Halo H2zero Troubleshooting guide

OWNERS MANUAL
& INSTALLATION GUIDE

HALO WATER SYSTEMS, LLC COPYRIGHT 2020 ALL RIGHTS RESERVED
H2 ZERO®Installation and Operation
ZERO ELECTRICITY • ZERO MAINTENANCE • ZERO WASTE
Whole House Filtration & Conditioning System
H2Z1054-CPI-100 H2Z1252-CPI-150
H2Z1054-CPSM-100 H2Z1252-CPSM-150
H 2 ZERO INTRODUCTION / INSTRUCTIONS BEFORE USING
1
Introduction
The HALO residential H2 ZERO®systems provide protection
from hardness related to scale formation throughout the
plumbing system. The H2 ZERO®system can be installed at
the point of entry to treat your entire home. These systems are
designed to treat the domestic water used in a single family
dwelling. For higher volume applications please contact your
HALO representative.
H2 ZERO®prevents scale by transforming the normal dissolved
hardness minerals into undissolved crystal microparticles.
These crystals stay suspended in the water and have a reduced
ability to react and attach to surfaces. Therefore, the problem
of internal buildup of scale in pipes, water heaters and plumbing
xtures is greatly reduced.
Unlike softened water, H2 ZERO®treated water maintains the
benecial essential mineral content of your water.
Read this Manual BEFORE using this equipment.
Failure to read and follow all safety and use information can result
in death, serious personal injury, property damage, or damage to
the equipment.
Keep this Manual for future reference.
The HALO H2 ZERO® system should be installed ONLY by a
licensed contractor.
FAILURE TO COMPLY WITH PROPER INSTALLATION AND
MAINTENANCE INSTRUCTIONS COULD RESULT IN PRODUCT
FAILURE WHICH CAN CAUSE PROPERTY DAMAGE,
PERSONAL INJURY AND/OR DEATH. HALO Water Systems, LLC
is not responsible for damages resulting from improper installation
and/or maintenance. Local building or plumbing codes may require
modications to the information provided. You are required to consult
the local building and plumbing codes prior to installation. If this
information is not consistent with local building or plumbing codes,
the local codes should be followed.
Refer to the enclosed for operating parameters to ensure proper use
with your water supply.
• Use only lead-free solder and ux for sweat-solder connections,
as required by state, province and federal codes.
• Handle all components of the system with care. Do not drop,
drag or turn components upside down.
• Be sure the oor under the system is clean, level and strong
enough to support the unit.
• Install the system in a protected area.
• Do not attempt to treat water over 100°F with the system.
• Always connect the system to the main water supply pipe before
the water heater.
• Do not expose the system to freezing temperatures. Water
freezing in the system causes equipment damage.
WARNING
WARNING

CK-V3007
1" PVC Male NPT Elbow
Assy.
(EDP#0002169)
H2 ZERO®Benefits
• Chemical free scale prevention. Provides cost savings and
environmental benefits
• Virtually maintenance free. No salt bags or other chemicals
to buy, transport and store
• No electricity, no wastewater, completely self-contained
• Beneficial minerals retained for more healthful drinking
water
• Improves the efficiency of water-using appliances
• Simple installation – no electrical and drain hookup
• Compatible with all on-site and community wastewater
treatment systems
• Not subject to water softener restrictions and “bans”
Tank Head
Media Tank
System Overview
CK-V3006
Bypass Assy.
(EDP#0002167)
Bypass Valve and Connection Fittings
Setup
Unpack and check the system components for damage or miss-
ing parts.
Installation Considerations
Consider the following points when determining where to install
the system:
• Do not install the system where it would block access to the
water heater, main water shutoff, water meter, or electrical
panels.
• Install the system in a place where water damage is least likely
to occur if a leak develops.
Figure 1.
H2 ZERO BENEFITS / SYSTEM OVERVIEW
2HALO WATER SYSTEMS, LLC COPYRIGHT 2020 ALL RIGHTS RESERVED
Setup
• Unpack and check the system components for damage or missing parts.
• Do not install the system where it would block access to the water heater, main water shutoff, water meter, or electrical panels.
• Install the system in a place where water damage is least likely to occur if a leak develops.
H2 ZERO® Benets
• ZERO maintenance required - no pre or post lter
• ZERO drain required
• ZERO waste, no backwash require
• Scale Prevention with ZERO chemicals
• No pre-soak required
• 10 year warranty on carbon media, 5 year warranty on scale media
• Exempt from “softener bans” or restrictions
• KDF55 media economic benet from longer lasting carbon
• NOT a softener
Bypass Valve and Connection Fittings
H-V3006
bypass assy.
H-V3007
bypass assy.
Head
Tank

SYSTEM SPECIFICATIONS / WARNING / NOTES
HALO WATER SYSTEMS, LLC COPYRIGHT 2020 ALL RIGHTS RESERVED
Equipment Specications
HALO Water Systems, H2 ZERO®systems are completely
loaded with media and ready to use. ZERO drain
necessary, ZERO maintenance & ZERO electricity required
H2 ZERO®media needs to be protected from excess levels
of certain metals that can easily coat the active surface,
reducing its effectiveness over time. If the water supply is
from a municipal supply or a private well, conrm that the
levels of iron (Fe) and manganese (Mn) are less than 0.3
mg/L and 0.05 mg/L, respectively.
Please have a comprehensive well water sample taken be-
fore installation to ensure proper functionality. DO NOT install
this system on a well without proper testing and recommen-
dations from the manufacturer. This will void the warranty
WARNING
New Copper lines need to be passivated for a minimum of
4 weeks before placing scale media into service. System
can run ltration only for 4 weeks before putting scale media
into service. For applications with copper concentration
greater than 1.3 ppm, please consult HALO Water Systems.
To further minimize any problem with excess copper, avoid
applying excessive ux on the inner surfaces of the pipe
and use a low corrosivity water soluble ux listed under the
ASTM B813 standard. This can be avoided by use of non-
copper pipes.
No hydrogen sulde can be present. Media will turn gray
and unit will no longer be effective.
System can run ltration only for 4 weeks before putting
scale media into service.
NOTICE: H2 ZERO® media does not reduce silica scaling.
While silica tends to have a less signicant effect on scale
formation than other minerals, it can act as a binder that
makes water spots and scale residue outside the plumbing
system difcult to remove. This 20 ppm limitation is for
aesthetic purposes.
Water known to have heavy loads of dirt and debris may
require pre-ltration (Sediment Filter SC510) prior to
H2 ZERO®.
Pressure ............ 15 psi to 90 (1.03 bar to 6.2 bar)
Temp. ............................................ 40º F to 100º F
Free Chlorine ............................................ <2ppm
pH............................................................... 6.5-8.5
Iron (maximum)........................................0.3 ppm
Manganese (maximum).........................0.05 ppm
Copper......................................................1.3 ppm
Maximum Hardness..................................35GPG
Feed Water Chemistry Requirements

H2 ZERO INSTALLATION AND START UP
•Shut off electrical power or gas valves supplying water heater(s).
Note to installer: Tank may be buried 2/3 under ground..
•Turn off the main water supply to the home and open an inside
faucet to relieve any pressure within the plumbing system.
• Place the bypass valve in the upow service position.
See bypass valve modication detail pictured left.
•Connect the cold water supply to the inlet of the H2 ZERO®
system. NOTE: The H2 ZERO® system operates in the upow
mode which is opposite of a traditional ltration / softener.
See Bypass Valve Modication below.
• Connect a hose to the outlet for the purpose of draining excess carbon.
•Turn the water back on to the house. Slowly open the supply
valve to the H2 ZERO® system. Allow the tank to ll with water.
Repeat these steps three times*
Carbon tank must be ushed individually. Do not attempt to ush
the carbon tank while it is connected to tank 2.
•Backwash tank 1 for 20 minutes in the upow service position.
•Backwash in the downow service position for 10 minutes.
•Close the valve to the outlet hose drain and let system stand
pressurized for 10 minutes.
*If time permits you can soak the system for 48 hrs instead of ushing.
•Connect the outlet of the H2 ZERO® system to the cold water
supply to the house.
•Open the supply valve to the H2 ZERO® system.
•Open hot and cold faucets downstream from the H2 ZERO®
system to relieve any air from the plumbing system and water
heaters. Introduce the water inside the H2 ZERO® to home, ush
for 5 minutes. System is now installed and ready for use.
Close the faucets.
As shipped, the bypass is set-up for downow use. The arrow
shape of the handles points in the wrong direction for UP-ow
use. To convert it to upow use, pull up on the red handles
until they come off. Rotate the handle 180° and put it back
on the valve stem.
Bypass Valve Modication
Installation and Start-up
1. Turn off water heater(s).
2. Turn off the main water supply to the home and open an
inside faucet to relieve any pressure within the plumbing sys-
tem.
3. Place the system in the desired location. Make sure that the
location is level and sturdy enough to support the weight of
the wetted system.
4. Place the bypass valve in the up flow service position. See
below Bypass Valve Modification Detail.
5. Connect the cold water supply to the inlet of the H2 ZERO®
system. NOTE: The H2 ZERO®system operates in the
UP-flow mode which is opposite of a conventional softener.
Follow the plumbing diagram in Figure 3.
6. Install a supply valve (user supplied) in the supply line and
close it.
7. Place a bucket under the outlet port or run a line from the
outlet port to a drain.
8. Turn the water back on to the house. Slowly open the sup-
ply valve to the H2 ZERO®system. Allow the tank to fill with
water. Close the supply valve when a steady stream of water
comes out of the outlet port. If the outlet is flowing into a
bucket, water could splash on nearby objects. If this
threatens the safety, value, structure, or appearance of these
objects, protect/remove them or use the outlet hose to drain
option.
9. Close the inside faucet.
10. Connect the outlet of the H2 ZERO®system to the cold
water supply to the house.
11. Open the supply valve to the H2 ZERO®system.
12. Open hot and cold faucets downstream from the H2 ZERO®
system to relieve any air from the plumbing system and
water heaters. Then close the faucets.
13. Check for leaks. Repair as needed.
14. The system is now ready for service.
IN
Cold Water
OUT
H2 ZERO®Treated Water
Figure 3.
shown with bypass as-sembly.
Service Position
down-flow tank. As shipped, the bypass is set-up for down-
flow use. The arrow shape of the handles
points in the wrong direction for UP-flow
use. To convert it to UP-flow use, pull up on
the red handles until they come off. Rotate
the handle 180° and put it back on the valve
stem.
Service Position
UP-flow tank.
Bypass Position
UP-flow tank.
Bypass Valve Modification
INCORRECT Service Position
THIS MUST BE CHANGED TO
UPFLOW POSITION BELOW.
Installation and Start-up Tank 1
H2 ZERO
®
TANK 1 Carbon
OUTLET TO HOME
H2 ZERO®
Filtered &
Conditioned Water
INLET/MAIN
Cold Water
INLET/OUTLET TO TANK 2
H2 ZERO®
Carbon Filtered Water
H2 ZERO
®
TANK 2 Conditioning*
* TANK 2 Available in two options
Option 1: HALO ION in-line conditioner
Option 2: HALO Proprietary scale media
Installation and Start-up Tank 2
Set up for tank 2 is the same for both ION and Scale Media
Service Position
UPow tank.
Installation and Start-up
1. Turn off water heater(s).
2. Turn off the main water supply to the home and open an
inside faucet to relieve any pressure within the plumbing sys-
tem.
3. Place the system in the desired location. Make sure that the
location is level and sturdy enough to support the weight of
the wetted system.
4. Place the bypass valve in the up flow service position. See
below Bypass Valve Modification Detail.
5. Connect the cold water supply to the inlet of the H2 ZERO®
system. NOTE: The H2 ZERO®system operates in the
UP-flow mode which is opposite of a conventional softener.
Follow the plumbing diagram in Figure 3.
6. Install a supply valve (user supplied) in the supply line and
close it.
7. Place a bucket under the outlet port or run a line from the
outlet port to a drain.
8. Turn the water back on to the house. Slowly open the sup-
ply valve to the H2 ZERO®system. Allow the tank to fill with
water. Close the supply valve when a steady stream of water
comes out of the outlet port. If the outlet is flowing into a
bucket, water could splash on nearby objects. If this
threatens the safety, value, structure, or appearance of these
objects, protect/remove them or use the outlet hose to drain
option.
9. Close the inside faucet.
10. Connect the outlet of the H2 ZERO®system to the cold
water supply to the house.
11. Open the supply valve to the H2 ZERO®system.
12. Open hot and cold faucets downstream from the H2 ZERO®
system to relieve any air from the plumbing system and
water heaters. Then close the faucets.
13. Check for leaks. Repair as needed.
14. The system is now ready for service.
IN
Cold Water
OUT
H2 ZERO®Treated Water
Figure 3.
shown with bypass as-sembly.
Service Position
down-flow tank. As shipped, the bypass is set-up for down-
flow use. The arrow shape of the handles
points in the wrong direction for UP-flow
use. To convert it to UP-flow use, pull up on
the red handles until they come off. Rotate
the handle 180° and put it back on the valve
stem.
Service Position
UP-flow tank.
Bypass Position
UP-flow tank.
Bypass Valve Modification
Bypass Position
UPow tank.
Installation and Start-up
1. Turn off water heater(s).
2. Turn off the main water supply to the home and open an
inside faucet to relieve any pressure within the plumbing sys-
tem.
3. Place the system in the desired location. Make sure that the
location is level and sturdy enough to support the weight of
the wetted system.
4. Place the bypass valve in the up flow service position. See
below Bypass Valve Modification Detail.
5. Connect the cold water supply to the inlet of the H2 ZERO®
system. NOTE: The H2 ZERO®system operates in the
UP-flow mode which is opposite of a conventional softener.
Follow the plumbing diagram in Figure 3.
6. Install a supply valve (user supplied) in the supply line and
close it.
7. Place a bucket under the outlet port or run a line from the
outlet port to a drain.
8. Turn the water back on to the house. Slowly open the sup-
ply valve to the H2 ZERO®system. Allow the tank to fill with
water. Close the supply valve when a steady stream of water
comes out of the outlet port. If the outlet is flowing into a
bucket, water could splash on nearby objects. If this
threatens the safety, value, structure, or appearance of these
objects, protect/remove them or use the outlet hose to drain
option.
9. Close the inside faucet.
10. Connect the outlet of the H2 ZERO®system to the cold
water supply to the house.
11. Open the supply valve to the H2 ZERO®system.
12. Open hot and cold faucets downstream from the H2 ZERO®
system to relieve any air from the plumbing system and
water heaters. Then close the faucets.
13. Check for leaks. Repair as needed.
14. The system is now ready for service.
IN
Cold Water
OUT
H2 ZERO®Treated Water
Figure 3.
shown with bypass as-sembly.
Service Position
down-flow tank. As shipped, the bypass is set-up for down-
flow use. The arrow shape of the handles
points in the wrong direction for UP-flow
use. To convert it to UP-flow use, pull up on
the red handles until they come off. Rotate
the handle 180° and put it back on the valve
stem.
Service Position
UP-flow tank.
Bypass Position
UP-flow tank.
Bypass Valve Modification

NOTE TO HOME OWNER
5
HALO WATER SYSTEMS, LLC COPYRIGHT 2020 ALL RIGHTS RESERVED
Conditioning - What to Expect & Best Practices
SPOTTING
•Spotting is normal
Remember, the beneficial minerals have been conditioned and left in your water. These conditioned
minerals will be easier to wipe up than unconditioned minerals, however if water is left to evaporate
continuously on hard surfaces, scale will begin to form. The solution is to not allow water to
evaporate on hard surfaces.
•Glass shower doors
Years of scale formations on glass doors can etch the surface of the glass and cause soap and
minerals to stick in those fissures. Using RainX® or a similar product in addition to a squeegee on
shower doors can seal pores on the glass surface causing water to sheet. This greatly reduces spots
and scale formation.
•Dishwasher
In leaving the beneficial minerals in your water this may cause some occasional spotting on dishes
and glassware. We recommend using Lemi-Shine© liquid rinse aid. This is an all natural product
and will not leave any chemical residue behind.
•Toilets
HALO Water is highly filtered to remove chemicals and disinfectants. When exposed the open
atmosphere of a toilet bowl the water can grow mildew and bacterial. This is especially true with
low flow toilets that do not fully flush away deposits and toilets that are unused for extended
periods of time. Use a product such as CLR to remove deposits. Flush ‘n Sparkle® is a
recommended to introduct chlorine to ONLY the toilet bowl without the chlorine eecting the toilet
gaskets, flapper or other components.
HARDNESS
•Total Dissolved Solids
TDS is the measurement of all dissolved solids in your water, including but not limited
to minerals The conditioning process alters the scale forming minerals so they are no
longer aggressive or harmful, but hardness tests cannot determine the dierence
between conditioned minerals and raw minerals and are ineective in determining the
performance of the HALO conditioning system. The TDS may increase slightly during
the descaling process.
•Boiling or Vaporizing Water
When boiling or vaporizing conditioned water and you may see white deposits form
on the bottom of the pan or appliance. This is a normal reaction between conditioned
minerals and extreme heat. If this causes a problem for humidifier or vaporizer use
distilled water or contact the manufacturer for more information.
•Slippery Water
The HALO Conditioning System uses no sodium or potassium. This is why you will not
experience that slimy, slippery feeling on your skin and hair. The slippery feeling is caused
by chemical additives. Instead the HALO Conditioning System provides you
with bottled water quality water.
HALO Water Systems • 2075 Corte Del Nogal, Suite S, Carlsbad, CA 92011 • 800-591-0538
HALO WATER SYSTEMS, LLC COPYRIGHT© 2021 ALL RIGHTS RESERVED

5 YEAR WARRANTY
HALO WATER SYSTEMS, LLC COPYRIGHT 2020 ALL RIGHTS RESERVED
TEN YEAR, LIMITED LIFETIME WARRANTY
1. HALO will provide one replacement tank for any tank that fails due to a manufacturing defect.
2. HALO warrants that components for the equipment will be available for the lifetime of the system.
3. HALO will provide comparable components of our selection to replace any obsolete items.
4. HALO will, within 10 years from date of install repair or replace warranted defective control valve
parts at no charge.
5. HALO will provide replacement carbon media at no charge (except freight and handling) for 10
years from the date of installation due to media failure.
CONDITIONS OF WARRANTY
1. The system must be installed and maintained according to local codes and secondarily in accor
dance with manufacturer’s recommendations.
2. The system must be maintained with HALO approved replacement components.
3. Failures resulting from re, freezing, neglect, accident, alteration, abuse, improper installation or
acts of nature are not covered.
4. Water pressure must be regulated between 40 to 80 pounds per square inch working or static pressure.
Pressure exceeding 80 pounds per square inch (psi) working or static pressure voids all warranty.
5. Pressures exceeding 120 pounds per square inch in excess of 5”HG (17 Pa) voids warranty on tank.
6. Internal water temperature exceeding 100°F voids warranty.
7. Inuent chlorine must not exceed 1 mg/L.
8. HALO does not warrant to perform, pay for, or nance any repairs and/or installations. The
customer must contact the HALO representative and provide pictures of installation, serial and model
number prior to any repairs or replacements.
OBTAINING WARRANTY SERVICE
All returns must be accompanied by a “Return Merchandise Authorization” (RMA) form, the defective
part(s), and original purchase receipt. HALO will, at our option, repair or provide replacement parts at no
cost. HALO warranty does not include freight, handling, or on-site labor charges. HALO does not provide
on-site service. You can contact HALO at [phone].
LIMITATIONS AND EXCLUSIONS
This warranty is exclusive and in lieu of any other warranty expressed or implied, including but not not
limited to, any implied warranty of merchantability of tness for a particular purpose. HALO shall not be
liable for any loss or incidental or consequential damages resulting from the misuse or inability to use
equipment by the buyer or any user.
