Haier HW80-B14979 User manual

EN
User manual
Washing machine
HW80-B14979
HW90-B14979
HW100-B14979
HW120-B14979

Thank You EN
2
Legend
Warning – Important Safety information
General information and tips
Environmental information
Disposal
Help protect the environment and human health. Put
the packaging in applicable containers to recycle it.
Help to recycle waste of electrical and electronic ap-
pliances. Do not dispose appliances marked with this
symbol with the household waste. Return the product
to your local recycling facility or contact your municipal
ThankyouforpurchasingaHaierProduct.
Please read these instructions carefully before using this appliance. The instructions con-
tain important information which will help you get the best out of the appliance and ensure
safe and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper
use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure
you also pass this manual so that the new owner can become familiar with the appliance
and safety warnings.
WARNING!
of it. Remove the door catch to prevent children and pets to get closed in the appliance.

EN Content
3
1-Safety information........................................................................................................................... 4
2-Product description......................................................................................................................... 7
3-Control panel .................................................................................................................................... 8
4-Programmes...................................................................................................................................11
5-Consumption..................................................................................................................................12
6-Daily use...........................................................................................................................................13
7-Eco-friendly washing ....................................................................................................................18
8-Care and cleaning ..........................................................................................................................19
9-Troubleshooting .............................................................................................................................22
10-Installation.....................................................................................................................................25
11-Technical data...............................................................................................................................29
12-Customer service........................................................................................................................30

1-Safety information EN
4
-
ing safety hints!
WARNING!
▶Make sure there is no transport damage.
▶Make sure all transport bolts are removed.
▶Remove all packaging and keep out of children´s reach.
▶Handle the appliance always with at least two persons because it
is heavy.
▶This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
▶Keep away children under 3 years of age from the appliance un-
less they are constantly supervised.
▶Children shall not play with the appliance.
▶Do not let children or pets come close to the appliance when the
door is open.
▶Store washing agents out of reach of children.
▶-
vent laundry from being entangled. If necessary, use an appropri-
ate bag or net.
▶Do not touch or use the appliance when barefoot or with wet or
damp hands or feet.
▶Do not cover or encase the appliance during operation or after-
wards to allow any moisture or dampness to evaporate.
▶Do not place heavy objects or sources of heat or damp on top of
the appliance.
▶Do not use or store flammable detergent or dry cleaning agent in
close vicinity to the appliance.
▶Do not use any flammable sprays in close vicinity to the appliance.
▶Do not wash any garments treated with solvents in the appliance
without having dried them previously in the air.
Before first use
Daily use

EN 1-Safety information
5
WARNING!
▶Do not remove or insert the plug in the presence of flammable
gas.
▶Do not hot wash foam rubber or sponge-like materials.
▶Do not wash any laundry which is polluted with flour.
▶Do not open detergent drawer during any wash cycle.
▶Do not touch the door during the washing process, it gets hot.
▶Do not open the door if the water level is visibly over the porthole.
▶Do not force the door to open. The door is tted with a self-lock
device and will open shortly after the washing procedure is ended.
▶
undertaking any routine maintenance and disconnect the appli-
ance from the electrical supply to save electricity and for safety.
▶Hold the plug, not the cable, when unplugging the appliance.
▶Make sure children are supervised if they carry out cleaning and
maintenance.
▶Disconnect the appliance from the electrical supply before un-
dertaking any routine maintenance.
▶Keep the lower part of the porthole clean and open door and de-
tergent drawer if appliance is not in use to prevent odours.
▶Do not use water spray or steam to clean the appliance.
▶Replace a damaged supply cord only by the manufacturer, its ser-
▶Do not try to repair the appliance by yourself. In case of repair
please contact our customer service.
▶The appliance should be placed in a well-ventilated place. Ensure
a location which allows opening the door fully.
▶Never install the appliance outdoors in a damp place, or in an area
which may be prone to water leaks such as under or near a sink
unit. In the event of a water leak cut power supply and allow the
machine to dry naturally.
Daily use
Maintenance /cleaning
Installation

1-Safety information EN
6
Intended use
This appliance is intended for washing machine-washable laun-
dry only. Anytime follow the instructions given on the label of each
garment label. It is designed exclusively for domestic use inside the
house. It is not intended for commercial or industrial use.
use may cause hazards and loss of of all warranty and liability claims.
WARNING!
Installation
▶Install or use the appliance only where the temperature is above
5 °C.
▶Do not place the appliance directly on a carpet, or close to a wall
or furniture.
▶Do not install the appliance in direct sunlight or in the near of heat
sources(e.g. stoves, heaters).
▶Make sure that the electrical information on the rating plate
agrees with the power supply. If it does not, contact an electri-
cian.
▶Do not use multi-plug adapters and extension cables.
▶Make sure only the delivered electric cable and hose set are used.
▶Make sure not to damage the electric cable and the plug. If dam-
aged have it replaced by an electrician.
▶Use a separate earthed socket for the power supply which is easy
accessible after installation. The appliance must be earthed.
Only for UK:
-
pliance is installed, the plug should be accessible.
▶
no leakage.

EN 2-Product description
7
2.1Pictureofappliance
Front(Fig.2-1): Rearside(Fig.2-2):
2.2Accessories
Check the accessories and literature in accordance with this list (Fig.2-3):
Note:
-
2-3
I1
R5
R9 R10 R6
R7
R8
1 Detergent /
Softener drawer
2 Work top
3 Programme selector
4 Panel
5 Washer door
6 Service flap
7 Adjustable feet
1 Iron bar (I1 - I2)
2Transportation bolts (T1-T4)
3Rear wall reinforcement
(Only HW90/100/120-B...)
(Only HW90/100/120-B...)
(Only HW90/100/120-B...)
4Power cord
5
Water inlet valve
6Drain hose
7Rear wall reinforcement screws
(R1-R10)
2-1 2-2
Inlet hose-
assembly 6 Blanking
plugs Drain hose
bracket User manual
Warranty
card
1 2 4 5 6 73
Noise reduc-
tionpads
2x
2x
7
5
6
3
14
2
Stain removal Steam
Temp.
SpeedExtra Rinse
REFRESH
525DRUM

3-Control panel EN
8
Note : Acoustic signal
In following cases, an acoustic signal is no sounds by default:
▶when pressing a button
▶when turning the programmes selector
▶
▶
at the end of programme
The acoustic signal can be selected if necessary ; see DAILY USE(see P17 6.13).
1“Power” button
2Programme selector
3Display
3.1 ”Power” button
3.2 Programme selector
3.3 Display
Touch this button (Fig. 3-2) gently to switch on, the
display is shining, the indicator of the “Start/Pause”
button is flashing. Press it again for about 2 seconds
to switch
By turning the knob (Fig. 3-3) one of 14 programmes
can be selected, related LED will light up, its default
settings will be displayed.
The display (Fig. 3-4) shows following information:
Washing time
▶End time delay
▶Error codes and service information
▶Function buttons and “Start/Pause“ button
activated after a while machine will shut down auto-
matically.
Detergent /Softener drawer4
5Function buttons
6
“Start/Pause“ button
Stain removal
Delay
Steam
Extra Rin se
Speed
Temp.
Stain removal Steam
Temp.
SpeedExtra Rinse
REFRESH
525 DRUM
4 2
3 1
6
5
3-1
3-2
3-3
3-4

EN 3-Control panel
9
3.5 Function buttons
The function buttons (Fig. 3-6) enable additional op
o-
-
tions in the selected programme before programme
starts. The related indicators are displayed.
gramme, all options are disabled.
If a button has multiple options, the desired option can
be selected by pressing the button sequentially.
By touching the buttons, when it is in dull light, the fun-
ction is unselected; when it is in bright light, the functi-
on is selected.
3.5.1-Function button “Delay“
3.5.2 Function button “ ”
Note: Factory settings
there is no special requirement default settings are recommended.
3.4 Detergent drawer
Open dispenser drawer,the following components can
be seen (Fig. 3-5):
3.5.3 Function button “Temp.“
1: compartment for powder or liquid detergent.
2: detergent flap slector, lift it up for powder detergent,
keep it down for liquid detergent.
3: compartment for sanitizer.
4: compartment for softner.
5: lock tab, press it down to pull out dispenser drawer.
The recommendation on the type of detergents is su-
itable for the various washing temperatures, please re-
fer to the manual of detergent(see P11).
Touch
Touch
this button (Fig. 3-7) to start the programme
with a delay. End time delay could be increased in steps
(The default delay is gre-
Delay I-time
time.Not all programmes can select this function. See
P11 for programme that can select this function.
different washing 8
Temp.
this button (Fig. 3-9) to change the washing
temperature of the programme. If no value is illumi-
nated(the display"--°C") the water will not be heated.
3.5.1 3.5.2
3.5.6 3.5.5 3.5.4
3.5.3
Delay
Temp.
3.5.7
Stain removal
Delay
Steam
Extra Rinse
Speed
Temp.
Note: Liquid detergent
If using liquid detergent, it is not recommended to activate the end time delay.
1
2
5
3
4
3-5
3-6
3-7 3-8
3-9
ater than the programme running time.) For example
display off 6:30 means end of programme cycle will be
in 6 hours and 30minutes. Touch “Start/Pause” button
to activate the time delay.It is not applicable to progra-
m
me Spin, Refresh, Eco40-60.

3-Control panel EN
10
Speed
3.5.4 Function button“Speed“
Touch this button (Fig. 3-10) to change or deselect the
spin of the programme. If no value is illuminated the dis-
play"0" ,the laundry will not spin.
3.6 “Start/Pause“ button
Touch this button (Fig. 3-14) gently to start or inter-
rupt the currently displayed programme. During pro-
gramme setting and during programme run the LED
above the button is shining, or if interrupted blinking.
3.5.5 “Extra Rinse” button
Touch this button (Fig. 3-11) to rinse the laundry more
intense with fresh water. This is recommended for people
with sensitive skin.
By touching the button several times one to three add-
itional cycles can be selected. They appear in the display
with P--0/P--1/P--2/P--3.The number of options may
be different for different programs.
3.7 Child lock
Choosing a programme and then start,touch button“ Sp-
eed”and ”Start/Pause ”( Fig .3-15) for 3 seconds simulta-
neously to block all panel elements against activation pa-
nel display .For unlocking please touch again the two
buttons.The child lock indicator lights up when the child
lock works.Feature is optional when the machine is run-
ning.
The display shows c oI
I- (Fig. 3-16) if a button will be
pressed, when the child lock is activated. The change
is not running.
3-16
3-10
3-11
3-14
3-15
Speed
3-12
3.5.6 “ Steam “ button
Touch this button (Fig. 3-12)
Speed
Steam
,the steam programme can
be selected.
is on.You can select if you req uire this funtion when progra-
mmes “Cotton,Synthetics,Mix,
Baby care,” are used.The
For programs with the steam function, the in-
dicator is green, and the indicator in the middle of the knob
steam wash icon will light up when using the steam wash
function.
3-13
3.5.7“Stain removal“ button
Touch this button (Fig. 3-13) to choose special features
for stains. The symbols are explained in the following table .
Grass
Soil
Wine
Blood
Extra Rinse
Milk
Juice

3
2
1)
Water is not heated up.
*
Choose 90°C wash temperature only for special hygienic requirements.
2)
Reduce detergent amount because programme duration is short.
The design and specifications are subject to change without notice for quality
improvement purposes.
3)
Do not use chemical reaction with detergent.
Max. load Temperature Preset
spin
speed
in rpm
Function
in kg
3)
in °C 1)
2)
Preset
Steam Extra Rinse Delay Stain removal
Programme selectable
range 1 2
Fabrics type
8/9/10/12 * to 90
40
Cotton
Synthetic / mixed
fabric
1400
1200
800
4/4.5/5/6 * to 60
30
40
•
º
800
* to 60
40 •
º
Lightly soiled mixed-
laundry of cotton and
synthetic
* to 30
30 •
º
Delicate laundry and
silk
600
30 •
º
Cotton
1000
/ 0
1000
•
* to 40
* to 90
/
•
º
1
* •
Cotton / Synthetic
Cotton / Synthetic
1000 /
* to 40
•
º
1000
*
Machine-washable
fabric made of wool
or with wool content
•
• • •
••
•
•
•
•
••
•
•
•
•
•
•
* to 20
/
20
/
•1000
1400
/•
/
/
Cotton / Synthetic
Cotton / Synthetic
Detergent compartment for:
1
2
Detergent
Softener or care product
4/4.5/5/6
2/2.5/2.5/3
4/4.5/5/6
1
4/4.5/5/6
2/2.5/2.5/3
1
2
/ / /
1000
4/4.5/5/6
40 /•
8/9/10/12 / /
All fabrics(Reference
cleaning label)
1000 ///
/
/
/
/
/
/
/
/
/
/
/
8/9/10/12
8/9/10/12
//
º
•
º
Cotton
/
•
i-time
• • • • •
•
••
•
//
•
/
•
•
/
/
•
HW80/HW90/
HW100/HW120
* to 40
30 •
/
/
4/4.5/5/6
º
Duvet
•
/
/
/
/
•
•
º
* to 40
//
* to 40
3sanitizer
3
•
Yes, º Optional, / No
EN 4-Programmes
11
3
º
º
º
º
ºº
/
/
/
/
/
º
º
º
•
ºº
(Cotton)
(Synthetics)
(Duvet)
(Wool)
(Delicate)
(Outdoor)
(Refresh)
(Babycare)
(Mix)
(Express 15′)
(Fast)
(Spin)
(Cotton 20°C)

5-Consumption EN
12
Note:AutoWeight
The appliance is equipped with a loading recognition. At low loading, energy, water and
washing time will be reduced automatically in some progr ammes. The display shows AUtO.
Scan QR code on energy label for energy consumption information.
The actual energy consumption may differ from the declared one according to local
conditions.

6.3 Preparing laundry
▶Sort out clothes according to fabric (cotton, syn-
thetics, wool or silk etc.) and how dirty they are
(Fig. 6-3).Pay attention to the care labelling of w- -
ashing labels.
▶Separate white clothes from coloured ones.
they fade or run.
▶Empty pockets (keys, coins, etc.) and remove
harder decorative objects (e.g. brooches).
▶
into a wash bag to care for this delicate laundry
(hand or dry cleaning would be better).
▶Close zippers, velco fastener and hooks, make
sure the buttons are sewn on tightly.
▶
hem, delicate underwear (Dessous) and small
items such as socks, belts, bras, etc. in a wash
bag.
▶Unfold large pieces of fabric such as bed sheets,
bedspreads etc.
▶Turn jeans and printed, decorated or color-inten-
sive textiles inside out; possibly wash separately.
6.1 Power supply
Connect the washing machine to a power supply
(220V to 240V~/50Hz; Fig. 6-1). Please refer also to
section INSTALLTION (see P28).
6.2 Water connection
▶Before connecting check the cleanliness and clar-
ity of the water inlet.
▶Turn on the tap (Fig.6-2).
Note: Tightness
Before use check for leakage in the joints between the tap and the inlet hose by turning on
the tap.
CAUTION!
Non-textile, as well as small, loose or sharp-edged items may cause malfunctions and
damage of clothes and appliance.
6-3
6-1 6-2
6-Daily use
EN
13

Care chart
Washing
Washable up to 95°C
normal process
Washable up to 60°C
normal process
Washable up to 60°C
mild process
Washable up to 40°C
normal process
Washable up to 40°C
mild process
Washable up to 40°C
very mild process
Washable up to 30°C
normal process
Washable up to 30°C
mild process
Washable up to 30°C
very mild process
Wash by hand
max. 40°C
Do not wash
Bleaching
Any bleaching allowed Only oxygen/
non -chlorine
Do not bleach
Drying
Tumbledryingpossible
normal temperature
Tumbledryingpossible
lower temperature
Do not tumble dry
Line drying Flat drying
Ironing
Iron at a maximum
temperature
up to 200 °C
Iron at a medial tem-
perature
up to 150°C
Iron at a low temper-
ature up to 110 °C;
without steam (steam
ironing may cause irre-
versible damage)
Do not iron
Professional Textile Care
Dry cleaning in tetra-
chloroethene
Dry cleaning in hy-
drocarbons
Do not dry clean
Professional wet clean Do not professional
wet clean
6.4 Loading the appliance.
▶Put in the laundry piece by piece.
▶
thumb for maximum load: Keep six inches between load and drum top.
▶Close the door carefully. Make sure that no pieces of laundry are pinched.
6-Daily use EN
14

6.5Selectingdetergent
▶
▶Use only machine wash approved detergent.
▶
▶See tips for countertop detergent stickers.
.
▶Do not use dry cleaning agents such as trichloroethylene and similar products.
Choosethebestdetergent
Programme Kindofdetergent
Universal Colour Delicate Special Softener
L/P L/P - - o
- L/P - - o
L L/P -
- -
- -
L/P L/P o
- - L/P L/P o
o- - - L/P
- - - - -
- - L/P L/P o
L L/P - - o
- L - - o
L/P L - - o
- - - - -
L/P L/P - - o
L/P L/P - - o
L = gel-/liquid detergent P = powder detergent O = optional _= no
If using liquid detergent, it is not recommended to activate the time delay.
We recomment by using:
▶Laundry powder: 20°C to 90°C* (best use: 40-60°C)
▶Color detergent: 20°C to 60°C (best use: 30-60°C)
▶Wool/delicate detergent: 20°C to 30°C (best use:20-30°C)
* Choose 90 °C wash temperature only for special hygienic requirements.
If you choose the water temperature 60°C or above,we would like to advise you to use
less detergent.Please kindly use the special disinfectant,which is suitable for cotton or
synthetic cloth.
*
* It is better to use less or free suds detergent powder.
15
EN 6-Daily use

6.7 Switch on the appliance
6.6 Adding detergent
1. Slide out the detergent drawer.
2. Put the required chemicals into corresponding
compartments (Fig. 6-4).
3. Push back the drawer gently.
Note:
▶Remove detergent residues before next wash cycle from the detergent drawer.
▶Do not overuse detergent or softener.
▶Please follow the instruction on the detergent package.
▶
▶Concentrated liquid detergent should be diluted before adding.
▶Do not use liquid detergent if function “Delay“ is selected.
▶Carefully choose the programme settings according to the care symbols on all laun-
dry labels and according to the programme table.
6.8 Select a programme
To get the best washing results, select a programme
type.
Turn the programme knob (Fig. 6-6) to select the right
programme. Related programme LED lights up and
the default settings are displayed.
6.9 Add individual selections
Select required options and settings (Fig. 6-7); refer to
Control panel.
6-5
6-6
6-4
Note: Odour removal
amount of detergent in washing agent compartment (2) or special
“COTTON+90 °C+600rpm”
cleaner to remove possib
machine ly corruptive residues.
6-7
1
3
2
Stain removal
Delay
Steam
Extra Rinse
Speed
Temp.
(Fig. 6-5). The LED of the „Start/Pause“ button is flas-
hing.
PowerTouch
16
6-Daily use EN

1. At programme cycle end END is displayed.
2.
3. Remove laundry as soon as possible to go easy on it and to prevent more wrinkling.
4.
5. Unplug the power cord.
6. Open the door to prevent formation of moisture and odours. Let it open while not used.
6.13 Activate or deactivate the buzzer
To interrupt a running programme press gently “Start/Pause“. The LED above the button
is flashing. Press it again to resume operation.
To cancel a running programme and all its individual settings:
1. Touch”Start/Pause” button to interrupt the running programme.
2.
3.
4. After closing the programm to restart the appliance, select a new programme and
6.12 After washing
Note: Door lock
▶For safety reasons the door is locked partially during the washing cycle. It is only pos-
sible to open the door at the end of the programme or after the programme was can-
celled correctly (see description above).
▶In case of high water level, high water temperature and during spinning it is not pos-
sible to open the door; Locl- is displayed.
Note: Standby-mode / energy-saving mode
The switched on appliance will go into standby-mode if it will not be activated within 2
6.10 Start wash programme
Touch“Start/Pause“ button (Fig. 6-8) to start. The LED of the”Start/
Pause“ button stops flashing and lights up continuously.
Appliance operates according to present settings.
Changesareonly possibleby cancellingtheprogramme.
6.11 Interrupt / cancel wash programme
6-8
PowerTouch
EN 6-Daily use
17
,ecnailppaehtnonrutotnottub"rewoP"ehthcuoT
start it.
minutes before srarting the programme or at the end of programme.The display swits-
select “no Speed” (speed lights
are off) and run programme Spin to drain the water.
ches off. This saves energy, To interrupt the standby mode touch “Power” button
The acoustic signal can be selected if necessary:
1. Switch on the appliance.
2. Select the programme.
3. Touch the “Delay“button and “Temp.” button at the same time for about 3 sec-
onds. “bEEP ON ” will be displayed and the buzzer will be activated.
For deactivating the buzzer touch these two buttons at the same time again. “bEEP OFF”
will be displayed.
XIM

Environmentally responsible use
▶To achieve best use of energy, water, detergent and time you should use the recom-
mended maximum load size.
▶Do not overload (hand width clearance above laundry).
▶For slightly soiled laundry select the Express 15’ programme.
▶Apply exact dosages of each washing agent.
▶-
ciently cleaning below 60°C.
▶Raise default settings only due to heavy staining.
▶Select max. spinning speed if a domestic dryer is used.
7-Eco-friendly washing EN
18

8.5 Long periods of disuse
If the appliance is left idle for a longer period:
1. Pull out the electrical plug (Fig. 8-6).
2.
3. Open the door to prevent formation of moisture
and odours. Let door open while not used.
Before next usage check carefully power cord, water
inlet and drain hose. Make sure everything is properly
installed and without leackage.
8-6 8-7
8-Care and cleaning EN
20
1.
2. Push and open service flap (Fig. 8-9).
3. Provide a flat container to catch leach water
(Fig. 8-10). There could be bigger amounts!
4. Pull the drainhose out and hold its end above the
container (Fig. 8-10).
5. Take the sealing plug out of the drainhose (Fig.
8-10).
6. After complete drainage close drainhose and
push it back into the machine(Fig.8-11).
7. Unscrew and remove counter clockwise the pump
8. Remove contaminants and dirt (Fig. 8-13).
WARNING!
hot! Before any action please ensure water has
cooled down.
for instance if the appliance:
▶Doesn´t drain the water.
▶Doesn´t spin.
▶Cause unusual noise while running.
8
8
8
8-10 8-11
8-12 8-13
8-8 8-9
