HAKO Advantage 15721000 User manual

ADVANTAGE
Cyclone Back Pack
Vacuum Cleaner
OWNER’S MANUAL
ADVANTAGE MODEL 15721000
PLEASE READ THIS MANUAL BEFORE OPERATING
Exclusively Distributed:
Australia / New Zealand
Hako Australia Pty Ltd
90 Wetherill St N,
Silverwater NSW 2128
Australia
The vacuum
you can
depend on
Enquiries:
Email: hk[email protected]
Toll Free: 1800 257 221 (only within Australia)
P: [phone]
F: [phone]
Website: www.hakoaustralia.com.au

Pg 1
WELCOME TO THE ADVANTAGE
CYCLONE VACUUM CLEANER
Discover the benefits of the Advantage cyclone technology, and surprise yourself with the amount of dirt you will vacuum
the first time youuse it. This is the dirt your previous vacuum left behind.
Health and hygiene is important to us. The Advantage provides clean healthy exhaust air using antimicrobial agents in the
vacuum hose, tank and motor filter, which eliminates odour causing bacteria, fungus and other microorganisms.
The long life vacuum motor, strong construction and quality manufacture, provides you with a, tough commercial vacuum
cleaner. KEY FEATURES
•Very powerful
•4 stage filtration
•No bags … just empty the bin
•Improves the working environment, does not use expensive filters.
•Reliability you can depend on HOW THE TECHNOLOGY WORKS
Unlike ordinary vacuum cleaners the Advantage does not use a bag orcartridge filter. Instead, filtration is provided by the
3TDC ( 3 Tier Dual Core)cyclones which separate dust from air centrifugally. Large objects are filtered into the clear dust
bin and retained by a mesh separator. Smaller cyclones then progressively filter finer dust into the internal bin. Finally the
washable Motor Filter infused with antimicrobial odour control agents, captures and eradicates microbes in its structure
providing an added level of filtration protection. Emptying the bin issimple; with the push ofa button dispose of the dust into
a rubbish bin or a disposable bag. TABLE OF CONTENTS
1 GUIDE TO YOUR MACHINE
10 CLEANING LID BIN, & FILTER MESH
2 SAFETY INSTRUCTIONS
3 ASSEMBLING YOUR MACHINE
4 PRE-USE CHECKS
5 TAKING ADVANTAGE
6 IMPORTANT INFORMATION
11 EXPLODED DIAGRAM
12 PARTS LIST
13 WIRING DIAGRAM
14 TROUBLE SHOOTING
15 SPECIFICATIONS
7 WEARING AND ADJUSTING
16 ADVANTAGE WARRANTY
8 EMPTYING & RETURNING THE BIN
9 CLEANING FILTER MOTOR
17 WARRANTY REGISTRATION DETAILS
1. GUIDE TO YOUR MACHINE
1
Button Bin Release
17
Switch ON/OFF
2
Lever Lock
18
Tool Holder
3
Handle
19
Pad Waist
4
Valve Poppet
20
Pad Back
5
Inlet
21
Pad Shoulder
6
Lid Bin
22
Lid Bin Catch
7
Exhaust
23
Lever Bin Release
8
Hinge
24
Cord Extension
9
Cord Coupling
25
Bent End Piece
10
Power Inlet
26
Suction Regulator
11
Socket Extension Cord
27
Hose Assembly
12
Cord Restraint Strainless
28
Wands
13
Tank Assembly
29
Floor Tool
14
Cover Filter
30
Crevice Tool (Optional)
15
Filter Motor
31
Dusting Brush (Optional)
16
Housing Motor Assembly
32
Turbine Brush (Optional)

Pg 2
v
1
2
7
11
6
10
5
21
3
9
4
12
28
26
25
27
29
13
17
16
15
14
18
23
24
19
20
8
30
31
32
22

Pg 3
2 SAFETY INSTRUCTIONS
Read this manual and follow the instructions before using the Advantage back pack
•This applianceis not intendedfor use by persons(including children) with reduced physical,sensory or mental
capabilities, orlack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible fortheir safety.
•(Europe) This appliance can be used by children aged from 8 yearsand above and persons with reduced physical,
sensory or mentalcapabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use ofthe appliance in a safe way and understand the hazards involved.
•(Europe) Cleaning and user maintenance shall not be made by children without supervision
•Children should be supervisedto ensure that they do not play with the appliance.
•Do not leave unattended whenit is plugged into the electricity supply
•Do not unplug with wet hands. Do not pull on cord tounplug. Do not pull or carry by cord
•Switch OFF and unplug from electricity supply when not in use and before cleaning or servicing.
•Do not use outdoors. Do not leave in the sun. Do not use to pick up water.
•This machine shall be stored indoors only
•Ensure that cordis not jammed or trapped during vacuuming. Extend the cord completely but do notstretch or tug
on the cord.
•Keep cord away from heated surfaces
•Use only with approved extension cord
•Do not put any objects into openings. Do not use withany openings blocked; keep free of dust, lint, hair and
anything that reduces airflow.
•Do not use with Tank Assembly detached from Motor Housing Assembly, or without filters in place.
•Do not use to pick up flammable, combustible, explosive, toxic or dangerous substances, or use in areas where they
may be present.
•Do not vacuumanything that is burning such as cigarettes,matches or hot ash
•If the appliance is not working,has been dropped, damaged, left outdoors,or dropped into water, return it to an
authorized service centre
•Use only with Rugged Industries recommended parts and attachments
•This machine is intended for commercial use, for example in hotels, schools, hospitals, factories,shops, offices and
rental businesses
SAVE THESE INSTRUCTIONS
3 ASSEMBLING YOUR MACHINE
1As standard you will receive 2 x stainless steelmetal wands,1 x Hose Assembly, 1 xEZ2GO wet anddry floor tool
2The machine isconfigured forright handed operators. You can change to left handed configuration by turning the
tank assembly 180°. Release the Tank Lock at the top ofthe machine to change configuration or to remove the tank.
3Insert Hose Assembly to Inletbayonet and turn anticlockwise to secure bayonet fitting
4Connect the 2 wands together to create one length.
5 Connect wand to the Bent End Piece.
6 Connect the EZ2GO™ floor tool to the wand
4 PRE-USE CHECKS
1 Test Poppet Valve byblockingthe Hose Inlet and listening fora change in the machine sound. This is the point
where the Poppet Valve is activated.
2 Empty and clean the tank bin when full. Check the motor filter for cleanliness when emptying the tank bin.
3 Ensure the bin catch is engaged onto the tank
4 Check that cordand plug are in good condition
5 Plug into a suitable electricalsocket and switch power ON at the power point
The Advantage vacuum cleaner is now ready to use.

Pg 4
5 TAKING ADVANTAGE
1 The EZ2GO™ floor tool has been designed for both hard and soft floors. Its low profile allows easy access to low
recesses, under desks, tables, chairs and furniture. The swivel neck tool automatically adjusts to the user’s height.
The rear rubber tyres reduces noise on hard floors, and with four wheels down it is EZ2GO™.
2 For vacuuming curtains, soft furnishings, or loose fabric, adjust the Suction Regulator by sliding to the desired level.
3 The Advantagecyclone is fitted with a Poppet Valve to relieve over suction and to maintain air flow for filtration, in
the event of blockage, or by not emptying the bin, or by not cleaning filters. When activated there will bechange in
machine sound. To prevent reoccurrence clear the blockage or empty the bin.
4 When rubbish reaches the Max level, emptythe bin.
5 If liquid is accidentally vacuumed, empty and clean the bin and as described in point 8 and point 10 in this procedure
6 The Advantage is equipped with tool holders on the Waist Pad for convenience when on the go.
7 Optional Extras
a) For ease of use and to improve housekeeping tasks we have thefollowing attachments available Crevice Tool,
Dusting Brush, and Turbine Brush.
b) The Crevice Tool is used for crevice cleaning on upholstered furniture or spot cleaning
c) The adjustable Dusting Brush Tool is used for upholstery, corners, blinds, desk tops and cornices cleaning
d) The Turbine Brush is used for large areas, or when improved productivity and efficiency are required e.g. carpet
cleaning 6 IMPORTANT INFORMATION
1. Fine dust such as powders, chalk dust can only bevacuumed in smallamounts. The Advantage is not intended for
industrial use such as automotive workshops, warehouse, construction or factories.
2. Do not vacuum sharp hard objects such as glass, gravel, screws, pins, metal objects etc
3. When vacuuming certain carpets, static electricity may develop in the bin. These are harmless and are not
associated with the mains power.
4. The Advantage is fitted with aPoppet Valve tomaintain airflow in event of blockages. In the event of blockage, turn
the power OFF, clear the blockage before using again. Check parts such as Floor Tool, Bent Elbow, Hose and
Vacuum Inlet, clear the blockage before turning the power ON. Ensure Filter Mesh and Filter Motor are clean.
5. Do not vacuumplastic bags orlarge paper objects these block the Mesh Filter and reduce filtration performance.
6. Clean the Mesh Filter of lint, fluff and dust using a paper towel, dry cloth or duster.
7. Empty the bin as soon as dirt reaches the Max mark. DO NOT OVER FILL.
8. To minimise dust contact when emptying, encase the clear bin in a plastic bag and empty, remove the bin carefully
when done.
9. Wash the Antimicrobial Filter regularly. The maintenance onthis filter varies according to the material surface
vacuumed and level of soiling. It is important to check the cleaner regularly and wash at least weekly.
10. Do not immerse the whole tank assembly in water or pour water into cyclones
11. Do not hose down internal parts of themachine
12. Do not use detergents, cleaning agents, polish,for cleaning or on any part of the Advantage vacuum cleaner.
13. Transport the Advantage in the upright position only.

Pg 5
7 WEARING AND ADJUSTING
8 EMPTYING & RETURNING THE BIN.
1. Loosen both Shoulder Pads
2 Lift Advantage onto Shoulder sliding
one arm through the shoulder harness.
Slide other arm through the second
shoulder harness
4. Secure Waist Pad around waist to suit
your personal comfort.
3. Tighten Shoulder Pad to suit your
personal comfort
5 Wear the Advantage as illustrated
1. Uncouple the Hose
2. Place slight downward pressure with
one hand on the Handle then release the
tank by turning the tank lock 180° with the
other hand.
3. Press release button to disengage
the Bin Lid to empty into a waste bin
4. Ensure seals indicated are clean and
free of fibre, hair and large debris
5 Re-engage the Bin Lid Catch to Tank
Assembly by gently pressing down on
handle with Bin Lid flat on floor

Pg 6
9 CLEANING THE FILTER MOTOR ANTIMICROBIAL
10 CLEANING LID BIN, AND FILTER MESH
Cleaning the Mesh Filter is when fibre lodges inthe mesh holes and Bin Lid is only when water is accidentally vacuumed
with dust at the same time.
1 Remove the Tank Assembly
2 Remove Cover Filter
3. Remove the Motor Filter.
4 Rinse Motor Filter under a tap
thoroughly.
5 Press Dry Filter. by hand and then
allow another 24h to thoroughly air dry or
use a second interchange clean dry filter..
Do Not Wring Dry. This damages the
Filter.
6 Only when dry reinsert the
filter with white backing, facing
the motor.
1. Remove Bin Lid at the hinge at the tank
as shown. Flush the Bin Lid under a tap to
clean. Then dry with a cloth towel.
24 h Drying
Time
2 Using a dry cloth, paper towel or
micro-dusting brush wipe mesh filter face
clean. Do Not Hose Out Internal Parts
Of The Machine

Pg 7
4x1
6x2
4x3
4
5
6
7
4x1
11
10
9
8
12
13
14
15
16
17
18
19
20
2x23
22
21
3
2x24
2x25
26
28
27
29
2x30
31
32
33
34
2x1
4x35
1
38
37
36
42
41
40
39
2x1
50
43
44
45
3x1
46
47
48
49
51
52
53
2x54
55
56
57
58
11. EXPLODED DIAGRAM ADVANTAGE MODEL 15721000

Pg 8
12 PARTS LIST ADVANTAGE MODEL 15721000
Item Part No. Description Qty Item Part No. Description Qty
1 16018004 Screw WN1412 KB40 x 12-Z 34 31 16011000 Lever Bin Release 1
2 16015006 Pad Motor Clamp 6 32 16018010 Spring Bin Release 1
3 16018007 Screw WN1412 KB50 x 20-Z 5 33 16017000 Retainer Button Spring 1
4 16022002 Wire Blue 180L 1 34 16001005 Button Bin Release 1
5 16018018 Switch Rocker 1 35 16002008 Cap Screw 4
6 16008000 Insulation Base 2pc set 1 36 16007000 Handle 1
7 16002002 Cap Motor 1 37 16002000 Cover Top 1
8 16002004 Cord Extension 18m 1 38 16018009 Spring Poppet Valve 1
9 16002003 Cord Coupling 1 39 16021000 Valve Poppet 1
10 16002006 Cord Restraint Strainless 1 40 16021001 Valve Poppet Inlet 1
11 16018017 Socket Inlet 1 41 16014002 O’Ring Bin Inner 1
12 16007002 Housing Motor 1 42 16007001 Hinge Tank 1
13 16022001 Wire Brown 160L 1 43 16005000 Filter Mesh 1
14 16008001 Insulation Side & Back 4pc set 1 44 16001003 Bin Inner 1
15 16002005 Clamp Motor 1 45 16006001 Gasket Filter 1
16 16012002 Motor Vac 900W 1 46 16001004 Bin Outer 1
17 16018012 Seal Top Motor 1 47 16018003 Seal Bin 1
18 16015001 Plate Motor Mounting 1 48 16018002 Seal Tank 1
19 16005002 Filter Motor Antimicrobial 1 49 16011001 Lid Bin 1
20 16002001 Cover Filter 1 50 16018000 Shell Tank 1
21 16022003 Washer 3/16 x 1/2 1 51 16007005 Hose Connect & 75Seal 1
22 16011002 Lever Lock 1 52 16007003 Hose BEP AM Assy 1
23 16013001 Nut M5 2 53 16707000 Hose BEP Connector AM Assy 1
24 16018016 Screw M5 x 60 2 54 16022005 Wand 32 x 500L S/S 2
25 16022004 Washer M5 2 55 16019004 Tool Floor EZ2GO 1
26 16005004 Frame 1 Optional Accessories
27 16015004 Pad Waist 1 56 16019003 Tool Dusting Brush 1
28 16015003 Pad Shoulder L & R 4pc set 1 57 16019002 Tool Crevice 1
29 16015002 Pad Back 1 58 16019005 Tool Turbine Brush 1
30 16018005 Screw WN1412 KB40 x 8 BZ 2 59 16005003 Filter Motor Antimicrobial 5/Pkt 1
13 WIRING DIAGRAM

Pg 9
14 TROUBLE SHOOTING GUIDE
Problem
Possible Cause
Solution
Machine does not operate
•Not plugged into power point
•Plug into Power socket
•No power at the power point
•Move to a functional power point.
•Machine switch orpower switch OFF
•Turn switch ON
•Faulty Cord or Coupling Cord
•Replace Cord
•Faulty Switch or Motor
•Contact Service Centre
Loss of Suction
•Blockage
•Check for blockage and clear
•Suction Regulator open
•Close Suction Regulator
•Bin Full
•Empty Bin
•Filter Motor Blocked
•Clean Filter
•Poppet Valve loose
•Tighten Poppet Valve
15 SPECIFICATIONS ADVANTAGE MODEL 15721000
Physical
Machine
Capacity (l)
5
Power (w)
900
Gross Package Weight (kg)
7.5
Suction (kPa)
25
Carry Weight (kg)
5.0
Voltage (V a.c.)
220 - 240
Noise (dB
A
)
74
Compliance
RCM
Cord Length (m)
18
Class
2
Hose Length (m)
1.2
Type
Dry
Reach Length (m)
20.5
Motor
Accessory Dimension (mm)
32
Type
Flow Thru
Wand (mm) 2 pc Stainless Steel
2 x 500
Air Flow (l/s)
49
Floor Tool (mm wide) EZ2GO
285
Life (hrs / Revs)
1,000+ / 2.0+ Billion
Filtration
Warranty
Primary
3 TDC cyclone
Parts 2 Years, Motor 3 Years
Motor Filter
Antimicrobial
Refer Warranty Statement
Re-emission (mg/m³)
< 0.08
Efficacy
99.9% CFU 24h
Bacteria: Escherichia Coli, Klebsiella Pneumoniae,
StaphylococcusAureus
, Pseudomonas Aeruginosa,
Corneybacterium Ammoniagenes
Moulds: AspergillusNiger,
Trycophyton, Mentagrophytes
Note: The Advantage vacuum cleaner design incorporates Patent App. No. 2015904843, Registered Design App. No.
201612860, Innovative PatentApp No. 2016101477, EZ2GO™ No. 1787984

Pg 10
16 ADVANTAGE WARRANTY
Appliances manufactured by Rugged Industries Pty Ltd are to the highest qualitystandards. We encourage you to care for
your product and follow theinstructions inthis manual, and in turn you will benefit with a product that provides performance
and long life.
The followingstatement is a requirement underAustralian Consumer Law and applies to consumersale of goods and
services. In this statement “Our” means Rugged Industries and “you” means original purchaser.
“ Our goods come with guarantees that cannot beexcludedunder the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable lossor damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a majorfailure ’
I n addition to guarantees under AustralianConsumer Law, RuggedIndustries warrants the Advantage vacuum cleaner
against faulty material and/or workmanship for a period oftwo years, and the vacuum motor for a period of 3 years from the
date of purchase, when operated and maintainedin accordance with the instructions in this manual.
The following explains conditions and what to do inthe event ofa claim:
RuggedIndustries willreplace parts
determined asfaulty, but does not apply to normal consumable partsthat require
replacement undernormal useincluding but not limited to rubber parts, filters, hoses, powercords, floor tools,
dusting brush, crevice tools, turbine brush etc.
Warranty does not cover any machine or component that has been altered, abused, neglected, modified used with
non-genuine Rugged Industrycomponents.
Warranty does not cover damage by transportation, accident, misapplication or improper service, blockages, sucking
up water, use andinstructionsthat is not in accordance with the AdvantageOwner’s Manual.
Warranty does not cover freight, transport, delivery or returnof product.
All repairs andservicing during the warranty period must becarried out byauthorised Rugged Industries service
agent or authorised person.
Rugged Industries will not be responsible for cost of repairs or damages caused by unauthorised persons.
Warranty claims must be made within the warranty period and proof of purchase must besupplied with the claim.
17 WARRANTY REGISTRATION DETAILS
Purchaser: Purchase Date:
Address:
State: Post Code: Contact: Ph:
Model No: Serial No:
Purchased From:
Address:

Pg 11
Rev: 01111
Manufactured by:
Rugged Industries Pty Ltd
33 Antoine Street
Rydalmere NSW 2116 Australia
Rev 011216
