Haier HWM100-97 User manual

HWM100-97
Automatic Washing Machine
Please read this manual carefully before use.
Please retain it attentively for future reference.
Please check if the power receptacle is earthed
reliably before usage to guarantee your safety.
The manufacturer is not responsible for any
risks occurred owing to disobey these
stipulations.

Contents
Names of the parts 1
Safety precautions 2
Installation and adjustment 4
Preparation before washing 6
Put in the laundries 7
Usage of detergent 7
Usage of the operation buttons 8
Close the top lid 14
Finish washing 14
After washing 15
Trouble shooting answer to question 16
Packing list 17
Specification the back cover

Names of the parts
1
Softener injection inlet
Bleach injection inlet
Adjustable feet
(4)
Cabinet
Control panel
Control panel seat
Inner tub
Top lid
Power line
Cold water inlet valve
Water absorption cushion
Door switch
Agitator
Drain hose joint
Hot water inlet valve
Meaning and description of the symbols
Water inlet hose
(2)
Outer drain hose component
(1)
Drain hose clamp
(1)
Drain hose hook
(1)
Warning sign
Forbidding sign
Contents marked with that symbol
are related to the safety of the
product and the personal safety
of the users. Please operate in
strict conformity to the contents,
otherwise it may cause damage
of the machine or injure the
personal safety of the user.
Contents marked with that symbol
are actions forbidden to perform.
Performing of those actions may
result in damage of the machine
or injure the personal safety of
the user.
Accessories
Please understand theshapes of thewashing machine andaccessories may bedifferent
from the sketchfigures in thismanual due toproduct improvement.

Safety precautions
2
Do not put the machine at damp place like the bath
room. Never wash it with water.Not put wet laundries
on the control panel.
Do not let the machine share one receptacle
with other electric appliances. If the power
plug is damaged, or the plugging into the
receptacle is loose, do not use the plug any
more.
Do not wash water-proof laundries like
the raincoat, bike covers etc. to avoid
abnormal vibrations in spinning.
Please insert the power cord into special three
-phase receptacle.The earthing terminal of the
receptacle must be earthed reliably.If possible ,
please adopt electric leakage protector.
Do not bend ,extend,twist,bind by force.Do not press or nip it with weight.
Keep the pin of the power plug clean,if the power plug is polluted with dust,please wipe
with dry cloth carefully.
If the power cord or the power plug is bad, to avoid risk it is required to have it replaced
by the technicians of our special shop or the after-sale service department.
The power cord plug should be convenient
to be pluged in or pluged out with hand
while the washing machine runs normally.
Be sure to pull the plug out and close the
water tap when the machine is idle,when
moving the machine,or when cleaning
the machine.Do not use wet hand to ins-
ert or pull out the power plug.
Do not use water hotter than 60
In case the washing machine is installed on ground
with carpet, be careful not to block the ventilation hole
with carpet.
Earth

Safety precautions
3
Do not decompose, repair or alter the
machine by yourself.
Do not stretch hands into the working
machine. It is dangerous even if the
rotation is slow. Take special care of
the children.
Do not put any hot or heavy items (such
as the kettle with hot water ) on the
washing machine.
The handicapped or children without
care shall not use the machine.
Keep the machine away from direct
sunlight and heat source like the heater.
Petrol
Thinner
Do not wash laundries with volatile
materials (such as thinner, petrol etc.)
To prevent your laundries and washing
machine from damage,be sure to take
out all of the foreign materials from your
pocket,such as coins,buttons,sand or
hair pins etc.
Before washing,please check if the water
tap is open ,and if the water inlet pipe is
connected properly.
It is suggested to use low-foaming was-
hing powder

Installation and adjustment
4
Adjust the installation position
The largest allowed slope of the base of the machine is 2 . The slanting or rough
ground will result in unstable running or stoppage of the machine. Please adjust
it with following methods:
Confirm it's horizontal:
Hang the lead line to confirm
if it is horizontal.
Adjust the adjustable foot:
To twist the adjustable foot, please first lift up
the side of the foot slightly, and twist the foot.
.
High Low
Adjustable foot
Install the drain hose
Drain hose joint
Drain hose clamp
Drain hose
Put the drain hose clamp on the outer
drain hose, insert the outer drain hose
into the joint, and then clutch tightly
with drain hose clamp.
Usage of the drain hose
The drainage shall be smooth with the drain hose.
1.put the drain hose up to suitable position.
2.Do not step on or press the drain hose.
1.0m-1.5m
Install the bottom plate
After you open the package, please lean the washing
machine gently down on soft items ( like the towel cloth,
blanket, etc. ). Install the bottom plate to the bottom of
the machine with the ten screws by a cross screwdriver,
then lift the machine up gently. See to the figure:
Front
Screw Soft materialBottom plate
Back

5
Install the water inlet hose
2. Connect the hot and cold water inlet hoses to the hot and cold
water faucet.
3. Connect the other ends to their respective cold and hot water inlet valve
located at the rear of the washer
Hot water needs to be at a temperature of at least 120 F- 140 F.
(49 C-60 C)for the soap to dissolve and to avoid soap residue
remaining on clothes.
Note:
C
H
Water absorption cushion
Jointer of the water inlet hose
Jointer of the
water inlet valve
C
H
Check the connection between the water inlet
hose and the water tap
1.Swaying the hose gently to confirm if it is fastened
stable.
2.After installation, open the tap to check if it leaks.
3.Do not bend the hose with overstrain.
4.Before each usage please check if the connection
between the water inlet hose and the water tap, is firm,
so as to prevent dropping from improve Installation
position.
1.Close the water tap.
2. Pull off the water inlet hose from the water tap and washer
Take down the water inlet hose
Figure 1
Figure 2
1. ttach the water inlet hoses to the hot water faucet and the cold
water faucet. Using pliers, tighten the coupling. ( As figure 1)
NOTE: Do not over tighten. Damage to the
valves can result.
Respectively a
Installation and adjustment

6
Preparation before washing
1.Connect the water inlet hose. Open the water
faucet.
2.Confirm that the washing machine is earthed
reliably. Then insert the power plug into the
receptacle. The earth terminal shall not link to
gas pipeline and faucet water pipeline.
3.Put the drain hose up.
Pay attention to followings before washing the laundries
1.0m~1.5m
Confirm if
there's special
requirment for
the laundries.
Clear the pocket.
Take out the
coins , sand,
hairpins etc.
Fasten the
buttons and
zippers.
When the pulsator
is running , the
buttons of the
laundries may
cause noise. For
the sake of
carefulness,please
put the laundries
with buttons into
other laundries.
The big laundries
like the jeans
shall be put in
loosely.
a.Please check if the laundries are applicable for washing.
b.Separate those not colorfast from other laundries.
c.For laundries not water absorbing,please put them into water with hands.
d.For laundries with much soil,please remove the soil first.You can add detergent on the
part with serious soil directly.It is much easier to remove the soil by that mean.
e.For laundries likely to get lint ball or with long fiber,please first turn the inside out before
putting them into the water.
f.Do not put the laundries polluted with chemicals directly into the washing machine.
Preparation before washing

7
Put in the laundries
The capacity of washing and spinning of the
machine refer to the largest weight of the
standard laundries under dry condition that
can be washed or spined in one time. Lau-
ndries quantity in one washing cycle shall
be lower than the rated capacity. The larg-
est capacity of this machines is 10.0kg.
The thickness, size, type of the cloth will
influence the actual washing capacity. It
is suitable to put in reasonable amount of
laundries and the laundries can be turned
round in washing for one time washing.
Do not select high water level for laundries
less than 4.0kg, so as to avoid splashing
of water.
Usage of detergent
Do not pour powdered bleacher into bleacher dispenser.
Never pour undiluted liquid chorine bleacher directly onto clothes or int
the inner tub.
Procedures
1.Check clothing care labels for special instructions
2. Measure liquid bleacher carefully, following instructions on the bottle.
How to use the washing powder
Direct dissolved in the machine
1.Fill water to "1" water level.
2.Add the power. Run for 30 seconds to dissolve it completely.
3.Put in the laundries. Select suitable water level.
The instant dissolving of the washing powder:
1. Prepare warm water of 30 and a container.
2. Add the powder while stirring to fully dissolve it.
The powder is more prone to pollute the laundries than the detergent.
Therefore please use it with proper quantity.
It is suggested not to use high sudsing detergent.
Different washing powders have different dosage. Please refer to the usage
manual of the washing powder for the details.
How to use the liquid bleacher
Washing powder
3. Before starting the washer, pour measured amount of bleach directly int
bleach dispenser. Avoid splashing or over-filling dispenser.
Note
Bleacher
Bleacher
dispenser
Inner tub
Do not mix chlorine bleacher with ammonia or acids such as vinegar and/or
rust remover. Mixing can produce a toxic gas which may cause death.
How use the fabric conditioner
Fabric conditioners help make clothes softer and fluffier and reduce static so that
clothes do not cling to you when you are wearing them.
Fabric
conditioner
Agitator
Procedure
1. Carefully follow the instructions on the fabric conditioner bottle or packet.
2. Mix conditioner with an equal amount of warm water but only mix enough to
fill to the line marked inside the cup.
3. Pour the mixed conditioner into the cup in the top of the agitator. The
conditioner will automatically be dispensed before the deep rinse cycle
Note:
Do not spill the conditioner onto the clothes because it may stain them.
Do not overfill the cup in the top of the agitator because the conditioner
may mix with the detergent and stain your clothes.
Do not stop the washing machine during the spray rinse cycle when using
a fabric conditioner.

8
Fabric
conditioner
Explanation of Buttons
Indicator mode and meaning
The indicator is off, indicating that the
program or mode is not selected
The indicator is on, indicating the program
or mode selected and about to run
Heavy
For setting, changingwater level andmanually
replenishing water.Water levels may be set at
beginning or pause.
Load Size button
Speed Wash/Spin button
Soil Level button
Cycles button
Select following six automatic programs with the
button
Delay/Start button
During no delay, the Delay/ Start indicator is
off, the remainingtime indicator ison, and
the nixie indicatordisplays the non-delayed
cycle remaining time.
Whites
Normal/Fast
Normal/Slow
Delicate/Fast
Delicate/Slow
Speed
Stain Wash
Heavy
Normal
Light
Load Size
Soil Level
Time Remaining
Cycles
Normal
Heavy Duty
Whites
Program
Washing the bigger, thicker or heavier
Normal Common washing
Quick Quick washing of the light dirt laundries
Delicate Washing the woollen textile or
Hand To imitatehand scrub washing effect
Washing the cotton textile
Pushing the button to select the reserve washing
time from 2 hour to 24 hour.
During Soak, Wash or Rinse,press this button
to manually replenishwater and release it to
stop. But thisfunction is disabled when water
reaches overflow protectionlevel.
Wash/Spin
For selecting clothessoiled degree.
Wash cycle increases2 minutes fora next
higher soiled degreeand decreases 2
minutes for anext lower soiled degree.
Push the button to select the spinning speed
S when program is
normal or delicate casual.
elect the spinning speed
Usage of the operation buttons
Time On
Delay
Start
Flashing Normal running mode
dirty laundries
Underwear
Duty
Wash
Casual
Wash

9
Process
Delicate Casual
Soak
2nd Rinse
Wash
Rinse
Spin
Start
Pause
Power
On/Off
Wash/Rinse
Hand Wash
Temp
Hot/Cold
Warm/Cold
Cold/Cold Cycle
Signal
Louder
Softer
Off
After switch on the power, push
it once to start the washing machine
In operating, push the button to pause
the operating.
In pause, push the button to resume
operating.
Start/Pause button
Numeral tube s window
Push the button once to switch on the power.
When the power is on, push the button once
to cut off the power.
Power On/Off button
Temp Wash/Rinse
For selecting inletwater temperature
during wash andrinse.
Cycle Signal button
Quick Wash
Toindicate remaining min. during
program running.
Toindicate remaining reserved hr.
during reservation period.
Toindicate fault symbols for
abnormal conditions.
For selecting louder, softer oroff
buzzer volume.
Process button
For selecting processes.Soak
process is Invalidif Hand wash,
Delicate Casual or Quick Wash
program is selected;
Water level indicatorturns off if only
Spin is selected.
After selecting aprogram, press
Process to select 2nd Rinse the
machine will includean additional
rinse process.

10
Buttons initial status for Normal program
Normal/Fast
Normal/Slow
Delicate/Fast
Delicate/Slow
Speed
Wash/Spin
Load Size
Soil Level
Stain Wash
Heavy
Normal
Light
Normal
Heavy Duty
Whites
Delay
Start
Cycles
Quick Wash
Delicate Casual
Hand Wash
Soak
Wash
Rinse
2nd Rinse
Spin
Process
Hot/cold
Warm/Cold
Cold/Cold
Temp
Wash/Rinse
Louder
Softer
Off
Cycle
Signal
Start
Pause
Power
On/Off
Cycle Signal Softer
Temp Wash/Rinse Warm/Cold
Process Soak, Wash, Rinse, Spin
Cycles Normal
Nixie display Remaining min. of the present cycle
Soil level Heavy
Load Size 6
Speed Wash/Spin Normal/Fast
Upon switching onthe power,the computer board buzzes once and the unit
enters from standbyto working status,i.e. initial status (Normal program);
5 minutes afterswitching on, if Start/Pause button isn'tpressed, the unitwill
automatically switch off and returnto standby;
Pressing Power On/Off button, allprograms will stop and the unit enters standby,
regardless of thecomputer conditions (start,pause, alarm etc.).
The washer hasintelligent wash resumption.After the power is cut off abnormally,
the washer couldresume working atstoppage while the power resumption.
1. Press Power On/Off to switch on the power supply
Power
On/Off
The unit returns to standby immediately after completion of a program;
b Operating procedure
Time Remaining
Time On
Usage of the operation buttons

11
3. Press the button of Process to select suitable
processes.
Page 9
2. Press the button of cycles to select a suitable
full-automatic program.
After switching on,the Normal program will be thedefault. If other
full-automatic program isdesired, you can press the button of cycles
to get thecorresponding indicator on. Refer to button of cycles on
page 8.
Example: Use the Quick program forslightly soiled articles
When Normal program is selected,
the washing machinewill perform
full-automatically controlled fuzzy
program to set water level, water flow
and wash durationaccording to the
cloth nature andweight.
Page 8
Quick Wash
Delicate Casual
Hand Wash
Cycles
Cycles
Buttons status for different program selected
,
Cycles Normal
(with soak)
Heavy
Duty Whites Hand
Wash
Delicate
Casual
Quick
Wash
Cycle Signal Softer Softer Softer Softer Softer Softer
Temp Wash/RinseWarm/Cold Warm/Cold Warm/Cold Warm/Cold Hot/Cold Cold/Cold
Process
Nixil Display
Wash, Rinse, Spin
Soil Level Heavy Stain Wash Heavy Normal Normal Light
Load Size
Speed Fast Slow
63 52 47 39 37 25
After the poweris switched on, the washing machinewill automatically set
a normal programcomprising of processes of Wash, Rinse and Spin . If other
process combination isdesired, press the button of Process to select one or
several process of soak, wash, rinse and spin. Refer to theparagraph of
processes selecting.
Process
Usage of the operation buttons

12
Spin shall begin after some time even
there is no water in the tub
Do not use soak process for woolen
articles.
Clothes prone to fade and other clothes
shall be separately washed.
Note
4. Press the button of Load Size to select a suitable
water level.
Load Size
Page 8
After switching on the power, the washing machine detects the load, and then
automatically sets a water level. If other level is wanted, press the button
Water level to select. Please refer to Button of 'Load Sizel'
on page 8.
Speed
6. Press the button of Soil to suit differently
soiled clothes.
Page 8
Page 9
5. Press the button of Speed to select suitable wash
and spin speeds
After the power is switched on, the washing machine will automatically set as
Normal/Fast . If the user desires to change it, press this button to select
according to Speed on page 8.
Wash/Spin
Soil Level
After the power is switched on, the washing machine automatically sets at
Heavy , the user may judge the clothes soil degree and select with the
Soil level button himself. See Soil on page 8.
Page 8
Temp
Wash/Rinse
7. Press the button of Temp. Wash/Rinse to select
different washing temperatures.
After the power is switched on, the washing machine will automatically set at
Warm/Cold . The user could also set three wash conditions of hot, warm and
cold. Refer to Temp. Wash/Rinse on page 9 to select.
Usage of the operation buttons

13
8. Press the button of Cycle Signal , which will
accordingly remind you of the cycle completion.
Confirming a reserved program
Page 9
Cycle
Signal
After the power is switched on, the washing machine will automatically set
at Softer . The user himself could also set three warning volumes Louder,
Softer or Off for the completion of a cycle. Refer to Cycle Signal
on page 9 to select.
9 Press the button of Delay/Start to select a suitable
reserve wash program
Delay
Start
After switching on, the washing machine reserved wash program will be
automatically set inactive. If you desire a wash cycle to end at a reserved
time, you can press the Delay/Start button to set a reserved wash program.
Refer to The button of 'Delay/Start' on page 8.
Page 8
When delay starts, program selected indicator turns off, while
the delay Indicator and remaining time turn on. During
reservation period, pressing Delay/Start button could
get reservation conditions displayed.
The wash cycle will end after 18 hrs
10. Press the Start/Pause button
Start
Pause
Press this button when you want the machine to start running.
During machine running,press this button to pause andpress once again to
resume operation.
Usage of the operation buttons

14
Finish washing
The power will be switched off automatically after the finishing of the washing.
Close the top lid
If you open the top lid, the machine
will stop working except for water
filling and draining water
After Finishing wash
alarm automatically

15
After washing
Agitator
Press
Lint filter
Lint Screen
Figure
Figure 2
Figure 3
Pull up out
After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise
it may influence your using the machine.
Please first pull off the power plug from the receptacle before cleaning.
If the cabinet is dirty, wipe it with wet cloth
Do not flush it directly with water.
Wipe it with neutral detergent.
Do not wipe it with thinner, petrol, alcohol etc.
Thinner
Petrol
Alcohol
1.After washing, close the water faucet. ( If needed, you can dismantle the water inlet hose).
5.Wipe off the water drops on the surface of the machine and inside the tub. Open the top lid for
some time (about 1 hour), then close the top lid.
4.Hang up the power cord and drain hose.
3.Be sure to pull off the power plug before maintenance.
2.Do not store water in the washing machine for a long period. Drain the water completely after
each using.
Cleaning the lint filter
The lint filter must be used during washing.
It must be cleaned in time after each using
1.Take off thelint filter
Pull up thelint filter onthe agitator
to remove.As shown inFigure 1.
2.Removing lint
Press the lintscreen clip withyour
thumb and indexfinger, andget the
screen downward asshown in Figure
2. While wet,remove the linton the
screen in water.
3.Mounting thelint filter
After cleaning,mount the screenback
onto the lintfilter as shownin Figure 3.
Then put thelint filter back in the agitator
barrel.
Press
The filter screen of the
water inlet valve is likely
to be blocked by foreign
materials and influence
the water inlet. Please
clean it with brush every
two months.

16
Trouble shooting answer to question
Phenomena
(If there's breakdown, please pull off the power plug before checking) The following
phenomena are not breakdowns sometimes. Please confirm again before sending it to
repair. If there are real breakdowns, please come to the special maintenance department
or after-sale service department of our company. Do not repair it by yourself.
Normal phenomena
Causes (explanations)
Intermittent spin afterspin starts Adjust balance toavoid clothes offset
Spin is selected, yet the machine doesn't spin The program sets a drain time, spin starts
after a time.
While water fillingin wash andrinse, the
pulsator pauses rotation
Toprevent splash during water filling.
Small amount ofwater flows outupon the
washing machine isinitially used
This is residualwater during factoryperfor
mance test.
The machine stopswhen top coveris opened
during running.
This is anormal fact. Due to the drum rotation,
an open coveralarm function isprovided for safety.
After the "reserve"is started,
it rings andthe digital tube
displays "E0"
The water faucetleaks.
There's abnormal sound
inside the machine.
The machine doesnot act.
(the indicators areoff.)
It does notdo water inlet or
the speed isslow (the water
level is notreached after 15
minutes). The digitaltube
displays "E4" andit rings.
The draining doesnot work,
or the speedof draining is
too slow.The digital tube
displays "E1" andit rings.
It stops runningduring wash,
rinse or spin.The digital tube
displays "E2" andit rings.
The top lidis not closed
The top lidis not closed
Is the drainhose blocked by
foreign material?
Is there metalmaterial inside
the washing machine?
Are the laundriesslanting in
spinning?
Is the machineslanting?
Is there powerfailure?
Is the waterfaucet open or is
there water supplyfailure?
Is the powerplug loose?
Is the waterinlet valve is
blocked
Is the jointerof the water inlet
hose is looseor twisted awry?
Close the toplid
Close the toplid
Use it whenthe power ison.
Level the machineproperly.
Fasten the jointerproperly.
Insert the powerplug tightly.
Fasten the buttonsand zipper
Re-order the laundries.Close the
top lid.
Clean the foreignmaterial. Open
and close thetop lid once.
Phenomena The reason How to settle
No water filling
If plug isinserted firmly?
If tap isturned on?
If Power On/Off and
Start/Pause is pressed?
Insert the plugfirmly
Turn on the tap
Press Power On/Off and
Start/Pause
Open the waterfaucet. Open
and close thetop lid once.
Clean the waterinlet valve.Open
and close thetop lid once.
The numeral tube shows
F2
Please contact the after-sales
service department.
Overflow alarm

17
Packing list
Name
User's manual
Quantity
1
1
1
2
Automatic washing machine
Drain hose
Water inlet hose
1
Drain hose hook
Drain hose clamp 1

Specification
Model HWM100-97
Rated voltage frequency 220-240V~ 50Hz
Rated washing / spinning capacity 8.5kg (weight of standard dry cloth)
Water level/Water quantity (about)
Max water consumption
Injection pressure 0.03MPa-1.0MPa
Rated washing power 525W
Rated spinning power 380W
Weight(about) 75kg
Dimension L 686 mm W 686 mm H 1080mm
About 185L(High water level; Normal program)
1/25L, 2/35L, 3/45L, 4/52L, 5/60L,6/68L, 7/72L, 8/80L, 9/88L, 10/100L
