Halcro SSP100 Quick start guide

AUDIOOUT1
MUTE DIM ZONE SOURCE MODE THX MENU
4
AUDIOOUT2 MICROPHONE RS232
USB
33 12
5
13 14 15 16 17
6 7 8 9 10 11
18
20 21 22 23 24 25 26 27 28 29 30 31 32
34 35 36 37 38
45 46444341 424039
19
SSP100front&rearpanels
SSP100FrontPanel
SSP100RearPanel
1
2
33
1IRreceiver
2
3StandbyLED
4Display.
5Mutebutton
6Dimbutton
7Zonebutton
8Sourcebutton
9Modebutton
Standby/Onbutton
187.1balancedaudioinput
197.1balancedaudiooutputs
20Compositevideoinputs1to6
21RecordoutputandMonitoroutput
22ZoneoutputandMonitoroutput
23S-Videoinputs1to6
24S-Videomonitoroutput(withoutOSD)
25S-Videomonitoroutput(withOSD)
26S-VideoRECoutput
27Opticaldigitaloutput
28Coaxialdigitalaudioinputs1to4
29Opticaldigitalaudioinputs1to2
30AES/EBUbalanceddigitalaudioinput
(withOSD)
(withoutOSD)
31RS232controlinterface
32IRsensorinputs
10THXbutton
11Menu
12Volumecontrol
13Headphoneaudiooutput1
14Headphoneaudiooutput2
15Microphoneinputsocket
16RS232controlinterface
17USBcontrolinterface
33Remotetriggeroutputs1to3
34Componentvideoinputs
35Componentvideooutputs
36HDMI™output
37HDMI™inputs
38USBcontrolinterface
39Analoginputs1to10
40Tapeinput/output
41Recordoutputs1&2
42ZoneBaudiooutput
437.1channelunbalancedinputs
447.1channelunbalancedoutputs
45Specialoutputs1&2
46Powerinletandmainswitch
