User’s Manual
KVMC-UH-8-UHD
8-Port HDMI KVM Switch Console
with
USB 2.0 and 4K Video Support
UMA1274 Rev B
Order toll
-
free in the U.S.
800
-
959
-
6439
FREE technical support: 714-641-6607 or [email protected]
Hall Research, 1163 Warner Ave. Tustin, CA 92780
www.hallresearch.com
CUSTOMER
SUPPORT
INFORMATION

KVMC-UH-8-UHD
2
Table of Contents
1.0 Introduction 3
2.0 Features 4
3.0 Installation 4
3.1 Sliding out the rear mounting brackets 4
3.2 Mount in 4-post Rack 5
4.0 Setup and Operation 5
4.1 Hotkey Sequences 7
5.0 Troubleshooting 7
6.0 Specifications 8
TRADEMARKS USED IN THIS MANUAL
Hall Research and its logo are trademarks of Hall Research. Any other trademarks
mentioned in this manual are acknowledged as the property of the trademark owners.
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
This device complies with part 15 Class A of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

8-Port KVM Switch Console with 4K HDMI LCD & USB 2.0
3
1.0 Introduction
The KVMC-UH-8-UHD is an 8-port HDMI KVM Switch Console in a 1U rack
drawer. The switch console features built-in LCD supporting Ultra-High
video resolutions such as 2560x1440, 2560x1600, and 3840x2160.
The switch provides keyboard and mouse emulation for all 8 PC inputs. It
does not matter if a PC is selected on the KVM Switch all the host PC's
“see” connection to a keyboard and a mouse. However, the data from the
“actual” built-in keyboard and mouse pad are only sent to the selected PC.
The KVM Switch also provides LCD emulation on all HDMI video inputs.
The HDMI outputs from all PCs get a HPD (hot plug detect) signal, as if
they were connected directly to an LCD. This reduces the video switching
times to 1~2 seconds. Since each PC always detects a monitor when
switching dual-video PCs, there is no interruption in the video since the
Operating System of the host PC is unaware of the KVM Switching.
The KVMC-UH-8-UHD also provides an integrated 2-port USB 2.0 Hub
with one port on the rear and one on the front. When you select a new PC
on the KVM, the USB 2.0 hub connects to the selected PC.
The console features 8 individual buttons for selecting inputs. LED
indicators show the currently selected input channel and the status of
each input. Inputs can also be selected via hot-key sequences from the
keyboard. The console provides self-locking rails and automatically locks
when the LCD panel is closed for simple and hassle free operation.

KVMC-UH-8-UHD
4
2.0 Features
 Enterprise grade performance
 Compact 1U drawer construction mountable in 19” rack
 Built-in LCD supports high resolutions such as 1920x1080,
1920x1200, 2560x1440, 2560x1600 and 3840x2160
 8 Individual buttons on the front panel for selecting PC inputs
 Emulates keyboard, mouse, and video monitor for each PC
 Fast-switch technology for minimal delay when switching PCs
 Provides USB 2.0 Hub that switches to the selected PC
 Computer OS independent - No driver or software required
 Durable 104-key keyboard and touch pad.
 Self-locking and auto release rails for ultra-convenience
 Hot-Key Switching
3.0 Installation
The KVM Switch Console is designed to mount in a standard 1U 19” 4-post
rack system. For installation in a two-post system, a special kit is
required; please contact Hall Research for more information.
3.1 Sliding out the rear mounting brackets
1. Remove the retaining screw from the rear mounting brackets
secured in channels on both sides of the console.
2. Slide and remove both brackets out towards the rear as shown.

8-Port KVM Switch Console with 4K HDMI LCD & USB 2.0
5
3.2 Mount in 4-post Rack
The Console must to be supported on all its four corners. Do not install the
rack using its front panel only. For installation in a two-post system, a
special kit is required.
1. Mount both brackets (separated from the console) to the inside
rear of a standard 1U rack system using user-supplied screws.
2. Take the console and gently slide it into the two rear-mounted
brackets in the rack and secure the console in place by inserting
user-supplied screws.
4.0 Setup and Operation
The figures below show the front and rear of the KVM Switch Console.
Cables are not included. For each input, you must provide one HDMI and
one USB cable.

KVMC-UH-8-UHD
6
Item Function
1 4K LCD Screen
2 LCD Controls: Use to turn LCD panel on and off or adjust image
3 Input selection panel with 8 push-buttons for selecting inputs,
and 8 LED indicators for input and selection status
Blinking = Current selection
Solid On = Input detected (or connected PC is on)
Off = No input detected (or connected PC is off)
4 Standard 104 keyboard with convenient number pad
5 Touchpad for mouse pointer operation. Note: There is a USB port
on the rear of the console for connecting an external mouse.
6 USB 2.0 Hub port. This USB port connects to the selected PC.
7 Power input connector and main power switch. Connect to AC
power (universal input accepts 100~240 VAC). The console has a
standard IEC320-C14 input connector. Customers are required to
provide their own AC input power cords. The Console consumes a
maximum of 30 watts of AC power. Power cords with rating of 6A
or above are recommended.
8 Keyboard and Mouse connector. For connection to an optional
external KM - normally not used.
9 USB 2.0 Hub port. This USB port connects to the selected PC.
10 HDMI and USB inputs for PC #1 to PC #8.

8-Port KVM Switch Console with 4K HDMI LCD & USB 2.0
7
4.1 Hotkey Sequences
 To select the different PC inputs, press the following key
sequence (1 represents the desired input channel)
 To start SCAN MODE press the following key sequence
Note: (1) You must complete the key sequence within 3 seconds.
(2) In SCAN mode, the switch automatically cycles through all
inputs one at a time. Each input is shown for 10 seconds. To stop
the scan mode, press any key.
5.0 Troubleshooting
If you are experiencing problems getting the switch to work properly,
please use the following troubleshooting suggestions.
 Make sure that all external connections are securely connected.
 Check the operation of all LEDs on the front panel.
 Disconnect power and all USB inputs and reconnect them
If you still are not able to get the system working properly, contact Hall
Research support via email or fill out the form on support page of
http://www.hallresearch.com.
Please give a detailed description of the issue and the troubleshooting
steps you have taken along with the serial number.
Do not open or try to repair the unit yourself, as this will void your
warranty.
To return the extender for repair, contact HR Support and obtain an RMA
(Return Material Authorization) number.

KVMC-UH-8-UHD
8
6.0 Specifications
Video
Standard
HDMI
Number of inputs
8
Bandwidth
6
00 MHz pixel clock or
18
Gbps video data rate
Max Resolution
3840 x 2160 @ 60Hz
Built
-
in LCD
Visible Size: 17.
4
" diagonal
Aspect Ratio: 16:9
Viewing Angle: Horizontal=140 Degrees / Vertical=120 Degrees
USB
Standard
Version 2.0
Connectors
8
x USB Type
B
Female for Hosts (PCs)
1x Keyboard Type A Female
1x Mouse Type A Female
2x USB 2.0 Peripherals from Built in Hub. Type A Female
General
Power Input
100
-
240V AC 50/60Hz via
standard
IEC
-
Type power
connector
Power
Consumption
5 watts in standby mode (or when display is off), 30 watts maximum
Temp/humidity
Operating: +32
~
+1
22
°F (0
~
+
5
0 °C) / 10%
~
90%, non
-
condensing
Storage: -4~+140 °F (-20~+60 °C) / 10%~90%, non-condensing
Cooling
Convection
Enclosure type
Metal
Dimensions
W x H x D
Device:
17.64
x
1.65
x
22.84 inch
(
448 x 42
x
580
mm)
Package/box: 28.15 x 5.51 x 30.71 inch (715 x 140 x 780 mm)
Weight
Device:
27
lbs (
12.
3
k
g)
Shipping: 38 lbs (17.2 kg)
Vibration
ISTA 1A in carton (International Safe Transit Association)
Safety
CE
EMI/EMC
CE, FCC Class A
MTBF
9
0,000 hours (Calculated Estimate)
Warranty
3
years parts and labor
Specifications are subject to change without notice

© Copyright 2020. Hall Research, Inc.
