Hamilton Beach KESG5803Y-UL User manual

1.7 L Electric Glass Kettle
with Tea Infuser User Guide
Model: KESG5803Y-UL
BEFORE USING YOUR NEW PRODUCT,
PLEASE READ THESE INSTRUCTIONS TO PREVENT ANY DAMAGE.

IMPORTANT SAFETY INSTRUCTIONS
2
1. Read all instructions before using.
2. Before connecting the kettle to the power supply, check that the voltage
indicated on the appliance (underside the kettle base) corresponds with
the voltage in your home. If this is not the case, contact your dealer and
do not use the kettle.
3. The attached base cannot be used for other than the intended use.
4. Do not operate the appliance without water to avoid damaging the heat
elements.
5. Unplug from the outlet when not in use.
6. Do not let the cord hang over the edge of a table or counter or touch hot
surfaces.
7. Do not place on or near a hot gas or electric burner or in a heated oven.
8. If you accidentally allow the kettle to operate without water, the boil-dry
protection will automatically switch it off. If this should occur, allow the kettle
to cool before filling with cold water and re-boiling.
9. Make sure that the kettle is used on a firm, flat surface where children can't
touch it. This can prevent overturning the kettle, resulting in damage to the
kettle or injury to the person.
10. To protect against a fire, electric shock, or personal injury, do not immerse
the electrical cord, electric plugs, or the kettle in water or other liquids.
11. Always take care to pour boiling water slowly and carefully without tipping
the kettle too fast.
12. Be careful when opening the lid for refilling when the kettle is hot.
13. Close supervision is necessary when any appliance is used by or near
children.

14. Do not touch the kettle when it is hot. Use the handle.
15. Extreme caution must be used when moving an appliance containing hot
water.
16. The appliance is not a toy. Do not let children play with it.
17. The use of attachments that are not recommended by the appliance
manufacturer may result in fire, electric shock, or personal injury.
18. While boiling water, avoid contacting steam from the spout when water is
boiling, or just after it has switched off. Do not be anxious to uncover the lid.
19. Unplug from the power outlet when not in use and before cleaning. Allow it to
cool before putting on or taking off parts and before cleaning the appliance.
20. Always make sure that the lid is closed. Do not lift the lid while the water is
boiling. Scalding may occur if the lid is removed during the brewing cycles.
21. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person, in order to avoid a hazard.
22. Do not use the kettle for other than its intended use.
23. Do not move the kettle while it is switched on.
24. The kettle should only be used with the stand provided.
25. If the kettle is overfilled, boiling water may be ejected.
26. Do not use the kettle outdoors.
27. This appliance can be used by children aged from eight years and above,
if they have been given supervision or instruction concerning use of the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless they
are older than eight and supervised. Keep the appliance and its cord out of
reach of children aged less than eight years.
3

28. Children should be supervised to ensure that they do not play with the
appliance.
29. Appliances can be used by persons with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
30. This appliance is intended to be used in household and similar applications
such as:
Staff kitchen areas in shops, offices, and other working environments
Farm houses
By clients in hotels, motels, and other residential type environments
Bed and breakfast type environments
31. This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Do not attempt to modify
the plug in any way.
32. A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
33. WARNING: You may use an extension cord if proper care is exercised.
34. If you use an extension cord, make sure that:
The marked electrical rating of the extension cord is at least as great as the
electrical rating of your kettle.
The extension cord is not draped over a counter or table top where children
can pull it or trip over it.
4

SAVE THESE INSTRUCTIONS
5
WARNING:
Electric Shock Hazard Touching some of the internal components can
cause serious personal injury or death. Do not disassemble this kettle.
WARNING:
Do not insert your fingers into any gaps or holes. It may cause injuries.
Package contents
1.7 L Electric Glass Kettle with Tea infuser
Kettle heating base
Tea infuser
User Guide
Features
Just one touch on the four preset temperature buttons to prepare your green
tea 175° F (80° C), delicate tea 160° F (70° C), herbal tea 195° F (90° C), or
black tea/boil 212° F (100° C) very efficiently. Equipped with the most
accurate temperature sensor that will never again burn your tea leaves.
You can also boil water 212° F (100° C) quickly.
The variable temperature kettle has a keep-warm function that holds your
desired water temperature for up to 60 minutes.
The memory feature allows the water kettle to be lifted off its base for up to
three minutes without shutting off or losing its place in the brewing process.
The glass body lets you easily see the water level.
The cordless kettle, with a 360° base, lets you pour water easily.
Boil-dry protection and auto-shutoff prevent your kettle from boiling dry.

1.7 L capacity heats enough water for everyone.
1.2 L capacity for tea to keep you energized through the day.
A mesh spout filter and a concealed heating element help reduce buildup.
The tea infuser has a separate lid to allow easy filling with tea leaves.
A simple twist removes the infuser to allow cleaning after every use.
Components
Control panel
Control panel
Base
Lid
Tea infuser
Glass kettle
Spout
Handle
ON/OFF
Button
DELICATE TEA
Button GREEN TEA
Button
HERBAL TEA
Button
BLACK TEA/BOIL
Button
KEEP WARM
Button
6
Delicate Tea
160°F Green Tea
175°F
Herbal Tea
195°F
Black Tea/Boil
212°F
Keep Warm

7
SETTING UP YOUR KETTLE
USING YOUR KETTLE
1. Remove your kettle and all materials from the carton.
2. Examine your kettle for any damage, such as dents or broken glass. Don’t
install or use your kettle if you find any damage.
3. Place your kettle on a level surface that provides enough open space for the
air vents.
4. Plug your kettle into a standard, grounded household outlet. Make sure that
the voltage and the frequency is the same as the voltage and the frequency
on the rating label.
5. Before you use your kettle, we recommend that you clean your kettle by
boiling a full kettle of water twice, then discarding the water.
Filling your kettle
1. Remove the kettle from the heating base, then remove the lid.
2. Add water to the kettle.
Notes:
Always fill the kettle between the minimum .5 qt. (0.5 l) and maximum
1.8 qt. (1.7 l) marks. Too little water results in the kettle turning off before
the water has boiled. Too much water results in boiling water overflowing.
Make sure that the lid is firmly in place before connecting the power cord
to the outlet.
If using the tea infuser, make sure that the water does not exceed the
“1.2 L Tea Max line”.
3. Close the lid, then position the kettle on the heating base. Make sure that
the kettle contacts the heating base completely.

8
Heating water
1. With the kettle filled, plug in the heating base. The lights on the control panel
will turn on for one to two seconds, then turn off.
2. Press the (power) button. The (power) button and 212° F buttons light.
The kettle begins heating the water.
You can press any of the other temperature buttons, such as 160° F, 175° F,
or 195° F, at any time. The kettle will heat the water to the selected
temperature.
3. If you want to keep the water warm, you can press the Keep warm button at
any time and choose a temperature. The kettle keeps the water at the
selected temperature for one hour (60 minutes).
CAUTIONS:
Make sure that the lid is firmly in place before connecting the power cord
to the outlet. If the lid is loose, hot water could overflow and result in a
scald or burn.
Always exercise caution when pouring water from your kettle. Contact
with boiling water could result in a scald or burn.
Do not open the lid while the water in the kettle is hot.
4. When the water reaches the selected temperature, the tea kettle beeps to let
you know. Lift the kettle from the heating base and pour the water.
Note:
You can store your kettle on the heating base when it’s not in use.
Make sure that the power is turned off.

Using the tea infuser
1. Remove the kettle lid, with the tea infuser attached, from your tea kettle.
2. Open the tea infuser lid by turning it until the arrow lines up with the “open”
mark.
3. Put the amount of tea you want into the infuser basket (we recommen one to
two teaspoons (5 - 10 g), then replace the lid by turning it until the arrow lines
up with “lock” mark.
4. Fill your kettle with enough water for the tea you want, making sure that you do
not fill it past the maximum mark (“1.2 L TEA MAX”), then replace the lid, with
the tea infuser attached, onto your kettle.
5. Plug in your kettle and press the (power) button to turn it on.
6. Press any preset temperature button ( 160° F, 175° F, 195° F, or 212° F).
The temperature indicator light turns on and the water begins heating.
7. After the water temperature reaches the preset temperature, the power turns
off. Let the infuser basket remain in the kettle to steep the tea, and remove it
when the color of the tea indicates that the tea is ready (depending on your
personal preference).
Using the tea kettle memory function
If you decide that you want your tea kept warm, the Keep Warm button can
be pressed at any time during the heating process. With the Keep Warm
function selected, you can remove the tea kettle from the heating base for
up to three minutes and have the heating base remain on.
The temperature buttons can also be pressed at any time to select the
temperature to which you want the water heated.
Boil-dry protection
Should you accidentally allow the kettle to operate without water, the boil-dry
protection will automatically switch it off. If this should occur, allow the kettle
to cool before filling with cold water and re-boiling.
9

CLEANING AND MAINTAINING YOUR ELECTRIC KETTLE
CAUTIONS:
Your tea kettle is NOT dishwasher safe - DO NOT put it in the dishwasher.
Always unplug the power cord and let your kettle cool down completely
before cleaning.
Never immerse your kettle, cord, or heating base in water, or let moisture
come in contact with these parts.
Do not use chemicals, steel wool, or abrasive cleaners to clean the outside
of your kettle. These substances can scratch the surface or fade the color.
Removing mineral deposits
Mineral deposits in tap water may cause the kettle interior to discolor or
“scale.”To remove this build-up, use non-toxic liquid de-scaler or tea scale
cleaning tablets.
1. Fill your kettle with three cups of white vinegar and the remainder with water
and let it stand overnight. Do not boil.
2. Empty the solution from your kettle. Remove remaining stains with a damp
cloth.
3. Boil two full kettles of water, then discard the water.
Cleaning the outside
Wipe the outside of your kettle and heating base with a damp cloth or sponge.
Cleaning the filter
Remember to clean the filter with a mild detergent and damp cloth at intervals.
Storing your kettle
When not in use, the kettle can be kept on the heating base.
Note:
Make sure that the power cord is unplugged. The power cord can be wound
around the cord storage under the base of kettle.
10

TROUBLESHOOTING
Do not try to repair your kettle yourself. Doing so invalidates the warranty.
If problems persist after you try the solutions below, contact technical support.
PROBLEM POSSIBLE SOLUTION
The kettle and indicator
light do not work when the
heating base is plugged in.
The water is boiling, but the
power switch and indicator
light are still on.
The kettle will not turn on.
There are mineral deposits
inside the kettle.
Make sure that your kettle is seated properly
on the heating base and that the base is
connected to a functioning electrical outlet.
Make sure that the kettle is seated properly
on the heating base and that the base is
connected to a functioning power outlet.
Before using your electric kettle for the first
time, clean your kettle by boiling two full
kettles of water, then discarding the water.
A certain amount of scale build-up is normal
after long periods of use and is caused by
minerals contained in hard water. The best
way to prevent mineral deposits is to always
use distilled water in the kettle.
To remove deposits, try filling your kettle with
water and a few slices of lemon, then boil.
Water or debris on the bottom of your kettle
or on the heating base may interfere with
the functioning of your kettle. Make sure that
the bottom of your kettle and the base are
dry and free of debris.
The auto-shut off function does not operate
properly if the lid is not completely closed.
Let the kettle cool, then make sure that the
lid is properly locked into place.
11

SPECIFICATIONS
ONE-YEAR LIMITED WARRANTY
Rated voltage
Dimensions (H×W×D)
Certifications
Power cord length
Net weight
120 V~60 Hz
UL certified
29 in. (70-75 cm)
3.3 lbs. (1.5 kg)
11 x 6.6 x 10.6 in (28 x 16.8 x 27 cm)
12
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased
the Product. Your purchase date is printed on the receipt you received with
the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or
workmanship of the Product is determined to be defective by an authorized
repair center or store personnel, we will (at its sole option):
(1) repair the Product with new or rebuilt parts;
(2) replace the Product at no charge with new or rebuilt comparable products
or parts. Products and parts replaced under this warranty become the
property of us and are not returned to you.
If service of Products or parts are required after the Warranty Period expires,
you must pay all labor and parts charges. This warranty lasts as long as you
own your Product during the Warranty Period.
Warranty coverage terminates if you sell or otherwise transfer the Product.

How to obtain warranty service?
If you purchased the Product from online website, please take your original
receipt and the Product to any store. Make sure that you place the Product
in its original packaging or packaging that provides the same amount of
protection as the original packaging.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at websites to
the original purchaser of the product in the country where the original
purchase was made.
What does the warranty not cover?
This warranty does not cover:
Food loss/spoilage due to failure of refrigerator or freezer
Customer instruction/education
Installation
Set up adjustments
Cosmetic damage
Damage due to weather, lightning, and other acts of God, such as power
surges
Accidental damage
Misuse
Abuse
Negligence
Commercial purposes/use, including but not limited to use in a place of
business or in communal areas of a multiple dwelling condominium or
apartment complex, or otherwise used in a place of other than a private
home.
13

Modification of any part of the Product, including the antenna
Display panel damaged by static (non-moving) images applied for lengthy
periods (burn-in).
Damage due to incorrect operation or maintenance
Connection to an incorrect voltage or power supply
Attempted repair by any person not authorized to service the Product
Products sold “as is” or “with all faults”
Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
Products where the factory applied serial number has been altered or
removed
Loss or Theft of this product or any part of the product
Display panels containing up to three (3) pixel failures (dots that are dark or
incorrectly illuminated) grouped in an area smaller than one tenth (1/10) of
the display size or up to five (5) pixel failures throughout the display. (Pixel
based displays may contain a limited number of pixels that may not function
normally.)
Failures or Damage caused by any contact including but not limited to
liquids, gels or pastes.
14

REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY.
WE SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED
TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS
OR LOST PROFITS.
OUR PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH
RESPECT TO THE PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES
FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE
WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES, WHETHER
EXPRESS OR IMPLIED, WILL APPLY AFTER THE WARRANTY PERIOD.
SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR
PROVINCE TO PROVINCE.
15
