Ham RemoteAC User manual

2 years warranty
1
2
Internet connection via Wi-Fi
2.4Ghz
Control your Air-Conditioner via
the Internet
Android, iOS, Voice control with
popular assistants
Setup Button
microUSB power
Status LED (green)
Disconnected LED (blue)
Temperature and
Humidity sensor
1.
2.
3.
4.
5.
RemoteAC
TROUBLESHOOTING
The Status LED (green) is not
lit and the device is shown as
disconnected on the app
This means that the device is not
connected to the Cloud
Make sure that the device gets power
Check your Internet connection. If
you cannot access the Internet with a
different device on the same Wi-Fi
network check your router or with your
ISP
Check that the server is accessible at
https://hamsystems.eu with your
browser. If it is not, check again in 5
minutes or refresh the app / webpage
Try restarting the device by
disconnecting and reconnecting
power. Wait for a few minutes
Check if the device is connected to
your Wi-Fi router / Access
Point. If the device does not appear
to be connected, then repeat the setup
procedure and make sure that the Wi-
Fi name and password are correct. The
device may also need to be whitelisted
depending on your network
configuration. Note that the device and
the app use the ports 9001 and 9002
3
Temperature and
Humidity real-time and
historical readings
Time schedules
The Air-Conditioner does not
respond to commands
Make sure that the device is powered
Make sure that your AC is in range of
the device's infrared signals
Make sure that the device is connected
to the cloud. The Status LED should be
fully on.
Make sure you have setup the correct
codeset from the device settings
Check that your air-conditioner has
power, by using the original remote
control.
5
14
This product is in compliance with the
Radio Equipment Directive (RED)
2014/53/EU and the Restriction of
Hazardous Substances (RoHS)
Directive 2011/65/EU and carries the
CE Mark. The complete EU declaration
of conformity can be found at
https://hamsystems.eu/res/doc/remote
ac_ce.pdf
76, 28th October, 54642, Thessaloniki, Greece
Manufacturer: Home Automation and More P.C.
More information about the installation
of our devices, their capabilities and the
use of our platform can be found at
https://hamsystems.tawk.help/
4

SETUP
Connect the device to power via microUSB.
Open the HAM Systems app. If you don't have an account create one
Click on (+) button on the devices list view on the app
Follow the instructions on the app
If the Status LED is fully on and the device does not appear on the app, then you may
also need claim the device to your account. Click on (+) and select the Claim
Device option
Click on the device on the list and select More
Scroll down to device settings and select your AC brand. If you can't find your
brand, you can try the "Others" option at the bottom.
Find a codeset that works for your AC and click OK
You should now be able to control your AC on the app
1.
2.
3.
4.
5.
6.
7.
8.
9.
In order to connect the device to your Wi-Fi network, you need to use the HAM Systems app.
All the other features are also available on the Web on https://hamsystems.eu
If you want to change the Wi-Fi network of your device, you can do
so by doing the steps 3-5 . You don't have to re-claim your device in this case
SAFETY WARNINGS
USAGE
TECHNICAL SPECIFICATIONS
In case you are having difficulties, you can try restarting the device by
disconnecting are re-connecting power and repeating the steps.
Do not disassemble the device. Doing so, voids the warranty.
In case of loss of network, you will not be able to control the device remotely.
You should not rely on the device in such a way that puts human or animal
lives at risk.
To use the device, visit our webapp at https://hamsystems.eu
or search HAM Systems at the App Store / Play Store
Control your Air-Conditioner from anywhere in the world via the Internet
Set up time based schedules and timers
View real time and historical output state
Create interactions between other HAM Systems devices by using IF this
THEN that style rules
Secured communications with TLS
Organize your devices with groups and floorplans
Some features of the app:
Enviromental conditions
Output
Dimensions
Connectivity
-10°C to 55°C, 0-90% RH
IR
50.9mm x 50.9mm x 16.5mm
Wi-Fi IEEE 802.11 b/g/n 2.4Ghz
Input 5VDC, 1.5A from microUSB
Measurements Temperature / Relative Humidity
Accuracy ±1 °C, ±5% RH
