.
Functions

Caution: In fuzzy or super freeze mode, the holiday mode cannot be activated.
Over temperature alarm
If appliance door is not properly closed or a large quantity of hot food is loaded,
temperature in appliance may exceed the set point, icon G will coruscate. Contact
authorized after-sales agent if icon G keeps coruscating a while later.
Power interruption memory
The current operating mode can be resumed if the power supply is regained
after a temporary interruption.
Caution: The clock needs to be reset if the power supply is regained after a
temporary interruption.
If any of the appliance sensors does not work properly, icon E or F will display F1, F2, F3,
F4, F5 or F6 accordingly. Although appliance does not cease operating, it is strongly
recommended that authorized sales service agent be contacted for technical assistance.
Malfunction display
In lock-off mode, hold button B pressed for 3 seconds, icon H and I appear and wide-temp
zone enters 007 mode. The 007 mode can either be manually inactivated by holding
button B pressed for 3 seconds again in lock-off mode, then icon H and I disappear, or
cease automatically when temperature in wide-temp zone reaches -18°C. The super
freeze 007 mode cannot be activated if temperature in wide-temp zone is not above -18°C.
Super freeze 007
Functions

The refrigerator is for short-term
food storage of daily
consumption.
Although the temperature in most areas in
the refrigeration compartment can be
regulated between 2°C and 10°C, extended
periods of food storage is not recommended.
Refrigerator should only be used for short-
term storage.
Storage areas
As cold air circulates inside the refrigerator,
temperature differences exist inside the
storage compartments. Area is the coldest.
Different foods should be placed in different
areas according to their properties.
Eggs, butter and cheese
Canned food, seasonings, beverages and
bottled food
Chinese onion, garlic bolt, turnip, carrot
and asparagus
Pickled food or canned pickled food
Wheaten food, canned food, milk and
beancurd
Cooked meat and sausages
Fruit, vegetables and salad
Sashimi, lamb and beef (stay best max. 3
days)
Lamp and its replacement
Lamp: 5V DC, 1W
LED lamp is used for low energy
consumption and extended service life. If the
lamp does not work properly, contact
authorized service agent for technical
assistance.
Wine rack
The wine rack is located right above the food
shelf and can be moved freely to either side.
The rack is contoured for loading beer and
wine bottles. (When the rack slides, a slight
sound might be heard.)
About refrigerator

How to use vegetable basket
* The vegetable basket is designed for holding
Chinese onion, garlic bolt, turnip, carrot and
asparagus.
* Over the baffle, cans, seasoning, beverage and
small bottles can be stored.
* Remove the baffle if Chinese onions or garlic bolts
or alike are to be placed. (As shown in the figure)
* Keep the baffle slightly tilted (about 30°) for easy
access.
* Other articles can be stored at your discretion.
Baffle
Vegetable
basket
Hot food must be cooled to room
temperature before storing in the appliance.
Dry any water droplets on the food before
placing it in the appliance.
Food to be stored should be properly
sealed.
This will prevent moisture in the food from
evaporating and prevent vegetables and
fruit from tainting in flavor.
Storage of sorted food
Food to be stored should be sorted
according to consumer requirements. Food
consumed daily should be placed in the
most convenient area, this will minimize
opening periods for the door.
Do not store excess quantities or weights
of food
Food should be stored with spaces in
between for better storage results.
Do not place food too close to the internal
walls
Food with high moisture content should not
be placed close to the walls of the inner
liner. Maintain a space to prevent food
from freezing onto the walls.
Do not load food, especially the food with oil content, against interior walls
as oil stains might result in corrosion of the walls. Always keep interior
walls clean.
Precautions

Ripe squash, melon, pawpaw, bananas
and pineapples should not be stored in
the refrigerator. Freezing will accelerate
the ripening process.
Leaves of carrots or turnips should be removed before storage.
Eggs should be stored vertically in the egg
holder.
Frozen food can be placed in the cold
compartment before serving, as this will
conserve energy.
Onions, garlic, ginger, water chestnuts
and other root vegetables should not be
stored in the refrigerator, as these foods
are suitable for long-term storage at
normal temperatures.
Caution: Vegetables and fruits should be stored on the upper areas in the
refrigerator when ambient temperature is between 0-10°C and the
temperature in the lower area of the refrigerator compartment is around 0°C.
Suggestions

The appliance has a wide temp zone (-3°C~-18°C). When temperature is
set at -18°C, the zone can be used as freezer compartment. When
temperature is set between -3°C and -7°C, the zone has the following
advantages:
* Defrosting free: Food in storage in the wide temp zone can be prepared for cooking
without manual or microwave defrosting
* Nutritional value preservation: Nutritional values of food in storage in the wide temp
zone can be better preserved.
* Easy processing: Meat in wide temp zone can be easily cut; Minced meat in wide temp
zone can serve directly.
* Stored overlapped food in wide temp zone can be easily separated before serve.
* Extended storage period as follows: 14 days for meat and 7 days for fish under -7°C;
10 days for meat and 5 days for fish under -5°C; 7 days for meat and 3 days for fish
under -3°C.
Food recommended for storage (-3°C~-7°C):
Fresh fish and meat, food with curry coating, minced meat, fresh fruit juice
Food not recommended for storage (-3°C~-7°C):
Ice cream and frozen food, which should be stored in the freezing compartment.
Advantages of wide temp zone (-3°C~-7°C):
* Fried food will be crisper if stored in the wide temp zone in advance.
* Cold dishes will become more delicious if stored in the wide temp zone before serving.
* Roasted sashimi and cuttlefish will be more delicious after stored in the wide temp
zone.
* Salad will be more delicious after stored in the wide temp zone.
* Vegetables such as spinach stored in the compartment can be servedafter slightly
steeped in hot water.
* Nutrient value and natural flavor of fresh fruits will be well preserved after stored in the
wide temp zone.
* Efficient cooling function for hot food can be achieved.
Caution: Cutting of meat or fish may vary due to their moisture contents and
sharpenness of kitchen knife. It is suggested that the meat or fish be cut
after being placed in room temperature a few minutes.
About wide-temp zone

Long-term storage of food
As the freezer storage temperature is very low, fresh
food can be stored in the freezer compartment for a
long time. Food requiring long-term storage can be
stored in the freezer. Follow the instructions on the
package for storage period.
Attention should be paid to the storage information printed on the food packing.
Food
Chicken, beef, mutton and shrimps
Dumplings, ribs and ice-creams
Cakes, breads, sliced meat and cheese
Seafood, sausages and icecream
Stay Best (Month)
4
4
2
1
Maximum (Month)
9
6
6
3
Storage period is subject to the detailed information on the food packing, property of the
food for storage and special requirements.
Super freeze
Select super freeze if a large quantity of fresh food is to be loaded in freezer (see relative
section afore); Do not select super freeze mode for the food less than 1kg or pre-frozen.
Making ice cubes
* As shown in Figure 1, hold and remove the ice cube box from the door lining.
* Place the uncovered ice cube box as shown in Figure 2, fill the box with water. Make
sure that the water surface is below the water level mark.
Caution: If excessive water is filled, ice cubes might not be easily removed. Turn the ice
cube box 90°around as shown in Figure 2, leave it alone until the water deposits well in
oval moulds and finally load the ice cube box back into the door lining.
* When ice cubes are ready for service, remove the ice cube box and immerse the box in
warm water for a while. Uncover and rap the box and pour all ice cubes from the water
inlet. (Make sure no ice cube is left inside the box, or ice cubes will not be easily
removed next time.)
Fig.1 Fig.2
About freezer
