MBD-12F

Antenna Switch Controller

Operation Manual

V. 2.6

MBD-12F –Operation Manual Page 1

MBD-12F

Automatic Antenna Switch Controller

MBD-12F is a standalone, intelligent controller, no PC required for configuration. It is compatible with

all twelve-antenna switches manufactured by Hamplus. The MBD-12F managing up to twelve antennas and

six radios, one unit for each radio provide all the interlock necessary for a save operation. It has a band

decoder to receive the information coming from the connected radio equipment. In addition to antenna

switching, the MBD-12F also offers eight frequency-driven GPOs (General Purpose Output), one Band Data

BCD Output, one output to command Band Pass Filter.

The MBD-12F interface, using only the panel antenna keys, has a unique ability to select a dedicated

receiving antenna or to lock the transmit antenna and use temporally receive on any other antenna you have

so you can find the best signal to noise ratio on the station you are working. You can also control dedicated

systems from Top Beam’s Waller Flag receiving antenna.

Antennas with dedicated tuning needs, like 80m Yagi or vertical antennas with tuner can use the GPI / O

for reading and triggering external relay or equipment. The MBD-12F also control up to eight Rotator using

only one indicator on your desk, using the RS-28 and RS-48 Rotator switches.

There are four ways that antennas and enabled rotators can be selected;

1) Manually by the front panel of the MBD-12F,

2) Manually by frequency or band change on the front panel of the transceiver,

3) Automatically by frequency or band change by the remotely controlled transceiver,

4) Automatically by a remotely controlled personal computer via Lan port to the MBD-12F.

GPI/O = General Purpose Input and Output

Functions and operation

1- Connect the MBD-12F to an antenna switch type AS-1202 / AS-1204 / AS-1206 ...

2- Startup

The MBD-12F storage the last antenna used for each band on an EEPROM memory. It does no lose the

information removing power on the unit. The MBD-12F records last antenna selected any time you

change band or turn off the unit. When you turn on the MBD-12F, it read the frequency form the radio

and auto selected the last antenna you used on the last band. The Rotator and GPI/O configuration are

saved in the EEPROM memory too.

3- Choose the antennas

To select an antenna, press one of the twelve push buttons. When the push button is pressed, it grounds

he output pin that activate the corresponding relay on the antenna switch connector. It also activates

the selected rotator for the antenna.

MBD-12F –Operation Manual Page 2

The Busy Net LED informs the antenna and the corresponding rotator programed for that antenna push

button, and send the information to the others MBD-12F connected on the busy-net, so the antenna

selected is in use, and cannot be selected by others unit. It does not allow another MBD-12F to select an

antenna or rotator already in use. If you try to select an antenna in use the busy-net LED will flash for

few seconds and the antenna won’t be selected when you release the push button. When there is

conflict the signaling flashes with cadence of 0.5 seconds as long as you try to select a used antenna or

used rotator.

4- SPLIT Mode

This mode allows operation with two antennas. One for transmission and one for reception. It temporally

locks the transmit antenna and you can choose any other antenna to receive. This function allows you

quickly to select the best antenna to receive and keep transiting on the antenna you locked.

Procedure to enter “SPLIT” mode:

a- First, select the transmission antenna #_x. The push button key will light and the busy-net LED

will light on the other units indicting that the antenna #_x is in use.

b- Then press the PTT of the radio and holding it down, and press the push button of the desired

antenna for reception until all the push buttons LED stat flashing.

c- When you release the PTT, the “Split” LED will light and the unit is now in “SPLIT” mode.

d- Now you can select any other antenna to receive, but only transmit on the locked antenna. To

change the receiving antenna simply press the push button of another antenna.

e- Because you are using two antennas, one for RX and another for TX, two busy-net LED will light

on the other units indicating that both antennas cannot be selected

Check the split function by pressing and releasing the PTT of the radio and observing the push button of

the MBD-12F that must switch between the chosen antennas.

To exit the SPLIT mode:

You have two options

1- Switch band on the radio.

2- Press the antenna button set to transmit, all the push button LED’s will flash indicating that

you are releasing the Split mode.

5- EXCLUSIVE Antennas for RECEPTION (Permanent Split Mode)

The MBD-12F can configure receive-only antennas. It means you cannot transmit or select that antenna

on that unit, if you are using several MBD-12F you need to configure the same antenna as receive only on

all units. Whenever you select an antenna configured as EXCLUSIVE for RECEIVE, the MBD-12F will

automatically activate the SPLIT mode and when leaving this antenna, the MBD-12F will disable the SPLIT

mode.

Procedure for setting up an antenna for EXCLUSIVE Reception:

Do the same on all other MBD-12F connected to your antenna switch.

a- Select the transmit antenna and press the PTT, and hold it, then press for ten seconds or more

the button of the antenna you chose for EXCLUSIVE reception until all the buttons LED’s will

flash for few times.

b- The Split LED will light on indicating that you enter in split mode.

c- Keep holding for 10 or more seconds until all the push buttons LED flash again.

d- Then the Split LED will turn off, indicating that the selected antenna for reception is now

EXCLISIVE for reception on this MBD-12F unit.

MBD-12F –Operation Manual Page 3

Checking the operation

Press on the MBD-12Fthe EXCLUSIVE Reception antenna button and see that the SPLIT LED

indicator will light. Press the PTT of the radio and note that the MBD-12Fswitches from the

EXCLUSIVE Receiving antenna to the antenna you selected before to transmit.

The advantage off EXCLUSIVE receive antenna is that you do not need to configure the Split mode all

the time. Let us say you have a beverage antenna receiving only antenna. The MBD-12F will not let

you transmit on the EXCLUSIVE receive antenna. Select the transmit antenna and after that select

the exclusive receiver antenna, the Split LED will light on. When you push the PTT the transmit

antenna will be selected.

Selecting any other antenna, the Split LED will turn off. Selecting again the EXCLUSIVE receive

antenna the SPLIT LED will turn on, and two busy-net LED will light on the others MBD-12F.

With the EXCLUSIVE receive mode, the configuring will not change when you change band or select

another antenna. It is permanent until you re-configure the receiving only antenna.

To remove an antenna from EXCLUSIVE Reception mode

a- First, select on the MBD-12Fany antenna not in receiving mode, the SPLIT LED should be not be

light.

b- Press the PTT, and hold it, then press for ten seconds or more the button of the antenna you

want to exit the EXCLUSIVE reception mode. All the buttons LED’s will flash for few times.

c- The Split LED will light, indicating that you enter the split mode.

d- Keep holding for 10 or more seconds until all the push buttons LED flash again.

e- Then the Split LED will turn off, indicating that exit the EXCLISIVE mode.

f- Push the PTT now and check that now you transmit and receive on the same antenna. The busy-

net LED will indicate that only one antenna is in use on this unit.

OBS: if you are configuring antenna push button #1, you may hold it long enough to enter the

MBD-12F in configuration mode. The LED’s # 1 to # 8 will flash in sequence indicating the unit is

waiting to select the mode.

Press the # 12 button to exit the configuration mode.

6- GPOs2 Activation

The GPOs2 are eight pins available on the DB-9 connector labeled GPO2 located on the back of the

MBD-12F. These GPOs2 are used to tune shortened antennas with high Q coils.

GPOs2 can be triggered in two ways. By frequency and or by band. Each GPO2 is individually configured

and is associated with one of the 12 antenna positions. This means that the eight GPOs2 can be configured

to a single antenna position or one can be configured for each of the twelve antenna positions.

To configure the GPOs2 see item 12 B

7- Antenna groups

On MBD-12F you can create groups of antennas. When a radio accesses one of the antennas in this

group, all the antennas in this group inform Busy Net that they are busy. This means that no other radio

has access to an antenna belonging to this group. Only the radio that is connected to one of the

antennas in this group is allowed to use the other antennas in this group.

Example for a contest.

Create a group with the antennas for the 10m band. Only the radio operating in the 10m band will have

access to the 10m band antennas. The other radios will not have access to any of the grouped antennas.

You can create several groups of antennas.

To configure a group of antennas, see item 12C

MBD-12F –Operation Manual Page 4

8- Switching Rotors

The MBD-12F also commands the RS-24, RS-44, RS-28 and RS-48 rotor switches. In this way a single rotor

control can control up to 8 rotors.

To configure the rotor switch, see item 12A

9- Communication with Icom, Yaesu, Kenwood, Elecraft K-3 and Flex Radio

a. ICOM - CI-V protocol (CI-V port) for reading the frequency for the activation of the selected

Antennas, Rotors and GPIs.

b. YAESU- BCD protocol for reading the band for the activation of the selected antennas and GPIs.

c. Kenwood- RS-232 protocol for frequency reading for the activation of Antennas and GPIs. K3

and Kenwood use the same RS-232 protocol.

d. Elecraft K3- protocol BCD and RS-232.

e. Flex Radio, K3 and Kenwood use the same RS-232 protocol.

10-Band Data Table

Band Frequency BCD

2200 m 0.0 to 399 KHz 1100

630 m 400 to 539 KHz 1101

160 m .540 to 2.9 MHz 0001

80 m 3.0 to 4.8 MHz 0010

60 m 4.9 to 5.9 MHz 0000

40 m 6.0 to 8.9 MHz 0011

30 m 9.0 to 12.9MHz 0100

20 m 13.0 to 16.9MHz 0101

17 m 17.0 to 18.9MHz 0110

15 m 19.0 to 22.9MHz 0111

12 m 23.0 to 25.9MHz 1000

10 m 26.0 to 34.9MHz 1001

6 m 35.0 to 54.9MHz 1010

------- above 55 MHz 1011

Frequency Band for communication via RS-232 and CI-V

Band 1 from 0 to 399KHz, Band 2 from 400KHz to 539KHz, Band 3 from 540KHz to 1.599MHz, Band 4 from

1.6 to 1.799 MHz, Band 5 1.800 to 1.999, Band 6 from 2.0 to 3.499MHz, Band 7 from 3.5 to 3.999

MHZ, Band 8 from 4.0 to 5.399 MHz, Band 9 from 5.499 to 6.999 MHz, Band 10 from 7.0 to 7.299

MHz, Band 11 from 7.3 to 7.999 MHz, Band 12 from 8.0 to 10.999 MHz, Band 13 from 11.0 to 14.999

MHz, Band 14 from 15.0MHz to 19.999 MHz, Band 15 from 20.0 to 21.999 MHz, Band 16 from 22.0 to

24.999 MHz, Band 17 from 25.0 to 27.999MHz, Band 18 from 28.0 to 29.999 MHz, Band 19 from 30.0 to

59.999 MHz, Band 20 From 60.0 to 143.499MHz, Band 21 from 143.5 to 144.399MHz, Band 23 144.400 to

147.999MHz, Band 23 148.0 to 224.999MHz, Band 24 225.0 to 429.999MHz Band 25 430.0 to 449.999MHz,

Band 26 450.0 to 999.999MHz, Band 27 1.0 GHz to 1.999GHz, Band 28 2.0 to 2.999GHz, Band 29 3.0 to

3.999GHz, Band 30 4.0 to 5.999GHz, Band 31 6.0 to 10.999GHz.

MBD-12F –Operation Manual Page 5

Antenna Memory per Band, Fixed or Mobile

All MBD-12F are shipped in Mobile Memory mode. In the Mobile Memory operation whenever a

band is selected in the radio the antenna to be connected will be the last used in that band.

In the operation by Fixed Memory whenever a band is selected the antenna to be connected will be the

same and not the last that was used in that band. Ex: 160m band> ant1, 80m band> ant2, 40m band> ant. 3

and so on. To choose the antenna that each band goes you must first be in the Mobile Memory mode. Then

go through the radio and choose the desired antenna for each band. Then enter setup mode and follow the

procedure to memorize your choice.

11-Firmware update via USB

To update the firmware, place the flash drive with the new Firmware in the USB port of the MBD-12F

and reset the CPU by pressing the internal key or press and hold push buttons 10, then 11 and finally 12.

This procedure starts the firmware update.

12-Configuration Mode

The setting mode is only possible when the Radio is properly connected to the MBD-12F.

To enter set up mode press and hold it the push button of the antenna that will receive the configuration plus

the push button 1 until the confirmation signal appears. (+ or - ten seconds).

In this mode the push buttons available for setup blink.

To exit setup mode, press the push button 12 for 1 second.

A- Configure Rotors

Enter configuration mode by pressing the push button of the antenna you want to configure to

the Rotor plus push button 1. After confirmation press the push button 1 to enter the Rotor

configuration mode. After the confirmation signal the push buttons 1 to 8 will flash indicating the rotors

1 to 8. Press the push button corresponding to the desired rotor. The push button and red indicator light

of the chosen rotor will be illuminated. The choice can be redone as many times as you want.

To undo your choice, press the illuminated push button.

To exit set up mode press the push button 12 for 1 second.

B- Configuring the GPO2

Enter setup mode by pressing the push button on the antenna you want to enable GPO2 plus push

button 1.

After confirmation press push button 2 to enter GPO2 configuration mode.

Press the push button1 for the frequency setting mode, the push button 2 for the Band configuration

mode, or the push button 3 for frequency setting with command activation on the average frequency

between the marked point and the previous point.

To trigger the GPOs2 by frequency:

The trigger points of the GPOs2 are chosen by varying the frequency in the radius in order to obtain the

desired frequency for the drive. Start with the lowest frequency and the first GPO2 by pressing the push

button 1. Raise the frequency to the next frequency and mark the second GPO2

pressing the push button 2 and so on for the next GPOs2.

To trigger the GPOs2 on the average frequency between two points:

Choose the frequency of the starting point and press the push button corresponding to the chosen

GPO2. This push button will blink. Advance the frequency on the radio dial to the desired point and press

the blinking push button again. It will stop blinking and the midpoint will be marked.

To exit setup mode, press the push button 12 for 1 second.

MBD-12F –Operation Manual Page 6

To trigger the GPOs2 by Band:

GPO2 can be triggered by Band, it can be done by reading the BCD or frequency according to item 11.

Put the radio in the desired band and press the push button corresponding to the GPO2 that you want to

trigger. Any available GPO2 can be used in any band.

To exit setup mode, press the push button 12 for 1 second

Conector DB-9 GPO2

Pins Function

1Cmd1

2Cmd2

3Cmd3

4Cmd4

5Cmd5

6Cmd6

7Cmd7

8Cmd8

9+12v

All Cmds are Active Low

C- To configure an antenna group

1- First- choose the Master Antenna, the one that will be the reference for all antennas in this group.

2- Second- enter the Configuration mode.

a- To enter the configuration mode, press the chosen antenna button to be the Master Antenna

plus the Ant1 button and keep them pressed for approximately two seconds. You are now in

Configuration mode and from the Ant1 button to the Ant8 button, which are flashing, press the

Ant6 button. You are now in the antenna group configuration mode. From this moment on, only

the Master Antenna button will be flashing.

b- Now you will press, one at a time, the buttons of the antennas you want to place in this group.

All the antenna buttons you placed in the group will be illuminated. Only the Master Antenna

button will be flashing.

c- To save and exit the configuration mode, press the button of the Master Antenna, the one that

is flashing.

IMPORTANT

You must memorize which is the Master Antenna of the Group, because when you want to change

or undo this group, you will have to enter the configuration mode through the Master Antenna.

SUJESTION

If you are going to create a group with antennas 4, 5 and 6, choose as the Master Antenna,

antenna 4. If you always use the first antenna of the group to be the Master Antenna, it will be easier

to remember in the future.

D- Undo or change an Antenna Group

a- Enter the configuration mode, press Master Antenna button plus the Ant1 button and keep

them pressed for approximately two seconds. You are now in Configuration mode and from the

Ant1 button to the Ant8 button, which are flashing, press the Ant6 button. You are now in the

antenna group configuration mode. From this moment on, the Master Antenna button will be

flashing and all other antennas in this group will be illuminated.

MBD-12F –Operation Manual Page 7

b- You can now add or remove antennas in this group. To remove press the buttons that are

illuminated, to add press the buttons that are not illuminated. If you turn off all the illuminated

buttons the group will be undone and only the Master Antenna button will be flashing.

c- To save and exit, press the button of the Master Antenna, the one that is flashing.

E- Set the Communication Speed (9600 - 19200 - 38400 - 57600 - 115200)

To configure the communication speed, enter setup mode. Then press the push button 4

to enter speed setting mode. After confirmation press the push button 1 to 9600,

2 for 19200, 3 for 38400, 4 for 57600, 5 for 115200.

To exit setup mode, press the push button 12 for 1 second.

F- Set up operation for Fixed Antenna or Last Antenna Memory Mode

Enter configuration mode. Then press push button 5 to enter Memory setup mode. After confirmation

press push button 1 for Last antenna Memory Mode or press push button 2 for Fixed Antenna Memory

Mode.

To exit setup mode, press key 12 for 1 second.

In Last Antenna Memory mode each radio band is linked to the last antenna used in this band. In Fixed

Antenna Memory mode, each radio band is linked to a previously chosen antenna.

To choose the antenna that each band will operate in the Fixed Antenna Memory Mode, you must

first be in the Last Antenna Memory Mode. Then go through all the radio bands and choose the desired

antenna for each one.

Then enter setup mode and follow the procedure to memorize your choice

G- Select and Store the Antennas for Operation in the Fixed Antenna Memory mode.

In the Last Antenna Memory mode select the desired antenna for each band, proceeding from the

following way:

Set the radio to 160m and choose the 160m antenna on the MBD-12F. Then set the radio to 80m and

choose the antenna for 80m on the MBD-12F. Do this for all bands. After choosing the antennas enter

the setup mode by pressing the push button 1. After confirmation press the push button 5 to enter the

Memory configuration mode. After confirmation press the push button 5 and the Fixed Antenna

Memory mode will have all the antennas configured.

To exit setup mode, press the push button 12 for 1 second.

H- Procedure to enter SPLIT mode:

a- First select the transmission antenna.

b- Then press the PTT of the radio and holding down, so press the push button of the desired

antenna for reception.

When the PTT is released, SPLIT mode is active and will be indicated by the illuminated Split Led.

Perform the function test by pressing and releasing the PTT of the radio and observing the push

button of the MBD-12F that must switch between the chosen antennas.

To change the receiving antenna simply press the push button of another antenna.

To exit SPLIT mode switch band on the radio or press the antenna button set to transmit

I- Band Data out

The DB-9 BCD Out connector on the rear of the MBD-12F provides a Band Data output

corresponding to the radio frequency that is connected.

When the MBD-12F receives the radio band information from the Radio Band Data, this same

information will be passed to the BCD Out connector. When receiving the information through

Frequency the conversion to Band Data will be done according to the table in item 1

MBD-12F –Operation Manual Page 8

DB-9 BCD Out connector

Pin Function

1Data A

2Data B

3Data C

4Data D

5NC

6NC

7NC

8GND

9NC

J- DB-9 To Bandpasser connector

Pins Band Frequency Function

1 20 m 13.0 to 16.9 MHz --------

2 40 m 6.0 to 8.9 MHz --------

3 80 m 3.0 to 4.8 MHz --------

4 160 m 0.0 to 2.9 MHz --------

5 --------- ----------------------- GND

6 --------- ----------------------- --------

7 --------- ----------------------- Bypass

8 10 m 26.0 to 34.9 MHz ---------

9 15 m 19.0 to 22.9 MHz ---------

All control pins are Active Hight + 12V

K- TOPBEAM Waller Flag connector

The HD-15 connector labeled TOPBEAM Waller Flag on the rear of the MBD-12F provides power

(+12V) and controls for triggering the filters of the Waller Flag receiving antenna control box. The

commands follow the Band data table or the Radio frequency.

Connector DB-9 TOPBEAM Waller Flag

Pins Band Frequency Data Function

1 160 m 0.0 to 2.99 MHz 0001 On Active Low

2 80 m CW 3.4 to 3.59 MHz 0010 On Active Low

3 80 m SSB 3.6 to 4.99 MHZ 0010 On Active Low

4 40 m 6.0 to 8.99 MHz 0011 On Active Low

5 30 m 9.0 to 12.9 MHz 0100 On Active Low

6 e 7 -------- ------------------- ------ +12v

8 -------- ------------------- ------ PTT

9 e 10 -------- ------------------- ------ GND

11 -------- ------------------- ------ RTX On A. Low

12 -------- ------------------- ------ RX1 On A. Low

13 -------- ------------------- ------ RX2 On A. Low

14 -------- ------------------- ------ RX3 On A. Low

15 -------- ------------------- ------ RX4 On A. Low

MBD-12F –Operation Manual Page 9

L-DB-9 To Radio connector

This connector receives from the Radio the power supply (+ 12v), the transmission command (Send)

and the data for frequency reading via RS-232 or Band reading via Band Data BCD

Pins Function

1+12V from Radio

2RX ( RS-232 )

3TX ( RS-232 )

4PTT ( Send ) from Radio

5GND

6BCD A from Radio

7BCD B from Radio

8BCD C from Radio

9BCD D from Radio

M- DB-25 To ANTSW connector

This connector connects the MBD-12F to the Antenna Switch and the Rotor Switch. It also offers

I2C Commands for the Expansion Interfaces.

Pins Function Pins Function

1 Ant 1 2 Ant 2

3 Ant 3 4 Ant 4

5 Ant 5 6 Ant 6

7 Ant 7 8 Ant 8

9 +12 out 10 GND

11 SDA 12 SCL

13 NC 14 Ant 9

15 Ant 10 16 Ant 11

17 Ant 12 18 Rotor 1

19 Rotor 2 20 Rotor 3

21 Rotor 4 22 Rotor 5

23 Rotor 6 24 Rotor 7

25 Rotor 8

MBD-12F –Operation Manual Page 10

1- GPI/O (DB-25F connector with 16 GPI /O for control of external equipment)

2- GPO2 (DB-9F connector with eight Frequency drive GPOs)

3- To Bandpasser (DB-9F connector to control Band Pass Filter. Active + 12v 120mA)

4- BCD OUT (DB-9F connector for BCD output)

5- TB Key Board (8-pin Mini Din connector for Top Beam WF antenna control keypad)

6- TOPBEAM Waller Flag (HD-15F connector for activating Top Beam WF antennas)

7- AUX. POWER SUPPLY

8- To Switch (DB-25F connector for Switch Antenna and Rotor Switch)

9- To Radio (DB-9F connector for connection to the radio)

10-LAN ( for remote operation)

11-USB (for software update)

12-CI-V (for communication with Icom radios)

13-Buzy Net (P2 connector for communication between MBD-12F controllers)

14-Send In/Out (RCA connector type for SEND connection. It has internal relay)

MBD-12F –Operation Manual Page 11

Settings List of MBD-12F

MBD-12F Settings

All settings can be made directly from the keyboard in just two steps. First step to enter the setup mode. The second

step is to choose the function you want to set.

1- First step

How to enter setup mode

Press the antenna push button that will receive the settings and the push button 1 until the

confirmation signal appear, about ten seconds. After confirming, the push buttons available for

configuration will flash. The push button 12 flashes different cadence from the others and when pressed

for more than one second the system exits the setting mode.

2- Second step

In setup mode choose the function to configure and press the corresponding button

1- Push Button 1 to set Rotators

a- Push Button 1 -> Rotator 1

b- Push Button 2 -> Rotator 2

c- Push Button 3 -> Rotator 3

d- Push Button 4 -> Rotator 4

e- Push Button 5 -> Rotator 5

f- Push Button 6 -> Rotator 6

g- Push Button 7 -> Rotator 7

h- Push Button 8 -> Rotator 8

To exit press the push button 12 for 1 second

2- Push Button 2 to set GPO2

a- Push Button 1 By frequency, with the activation point at the frequency indicated on the Radio

b- Push Button 2 By Band

c- Push Button 3 By frequency with the activation at the midpoint between the chosen point and

the previous point

To exit press the push button 12 for 1 second

3- Push Button 4 to set the communication speed

a- Push Button 1 -> 9600

b- Push Button 2 -> 19200

c- Push Button 3 -> 34800

d- Push Button 4 -> 57600

e- Push Button 5 -> 115200

To exit press the push button 12 for 1 second

MBD-12F –Operation Manual Page 12

4- Push Button 5 to configure antenna memory mode

a- Push Button 1 -> Last Antenna Memory Mode

b- Push Button 2 -> Fixed antenna Memory Mode

c- Push Button 5 -> To record the antennas chosen for the Fixed Antenna Memory mode

To exit press the push button 12 for 1 second

5- Push Button 6 to configure Antenna Group

A- Configure Antenna Group

1- First- choose the Master Antenna, the one that will be the reference for all antennas in this group.

2- Second- enter the Configuration mode.

a- To enter the configuration mode, press the chosen antenna button to be the Master Antenna

plus the Ant1 button and keep them pressed for approximately two seconds. You are now in

Configuration mode and from the Ant1 button to the Ant8 button, which are flashing, press

the Ant6 button. You are now in the antenna group configuration mode. From this moment on,

only the Master Antenna button will be flashing.

b- Now you will press, one at a time, the buttons of the antennas you want to place in this group.

All the antenna buttons you placed in the group will be illuminated. Only the Master Antenna

button will be flashing.

c- To save and exit the configuration mode, press the button of the Master Antenna, the one that

is flashing.

B- Undo or Change an Antenna Group
