HAMPTON BAY HD33679 User manual

Item #1001 000 000
Model #HD33679
Use and Care Guide
LOW VOLTAGE FLOODLIGHT KIT
Part Description Quantity
AHeads 4
BAdjustment screw 8
CPosts 4
DSpikes 4
EConnectors 4
F45W transformer 1
GCable 1
HScrew 1
IPlastic anchor 1
PACKAGE CONTENTS
Assembly and Installation
1Attaching and installing the pathlight
WARNING: Never push the xture into the ground by the head or use a hammer
to insert the spike (D) into the ground.
CAUTION: Safe for outdoor operation.
WARNING: To reduce the risk of FIRE OR INJURY TO PERSONS:
WARNING: Do not operate the luminaire tting with a missing or damaged lens
or bulb protector.
□Carefully remove the xture from its protective packaging.
□Screw the post (C), the spike (D) and the oodlight’s head (A)
together.
WARNING: Install in accordance with all local codes and ordinances.
Only for use with low voltage power units with a maximum output rating of 15V,
300W per secondary.
FOR LANDSCAPE LIGHTING SYSTEMS ONLY. OUTDOOR USE ONLY. THE DEVICE IS
ACCEPTED AS A COMPONENT OF A LANDSCAPE LIGHTING SYSTEM WHERE THE
SUITABILITY OF THE COMBINATION SHALL BE DETERMINED BY CSA OR LOCAL
INSPECTION AUTHORITIES HAVING JURISDICTIO
N.
FLOODLIGHT ETL LISTED UNDER MODEL # U000-1998
Please read and save these instructions
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS
Lighted lamp is HOT!
2Connecting the wires
WARNING: The wire connector (E) contacts have sharp edges for piercing the
main low voltage cable. To avoid injury, do not touch the metal contacts.
CAUTION: The wire from the low voltage power unit shall be 12-18 AWG type
underground low Energy Circuit Cable or SPT2W.
IMPORTANT:
• Protectthewiringbyroutingitincloseproximitytothelighttting,ornexttoa
building structure such as a house or deck.
• Thelandscapewireandconnectorcanalsobehiddenunderstoneorburied
under grass at a maximum depth of 6 in. (15.24 cm).
• Donotsubmergethextureinwater.
WARNING: Risk of Electric Shock. Install all luminaires 10 ft. (3.05 m) or more
from a pool, spa or fountain.
A
B
C
D
E
F
G
D
A
B
C
E
I
H
WARNING: There are no serviceable parts inside the power supply unit. DO NOT
DISASSEMBLE.
WARNING: Do not submerge the transformer.
WARNING: Do not connect two or more transformers in parallel.
WARNING: For use with 12 volt low voltage outdoor landscape lighting system only.
Not for use with submersible light or pool/spa equipment.
WARNING: Do not use with a dimmer.
CAUTION: Plug the power supply unit directly into a GFCI outlet that is marked “wet
location”. The maximum output of this transformer is 45 watts. Do not overload
the
transformer. Be sure that the total cumulative wattage of all 12 volt xtures connected
to the transformer is equal to or less than 45 watts. This garden light system must be
installed in accordance with all local codes and ordinances. If you are experiencing
problems, contact a qualied electrician.
WARNING: Do not use an extension cord.

Assembly and Installation (Continued)
□Remove the landscape wire insulation 1/2 in. from both wires
and twist ends.
□Insert wires under each terminal plate on the transformer and
tighten screws.
□Gently pull on the landscape wire to verify if the connection is
strong.
□Verify that there are no loose cable strands.
4Connecting the cable to the transformer
5How to operate the transformer
□Simply press on the push button on the front of the
transformer until the desired mode is selected. The modes
are ON, Auto, 2H, 4H, 6H and 8H. Auto is the dusk-to-dawn
function. The lights turn on at dusk and then turn off at dawn.
2H, 4H, 6H and 8H will turn on at dusk and then turn off based
on the selected hours setting.
Note: Prior to installing and powering the transformer, a safety approved GFCI receptacle
and GFCI watertight protective cover must be installed by a qualied electrician. GFCI
receptacle and cover must be mounted a minimum of 12 in. (0.3 m) above ground level.
The transformer must be mounted at least 1 ft. (0.3 m) above ground level.
12 in. (12.7 mm)
1/2 in.
(12.7 mm)
PULL
□This transformer is weatherproof and suitable for outdoor and
indoor use.
□Install the transformer at a level where the controls are
visible and accessible.
□Do not install behind shrubs. It will affect the dusk-to-dawn
photocell.
□Photocell will not operate properly if installed too close to a
nighttime light source.
□MOUNT AT LEAST 12 INCHES (30CM) ABOVE GROUND.
3Installing the transformer
□SAFE
Mount the transformer
□Option 1: Standard wall mounting
Insert the included support screw (H) in a wall near an electrical
outlet and mount the transformer.
□Option 2: Brick or cement wall mounting
Drill a 5/16 in. (8 mm) hole in a wall near an electrical outlet and
place the plastic anchor (I) included. Insert the screw in the
anchor until it has about 1/4 in. (6 mm) of space left to mount the
transformer.
□Place the wire connector (E) on opposite sides of the low
voltage cable (G) where the xture will be located.
□Align and t the main low voltage cable (G) vertically to the
slot of the wire connector (E) as shown.
□Press the wire connector (E) together until fully seated and
locked around the cable (G). Pre-set prongs will pierce the
cable insulation and establish contact. Turn on the power unit.
If the light xture does not turn on, repeat previous steps.
□Once the clip-on connector (E) is in place, wrap it with
electrical tape for additional protection.
□After all xtures are installed, turn on the transformer.
E
CAUTION: BE CAREFUL! THE WIRE STABS ARE VERY SHARP!

Care and Cleaning
Troubleshooting
Warranty
Cable Selection
□Clean the xture with a soft, dry cloth.
□Do not use any cleaners with chemicals, solvents or harsh abrasives.
The xture will not
light.
Only some lights
work.
• Thereisnopower.
• Thereisadisconnectionorbreakin
the wire.
• Thereisalightsourcenearthe
transformer.
• Therearetoomanyxtures
connected to the transformer.
•Theproblemiswiththexture’s
connector or LED.
• Checkthatthepowerison.
• Checkifthereisalooseconnectionatthetransformerscrewterminal.
• Makesurethephotocellisnotnearalightingsource.
• Removesomexturesthenpressthebuttonuntilthedesiredmodeis
selected. Make sure you are using less than 35 watts of xtures.
•Checktheconnectortomakesurethewirestabshavepiercedthelandscape
wire.
Problem Possible cause Solution
WHAT IS COVERED
The manufacturer warrants this lighting xture to be free from defects in materials and workmanship for a period of ve (5) years from the date of
purchase. This warranty applies only to the original consumer and only to products used in normal use and service. If this product is found to be
defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s discretion,
provided that the product has not been damaged through misuse, abuse, accident, modications, alterations, neglect or mishandling.
WHAT IS NOT COVERED
This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way not in accordance with the
instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence,
alteration or faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not apply to the nish on any
portion of the product, such as surface and/or weathering, as this is considered normal wear and tear.
The manufacturer does not warrant and specially disclaims any warranty, whether express or implied, of tness for a particular purpose, other than
the warranty contained herein. The manufacturer specically disclaims any liability and shall not be liable for any consequential or incidental loss or
damage, including but not limited to any labor / expense costs involved in the replacement or repair of said product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.hamptonbay.com
Total Fixture Wattage
0-60 Watts
61-120 Watts
121-180 Watts
181-240 Watts
241-300 Watts
600W Transformer = (2X300) Watts
900W Transformer = (3X300) Watts
51-100 feet
Cable Length
101-150 feet
16 AWG 16 AWG 14 AWG
16 AWG 14 AWG 12 AWG
14 AWG 12 AWG NOT RECOMMENDED
14 AWG 12 AWG NOT RECOMMENDED
12 AWG NOT RECOMMENDED NOT RECOMMENDED
12 AWG NOT RECOMMENDED NOT RECOMMENDED
12 AWG NOT RECOMMENDED NOT RECOMMENDED
0-50 feet
12 VOLT TAP
Total Fixture Wattage
0-60 Watts
61-120 Watts
121-180 Watts
181-240 Watts
241-300 Watts
600W Transformer = (2X300) Watts
900W Transformer = (3X300) Watts
51-100 feet
Cable Length
101-150 feet
16 AWG* 16 AWG 16 AWG
16 AWG* 16 AWG 12 AWG
14 AWG* 14 AWG 12 AWG
14 AWG* 14 AWG 12 AWG
12 AWG* 12 AWG NOT RECOMMENDED
12 AWG* 12 AWG NOT RECOMMENDED
12 AWG* 12 AWG NOT RECOMMENDED
0-50 feet
15 VOLT TAP
This data is provided as a general guideline. Actual performance will depend on the installation layout, the xtures, and the
condition of the cable. NOTE: Most LED landscape lighting xtures can operate with full illumination from 9V down to as little as
6V. It is possible to have extended length runs with LED xtures that go beyond the specications shown in the guidelines above.
Additional landscape lighting cable can be purchased at your local Home Depot store.
* NOT RECOMMENDED FOR HALOGEN LANDSCAPE LIGHTS
