Haiyang HIS-700R Operator's manual

Quick Instruction
1 of 15
Tel.:[phone] www.haiyang.co.kr
„HIS-700R“
Operation/Mounting manual
HAIYANG OLIX.
103-903 Bucheon Technopark 364
Samcheongdong Ojeonggu Bucheon Gyeongi, Korea
Tel. :[phone]
Fax: [phone]
www.haiyang.co.kr

Quick Instruction
2 of 15
Tel.:[phone] www.haiyang.co.kr
Content
1.ENGLISCH............................................................................................3
1.1.Safety information..................... 3
1.2.HIS-700R.................................. 6
1.3.Use of HIS-700R ....................... 6
1.4.Package contains....................... 6
1.5.Mounting of the HIS-700R ......... 7
1.5.1Connecting of the HIS-700R... 8
1.5.2Connection and settings of the Chartplotter 9
1.5.3Settings of the Chartplotter/PC 10
1.6.Technical data/Specification....... 11
1.7.External NMEA, e.g. GPS – pass through HIS-700R 11
1.8.Change of Baud rate.................. 12
1.9.Contact..................................... 13
1.10.What to do if not working properly? 14

Quick Instruction
3 of 15
Tel.:[phone] www.haiyang.co.kr
1. ENGLISCH
1.1. Safety information
Software License Agreement
BY USING THE HIS-700R YOU AGREE TO BE BOUND BY THE TERMS
AND CONDITIONS OF THE FOLLOWING SOFTWARE LICENSE
AGREEMENT.
PLEASE READ THIS AGREEMENT CAREFULLY.
HAIYANG grants you a limited license to use the software embedded
in this device (the “Software”) in binary executable form in the
normal operation of the product. Title, ownership rights, and
intellectual property rights in and to the Software remain in
HAIYANG.
You acknowledge that the Software is the property of HAIYANG and
is protected under the Korea copyright Laws and international
copyright treaties. You further acknowledge that the structure,
organization and code of the software are valuable trade secrets of
HAIYANG and that the Software in source code remains a valuable
trade secret of HAIYANG. You agree not to decompile, modify,
reverse assemble, reverse engineer or reduce to human readable
form the Software or any part thereof or create any derivate works
based on the software. You agree not to export or re-export the
software to any country.
Limited Warranty
This HAIYANG product is warranted to be free from defects in
materials or workmanship for 12month from the date of purchase.
Within this period, HIAYANG will at its sole Option repair or replace

Quick Instruction
4 of 15
Tel.:[phone] www.haiyang.co.kr
any components that fail in normal use Such repairs or replacement
will be made at no charge to the customer for parts or labour,
provided that the customer shall be responsible for any
transportation cost. This warranty does not cover failures due to
abuse, misuse, accident or unauthorized alteration or repairs.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE
EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED OR
STATUTORY, INCLUDING ANY LIABILITY ARISING UNDER ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, STATUTORY OR OTHERWISE.
IN NO EVENT SHALL WEATHERDOCK BE LIABLE FOR ANY
INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES,
WHETHER RESULTING FROM THE USE, MISUSE, OR INABILITY TO
USE THIS PRODUCT OR FROM DEFECTS IN THE PRODUCT.
HAIYANG retains the exclusive right to repair or replace the unit or
software or offer a full refund of the purchase price at its sole
discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE
REMEDY FOR ANY BREACH OF WARRANTY.
Warnings and Precautions
If you choose to use the HIS-700R in a boat, it is the sole
responsibility of the owner/operator of the HIS-700R to secure the
HIS-700R so that it will not cause damage or personal injury in the
event of an accident.
If you choose to use the HIS-700R in boat, it is the sole
responsibility of the operator of the boat to operate the boat in a
safe manner, maintain full surveillance of all boating conditions at all
times, and never become distracted by the HIS-700R to the
exclusion of safe operating practices.

Quick Instruction
5 of 15
Tel.:[phone] www.haiyang.co.kr
SOME VESSELS DO NOT CARRY AIS.
IT IS IMPORTANT AT ALL TIME TO KEEP A
PROPER LOOKOUT.
NEITHER THE “HIS-700R” is NOT A
SUBSTITUTE FOR GOOD SEAMANSHHIP.

Quick Instruction
6 of 15
Tel.:[phone] www.haiyang.co.kr
1.2. HIS-700R
Thank you to buy an HIS-700R from the company HAIYANG. It is the latest
and the best available unit in the market. The core features are:
2 channel AIS receiver with newest µP technology
Highest sensitivity (-112dBm) at optimised selectivity
Integrated multiplexer upconverting from 4,8kB to 38,4kB
Enlarged DC power input from 9-28VDC
1.3. Use of HIS-700R
It is very simple to use.
After mounting and connecting to the chartplotter or the PC is nothing more
to do with the unit.
The Green LED is on, if correct connected to the board power
The Channel A LED is flickering, each time there is an AIS signal received on
channel A
The Channel B LED is flickering, each time there is an AIS signal received on
channel B
1.4. Package contains
The package contains:
The cable to connect to the PC or chartplotter
Adapter plug to use the HIS-700R with the PC (SUB-D 9)
2 stainless steel screws to mount the HIS-700R.

Quick Instruction
7 of 15
Tel.:[phone] www.haiyang.co.kr
1.5. Mounting of the HIS-700R
The HIS-700R is equipped with a enhanced driver circuit. Therefore it is
possible to have the HIS-700R mounted in a distance up to 10m from the
Chartplotter.
The HIS-700R should not be mounted close to other units transmitting and
receiving radio signals.
The HIS-700R is mounted with 2 screws under deck. Please leave some
space of about 125mm below the unit so that the cables entering the unit
do have enough space
If you use an own AIS antenna, please assure that the antenna is at least
1m in distance mounted to the VHF antenna, otherwise part of the
transmission power of the VHF is entering the HIS-700R and disturbs the
excellent performance.
The HIS-700R is connected to the antenna and to the PC or the chartplotter

Quick Instruction
8 of 15
Tel.:[phone] www.haiyang.co.kr
1.5.1 Connecting of the HIS-700R
The HIS-700R is connected to its ownVHF antenna to the VHF
antenna of the VHF Radio) and to the chartplotter or PC.
List Cable connection:

Quick Instruction
9 of 15
Tel.:[phone] www.haiyang.co.kr
HIS-700R, Cable colour Function
Red Power supply, positive DC +9 ... +28V
Black Power supply, negative (and signal ground)
White NMEA-out (+), AIS-Data ,
Green NMEA-out (-), AIS-Data
Yellow Additonal NMEA-in (+), e.g. GPS-data
(optional)
Brown Additonal NMEA-in (-), e.g. GPS-data
(optional)
1.5.2 Connection and settings of the Chartplotter
The only thing you have to do is:
to connect the white (out +) cable to your input (+) of the NMEA port
to connect the green (out – ) cable to your input (-) of the NMEA port
Please find details of the settings in your Chartplotter manual. Every
chartplotter is a little bit different.
Nevertheless the main settings of your input NMEA channel should be:
Select the right input channel at your Chartplotter. (Some do have up to 3
and more input channels)
Set transmission data rate to 38400
Set the input channel of the chartplotter to the following bit configuration:
8/N/1

Quick Instruction
10 of 15
Tel.:[phone] www.haiyang.co.kr
1.5.3 Settings of the Chartplotter/PC
The only thing you have to do is:
to connect the white (NMEA out +) cable to PIN 2 of the SUB-D9 connector
(enclosed in the package).
to connect the green (NMEA out – ) cable to PIN 5 of the SUB-D9 connector
(enclosed in the package).
Plug the cable to the serial port of your computer.
If your computer does not have a serial port anymore, which is often the
case with new computers, you can use also a serial<->USB adapter.
But if you use such an adapter please do first install the adapter. Please
assure that the adapter is not yet connected to the HIS-700R. In some
cases this could lead to misinstallation of the adapter and a final reliable use
of the HIS-700R is not possible.
Select the right input port at your PC
Set transmission data rate to 38400
Set the input port to the following bit configuration: 8/N/1

Quick Instruction
11 of 15
Tel.:[phone] www.haiyang.co.kr
1.6. Technical data/Specification
Receiver
•2 channel AIS receiver for AIS Signals on the frequencies 161.975 and
162.025 MHz
•Channel spacing: 25kHz
•Sensitivity: -112dBm
•Data rate: 9600Bps
•Antenna impedance: 50Ohm
Electrical performance:
•Power supply: 9V up to 28VDC @< 100mA
•Antenna connector: BNC
•Cable for power supply and data: 6 pole plug, included
Output:
•Default Baud rate: 38,4kB
(4,8kB can be set by Dealer on request or the
ambitioned sailor itself)
•Format: NMEA 0183
•NMEA Telegramme: VDM
Dimensions (overall):
•Length: 150mm, Width: 150mm, Height: 30mm
•Weight: app. 500gr.
1.7. External NMEA, e.g. GPS – pass through
HIS-700R
External NMEA data, e.g. of an external GPS, can be passed through to the
HIS-700R. This input is optodecoupled. The yellow and the brown cable are
used for this feature. The yellow cable is the positive input for the additional
NMEA data (NMEA +). The brown cable is the negative input for the
additional NMEA data (NMEA -). Please be sure that all external data need
to be at a data rate of 4k8. All data is speeded up to 38k4 and are

Quick Instruction
12 of 15
Tel.:[phone] www.haiyang.co.kr
outputted via the NMEA (+/-) data lines (white/green) multiplexed with the
received AIS telegrams.
1.8. Change of Baud rate
The change of the baudrate, if necessary, is easy to be done.
The default value is a transfer rate of 38400 Baud.
To change to 4800 you have to follow the following procedure:
1) Switch off the HIS-700R, disconnect it from the lines
2) Connect the NMEA cables in the following way:
3) White and Yellow
4) Green and Brown
5) Leave these cable connections like described under 2.
6) Switch on the HIS-700R, this means connect it to the lines.
7) The “on” LED will appear
8) The “channel B” LED will appear for a new programmed datarate of
4800Baud
9) Disconnect the NMEA cable connection
10) Now the new datarate is programmed
11) Then “channel B” will shortly disappear and turn on again for app.
1 sec.
If you want to set back to 38400 Baud the procedure is the same like step
1-7 and 9.
Step 8 and 10 will be different:
8) The “channel A” LED will appear for a new programmed datarate of
38400 Baud
10) Then “channel A” LED will shortly disappear and turn on again for app.
1 sec

Quick Instruction
13 of 15
Tel.:[phone] www.haiyang.co.kr
1.9. Contact
Servicel/Technical Advice:
Your local saler or contact the manufactorer directly over the homepage:
www.haiyang.co.kr
HAIYANG OLIX.
103-903 Bucheon Technopark 364
Samcheongdong Ojeonggu Bucheon Gyeongi, Korea
Tel. :[phone]
Fax: [phone]
www.haiyang.co.kr

Quick Instruction
14 of 15
Tel.:[phone] www.haiyang.co.kr
1.10. What to do if not working properly?
Po
s Problem Reason Solution
1 "ON" LED not lit Board power Please check the board
power connection
2 Not either
Channel A or
Channel B LED
flickering
No signals around Are you in an area with
enough AIS traffic?
3 Antenna connection bad Check your connectors
and your antenna cable.
Please be very carefully
with the soldering of
sockets and plugs. Bad
work will cause a loss of
sensitivity.
4NoAISTargets
on the screen Not well connected to the PC or the
chartplotter
This can be checked
with a PC and the
"Hyperterminal
software" of Windows.
You find the
Hyperterminal SW
under
/Programms/Accesories/
Communication/.
Connect the easyAIS by
means of the cable and
the SUB D9 plug, which
is also enclosed to the
serial port of the PC.

Quick Instruction
15 of 15
Tel.:[phone] www.haiyang.co.kr
Please configure the
port and the cable as
discribed under topic.
"Configuration for PC".
Each time when the
HIS-700R is first
connected to the lines,
it is sending a message.
If you see the message,
the connection works
well.
5 Antenna connection bad See under 3)
