Haier HWT12AD1 User manual

HW 10AD1
H T09AD1
H 12AD1
Please read this manual carefully before
operating your washing machine and retain
it for future reference.
TOP LOAD FULL-AUTOMATIC
WASHING MACHINE
USER’S MANUAL
0030517190B
MODEL
T
W
WT
HWT10ADB1

CONTENTS
Product Description
Safety Information
Installation & Adjustment
Before Starting
Operation
Cleaning and Maintenance
Packing list
Specification
Troubleshooting
1
2
2
2
4
4
5
5
6
7
8
8
10
24
7
8
22
23
25
Symbol Description
Warnings
Installing the bottom plate
Balancing the washing machine
Installation of the drain hose
Installation of water inlet hoses
Check the following before washing
Usage of detergent and softener
Loading your laundry
Explanation of the display
Operation and Wash Cycles 10
Safety 2

Product description
Outer tub cover
Top lid
Inner tub
Pulsator
Detergent and
softener tray
Plinth
Lid lock
Adjustable feet (2 pieces)
Top deck
Cabinet
Cold water inlet valve
Fixed
feet (2 pieces)
Control panel
Handle
Hook
Power cord
Back cover
Please understand that shapes of the washing machine and accessories may be
different from the sketch figures in this manual due to product improvements.
Drain hose connector
Drain pump filter cap
Hot water inlet valve
(Not to be removed by
the customer)
NOTE: The number of handles are model dependent. Refer to specification details on
page 25.
Dial
Lint Filter Box

Symbol Description
Warning sign
Forbidden sign
Contents marked with this symbol are related to the safe use of
the product and the personal safety of the user.
Please operate the machine in accordance with the contents of
this manual to avoid harm to the user or damage to the
machine.
Contents marked with
this symbol indicate operations or
actions that should not be undertaken by the user.
Performing of such actions may result in an injury to the user or
damage to machine and void the warranty.
Safety information
Warnings
A separate, earthed power socket is
required for the power supply.
Hold the plug, not the electric cable, when
unplugging the washing machine.
Do not insert or remove the power plug
with wet hands.
The power plug should be accessible after
machine installation.
Ensure the plug is removed and the taps
are turned off in the following cases.
Power failure, cleaning, moving,
installation of the machine and when
not in use.
2
Safety
This appliance is designed to be used in household and similar applications such as:
Staff kitchen areas in shops, offices, and other working environments;
Farmhouses;
By clients in hotels, motels, and other residential type environments;
Bed and breakfast type environments;
Areas for communal use in blocks of flats or launderettes,
Max. capacity 9 kg (HWT09AD1), max. capacity 10 kg (HWT10AD1) ,max. capacity 10 kg
(HWT10ADB1), max. capacity 12 kg(HWT12AD1),water pressure Min. 30kPa,Max. 1MPa.
If the Power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified people to avoid a hazard.
CAUTION: If this appliance is supplied by a cord extension set or
electrical portable outlet device, the cord extension set, or electrical
portable outlet device must be positioned so that it is not subject
to splashing or ingress of moisture.

Safety information
Forbidden
60
If you are using an extension cord or
an electrical portable outlet device
(not recommended), ensure that it
is positioned so that it does not come
into contact with water or moisture.
Do not install this appliance in a
damp or wet environment. Do not
leave wet laundry on the Control
Panel or spray water directly onto
this appliance as this may cause the
machine to malfunction, or cause an
electrical fault.
Do not wash
waterproof clothing
as this may affect load
balance during
spin cycle(s).
Do not connect to hot
water with temperature
higher than 60°C .
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or
instruction by a person responsible
for their safety.Children should be supervised to
ensure that they do not play with the appliance.
Do not take apart,
repair or alter the
machine by
yourself.
Do not attempt to remove washing or place
hands inside the washing machine while in
operation. Please ensure that children are
supervised around the machine to avoid
harm.
Do not leave hot or heavy items on the lid
or control panel as this may cause
damage to the washer or make the
washer unsafe to operate.
Do not wash laundry
with chemicals or other
volatile materials (such as
petrol, solvents or thinners)
as this may cause
damage to the
machine.
Keep the machine away
from heat sources
such as heater,
stoves or direct sunlight.
3
Failure to do so, may result in electric
shock.

If power cord or other parts of this machine are damaged or broken, please
contact a technician to have it repaired. Do not attempt repairs by yourself as this
may cause personal harm or void the warranty.
Please install and adjust the machine according to the directions contained in this
manual. It is very important to follow these
directions for the safe operation of the
machine, and to ensure your machine is being operated correctly.
Installation & Adjustment
4
Back
Front
Screw
Bottom plate Carpet
Installing the bottom plate
The purpose of the bottom plate is to sup press noise
from the washing machine during operation.
Steps:
2. Place the plate onto the bottom of the machine.
3. Use a screwdriver to tighten the screw (in accessory
bag) securing the panel to the bottom of the washer.
4. Once the screw is tight and the panel is secure, return
the washer to its standing position.
1. Tilt the machine backwards against a wall (ensure that
the machine is well supported).
The new hose sets supplied by the appliance are to be used and the old
hose sets should not be reused.
NOTE: The washing machine has ventilation openings in the base, the product must not be
placed on a carpeted surface.
Please do not remove the pump filter cap at the bottom
rear of the product in any situation as water remaining
in the product will flow directly out of the product.
In the event of a blockage or a failure to drain, please contact
the customer care centre for assistance.
The pump filter cap is only to be removed by a trained service
technician.
Pump filter cap
Safety information

Installation & Adjustment
Drain hose
5
Drain hose
clamp
Drain hose joint
1. The height of the standpipe or washbasin should be
between 0.8 - 1.2 m.
Bracket
0.8mh
1.2m
1. Remove the cap of the drain hose outlet.
Note: A small amount of water may come out when the cap is removed. This is
normal as there may be some water left in the pump from
when the machine was tested during manufacture.
60mm20mm
Installation on an uneven surface can lead to“out of balance”events, instability in the
machine operation, or even failure to successfully complete a wash cycle.
Please refer to the following steps for adjustment:
1. Confirm whether the machine is level.
2. Lift the lid and ensure that the bowl is central to the top deck opening.
Adjust the two front leveling feet as necessary.
Balancing the washing machine
NOTE:：
Not level level
and the washing machine's rear end should be at
least 60mm away from the wall.
2. First, connect the drain hose to the connection point on
the lower right side of the cabinet, and fasten with drain hose
clamp (provided).
3. Connect the drain hose guide onto the outside of the drain hose
To guide the drain hose over the washbasin or standpipe,
the bracket must be fitted to the drain hose.
2. To avoid siphoning, the drain hose should not
extended that more than 20 mm from the end of
the guide.
Ensure the drain hose is held in place to avoid
leakage or spills.
CAUTION: The drain hose is subject to water pressure in use and may come loose
from the installed connection point. Secure the drain hose against
unintentional loosening.
The washing machine requires at least a 20mm
clearance to a side wall or other adjacent product,

Installation & Adjustment
Connection between the water inlet hose and the
washer
the nut of the water inlet hose
Thread of the water inlet valve
Water absorption cushion
6
fastened and can be pivoted as required.
Check the inlet hose connections
Water inlet
1. Connect the cold hose (blue connector) to the cold tap
and the hot hose (red connector) to the hot tap. You
may have to use pliers to tighten the coupling. Do not
over-tighten as this may cause damage to the valve or
hose fittings.
2. Connect the other end of the hose to the respective hot and cold
inlet valves located at the rear of the washing machine.
3. We recommend you to replace the inlet hoses every 5 years. Hoses should be
checked from time to time and replaced if any wear, damage or leaks are found.
1. Do not take off the water absorption cushion.
Please check if the cushion is dropped or
damaged before each usage. If this happens,
please contact with after-sales department
immediately.
2. Put the nut of the water inlet hose onto
the inlet valve thread.
3. Fasten the nut.
2. After installation, open the tap to check for leakage.
CAUTION:
1. If the water pressure is too high or too low, the appliance may not be able to operate properly.
2. Ensure the water pressure in the water supply system is at least 30 kPa（1 bar）and a maxmum
of 1 Mpa (10bar).
3. If the water pressure exceeds the maxmum value specified, a pressure reducing valve must be
installed between the water outlet and the hose set connection.
4. Modified or damaged water hoses may result in water leakage resulting in property or
appliance damage.
5. Never kink, crush, modify or cut through water hoses.
6. Only use the new water hoses supplied with the appliance or genuine spare hoses.
7. Never re-use water hoses that have been used before.
1. Swing the hose gently to confirm that the hose is securely
3. Do not bend the hose unduly.
at both ends. This is to ensure the connections remain
4. Periodically check the hose connections are firm
watertight over time.

Preparation before washing
1. Connect the water inlet hose.
3. Insert the power plug into the wall power socket.
4. Ensure that the drain hose is installed at the correct height.
5. When the water pressure in the user's
home is too low, it may not be able to
flush detergents and softeners
effectively.
6. Please clean the detergent box when
required to maintain a clean surface.
It is suggested to dilute the detergents
before putting laundry into the inner tub. It is suggested that the
softener be diluted and put into the inner tub directly after the last rinse.
Check the following before washing
Before washing
Clear pockets and
take out loose items
such as coins, sand,
hairpins, etc,
a. Check if the laundry has any special washing instructions.
b. Divide the laundry into colour fast and non-colour fast items. When washing jeans and
other easily coloured clothes, please soak them with water first. After soaking, put
into the washing machine.
c. Separate items that do not absorb water easily and wash by hand.
d. For heavily soiled items, please first remove loose dirt or select Pre Wash option (if
avalible).
e.
For those items that may attract lint, please turn inside out before washing.
f. Do not put laundry soiled with chemicals or solvents into the washing machine.
Tie any long
straps or strings,
fasten buttons
and close zippers.
The weight of the
laundry
shall not exceed the rated
capacity of your machine.
Loosen the laundry before
placing it evenly in the tub.
Make sure the clothes are
completely placed in the
inner tub.
When the machine is
running, buttons may
cause noise.
To reduce the noise,
turn clothes inside
out or place them in
a laundry bag.
7
0.8m 1.2mH
7. Before washing, we recommend that a " Drum Clean " cycle is run
without any clothing.
2. Open the water faucet.

Usage of detergent:
Applicable only to HWT09AD1
How to use liquid detergent
How to use softener
The rated washing capacity refers to the largest dry
weight of a load that can be washed.
Before washing, please make sure that the water level covers th e clothes. Adjust the number of
clothes according to the cycle chosen. Refer to page13 for maximum load sizes.
The load should not exceed the height of the metal drum surface.
The thickness, size and type of clothes will influence
the actual capacity.
Do not select higher than water level“Med”for
clothes less than 2.0kg, to avoid splashing of water.
It is recommended that low suds/high efficiency
washing powder or liquid is used.
Operation
Loading your laundry
The usage and dosage of the softener should
follow the manufacturer's instructions.
Before washing, put the softener into the softener
inlet tray. See the above figure. The softener will
Do not leave softener in the softener tray for a
long time before washing as it could become
solidified and may not be dispensed correctly.
How to use powdered detergent
8
Washing powder
Remove the blue liquid tray and place the powder
detergent directly into the detergent cavity.
If you select“Express”program, it is
recommended to use liquid detergent instead of
washing powder to ensure the most effective
Old or poor quality washing powder may causing
caking in detergent dispenser.
Clean the detergent box periodically to ensure that
washing power is evenly distributed and remove
any detergent build up.
Before washing, put the detergent liquid into the
detergent tray situated on the left-hand side of the
drawer, as the above figure shows.
The usage and dosage of the detergent should
follow the manufacturer's instructions.
Liquid detergent tray
Softener inlet
be dispensed during the last rinse cycle.
NOTE:
Before using powder detergent, please remove
"blue" liquid detergent tray which serves only for
wash performance.
liquid detergent.

Operation
Usage of detergent：
Washing powder
Liquid detergent tray
Softener inlet
Smart-dose tray
How to use liquid detergent
How to use powdered detergent
Remove the blue liquid tray and place the powder
detergent directly into the detergent cavity.
If you select“Express”cycle, it is
recommended to use liquid detergent instead of
washing powder to ensure the most effective
Old or poor quality washing powder may causing
caking in detergent dispenser.
Clean the detergent box periodically to ensure that
washing power is evenly distributed and remove
any detergent build up.
wash performance.
How to use softener
.
Before washing, put the softener into the softener
inlet tray. See the above figure. The softener will
Do not leave softener in the softener tray for a
long time before washing as it could become
solidified and may not be dispensed correctly.
be dispensed during the last rinse cycle.
Applicable only to HWT10AD1,HWT10ADB1 and HWT12AD1
How to use Auto Dose
Before washing, the user can open the automatic
drop box cover, put the liquid detergent into the
smart-dose tray in advance, after starting the
machine, it will automatically dose the detergent
amount according to the user's load.
Note: no solid detergent, such as washing powder,
can be put into the smart-dose tray.
9
Before washing, put the detergent liquid into the
detergent tray situated on the left-hand side of the
drawer, as the above figure shows.
The usage and dosage of the detergent should
follow the manufacturer's instructions.
The usage and dosage of the softener should
follow the manufacturer's instructions.
NOTE:
If powder or liquid detergent has been manually
placed in the detergent tray ensure the Auto Dose
option is not selected. Otherwise too much
detergent will be dispensed into the machine and
excessive suds may occur.
Before using powder detergent, please remove
"blue" liquid detergent tray which serves only for
liquid detergent.

Operation and Wash Cycles
10
Explanation of buttons
Indicator display
Off :
On : Indicates that the program is running and indcates the selected
cycle and options.
Flashing: When it pauses, it indicates the washing progress status of the current
A B C D E F G H I J
washing cycle. It also flashes to indicate where it is in the wash cycle.
Indicates that the operation is complete or disabled.
Page23
During the wash cycle, the digital display will show the
time remaining in minutes.
If an issue occurs, the display will show a user warning
or error code (see page 23)
If“Delay start”is selected, after the startup, the delay start time remaining
is displayed first.
Digital display
Press the water level button to select the water level you want to set.
When there is water or wet clothing in the tub, it can't automatically detect
the load size.
All of the cycles except Drum Clean cycle default to“Auto”water level,
you can choose other water levels manually. The Drum Clean cycle
defaults to“High”water level.
Load Sensing is only accurate with dry clothing items, If wet items are
put into the machine it is advised to manually select the water level.
r
Water
level
A: "Water Level" button
If you choose Auto, the machine will detect the load size and automatically
select the suitable water level.

Operation and Wash Cycles
11
B: "Water Temp" button
Water
Temp
Press the “Water Temp” button to select your wash temperature.
Eco, Delicate and Wool cycles:“Warm hot”and“Hot”temperatures
cannot be chosen.
During Hygiene and Drum Clean cycles,“Hot”is the only option available.
Bulky cycle: temperature cannot be chosen. (see page 15)“Hot”
C: " Wash+ " button
Auto Dose: When AutoDose is selected the machine will
automatically dispense the correct amount of detergent from the
Smart Dosing tank based on the sensed load size.
The user has the ability to adjust the amount of detergent for each
program if required. There are 5 levels (1, 2, 3, 4, Hi). The default is 3
(see page 16).
Wash+
Soiled+: For heavily soiled items the user can choose Soiled+ which
increases the wash time by 30% and incorporates a 15min soak sequence
to the middle of the wash phase. During the soak phase the machine will
periodically agitate for a few seconds every minute to help remove
loosened dirt from clothing items.
Soiled+ is not available on Drum Clean, Express, Delicate and Wool cycles.
UV Sanitise: When UV Sanitise is selected, sanitisation is turned on
during the wash and deep rinse to kill bacteria.
Delicate, Bulky, Express, Wool cycles cannot choose UV Sanitise.
Hygiene and Drum Clean have UV Sanitise functions by default.
Favourite
Favourite can be set on any cycle. (see page 17)
Special features can be selected using the Options button: Pre Wash, Extra
Rinse, Eco Rinse.
cannot be selected for Eco, Delicate, Express, Wool, and Drum
Clean programs. If Auto Dose is not selected, Pre Wash is unavailable.
Note: The Auto Dose function only applies to HWT10AD1,HWT10ADB1 and HWT12 AD1, but not HWT09AD1.
D: "Options" button
Options
Pre Wash:
Eco Rinse:cannot be selected for Hygiene, Bulky, Delicate, Express, Wool,
and Drum Clean programs, Eco Rinse is the default on the Eco cycle.
Extra Rinse: cannot be selected for Express and Eco, Extra rinse is the
default on the Hygiene cycle.
If Soak and Soiled+ are both selected the wash time will be increased by
30% and a one hour soak sequence will be added to the middle of the
wash phase. During the soak phase the machine will periodically agitate
for a few seconds every minute to help remove loosened dirt from clothing
items.

Operation and Wash Cycles
12
Advance
Wash
F: "
Advance Wash
" button
On Eco, Express and Wool cycles,
“Soak”function cannot be chosen.
After Wi-Fi connection is successful, if you use the mobile APP to control
the washing machine, press "Advance Wash" + "Delay Start" for 3 seconds
at the same time, when the remote authorization indicator light is lit solidly.
You can use the mobile APP to run your washing machine.
Press Advance Wash button to choose“Soak”“Wash”“Rinse”
“Spin”.
When no Spin is selected or Advance Wash is selected, Spin is not optional.
Use this button to select the spin speed, press“Spin Speed”button to
choose
No Spin: The machine will drain water out. Eco and Express can not choose
"No Spin".
Speed
E: "Spin Speed" button
Delicate, Wool and Bulky cycles,“High”spin speed can not be chosen.
Spin
“No Spin”“Low”“Med”“High”
NOTE:
Delay Start counts down in hours and minutes.
Delay displays the approximate length of time before the chosen cycle will
start.
G: "Delay Start " button
Delay
Start
Delay will be set if the user presses the Delay start button. Delay starts
at a minimum of 15 minutes the next increment is 30 minutes.
From there it increases in 1 hour increments e.g.1, 2, 3,4, 5 hours, etc,
to a maximum of 12 hours.
The Delay time remaining will display solidly lit on the viewing screen.
When a delay cycle is started, the displayed viewing screen the reservation
time remaining will flash to show it has started.
If a delay has been started, then paused, the delay led will flash to indicate
it is paused, and the viewing screen will display solidly.
After the machine is powered on, press the“ ”button to start the
To pause the wash cycle, press the“ ”button.
To restart a wash cycle, press the“ ”button again.
H: " " button
machine.
.

Operation and Wash Cycles
13
Cotton
Eco
Express
Wool
Delicate
Bulky
Drum
Clean
Warmer wash for cotton clothing.
The water saving cycle.
Durable
Program
I "Program" select : Set the program by rotating the dial
Quick wash for smaller lightly soiled loads & brand new
clothes.
Gentle wash action and a medium spin for wool items.
Gentle wash action with slow spin speed for delicate
items.
A cycle designed for washing heavily soiled durable
items.
A warm wash with a special wash action and reduced
spin speed.
A hot cycle with a soak to clean the build-up of dirt in
the machine.
Bedding
Mix
Hygiene
Down-
loaded
A normal wash action for mixed everyday loads
including cottons and blends.
A cycle specifically designed to wash sheet loads.
Programs can be downloaded through the SmartHQ app; Towels, Baby Care,
Shirts, Sports, and Synthetic are available (see page 19). The preloaded cycle
when first purchased is the Towel cycle.
Note: The last cycle programmed into the downloadable cycle, wi ll become
the default until it is changed through the app.
A warmer wash for cotton towelling items.
Max Load Size
A hot concentrated wash with extra rinses.
You can choose the UV function to strengthen the
cleaning. Uv function is the default option.
9kg/10kg/12kg
9kg/10kg/12kg
3kg/3kg/5kg
9kg/10kg/12kg
9kg/10kg/12kg
4kg/4kg/4kg
6kg/6kg/8kg
3kg/3kg/5kg
9kg/10kg/12kg
4kg/4kg/4kg
9kg/10kg/12kg
/
NOTE:
Only Heat-safe fabrics can be washed.
Towels
A warmer wash for baby clothes. 4kg/6kg/6kg
Baby
Care
A cycle tailored to washing sports type clothing. Sports 4kg/6kg/6kg
A gentle cycle designed for a range of everyday
synthetic and blended fabrics.
Synthetic 4kg/6kg/6kg
A cycle designed for business shirts and workwear. Shirts 4kg/6kg/6kg
Note:
Refer to page 14 for information about the Max Load size.

Operation and Wash Cycles
14
Push the " " button to power on the machine.
Under power-on mode, push it to power off the machine.
If the " " button is not pushed, the machine will power off
automatically after 10 minutes.
J " " button
Note:
HWT10AD1, HWT10ADB1, and HWT12AD1:
Eco, High Water Level, no wash + options selected, Warm Water Temp, High Spin
speed is recommended for a normally soiled cotton load.
HWT09AD1:
Eco, High Water Level, Warm Water Temp, High Spin Speed is recommended for
a normally soiled cotton load.
The Max load size in the above table represents, from left to r ight, the maximum
wash load of each model.
(For example,“9kg/10kg/12kg”stands for“The Max load size of HWT09AD1
model under this cycle is 9kg”, “The Max load size of HWT10AD1 model
under this cycle is 10kg”, “The Max load size of HWT12AD1 mode l under this
cycle is 12kg”
.)

Operation and Wash Cycles
15
After the power is turned on, the default is Mix program. Rotate the dial clockwise to
select the Cotton, Delicate, Durable, Eco, Express, Bedding, Wool, Hygiene, Bulky,
Drum Clean, and Downloaded programs.
For example, when you want to wash light soiled clothes quickly
, use Express cycle.
All of the cycles except Drum Clean have a load sensing function, the water level is
adjusted according to the texture and quantity of clothing. After the detection is
completed the water level is set automatically.
When the washing machine is working, the water level is not optional. If the user needs
Press the button to reset the water level and press the “ ”button to start running.
Some wash modifiers have ‘in-between’ parameters which will display two LEDs.
For example, the Water level has Low, Low/Med, Med, Med/High, High, and Auto.
1 Press the button to power on/off
2 Rotate the dial to select automatic program
3Press the button to change the water level
4 Press the button to change the water temperature
Set the wash temperature in accordance to the requirements of each load.
5
Press the buttons to
customise the preset options
Some wash modifiers have ‘in-between’ parameters which will display two LEDs.
For example, the Water temperature has Cold, Cold/Warm, Warm, Warm/Hot, and Hot.
Wash+ Spin
Speed Options Advance Wash
to change water level during the cycle, then they need to press“ ”button first.

Operation and Wash Cycles
16
The amount of detergent for a given cycle can be adjusted to the following levels 1, 2, 3, 4,
5, and Hi. Turn the dial to the selected wash cycle you want to adjust the Auto Dose level.
Hold down the Wash + button for 3 seconds, the screen wiill then display SEt.
Rotate the dial clockwise to increase the detergent level up to Hi, or rotate
counterclockwise to reduce level down to 1.
To store the new detergent level setting press "Wash+" for 3 seconds,
the screen will flash SEt.
NOTE:
The Auto Dose function only applies to HWT10AD1, HWT10ADB1 1 and HWT12AD1,
but not HWT09AD1.
When‘Soiled +’is selected,‘Wash’,‘Rinse’and‘Spin’is the default for the
‘Advance Wash’modifier. The cycle will start the wash by flash ing the‘Wash’LED
continuously. When the cycle progresses to the short soak phase the‘Soak’LED will
flash continuously ,while the‘Wash’,‘Rinse’and‘Spin’LEDs are solid. At the
completion of the soak phase when the machine resumes the wash the‘Soak’LED
will go out , and the‘Wash’LED will flash continuously.
The wash will continue to progress flashing the LED of the current cycle stage.
As it progressed it turns off the LED when the stage has completed.
Wash operation sequence: This parameter is applicable only to HWT10AD1,HWT10ADB1
and HWT12AD1.
When the Smart Dose detergent tray is almost out of detergent the display will flash FILL
on the screen. The tank will need re-filling before another Auto Dose cycle is run.

Operation and Wash Cycles
17
6Press the button to start the cycle
7Press the button to select the delay wash program
Delay display: After the delay is started, the remaining delay time is displayed. After the
delay is started, it can be suspended, but parameters cannot be changed after the
suspension.
8Specific features
Favourite
There is a ‘favourite’ icon above the view screen to allow users to create
favourite cycles with their chosen wash modifiers which will then replace the default
settings for that cycle.
Once the user has selected the wash modifiers they desire, press and hold both
Options button and Wash+ button for 1 second to save the setting for that particular
cycle - this is indicated by a single beep when the FAVOURITE LED illuminates.
Holding down the two buttons again for 1 second will delete that favourite.
Changing any modifier after the FAVOURITE is set will turn them off as the set of
modifiers is no longer the same as what they had saved as a FAVOURITE.
CHILD LOCK
There is a CHILD LOCK function designed to prevent accidental changes to the washing
cycle once the machine has started or when the machine has a delay start modifier.
When the CHILD LOCK is activated, all controls will remain inactive, with exception of
the " " button. If any control is pressed when the CHILD LOCK function is activated,
the machine will sound 3 warning tones.
After starting the washing machine by pressing START/PAUSE, the user can hold both
“Spin Speed”&“Advance Wash”buttons for 1 second - the CHILD LOCK function will
turn on and the product will beep once. CL will display on the screen for 2 seconds to
indicate that the CHILD LOCK is set.
No Favourite Favourite set

18
Operation and Wash Cycles
Turning off the machine by pressing Power button or unplugging will not remove or delete
any saved information in the machine, e.g. Favourites will not be removed in this case.
If a loss of power occurs during a cycle, the machine will remember where the washing
progress was and will turn back on in a PAUSED state ready to resume the washing progress.
POWER OFF & LOSS OF POWER
To release the child lock function: push down “Spin Speed” button and “Advance
Wash” button at the same time for more than 1 seconds.
The digital screen will
display“CL”for 2
seconds.
NOTE: After the child lock is released, press the button to open the lid. If the lid is forced to
open when washing, the machine will alarm E2 and stop running. The machine will automatically drain
after 10 seconds. If you confirm the safety, please close the lid and press“ ”button to
wash the clothes. The machine will continue to run. If a separate washing or rinsing process is selected,
the washing machine will drain automatically after running.
During running, the child lock function (including alarm) can be activated or deactivated.
After the child lock is activated, all controls will remain inactive, with
“ ”
exception of the " " key.
