EN Food Processor
STM 3770 WH / STM 3771GR / STM 3772BL
STM 3773OR / STM 3774RD / STM 3775 VT
STM 3776 YL / STM 3777 TQ / STM 3778RS

04/2017
- 2 -
Copyright © 2017, Fast ČR, a.s.
EN Food Processor
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
■This appliance may be used by persons with physical or mental impairments or
by inexperienced persons, if they are properly supervised or have been informed
about how to use the product in a safe manner and understand the potential
dangers.
■Children must not use this appliance or play with it. Keep this appliance and the
power cord out of reach of children.
■Before connecting this appliance to apower socket, make sure the rated voltage
stated on its rating label corresponds to the voltage in your power socket.
■Never use accessories, which have not been supplied with this appliance or which
have not been explicitly recommended by the manufacturer for this type of
appliance.
■This appliance is designed for household use. Do not use it for commercial
purposes, in industrial surroundings, or outdoors, or for purposes other than those
for which it is intended.
■Always place the appliance on an even, dry and stable surface. Do not place it
on an electric or gas stove, in the vicinity of an open flame or appliances that are
sources of heat.
■Never use multiple attachments simultaneously.
■Before putting the appliance into operation, check that it is correctly assembled
and that the multi-function head is tilted down in the horizontal position. For
safety reasons, this appliance is equipped with asafety mechanism that prevents
the motor from being started when the multi-function head is tilted out.
■In the event that the multi-function head tilts out during operation, the appliance
will automatically stop running.
■Do not touch rotating parts of the appliance and ensure that foreign items such as
clothing, hair, etc. are kept away. An injury could occur or the appliance could be
damaged.
■In the event that an item, such as aspoon, falls into the bowl during operation,
immediately set the speed control knob to the 0 (off) position and disconnect the
power cord from the power socket. Wait until the rotating parts come to astop and
then remove the item.
■In the event that ingredients stick to the attachment or the sides of the bowl, turn
the appliance off, disconnect it from the power socket, and wait until rotating
parts come to astop. Use asilicone spatula to clean the attachment and the inside
of the bowl. Then you can restart the appliance.

04/2017
- 3 -
Copyright © 2017, Fast ČR, a.s.
■Make sure that no hair, clothing or other items enter the feed tube of meat grinder
while it is running. Do not put anything other than the ingredients that are to be
processed into the feed tube.
■Never use your fingers or other items to push ingredients through the meat grinder
feed tube. For this purpose there is apusher included as an accessory.
Warning:
Incorrect use may lead to injuries.
■To prevent injury caused by sharp edges, be especially careful when handling
the grinding blade of the meat grinder and the blade assembly of the blender.
Increased attention must also be paid when emptying out the blending jar, when
removing the grinding blade from the chamber, and when cleaning the appliance.
■Do not attempt to grind bones, frozen meat or other hard ingredients.
■Hot liquids up to atemperature of 80 °C may be processed in the blending jar. Be
especially careful when handling hot liquids. Hot steam or splashing hot foods and
liquids may cause scalding. Never start the blender without the lid properly seated
in position. When processing hot liquids, do not remove the inner cap during
operation. Do not touch the hot surface. Use the handle to carry the blending jar
when it is hot.
■The maximum continuous operating time is 10 minutes. Do not exceed the
maximum operating time of 5 minutes when in the kneading mode and do not
exceed the maximum operating time of 3 minutes when using the blender. Before
starting it again, allow the appliance to cool down for 30 minutes.
■Always turn off the appliance, disconnect it from the power socket when
not be using it, when leaving it without supervision, and before assembling,
disassembling, cleaning or moving it. Prior to disassembling the appliance and
replacing accessories or accessible parts that move during use, wait until all
moving parts come to astop.
■Clean it according to the instructions in chapter Cleaning and maintenance.
■Never wash the appliance under running water or submerge it in water or another
liquid.
■Do not turn on the appliance when it is empty. Incorrect use of the appliance may
negatively affect its lifetime.
■Ensure that the power plug contacts do not come into contact with water or
moisture. Do not place heavy items on the power cord. Make sure that the power
cord does not hang over the edge of atable or that it is not touching ahot surface.
■Disconnect the power cord from the power socket by pulling on the plug, never
pulling on the cord. Otherwise, this could damage the power cord or the socket.
■If the power cord is damaged, have it replaced at aprofessional service centre. It is
forbidden to use the appliance if it has adamaged power cord.

04/2017
- 4 -
Copyright © 2017, Fast ČR, a.s.
■To avoid the danger of injury by electrical shock, do not repair the appliance
yourself or make any adjustments to it. Have all repairs performed at an authorised
service centre. By tampering with the appliance, you risk voiding your legal rights
arising from unsatisfactory performance or quality warranty.

04/2017
- 5 -
Copyright © 2017, Fast ČR, a.s.
P
0
1
23 4
5
10
1
2
3
A6
7
4
5
8
9
10
11
12
13
1
2
3
4
5
6
7
8
9
10
11
12
B

04/2017
- 6 -
Copyright © 2017, Fast ČR, a.s.
4
1
3
C
2
5
D

04/2017
- 7 -
Copyright © 2017, Fast ČR, a.s.
EN Food Processor
User'smanual
■ Prior to using this appliance, please read the user’s manual thoroughly, even
in cases, when one has already familiarised themselves with previous use of
similar types of appliances. Only use the appliance in the manner described in
this user’smanual. Keep this user’smanual in asafe place where it can be easily
retrieved for future use.
■ We recommend saving the original cardboard box, packaging material,
purchase receipt and responsibility statement of the vendor or warranty card
for at least the duration of the legal liability for unsatisfactory performance
or quality. In the event of transportation, we recommend that you pack the
appliance in the original box from the manufacturer.
DESCRIPTION OF THE FOOD PROCESSOR
A1 Kneading hook
A2 Balloon whisk
A3 A-shaped beater
A4 5.5-litre stainless steel bowl
A5 Base unit
A6 Removable cover of the front meat
grinder attachment hub
A7 Removable cover of the top
blender attachment hub
A8 Tilt-out multi-function head
A9 Bowl cover with ahole for adding
ingredients
A10 Hub for attaching attachments
A1–A3
A11 Multi-function head release lock
A12 Speed control knob
serves to set speeds 1 to 10, sets
the pulse level and turns off the
appliance.
A13 Suction cups
provide stability to the appliance
during operation.
DESCRIPTION OF MEAT GRINDER ACCESSORIES
B1 Pusher
B2 Hopper
B3 Feed tube
B4 Grinding chamber
B5 Screw shaft
B6 Grinding blade
B7 Screw ring
B8 Fine grinding plate
B9 Coarse grinding plate
B10 Separator
B11 Thin sausage stuffer attachment
B12 Thick sausage stuffer attachment
DESCRIPTION OF THE BLENDER ACCESSORIES
C1 Inner cap of the blending jar
C2 Outer lid of the blending jar with
ahole for adding ingredients
C3 Glass blending jar with 1.5 l
capacity
C4 Handle
C5 Blade assembly
is an integral part of the blending
jar.
BEFORE FIRST USE
1. Take the appliance and its accessories out of the packaging materials.
2. Thoroughly wash all accessory parts that are intended to come into contact
with food using warm water and aneutral kitchen detergent. Then rinse them
under clean running water and thoroughly wipe dry with afine wiping cloth or
allow them to dry naturally. After washing and drying, we recommend to coat
the grinding blade B6 and the grinding plates B8 andB9 with cooking oil.
3. Do not submerge the food processor or its power cord in water or any other
liquids.
Attention:
The metal parts of the meat grinder and attachments A1–A3 are not
intended for washing in a dishwasher. Other removable parts may be
washed in adishwasher.
BEATING, WHIPPING AND KNEADING
SELECTING ATTACHMENT TYPES
Attachment type Purpose of use
Beater A3 It is used for beating light and medium heavy yeast-free
doughs, for preparing sauces, creams, fillings, etc. Do not
use it for kneading heavy doughs.
Balloon whisk A2 It is used for whisking whole eggs or egg whites, whipped
cream, foamy creams, etc. Do not use it for beating or
kneading doughs.
Kneading hook A1 It is used for kneading various types of doughs including
heavy and thick doughs such as for example bread dough,
pizza dough, fresh pastry doughs, etc.
ASSEMBLING AND DISASSEMBLING THE FOOD PROCESSOR
■ Before you start assembling or disassembling the food processor, check that it
is turned off and disconnected from the power socket.
1. Inserting the bowl
1.1 Place the food processor on an even, dry surface, for example on akitchen
countertop.
1.2 Use the lock A11 to release the multi-function head A8 and tilt it out all the
way. The locked status of the multi-function head A8 in the open position is
indicated by the lock A11 returning to the default position.
1.3 Insert the stainless steel bowl A4 into the base unit A5 and secure it in place
by turning it clockwise. When the bowl A4 is properly attached, it cannot be
separately lifted out of the base unit A5.
2. Mounting attachments and the cover
2.1 When attaching an attachment, the multi-function head A8 must be locked
in the open position, see point 1.2 in the previous chapter. Attach one of the
attachments on to the shaft on the underside of the multi-function head A8
so that the shaft fits into the hole on the attachment. Push the attachment
towards the multi-function head A8 and turn it anticlockwise to secure it in
place. Lightly pull the attachment downwards with one hand to check that it is
properly attached.
2.2 Place the ingredients that you wish to process into the bowl A4. Release the lock
A11 and tilt the multi-function head A8 to the horizontal position. After tilting
down the multi-function head A8, release the lock A11.The locked status of the
multi-function head A8 in the tilted down work position is indicated by the lock
A11 returning to the default position. This is accompanied by an audible click.
2.3 Place the cover A9 on to the bowl A4.
3. Disassembly
3.1 Remove the cover A9. Release the lock A11 and tilt out the multi-function head
A8 all the way. After tilting out the multi-function head A8, release the lock A11.
Locking of the multi-function head A8 inthe open open position is indicated
by the lock A11 returning to the default position, which is accompanied by an
audible click.
3.2 Push the attachment gently towards the multi-function head 8. Then rotate it
clockwise until it is released from the shaft and take it off. Turn the bowl A4
anticlockwise and remove it from the base unit A5. Move the arm A8 back to
the horizontal position.
USING THE FOOD PROCESSOR
1. Select the right type of attachment based on its intended use and assemble
the appliance according to the instructions in the chapter Assembling and
disassembling the food processor. Put the ingredients into the bowl A4 before
tilting the multi-function head A8 to the horizontal position.
Attention:
In asingle batch, it is possible to process no more than 2.2 litres of light
dough or 0.8 litres of thick, heavy dough. The maximum number of egg
whites that can be whisked at once is 12.
If an insufficient amount of ingredients are put in the bowl A4 (less than
0.3 litres of dough), then they may not be perfectly processed.
2. Make sure that the speed control knob A12 is set to position 0 (off) and that the
multi-function head A8 is tilted down in the horizontal position. The cover A7
must be properly attached to the multi-function head A8. Otherwise, the food
processor will not start. Connect the power cord to apower socket.
3. Set the required speed using the speed control knob A12. Gradually turn the
speed control knob A12 clockwise to increase the speed, turning it in the
opposite direction will reduce the speed. To initially stir in the ingredients, first
set alower speed and then adjust it as required. Electronic speed regulation
ensures that the set speed will be maintained under various loads. While it is
running, ingredients may be added into the bowl A4 through the hole in the
cover A9.
4. The pulse mode is used for increasing the speed to maximum for ashort time.
To activate the pulse mode, turn the speed control knob A12 to the ”P”position
and to ensure continuous operation hold it down in this position. As soon as
you release the speed control knob A12, it will automatically return to position
0 (off).
5. If it is necessary to wipe ingredients off the inside of the mixing bowl A4 and
the attachment, first turn off the food processor by setting the speed control
knob A12 to position 0 (off) and then disconnect it from the power socket.
Wait until the rotating parts come to a stop and only then scrape away the
ingredients with aspatula.
6. After you have finished using the appliance, set the speed control knob A12 to
position 0 (off) and disconnect the power cord from the power socket.
7. Wait until the rotating parts come to a stop and disassemble the food
processor according to the instructions included in chapter Assembling and
disassembling the food processor. Use asoft plastic spatula to empty out the
contents of the bowl A4.
8. Clean out the food processor after each use according to the instructions in
chapter Cleaning and maintenance.

04/2017
- 8 -
Copyright © 2017, Fast ČR, a.s.
QUICK GUIDE TO PROCESSING INGREDIENTS
Attachment type Ingredients Maximum
load
Processing
time
Speed
selection
Balloon whisk A2 Egg whites 12 pcs 4 min 8–10
Balloon whisk A2 Whipping cream 1l 6–8 min 8–10
Beater A3 Cake dough 2.2l 6 min 3–6
Kneading hook A1 Bread dough 0.8l 4–5 min 1–2
Note:
The above processing times are only areference.
When whipping egg whites, the bowl A4 and the beater A2 must be
perfectly clean and dry. Even asmall amount of fat may cause the egg
whites not be whipped to the desired snowy consistency.
Whipping cream should be cooled to atemperature of 6 °C prior to being
whipped.
Prior to processing them, and allow the ingredients used for making
various doughs and mixtures to rest at room temperature.
GRINDING MEAT AND MAKING SAUSAGES
ASSEMBLING AND DISASSEMBLING THE MEAT GRINDER
1. Insert the screw shaft B5 into the grinding chamber B4 with the cogged wheel
entering first.
2. Place the grinding blade B6 on to the shaft B5 (with the edge facing outwards
from the chamber) and on to it attach either the fine or coarse grinding plate
B8 or B9 depending on the preferred coarseness of the grind. Make sure that
the notch in the grinding chamber B4 slides into the groove in the grinding
plate.
Attention:
When attaching the blade B6, be very careful not to injure yourself on
the sharp edge.
3. Place the screw ring B7 on to the grinding chamber B4 and tighten it securely
by screwing it clockwise.
4. Make sure that the food processor is turned off and disconnected from the
power socket. The arm A8 must be tilted down to the horizontal position
and the attachments A1, A2 or A3 must be removed. The cover A7 must be
properly attached to the multi-function head. Otherwise, it will not be possible
to start the appliance. Remove the cover A6 from the multi-function head.
Place the assembled meat grinder at an angle of approximately 45° against the
attachment hub so that the feed tube B3 is tilted to the right at an angle of
approximately 45° from the vertical axis and set the attachment into avertical
position by turning it anticlockwise (fig. D) all the way. Place the hopper B2 on
to the feed tube B3. The meat grinder is now assembled and ready for use.
5. Disassemble in reverse sequence.
USING THE MEAT GRINDER
1. First prepare the meat for grinding in the following way. Remove all bones,
tendons, cartilage and cut the meat into 2× 2 × 6 cm size pieces that will freely
pass through the feed tube B3.
Attention:
Do not process frozen meat. Allow it to defrost before grinding it.
2. Make sure that the meat grinder is correctly assembled and that the speed
control knob A12 is set to the 0 position (off).
3. Place the stainless steel bowl A4 or another suitable container under the meat
grinder. Insert the power plug into apower socket.
4. Use the speed control knob A12 to set the desired speed. We recommend that
you initially set it to 5 and then lower or increase the as required. Gradually
place the meat pieces into the feed tube B3 and push them in using the pusher
B1. Take care not to clog up the feed tube B3 by alarge amount of meat. Do not
process more than 5 kg of meat per batch. The processing time is only several
minutes.
Attention:
Do not use fingers or other utensils to push meat through the feed tube
B3. Always use the pusher B1 designed for this purpose.
5. The ground meat will fall into the prepared bowl. The meat that remains in the
grinding chamber B4 can be removed by grinding aslice of bread or abread
roll.
6. To turn off the appliance, set the speed control knob A12 to the 0 position (off).
7. Clean out the meat grinder after each use according to the instructions in
chapter Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE SAUSAGE STUFFER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the
difference that instead of the grinding blade B6 and the grinding plate B8 or
B9 only parts B10 and B11 or B12 are used.
2. Place the separator B10 on to the screw shaft B5 so that the notch in the
grinding chamber B4 fits into the groove in the separator B10. Place the
sausage stuffer attachment B11 or B12 on to the separator B10 and complete
the entire sausage stuffer assembly by screwing the screw ring B7 on to the
grinding chamber B4 and attaching the hopper B2 to the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in
point 4 in chapter Assembling and disassembling the meat grinder.
4. To disassemble proceed in the reverse sequence.
USING THE SAUSAGE STUFFER ATTACHMENT
1. Make sure that the appliance is correctly assembled and that the speed control
knob A12 is set to the 0 position (off). Insert the power plug into a power
socket.
2. Prepare asausage casing that you will stuff with ground meat and allow it to
soak in lukewarm water for approx. 10 minutes. Place the ground meat mixture
on to the hopper B2. Take the sausage casing out of the water and skewer or
tie up one end and slide the other end like asock on to the sausage stuffer
attachment B11 or B12.
3. Use the speed control knob A12 to set the desired speed. We recommend to
initially set the lowest speed and then increase it as required. With one hand
hold the sausage casing on the attachment B11 or B12 and use the other hand
to push the ground meat mixture with the pusher B1 through the feed tube
B3. If the sausage casing sticks to the attachment B11 or B12, it is necessary to
moisten it with water again.
Attention:
Do not use fingers or other utensils to push minced meat through the
feed tube B3. Always use the pusher B1 designed for this purpose.
4. To turn off the appliance, set the speed control knob A12 to the 0 position (off).
5. Clean out the individual parts of the attachment after each use according to the
instructions in chapter Cleaning and maintenance.
BLENDING
ASSEMBLING AND DISASSEMBLING THE BLENDER
1. Place the outer lid C2 on to the blending jar C3 so that the arrow symbols on
the lid C2 and handle C4 are aligned. Firmly push down the lid C2 along the
entire perimeter so that it adheres well to the edge of the blending jar C3.
Place the inner cap C1 into the opening in the lid C2 so that the tabs along the
perimeter of the cap C1 slide into the grooves in the lid C2. Turn the cap C1
clockwise to secure it in place.
2. Make sure that the food processor is turned off and disconnected from the
power socket.The multi-function head A8 must be tilted down in the horizontal
position and the beater, blender or kneading attachments must be removed.
Remove the cover of the top attachment hub A7 from the multi-function head
A8 and place the assembled blending jar on to the top attachment hub so that
the arrow marked on the blending jar C3 is aligned with the open padlock
symbol on the multi-function head A8. Turn the blending jar C3 towards the
closed padlock symbol all the way. This will secure the assembled blender
to the multi-function head A8. The food processor is equipped with asafety
mechanism that will prevent the blender from starting unless it is correctly
attached.
3. To disassemble proceed in the reverse sequence.
USING THE BLENDER
1. The blender is intended for preparing meals and drinks such as milkshakes,
creamy soups, sauces, spreads, fresh baby foods, etc. It is not intended for
juicing fruit and vegetables, preparing potato purée, yeast dough or for
whipping egg whites.
2. Place the prepared ingredients into the blending jar C3 and assemble the
blender according to the instructions in chapter Assembling and disassembling
the blender.
Note:
The maximum capacity of the blending jar C3 is 1.5 litres. Never fill it past
the maximum mark. When processing hot liquids or liquids that expand
in volume during the blending process, it is recommended to fill the
blending jar C3 to no more than ²/₃of its maximum capacity.
3. Make sure that the food processor is correctly assembled and that the speed
control knob A12 is set to the 0 position (off). Connect the power cord to
apower socket.
4. Set the required speed using the speed control knob A12. We recommend to
first set aslower speed to allow the ingredients to mix together. Then you can
increase the speed. While blending, always use your hand to hold down the lid
from above. The pulse level is appropriate when you wish to blend food only
very quickly. To start the pulse level, turn the speed control knob A12 to the“P”
position and hold it in this position for amoment. As soon as you release the
speed control knob A12, it will automatically return to position 0 (off).
Attention:
The maximum operating time of the blender is 3 minutes. Do not leave
the appliance in continuous operation for longer than indicated above.
Then allow it to cool down for 30 minutes.

04/2017
- 9 -
Copyright © 2017, Fast ČR, a.s.
5. While blending, you may add food or liquids to the blending jar C3 through the
hole in the lid C2 after removing the inner cap C1. Never open the outer lid C2
during operation. When processing hot liquids, the inner cap C1 must remain
closed.
6. In the event that food is sticking to the blade assembly C5 or the walls of the
blending jar C3, turn the appliance off by turning the speed control knob A12
to the 0 position (off) and disconnect it from the power socket. Make sure that
the blade assembly C5 has stopped rotating. Carefully remove the blending jar
from the multi-function head A8. Take off the lid and using aplastic spatula,
clean the blade assembly C5 and the inside of the blending jar C3. Put the lid
back on and reattach the blender assembly to the multi-function head A8. Plug
the power cord into apower socket and continue blending.
7. After you have finished using the appliance, set the speed control knob A12 to
position 0 (off) and disconnect the power cord from the power socket. Check
that the blade assembly C5 has stopped rotating and take the blending jar
assembly off the multi-function head A8. Use asoft plastic spatula to remove
food from the blending jar C3.
8. Clean out the individual parts after each use according to the instructions in
chapter Cleaning and maintenance.
ADVICE AND TIPS FOR BLENDING
■ First cut food with afirm consistency such as fruit and vegetables into smaller
pieces measuring 3 cm and only then blend it.
■ First, blend a smaller amount of ingredients and then gradually add more
ingredients through the hole in the lid C2 while blending. In this way, you will
achieve better results than by adding all ingredients into the blending jar C4
at once.
■ If you need to blend food of a solid consistency together with liquids, we
recommend that you first blend the food of solid consistency and apart of the
liquids. Then gradually add the remaining liquids through the hole in the lid
C2 while blending.
■ To blend very thick liquids, we recommend using the pulse level so that the
blade assembly C5 does not get jammed too often. Start the blender repeatedly
in short intervals.
■ Ice cubes must be processed immediately upon being removed from the
freezer. When the ice starts to melt, the ice cubes will stick together and it will
not be possible to blend them.
QUICK GUIDE TO PROCESSING INGREDIENTS
Ingredients Speed
selection
Recommended
blending time
Fruit and vegetables cut into smaller pieces 5–7 30 s
Baby food 5–7 40 s
Spreads, dressings and marinades 4–6 30 s
Smoothies and cocktails 6–10 40 s
Soups 6–10 30 s
Ice cubes P (Pulse level)
Note:
The above food processing times are only a reference. The actual
blending time depends on the size of the ingredients, their amount and
the required final consistency.
CLEANING AND MAINTENANCE
■ Before cleaning the food processor, always switch it off by setting the speed
control knob A12 to the 0 (off) position and disconnect it from the power
socket.
■ Disassemble the food processor into its individual parts.Wait until moving parts
come to acomplete stop before disassembly.
■ Thoroughly wash the removable parts after every use using warm water with
a neutral dishwashing detergent. Then rinse using clean running water and
wipe dry with afine wiping cloth. After washing and drying, we recommend to
coat the grinding blade B6 and the grinding plates B8 andB9 with cooking oil.
■ If you whisked egg whites, first rinse the bowl A4 and the beater A2 under cold
water. If you were to use hot water, the egg white remains would harden and
their removal would be more difficult.
Attention:
When cleaning the grinding blade B6 and the blending blade assembly
C5, take special care to avoid injury.
■ The metal parts of the meat grinder and attachments A1–A3 are not intended
for washing in a dishwasher. Other removable parts may be washed in
adishwasher.
■ For cleaning the base unit A5 and the multi-function head A8, use a cloth
lightly dipped in aweak detergent solution. Then wipe everything with aclean
dampened cloth and thoroughly wipe dry.
■ Do not submerge the food processor or its power cord in water or any other
liquids. For cleaning, do not use solvents, abrasive cleaning products, etc.
Otherwise the surface may be damaged.
STORAGE
■ If you will not be using the food processor, store it in a dry place out of
children’sreach. For storage, make sure that the multi-function head A8 is tilted
down in the horizontal position.
TECHNICAL SPECIFICATIONS
Rated voltage range......................................................................................................220−240 V
Rated frequency..................................................................................................................50/60 Hz
Rated power input.............................................................................................................. 1 000 W
Electrical shock protection class..................................................................................................II
Noise level ............................................................................................................................ 85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which represents
alevel Aof acoustic power with respect to areference acoustic power of 1 pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-duty insulation.
Changes to text and technical parameters are reserved.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling hand
over these appliances to determined collection points. Alternatively,
in some European Union states or other European countries you
may return your appliances to the local retailer when buying an
equivalent new appliance.
Correct disposal of this product helps save valuable natural
resources and prevents potential negative effects on the environment and human
health, which could result from improper waste disposal. Ask your local authorities
or collection facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or
supplier for the necessary information.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the
local council or from your retailer.
This product meets all the basic requirements of EU directives related
to it.
