Haier HVS1200 User manual

Table of Contents
Before using the appliance
Matters needing attention......1-3
Installation.............................4-5
Function ...............................6-8
How to operate the wasing machine
Program description table........9
Preparation ...........................10
Washing Procedure ..........11-12
Maintenance ..........................13
Technical Specifications ........15
Wiring Circuit .........................16
Maintenance
Troubleshooting Guide ..........14
Operation Manual
Automatic Drum Washing Machine
Name of parts...inside front cover
HVS1200 HVS1000

Top
Handle
Program selector
Detergent dispenser
Name of Parts
Door
Porthole
Function selector
Caution and Warning symbols
Bottom panel
This diagram may be slightly different from the layout of the washing machine you have just purchased due to techincal improvements
For you safely,any instructions in this manual with this "Warning"sign must be followed strictly.
For your safety and to prevent damage to the washing machine,any instructions in this manual with this "Stop" sign must be followed strictly.
ON/OFF button


Matters Needing Attention
ƽSafety

.A separate earthed socket is required for the
power supply. The washing machine must be positioned so that the plug is accessible.
2. Hold the plug and not the electric cable when
unplugging the washing machine.
3.Fuses in the power circuit should be rated for 15A.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
4. Do not touch or use the washing machine bare-
footed or when the hands or feet are wet.
5.Do not use flammable detergent or dry clean
ing agent; do not use flammable spray in close vicinity to the washing machine; do not remove
or insert the plug in the presence of flammable
gas.
6. The door of the washing machine will become hot
during the heating process. Avoid contact with the
door during the heating process. For safety, keep children away from the washing machine.

Keep children away from the packing materials after unpacked.

Wiring Circuit
HVS1200

HVS1000

15
2
8.The washing machine should not be installed
outdoors or in a damp place. In the event of water
leakage or splashes allow the machine to dry
naturally.
10.Keep away from heat sources and direct sunlight
to prevent plastic and rubber components from
aging.
11.During installation, ensure that the electric
cable is not trapped by the washing machine
and avoid damage to the electric cable.
During Use
1. Before use, check the joints of the filling hose,
the tap and the drainage hose for possible problems from water pressure fluctuations.
If joints are loose or there is leakage, turn
off the tap and repair. Do not use the washing
machine until the hoses are properly fixed.
The appliance is to be connected to the water
mains using new hose-sets
and that old hose
-sets should not be reused
2.
Keep the door slightly open when the washing machine is not in use to prevent formation of odors; do not cover the washing machine with plastic cover so that inside dampness cannot be kept in.
Matters Needing Attention
9. The carpet must not obstruct the ventilation
openings in the base of the washing machine.
Technical Specifications
Model
Power supply
Power(Max)
Water pressure (MPa)
Max. wash load (kg)
Spinning speed (MAX) (r/min)
Wash program
Heating power (W)
Net weight (kg)
Anti-Electric shock
Anti-Water class
HVS1000
(220-240)V~/(50Hz)
2000
5
1000
11
1800
82
I
IPX4
0.03p1
HVS1200
(220-240)V~/(50Hz)
2000
5
1200
11
1800
82
I
IPX4
0.03p1



3. Do not place heavy, heating source or wet articles
on the top of the washing machine.
4. Do not hot wash foam rubber or sponge-like
materials.
6. Do not open the detergent distribution drawer
during the wash cycle..

7. The door is fitted with a self-lock device and will not
open until 2~3 minutes after the washing machine
stops. Do not force the door open. Do not open the door if water level can reach the porthole.
8. After each wash program, turn off the tap to prevent
leakage; and unplug the washing machine and
wipe clean the lower part of the porthole.
Steel wires in bras will pop
out during washing; never
wash bras containing steel
wires.
5. Before washing, do up zippers, buttons and clothes
straps and put small articles, such as socks, laces
or bras, into a washing bag or a pillow.
Matters Needing Attention Troubleshooting
The following circumstances do not constitute problems. Do not contact the maintenance service until the problem has been confirmed.
Problem Possible cause
The washing machine fails to operate
Poor connection to power supply Power failure Door is not properly closed (It will show E1) Machine has not been switched on
Washing machine cannot be filled with water
Water tap is not turned on(It will show E4) Water pressure is less than 0.03Mpa The inlet hose is kinked Water supply failure The program dial is not properly set The door is not properly closed The inlet hose filter is blocked
The machine is draining while is being filled
The height of the drainage hose is below 80cm (it should be within 80-100cm)
The drainage hose end is in water
Drainage failure
Drainage hose is blocked (It will show E2) Drainage hose end is exceed 100cm above the floor
level The filter is blocked
Strong vibration during spin drying
Not all packing bolts have been removed Washing machine is located on an uneven surface Machine load is over 5kg.
Operation stops before completion of a wash cycle
Water or electricity failure Washing machine is in soak cycle
Operation stops for a period of time
Washing machine is in soak cycle Washing machine gives an error message.
Excessive foam in the drum, which is spilled to the distribution drawer
The detergent is not a low-foaming type or for manual wash
Excessive use of detergent
9.Keep the door slightly open when the washing machine is not in use to prevent formation of doors; do not cover the washing machine with plastic cover so that inside dampness cannot be kept in.

13
4
ƽ
Remove all the packing materials (including the
EPE base)to prevent vibration during use, as
shown in the right picture.Upon opening of the package, water drops may be seen on the plastic
bag and the porthole. This is normal phenomenon
resulting from water test in the factory.
ƽ
Check attachments and materials with reference to the following
ƽ
Dismantle the packing bolts as shown in Fig. 2.
The packing bolts are designed for clamping anti-vibration components inside of the washing machine during the transportation process. Before use: 1. Remove the back plate; 2. Remove the three packing bolts on the back plate and take out the rubber hose; 3. Replace the back plate; 4. Fill the holes left by the packing bolts with plastic plugs. (Attention: The packing bolts and rubber hose should be kept in a safe place for later use)
Fig.3
ƽ
Adjusting the washing machine
There are adjustable feet under the bottom of the washing machine. Before use, the washing machine should be adjusted, as shown in Fig. 3, so that it is level.
Fig.2
Model
HVS1200 HVS1000
Qty Name Operation
manual
Quality certificate
Water hose
Drainage holder
Plastic plugs
Installation
1
11
11
3
4. Clean the filter Cleaning methods (once a month)
1) Pick up the bottom cover lightly (Fig. 1); 2) Screw out filter by turning counterclockwise (Fig. 2); 3) Flash clean with running water; 4) Replace the filter by turning clockwise and remount the cover. Caution: The filter must be in place, or it may lead to leakage. (
Fig3
)
Fig1
Fig2
Fig3
Warrantly card

5
12
F
Hints for Saving Energy
5. Function selecting button Select functions as required (refer to the "Operational Functions" section).
Hints for saving energy During operation 1. Collect clothes for one full wash load. 2. Do not overload the washing machine. 3. Pre-wash heavily soiled clothes. 4. Reduce the amount of detergent or choose standard or delicate wash programs for slightly soiled clothes. 5. Choose a proper washing temperature. Only exceed 60
ć
for heavily
soiled clothes. 6. Do not use more detergent than required. 7. Softening agent makes clothes feel softer and easier to iron.
7. Finish The washing machine will stop operation automatically when a wash cycle ends. The "End" sign will appear. Open the door and take out the laundry. Then turn off the tap and unplug the power cable.
4. Setting washing temperature Press the temperature button until " -- " is displayed if heating is not needed; otherwise, select an appropriate temperature as required (refer to the "Guide to Operational Program Selection").
6. Washing Press Start/Pause key and the LCD will display "", which means the washer has started
operation. The LCD will display program remaining time.
T
he following functions cannot be re-selected.
1).
2)
3).
.
Temperature Selection Key Reserve Time Key Power Clean Key
4). All the functions already completed.
ƽ

Spin-dry
Pre- wash
y

Operational Functions

Display Information Introduction
A. Power On/Off Key
Press the key and the washer will be automatically energized, release the key and powe is disconnected.
B. Program Selection Knob
Turn the knob clockwise/counterclockwise to select the desired program. (please refer to Program Setting Guidance Table for details)
C. Detergent Distribution Box-See Figure a for the drawer- type Detergent Dispenser
Open the dispenser box and you will see four detergent compartment of 1, 2, 3: Compartment 1: Pre-wash Detergent Compartment 2: Washing Detergent Compartment 3:Softener , Conditioner and Perfume
D. Reservation Selection Key
Press the key to select the desired time when the washing progress completes. When setting this feature, the indicator lamp on the upper left corner of the key will illuminate. Time reservation range is from 1 to 24 hours. The reserved ti me will increase by one hour at each press of the key. When the feature is set, press Start/Pause key and th
e
reserve time will be displayed and countdown will start. At the same time, reservation indicator lamp will start blinking and will go off after th e washer enters into normal washing progress.
Figure a
Control Panel Function Description
Washing Procedure
Notes: 1) When first using the washing machine,let it run unloaded for one program to prevent the laundry from being tainted by oil or dirty water from the washing machine. 2) Do not overload the washing machine.
To get the best washing effect, an appropriate washing program should be selected according to the laundry type. Note: The above operations refer to conditions without power-off memory. Or the washing machine will continue operation from where the program was broken. To clear memory, press the Start/Pause button. Turn off the power for a few seconds and turn on again, all the settings will be renewed.
1. Loading
Slide out the detergent drawer and put the required detergent and softening agent into the corresponding boxes. Push back the drawer gently. Caution: 1) For pre-washing program, detergent should be added to both compartments 1 and 2. Compartment 2 allows only solid detergents. For other programs, do not add detergent to compartment 1. 2) Do not overuse softener; otherwise, it will damage the artificial fibers. Refer to the instructions during use.
2. Adding detergent
3. Selecting washing program
Load Reference
ƽ
Overalls
(cotton appr 950g)
ƽBlended fabric
clothes (appr 800g)
ƽ
T-shirt (cotton appr 300g)
ƽJackets (cotton
appr 800g)
ƽWoolen
blankets (appr 3000)
ƽSingle bed sheets
(cotton appr 800g)
ƽSocks (blended
fabrics appr 50g)
ƽ
Underwear (blended fabrics appr 70g)
ƽ
-HDQV
J
ƽPajamas
(appr 200g)
ƽShirts
(appr 300g)
Open the door, put in the laundry piece by piece. Close the door tightly.
231
.
ⳳ㑪
Slik
Quick wash
Single wash
Rinse
Drain
Spin
Power
Slim5
HVS1000
Cottonprewash
Cotton
Synthetic
Wool
Cashmere
㕞㑪
㕞↯
࣪㑪 ẝ咏
ẝ㑪⋫
䗳⋫
ⓖ
ᥦ∈㒛
㑪∈
㑪㑪

4)If select the delay-time function,make sure the compartment is dry,or the detergent will remain in the compartment.
Delay time
Baby care
Speed
Tem p.
Rinse hold
Start/Pause
Time
Cotton
prewash
Cotton
Synthetic
Wool
Cashmere
Silk
Quick wash
Single wash
Rinse
Drain
Spin
Power
HVS1000
.


Functions

Preparation
1.Power supply Plug in the power supply ď220 -240ĐV~ /50HZ
2.Water supply Turn on the tap ensure that the water in clear. Caution:Before staring the washing machine turn on the water faucet to ensure the water faucet and the water inlet hose are connected correctly and do not leak
3.Detergent selection Only special low foam detergent should be used in automatic drum washing mashine,form blended or wool fabrics special deter-gent should ne used.dry clearning solvent should not be used such as trichhloroethy-lene or alike (caution :load the required amount of detergent only).
4.Laundry treatment
Sort out clothes according to type and extent of dirt.There are three types of clothes:cotton,synthetical and woolen (silk) fabrics.
Separate white clothes from colored.If whites and coloreds are combimed for one load,make sure the coloreds are colorfast
-Clothing with frayed edges or yams should be put in a wash bag or special bag before washing -repair damged clothing,lose buttons or damaged zips and hooks before washing. -Bed sheets and table ware should be loosely loaded and not folded.
This washing mashine is for househould use and designed for mechanically washable clothes.When washing,separate unwashable clothes with reference to clothes labels.
Note.
If Program key is turned after reservation time is set and before program starts, the
reservation will be automatically cancelled.
When reservation feature is activated, the washing start time is fixed. There will be some
difference between the reserved time and the actual program completion time due to differen
t
water inlet time and load distribution condition during spin
-
dry process.
E. LCD
LCD is a window to display information including washing status, washing progress,
reservation time, remaining time, heating temperature, spin
-
dry speed, load selection and error etc.
as well as to display additional features such as power clean, super clean rinse and foaming auto
-
check etc.
F. Start/Pause Key
When the washer is energized, select the desired washing program and press the Start/Pau
s
key. The indicator lamp on the upper left corner of the key will illuminate to indicate that the washer has started operation. If it needs to pause the washing process, simply press the Start/ Pause key and the indicator lamp and remining time display will blink and the washer enters into
condition. Press the Start/Pause key again to resume washing process.
(Note: Press the Start/Pause key only after the desired program and feature are set.
G. Rinse Hold Key
Press the key lightly,the screen displays the symbol.The washing machine does not drain the
water after the last rinse,but the laundry remains in a soak.To spin the laundry ,press this key again .The symbol disappears from the screen and the program continues to the end .The function is used to prevent the laundry creasing when left in the drum for a long time .
H. Temperature Selection Key
Press the key and LCD will display the selected heating temperature, which is adjustable as
needed. Note: 20
o
C means cold water washing and no heating is involved.
.
I. Spin Speed Selection Key
Press the key and LCD will display the selected spin
-
dry revolution speed, which is adjustable
as needed. (When No Spin
-
dry feature is selected, the time will decrease correspondingly
.)
J. Load Selection key
Turn the Program Knob to select the desired program (see Program Setting Guidance Table)
Press the key and manually select different programs and power-saving and water-seaving fea-
ture based on the volume of load. LCD will display L-1(2,3,4,5), indicating the washing load is 1
(2,3,4,5) kg and program time will change accordingly. (The feature is not
available in Wool,
Cashmere, Silk, Speedy, Drainage Only and Spin Only Program. Only L
–
1, 2, 3 are available for
Chemical Fiber program. )
5.Wash load
Type
Max load
Cotton fabrics Synthetic fabrics Wool/cashmare/silk fabrics
NJ NJ NJ


Default Program Detergent Usage MethodProgram
Setting
Mode
Recommended
Laundry Capacity Temperature Total
Time
Temperature
Adjustment
Range
Rinse
Hold
Load
Selection
Super Clean
Rinse
Reserve Compartment
1
Compartment
2
Compartment
3
Cotton Pre-wash
Heavily-soiled
Cotton Fabrics 540
1000 5:52
__
-40-50-
60-90
__
-40-50-
60-90
__
-40-50-
60
__
-40
__
-40
__
-40
__
-40
__
-40-50-
60
YES YES YES YES
ƾƾ
嗟
Cotton Cotton Fabrics 5 40 1000 2:38 YES YES YES YES X
ƾ
嗟
Synthetic Fsat-colour-
Fiber 3 60 800 1:42 YES YES YES YES X
ƾ
嗟
Cashmere Cashmere
/40 600 1:10 YES NO YES YES X
ƾ
嗟
/40 400 1:10 YES NO YES YES X
ƾ
嗟
Slik Silk /40 400 1:05 YES NO YES YES X
ƾ
X
/_ _ 800 0:29 YES NO NO YES X
ƾ
嗟
Rinse
54001:33 NO YES NO YES X
ƾ
X
5 800 0:25 /YES YES YES YES XX
嗟
Drain ////0:03 /NO NO NO YES XXX
Spin ///
1000 0:09 /NO NO NO YES X
X
XX
Note:
嗟
means that it needs to add perfume such as softener
ƾ
meansthatitneedstoadd
detergent otherwise the
desired washing result will not be achieved. means it must not ad
d
detergent. The data in Speed column is default spin speed of corresponding model (whe
n
speed is not selected.)
Note: 1.
Washing temperature refers to the highest temperature allowable during the whole
washing process. The washing time varies according to the type of clothes, selected temperature and feature. The total operation time provid ed in the above table is for referenceonly(Therewillbeaslightdifferenceduetodifferentwatertemperature.)
Pro
g
ram Settin
g
Guidance Table
A
.
Power-off Memory Function:Thewasher has power-off memory function.In case of
abrupt power failure or the power must be cut off during a program cycle, the present settings will be saved and the preset operation will resume when the power is rezum- ed.If it needs to cancel this feature, press Start/Pause key so that the washer will will stop temporarily. Turn off the power key and restart the washer after a few seconds and the feature will be cancelled.
B.
Safety Child Lock Function: During the operation of the program, press down Temperature key and Load Selection key concurrently and hold for 3 seconds." "
will be displayed indicating that the program is locked. Repeat the above procedures to unlock.
C.
Foaming Auto
-
check Function: The washer offers foaming auto- check function, which is
is a solution to incomplete rinse due to over
-
dispensing of detergent. The washer can
sense the volume of foam formed automatically. When foaming is detected, the
Introduction of Other Functions
2. For clothes made of special materials such as woolens, cashmere and wool, please check if the clothes has a machine
-
washing tag and the requests to the temperature.

K. Super-clean Rinse Key
Press the key and super
-
clean icon in the LCD will illuminate. When the program comes to
softening process, the washer will add an extra rinse process. ( This feature is not available in some
programs. Please see Program Setting Guidance Table for details.)
Functions
Foaming icon
in the LCD will illuminate and an extra rinse cycle will be
added before the program completes. Program time duration will increase automatically.
Quick wash Slightly-soiled
Textiles
Slightly-soiled
Textiles
Slightly-soiled
Textiles
Single wash
Wool Wool
D. Auto-shower function:
E
__
