Hamilton Beach Professional 70825-SAU User manual

Dicing Food Processor

English – Original Translation........... 2
Arabic .............................................. 25
840288900 9/17
Hamilton Beach Brands, Inc.
4421 Waterfront Drive
Glen Allen, VA 23060 USA
CAUTION: READ
OPERATOR’S MANUAL
BEFORE USE
Visit www.hamiltonbeach-me
.com for our complete line of
products and Use and Care
Guides – as well as delicious
recipes and tips!

2
1. Read all instructions.
2. This appliance is not intended for use by persons
with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge,
unless they are closely supervised and instructed
concerning the use of the appliance by a person
responsible for their safety.
3. This appliance should not be used by children.
Keep the appliance and its cord out of reach
of children. Children should be supervised to
ensure that they do not play with the appliance.
4. To protect against risk of electrical shock, do
not immerse base, motor, cord, or plug in water
or other liquid.
5. Unplug cord from socket when not in use,
before putting on or taking off parts, and before
cleaning.
6. Avoid contacting moving parts.
7. Do not operate any appliance with a damaged
supply cord or plug, or after the appliance
malfunctions or has been dropped or damaged
in any manner. Supply cord replacement and
repairs must be conducted by the manufacturer,
its service agent, or similarly qualified persons
in order to avoid a hazard. Call the provided
customer service number for information on
examination, repair, or adjustment.
8. The use of attachments not recommended or
sold by the appliance manufacturer may cause
fire, electric shock, or injury.
9. Do not use your food processor if any part is
broken.
10. Do not use appliance outdoors.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of
fire, electric shock, and/or injury to persons, including the following:

3
11. Do not let cord hang over edge of table or
counter, or touch hot surfaces.
12. Keep hands and utensils away from moving
blade and disc while processing food to
reduce the risk of severe personal injury and/
or damage to the food processor. Arubber
scraper may be used but ONLY when the food
processor is not running.
13. The blades and discs are sharp. Handle
carefully during assembly, when emptying the
bowl, and during cleaning. Store out of reach
of children.
14. To reduce the risk of injury, never place cutting
blade or disc on base without first putting work
bowl properly in place.
15. Be certain lid is securely locked in place before
operating appliance.
16. Never feed food into food chute by hand.
Always use the food pushers.
17. Do not attempt to defeat the lid interlock
mechanism.
18. Make sure the blade or disc has come to a full
stop before removing lid.
19. To reduce the risk of injury, be sure to insert
or remove blade and disc using hubs provided
for this purpose. Use caution when removing
blade and disc from the work bowl, when
emptying the work bowl, and when cleaning.
20.Check that controls are clear of objects and
hands before plugging cord into wall outlet. To
disconnect, press “STOP” ( ); then remove
plug from wall socket.
21.Always use the pushers to clear the food chute.
When this method is not possible, unplug cord
from outlet and disassemble unit to remove the
remaining food.
22.The appliance is not intended for commercial,
professional, or industrial use. It is designed and
built exclusively for household use only.

4
23. Never use appliance for a longer period or with
a larger amount of ingredients other than that
recommended by appliance manufacturer.
24. Be careful if hot liquid is poured into the
food processor as it can be ejected out of the
appliance due to a sudden steaming.
25. The maximum rating of this unit is based on
using the chopping/mixing blade. Using the
slicing/shredding disc may draw significantly
less power.
26. Do not place on or near a hot gas or electric
burner or in a heated oven.
27. Do not use appliance for other than intended
purpose.
28. CAUTION! In order to avoid a hazard
due to inadvertent resetting of the thermal cut-
out, this appliance must not be supplied through
an external switching device, such as a timer, or
connected to a circuit that is regularly switched
on and off by the utility.
29. Your plug is provided with a 13-amp fuse
approved by ASTA to B.S. 1362. If you
need a replacement fuse carrier, it must be
replaced with the same colour-coded carrier with
the same markings. Fuse covers and carriers
can be obtained from approved service agents.
30. The appliance normal operating cycle is a
maximum 2-minute high-speed operation
followed by a 1-minute off period.
SAVE THESE INSTRUCTIONS

5
Other Consumer Safety Information
This appliance is intended for household use only.
wWARNING Electrical Shock Hazard: This appliance is
provided with a grounded (3-prong) plug to reduce the risk
of electric shock. The plug fits only one way into a grounded
outlet. Do not defeat the safety purpose of the plug by
modifying the plug in any way or by using an adapter. If the
plug does not fit into the outlet, have an electrician replace the
outlet.
The length of the cord used on this appliance was selected
to reduce the hazards of becoming tangled in or tripping
over a longer cord. If a longer cord is necessary, an approved
extension cord may be used. The electrical rating of the
extension cord must be equal to or greater than the rating of
the appliance. The extension cord must be a grounding-type,
3-wire cord. Care must be taken to arrange the extension cord
so that it will not drape over the countertop or tabletop where
it can be pulled on by children or accidentally tripped over.
To avoid an electrical circuit overload, do not use another high-
wattage appliance on the same circuit with this appliance.
This machine is equipped with motor overload protection. If
the motor stops during operation due to overheating, unplug
and allow it to cool down for 15 minutes. Plug machine back in
after 15 minutes to resume normal operation.
Recycling the Product at the End of Its Service Life
The wheeled bin symbol marked on this appliance signifies that it
must be taken over by a selective collection system conforming to the
WEEE Directive so that it can be either recycled or dismantled in order
to reduce any impact on the environment. The user is responsible for
returning the product to the appropriate collection facility, as specified
by your local code. For additional information regarding applicable local
laws, please contact the municipal facility and/or local distributor.

6
Parts and Features
Removable
Lid Seal
Large Food
Pusher
Medium
Food Pusher
Small Food
Pusher
Food Chute
BEFORE FIRST USE: Unpack processor and remove protective
covers from the blades and discs to prevent damage and
scratches to work bowl. Note that the removable dicing grid
will fall out of the dicing disc when turned upside down. Handle
blades and discs carefully; they are very sharp. Wash all parts
except base in hot, soapy water. Rinse; then dry.
Pour Spout Work Bowl
Locking Arm
Base Control
Panel
MAX Fill Line
Dicing Cleaning Tool
Motor Shaft
Lid
Model 70825-SAU
Type: FP28
Ratings:
220–240 V~ 50–60 Hz 600 W

7
Dicing Disc With
Removable Grid
Adjustable Slicing
Disc (1)
Use to slice carrots,
cucumbers, potatoes,
pepperoni, onions,
peppers, tomatoes,
and chilled cheeses.
Dough Blade (4)
Use to mix bread, pizza,
cookie doughs, and
dumpling dough.
Storage Case, Parts, and Control Panel
Chopping/Mixing Blade (5)
Use to coarsely chop, grate,
mince, mix, or puree food.
Storage Case
and Parts
Control Panel
Dicing Assembly (3)
Shredding Disc (2)
Use to shred a variety of
foods such as chilled
cheese, carrots,
cabbage, and potatoes.
Use to make 1/2-inch
(12-mm) cubes of potatoes,
tomatoes, beets, onions,
peppers, carrots and apples.
Adjustment Post
Shredding
Disc
Dough
Blade
Chopping/
Mixing
Blade
Adjustable
Slicing Disc
Dicing
Cleaning
Tool
Cutting Disc
Store dicing assembly
in work bowl.
NOTE: The cutting disc and
dicing disc must always
be used together as one
assembly.
If the lights on the control panel are flashing, then the food processor is
not yet assembled correctly. Either the locking arm is not in place or the
large food pusher is missing. When all parts are properly installed, the
control panel lights will be lit continuously. The unit is ready to operate.
The control lights on the product will shut off automatically after
3 minutes of inactivity. Press any button to reactivate controls.

8
How to Use Dicing Assembly
7
1
Place large food pusher in
food chute. Add food and use
medium or small food pushers
for dicing.
NOTE: Unit will not work unless
locking arm is snapped into place
on bowl and large food pusher is
inserted.
wWARNING
Laceration Hazard.
Handle blades carefully; they are very sharp.
Press STOP () and unplug before inserting
or removing blades.
4
5
Secure four latches of the dicing
disc into place.
Place lid on bowl so the chute
lines up with the handle.
2
To insert the dicing assembly, lower the dicing disc onto the motor
shaft, making sure the removable grid is next to the handle. Then lower
the cutting disc onto the motor shaft until it sits flush to the dicing disc.
TIP: When using the feed chute to dice, slice, or shred, make sure no
other blades are in the bottom of the work bowl.
Place work bowl on base with
handle facing forward.
3
6
Raise locking arm up and over
bowl and snap into place.

9
How to Use Dicing Assembly (cont.)
15
1110
When finished, press STOP ( )
and unplug. Push locking arm back
to unsnap and lower onto counter.
Remove lid from bowl.
8
Press button. For best results use medium or small pusher.
wWARNING Laceration Hazard.
Always use food pusher to feed food
into the chute. Never push food through chute with hands or other objects.
Never remove locking arm during operation.
13
Use cleaning tool to press food
from dicing grid into bowl.
NOTE: Dicing parts are color-coded
green to remind you to use the
medium pusher when dicing and the
green cleaning tool to clean out the grid.
9
12
Unlatch four metal clips. Carefully
remove cutting disc.
14
Remove dicing disc from motor
shaft by grabbing metal clips. NOTE:
If cutting disc stops
working during operation, press ( )
button to continue operation.

10
How to Use
Adjustable Slicing Disc
21
Place work bowl on base with handle facing forward. Adjust disc
to desired thickness by turning the adjustment post. There are 14
adjustment positions, ranging from 1/32” to 1/4” (0.8 to 6 mm) thickness.
wWARNING
Laceration Hazard.
Handle disc carefully; it is very sharp. Press STOP ( ) and
unplug before inserting or removing blades.
4
Carefully place disc onto motor shaft. Place lid on work bowl.
TIP: Check to make sure no other blades are in the bottom of the
work bowl.
6
NOTE: Unit will not work unless the large food pusher is inserted and
the locking arm is snapped into place on the bowl.
7
For smaller, thinner foods: Put
large food pusher into place. Place
food into smaller open tube and
use small food pusher to push
in food. For larger foods: Keep
large, medium, and small pushers
together. NOTE: Unit will not
operate until large food pusher
engages the protective interlock.
Do not add food above the MAX
fill line.
5
Raise locking arm up and over
bowl and snap into place.
3

11
How to Use Adjustable Slicing Disc (cont.)
Press button. NOTE: If the large pusher is removed, the last setting
will be remembered. This setting will blink. To start slicing again,
simply insert the large pusher.
wWARNING Laceration Hazard. Always use food pusher to feed
food into the chute. Never push food through chute with hands or
other objects. Never remove locking arm during operation.
10
When finished, press STOP ( )
and unplug. Push locking arm back
to unsnap and lower onto counter.
12 13
Carefully remove disc from motor shaft using the finger holes.
14
119
Remove lid.
8

12
How to Use Shredding Disc
For larger foods: Keep large,
medium, and small pushers
together. NOTE: Unit will not
operate until large food pusher
engages the protective interlock.
Do not add food above the MAX
fill line.
wWARNING Laceration Hazard.
Always use food pusher to feed
food into the chute. Never push
food through chute with hands
or other objects. Never remove
locking arm during operation.
4
4
wWARNING
Laceration Hazard.
Handle disc carefully; it is very sharp. Press STOP
() and unplug before inserting or removing blades.
2
Place work bowl on base with
handle facing forward.
3
Carefully place disc onto motor shaft. Place lid on work bowl so the
chute lines up with the handle. Raise locking arm up and over bowl
and snap into place. TIP: Check to make sure no other blades are in
the bottom of the work bowl.
55
For smaller, thinner foods: Put large food pusher into place. Place food into smaller open tube and use
small food pusher to push in food. NOTE: Soft cheese like mozzarella should be placed in the freezer for
30 minutes prior to processing to ensure it is firm enough for shredding.
OR

13
How to Use Shredding Disc (cont.)
98
When finished, press STOP ( )
and unplug.
7
Push locking arm back to unsnap
and lower onto counter.
12
Carefully remove blade from
motor shaft using finger holes.
11
6
Press button.
1310
Remove lid.

14
How to Use Chopping/Mixing Blade
Place food pushers in food
chute. Unit will not operate until
large food pusher engages the
protective interlock. Do not add
food above the MAX fill line.
wWARNING Laceration Hazard.
Always use food pusher to feed
food into the chute. Never push
food through chute with hands
or other objects. Never remove
locking arm during operation.
7
4
Place lid on work bowl so the
chute lines up with the handle.
wWARNING
Laceration Hazard.
Handle blade carefully; it is very
sharp. Press STOP ( ) and unplug
before inserting or removing blades.
2
1
Place work bowl on base with
handle facing forward. Carefully slide blade straight down onto the motor shaft.
NOTE: Operate using only one
blade or disc at a time.
3
Place food to be chopped/mixed
in bowl.
65
Raise locking arm up and over bowl and snap into place. NOTE: Unit
will not work unless locking arm is snapped into place on bowl and
large food pusher is inserted.

15
How to Use Chopping/Mixing Blade (cont.)
11
10
13
When finished, press STOP ( )
and unplug.
9
Press , or for more control
use the button.
Carefully remove blade from
motor shaft.
Push locking arm back to unsnap
and lower onto counter.
12
8
If the lights on the control panel
are flashing, then the food
processor is not assembled
correctly. Either the locking arm
is not in place or the large food
pusher is missing. When all parts
are properly installed, the control
panel lights will be lit continuously.
The unit is ready to operate.
14
Remove lid.

16
How to Use Dough Blade
NOTE: Unit will not operate until
large food pusher engages the
protective interlock. Do not add
food above the MAX fill line.
wWARNING Laceration Hazard.
Always use food pusher to feed
food into the chute. Never push
food through chute with hands
or other objects. Never remove
locking arm during operation.
7
4
Place lid on work bowl so the
chute lines up with the handle.
2
Place work bowl on base with
handle facing forward. Carefully slide blade straight down onto the motor shaft.
NOTE: Operate using only one
blade or disc at a time.
3
65
Raise locking arm up and over
bowl and snap into place.
1
Place food pushers in food chute.

17
How to Use Dough Blade (cont.)
11
10
14
When finished, press STOP ( )
and unplug.
9
Press button and process
following your recipe.
Carefully remove blade from
motor shaft.
Push locking arm back to unsnap
and lower onto counter.
13
8
If the lights on the control panel
are flashing, then the food
processor is not assembled
correctly. Either the locking arm
is not in place or the large food
pusher is missing. When all parts
are properly installed, the control
panel lights will be lit continuously.
The unit is ready to operate.
12
Remove lid.

18
Tips and Techniques
• For a more uniform consistency,
start with pieces of food that
are similar in size. Cut food
into 1-inch (2.5-cm) pieces
before processing with
chopping/mixing blade and
leave room in work bowl for
the food to be tossed around.
• This food processor is
excellent to chop, dice, mix,
slice, or shred most foods.
However, to maintain peak
performance, do not use
your food processor for the
following: grinding coffee
beans or spices, slicing frozen
meats, or crushing ice.
• When chopping foods, pulsing
on and off will produce the
best results.
• Operating time will depend
on quantity of food being
processed. Most foods can
be sliced, diced, chopped,
or shredded in seconds. The
appliance normal operating
cycle is a maximum 2-minute
high-speed operation followed
by a 1-minute off period.
• Do not puree or mash starchy
vegetables like potatoes as
they are easily overprocessed
and will become gummy.
• To slice or shred cheese, use
only firm cheese like Cheddar
or Swiss that has been chilled
for at least 30 minutes.
Cheese should be processed
immediately after being
removed from the refrigerator.
Soft cheese like mozzarella
should be placed in the
freezer for 30 minutes prior to
processing to ensure it is firm
enough for shredding.
• The adjustable slicing disc can
slice foods as thin as 1/32 inch
(0.8 mm) and as thick as
1/4 inch (6 mm).
Processing Charts
When using attachments, do not process past the MAX LEVEL on the
work bowl.
ATTACHMENT FOODS
(5) Chop: nuts, meat, garlic, onions,
peppers, celery, herbs, bread (for
crumbs), crackers
Mince/Puree: vegetables, fruit
Mix: salad dressings
Puree: soups, sauces
Grate: cheese, such as Parmesan
(chilled)
(1) Cucumbers, apples, mushrooms,
carrots, potatoes, cabbage, tomatoes,
pepperoni, peppers, radishes, firm
cheeses (chilled)
(2) Cabbage, potatoes, carrots, cheese
(chilled)
(3) Potatoes, tomatoes, onions, peppers,
beets, carrots, cucumbers, and apples

19
Care and Cleaning
Wipe base, control panel, and
cord with a damp cloth or
sponge. If necessary, use a mild
nonabrasive cleanser.
NOTE: If food particles get trapped in the back of the food chute,
place openings on sides of enclosure under running water to rinse
out pieces before putting in the dishwasher.
DO NOT use the “SANI” setting
when washing in the dishwasher.
“SANI” cycle temperatures
could damage your product.
All removable parts may also
be cleaned in the sink with hot,
soapy water. Use caution when
washing blades and discs.
2 3
DISHWASHER-SAFE
1
wWARNING Electrical Shock Hazard.
Disconnect power before cleaning. Do not immerse cord, plug, or
base in water or any other liquid.
wWARNING Laceration Hazard.
Handle blades and discs carefully; they are very sharp.
4

20
BLADE TYPE RECOMMENDED FOOD
RECOMMENDED
PROCESSING TIME RECOMMENDED AMOUNT
(4) Bread dough 1 1/2–2 minutes 3 cups (375 g) bread flour, 2 tablespoons (30 ml) oil, 1 cup (237 ml)
water, 1 pkg (21 g) yeast
Pizza dough 1 1/2–2 minutes 3 cups (360 g) all-purpose flour, 1 tsp (5 ml) sugar, 2 tablespoons
(30 ml) oil, 1 cup (237 ml) water, 1 pkg (21 g) yeast, 1 tsp (5 ml) salt
(5) Chickpeas/hummus 1 1/2–2 minutes One 15-ounce (425-g) can
Grains for flour 1 1/2–2 minutes 1 cup (200 g)
Nuts (chopped) 20–25 seconds 250 g
Onions 5 pulses (10–15 seconds) One 3- to 4-inch diameter onion, approx. 200 g
Parmesan cheese 60–75 seconds 140 g
Parsley or cilantro 10 pulses (20–30 seconds) 20 g
Pesto 1–2 minutes 4 cups (210 g) basil, 1 cup (140 g) pine nuts, 4 garlic cloves, 1 cup
(237 ml) olive oil, 1 cup (110 g) grated parmesan cheese, 1 tsp
(5 ml) salt
Pie crust or biscuit dough 45–60 seconds 3 cups (375 g) all-purpose flour, 1 tsp (5 ml) salt, 1 cup (237 ml)
butter, 1/4 cup (59 ml) water
Pureed soup 1–2 minutes 4 cups (946 ml)
Processing Times
NOTE: For all blade types, do not exceed 2 minutes per processing cycle. Allow appliance to cool for 1 minute between each cycle.
