HAMPTON BAY Hampton H15-NG Quick start guide

FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
918-219b
MODELS: H15-NG Natural Gas H15-LP Propane
01/09/06
H15 Direct Vent Gas Fireplace
Owners &
Installation Manual
WARNING:
If the information in these instructions are not
followed exactly, a fire or explosion may result
causing property damage, personal injury or loss
of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
This appliance may only be
installedinanaftermarketper-
manently located, manufac-
tured (USA only) or mobile
home, where not prohibited
by local codes.
This appliance is only for use
with the type of gas indicated
ontheratingplate.Thisappli-
anceisnotconvertibleforuse
withothergases,unlessacer-
tified kit is used.
Tested by: Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.hampton-fire.com

2Hampton H15 Direct Vent Freestanding Gas Stove
HAMPTON
Direct Vent Freestanding Gas Stove
UNIT DIMENSIONS
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Hampton Gas Stove by FPI FIREPLACE PRODUCTS INTERNATIONAL LTD.
The H15 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood
fireplace at the flick of a switch. The model H15 has been approved by Warnock Hersey for both safety and efficiency.
As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free
years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your
Hampton Stove.

Hampton H15 Direct Vent Freestanding Gas Stove 3
TABLE OF CONTENTS
Page Page
Support Extension - Round or Square .......................25
High Elevation.........................................................25
Gas Connection ......................................................25
System Data Chart .................................................25
Aeration Adjustment ................................................26
Gas Pipe Pressure Testing ......................................26
Valve Description ....................................................26
Conversion to Propane.............................................27
Log Installation .......................................................28
Optional Wall Thermostat ........................................30
Optional Remote Control..........................................30
Final Check ............................................................30
Wiring Diagram .......................................................31
Operating Instructions
Operating Instructions .............................................32
Lighting Procedure ..................................................32
Shutdown Procedure ...............................................32
First Fire ................................................................32
Adjusting Flame Height ...........................................32
Convection Fan Operation ........................................32
Copy of Lighting Plate Instructions ............................33
Normal Operating Sounds of
Gas Appliances ................................................34
Maintenance
Maintenance Instructions .........................................34
General Vent Maintenance.......................................35
Log Replacement ....................................................35
Glass Replacement .................................................35
Fan Maintenance ....................................................35
Removing and Installing Valve ..................................36
Parts List
Replacement Parts List ...........................................37
Warranty
Warranty ................................................................39
Safety Label
Safety Label ........................................................... 4
Installation
Specifications .......................................................... 5
Information for Mobile/Manufactured Home
After First Sale .................................................. 5
Before You Start ...................................................... 5
General Safety Information ........................................ 6
Installation Checklist ................................................ 6
Clearances to Combustibles ..................................... 6
Locating Your Gas Stove ......................................... 7
Manufactured Mobile Home Requirements.................. 7
Combustion and Ventilation Air ................................. 7
Optional Fan Installation ........................................... 7
Venting Introduction ................................................. 9
Installation Precautions ............................................ 9
Safety Precautions for the Installer ............................ 9
Vent Restrictor Position............................................ 9
Rotating Elbow ........................................................ 9
Exterior Vent Terminal Locations ..............................10
Rigid Pipe Venting Components List .........................11
Rigid Pipe Venting Systems
Horizontal or Verical Terminations ......................12
Horizontal Venting With Two Elbows .........................13
Veritcal Venting Wtih Two Elbows ............................14
Venting Arrangements - Horizontal Terminations ........15
Venting Arrangements - Vertical Terminations ...........15
Vertical Termination with Co-linear Flex system .........16
Horizontal Termination Kit ........................................17
Horizontal Termination Kit Installation ...........................17
Residential and Manufactured Homes / Mobile Homes
Minimum Horizontal Termination Installations ............19
Dura-Vent Termination Kits ......................................................20
Planning Your Dura-Vent Installation .....................................20
Dura-Vent Venting Components Parts List ................21
Minimum Dura-Vent Components - Horizontal
Installation........................................................21
Minimum Dura-Vent Components - Vertical
Termination ......................................................22
Converting a Class-A Metal Chimney or Masonry
Chimney to a Direct Vent System ............................24
Cathedral Ceiling Installations ..................................25

4Hampton H15 Direct Vent Freestanding Gas Stove
This is a copy of the label that accompanies
each DirectVentFreestandingGasStove.We
have printed a copy of the contents here for
your review.
SAFETY LABEL
Copy of Safety Label for H15-NG & H15-LP
NOTE: Hampton units are constantly being
improved.Checkthelabelontheunitandifthere
isadifference,thelabelontheunitisthecorrect
one.
FortheStateofMassachusetts, installation and repair must bedonebyaplumberorgasfitterlicensedinthe
Commonwealth of Massachusetts.
For the State of Massachusetts, flexible connectors shall not exceed 36 inches in length.
For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve.

Hampton H15 Direct Vent Freestanding Gas Stove 5
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The DirectVentFreestandingGasStovemust
be installed in accordance with these instruc-
tions. Carefully read all the instructions in this
manualfirst.Consultthebuildingauthorityhav-
ing jurisdiction to determine the need for a
permit prior to starting the installation.
Note: Failure to follow the instructions
could cause a malfunction of the
heaterwhichcouldresultindeath,
seriousbodilyinjury,and/orprop-
erty damage. Failure to follow
these instructions may also void
your fire insurance and/or war-
ranty.
Note: These instructions take prece-
dence over Simpson Dura-Vent
instructions.
SPECIFICATIONS
Fuels: H15-NG is approved for use with
natural gas.
H15-LP is approved for use with
liquefiedpetroleumgases(propane).
Electrical: 120V A.C. system.
Optional Circulation Fan:
Variable speed, 125/75.
Log Sets: Ceramic fibre, 4 per set.
Vent System:Coaxial(6-5/8"outer/4"inner
liner) rigid flue and termination cap.
INFORMATION FOR
MOBILE/
MANUFACTURED
HOMES AFTER
FIRST SALE
This Hampton product has been tested and
listedbyITS Testing ServicesasaDirectVent
Room Heater to the following standards:
CGA-2.17-M91,andANSIZ21.88B-2003/CSA
2.33B-2003.
This Direct Vent System Appliance must be
installed in accordance with the manufactur-
er's installation instructions and the Manufac-
turedHomeConstructionandSafetyStandard,
Title24CFR,Part3280,orthecurrentStandard
of Fire Safety Criteria for Manufactured Home
Installations,Sites,andCommunitiesANSI/NFPA
INSTALLATION
501A, and with CAN/CSA Z240-MH Mobile
Home Standard in Canada.
Thisapplianceinstallationmustcomplywiththe
manufacturer's installation instructions and lo-
calcodes,ifany.Intheabsenceoflocalcodes
followthecurrentNationalFuelGasCode,ANSI
Z223.1andthecurrentNationalElectricalCode
ANSI/NFPA 70 in the U.S.A., and the current
CAN/CGA B149 Gas Installation Code and the
currentCanadianElectricalCodeCSA C22.1 in
Canada.
This Hampton Mobile/Manufactured
Home Listed appliance comes factory
equipped with a means to secure the
unit.
This Hampton Mobile/Manufactured
Home listed appliance comes
equipped with a dedicated #8 ground
lug to which an 18 gauge copper wire
fromthesteelchassisgroundmustbe
attached.
Thisappliancemayonlybeinstalledin
an aftermarket permanently located,
manufactured (USA only) or mobile
home, where not prohibited by local
codes.
Thisapplianceisonly forusewiththe
type of gas indicated on the rating
plate. This appliance is not converti-
bleforusewith othergases,unlessa
certified kit is used.
INSTALLATION AND REPAIRS
SHOULD BE DONE BY A QUALI-
FIED SERVICE PERSON. THIS AP-
PLIANCESHOULDBEINSTALLED,
REPAIRED, INSPECTED BEFORE
USE AND AT LEAST ANNUALLY
BY A QUALIFIED SERVICE PER-
SON. MORE FREQUENT CLEAN-
ING MAY BE REQUIRED DUE TO
EXCESSIVE LINT FROM CARPET-
ING,ETC. ITISIMPERATIVETHAT
THE CONTROL COMPARTMENT,
BURNERS AND CIRCULATING AIR
PASSAGEWAYS OF THE APPLI-
ANCE BE KEPT CLEAN.
BEFORE YOU START
Safeinstallationandoperationofthisappliance
requires common sense, however, we are
required by the Canadian Safety Standards
andANSIStandardstomakeyouawareofthe
following:
1) Provide adequate clearances for servic-
ing, proper operation and around the air
openings into the combustion chamber.
2) The appliance must be installed on a flat,
solid,continuoussurface(e.g.wood,met-
al,concrete).Thismaybethefloor,oritcan
be raised up on a platform to enhance its
visual impact. The appliance may be in-
stalled on carpeting, tile, wood flooring or
other combustible material, because the
appliance'sbaseextendsthefullwidthand
depth of the appliance. The Direct Vent
FreestandingGasStovecanbeinstalledin
a wide variety of ways and will fit nearly
any room layout. It may be installed in a
recessedposition,framedoutintotheroom,
or across a corner.
3) The DirectVentFreestandingGasStove is
approved for alcove installations, which
meettheclearances listed onpage6. This
unit is approved for manufactured home
installations,seepage7andpages13to16
for the required vent arrangements. If in-
stalled into a manufactured home the unit
must be bolted down to the floor.
4) ThisapplianceisListedforbedroom instal-
lations when used with a Listed Millivolt
Thermostat.Someareasmayhavefurther
requirements, check local codes before
installation.
DUE TO HIGH TEMPERATURES,
THE APPLIANCE SHOULD BE LO-
CATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE AND
DRAPERIES.
WARNING: FAILURE TO INSTALL
THIS APPLIANCE CORRECTLY
WILLVOIDYOURWARRANTYAND
MAY CAUSE A SERIOUS HOUSE
FIRE.
CHILDRENANDADULTSSHOULD
BE ALERTED TO THE HAZARDS
OF HIGH SURFACE TEMPERA-
TURES, ESPECIALLY THE FIRE-
PLACE GLASS, AND SHOULD
STAY AWAY TO AVOID BURNS
OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISEDWHEN
THEYAREINTHESAMEROOMAS
THE APPLIANCE.
CLOTHING OR OTHER FLAMMA-
BLE MATERIAL SHOULD NOT BE
PLACEDONORNEARTHEAPPLI-
ANCE.

6Hampton H15 Direct Vent Freestanding Gas Stove
INSTALLATION
5) ThisapplianceisListedfor Alcove installa-
tions,maintainminimumAlcoveclearances
as follows, minimum width of 32-1/2"
(825mm),amaximumdepthof36"(914mm),
andminimumheightof24"(610mm)fromtop
of unit to ceiling.
6) We recommend that you plan your installa-
tion on paper using exact measurements
for clearances and floor protection before
actually installing this appliance. Have a
qualified building inspector review your
plans before installation.
GENERAL SAFETY
INFORMATION
1) The appliance installation must conform
with local Canadian Electrical Code.
2) Theappliancewheninstalled,mustbeelec-
trically grounded in accordance with local
codes,orintheabsenceoflocalcodeswith
the current National Electrical Code, ANSI/
NFPA 70 or CSA C22.1 Canadian Electrical
Code.
3) The appliance should be inspected for
shippingdamagebeforeuseandserviced
annuallybyaprofessionalserviceper-
son. More frequent cleaning may be re-
quiredduetoexcessivelintfromcarpeting,
bedding material, etc. It is imperative that
control compartments, and circulating air
passageways of the appliance be kept
clean and free from excessive lint from
carpeting.
4) See general construction and assembly
instructions.Theapplianceandventshould
be enclosed when installed in or passing
through a living area, where children may
come in contact with it.
5) This appliance must be connected to the
specified vent and termination cap to the
outside of the building envelope. Nev-
erventto another roomorinsideabuilding.
Make sure that the vent is fitted as per the
instructions starting on page 10.
6) Inspect the venting system annually for
blockage and any signs of deterioration.
7) Ventingterminalsshallnotberecessedinto
a wall or siding.
8) Any safety glass removed for servicing
must be replaced prior to operating the
appliance.
9) Topreventinjury,donotallowanyonewho
is unfamiliar with the operation to use the
fireplace.
INSTALLATION
CHECKLIST
1) Check Clearances to Combustibles (page
6), location of unit (page 7) and venting
requirements (pages 9-12).
2) Install Optional Fan, see page 7.
3) Set vent restrictor, page 9.
4) Install venting: Check all venting require-
ments, pages 9-22. Vertical Termination
with Co-linear Flex System, page 16. Hor-
izontalTerminationKits,page17. Minimum
HorizontalTermination,page19.Dura-Vent
Termination Kits, page 20-23.
5) Make gas connections, page 25. Test the
pilot. Must be as per diagram, page 34.
If converting to Propane, make changes
prior see pages 27.
6) Test Gas Pressure, page 26.
7) Installlogsandemberswhereindicatedon
page 28-29.
8) InstalloptionalRemoteControl,orWallTher-
mostat, page 30.
9) Final check, page 30.
Before leaving this unit with the customer, the
installermustensurethattheapplianceisfiring
correctly and operation fully explained to
customer.
This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on label) after
burning appliance for 15 minutes.
2) If required, adjusting the primary air to
ensurethattheflamedoesnotcarbon.First
allow the unit to burn for 15-20 min. to
stabilize.
CAUTION: Any alteration to the product
that causes sooting or carboning that
resultsindamageisnottheresponsibil-
ity of the manufacturer.
CLEARANCES TO
COMBUSTIBLES
The clearances listed are MINIMUM distances.
Measure the clearance to both the appliance
and the chimney connector. The farthest
distance is correct if the two clearances
do not coincide.
Forexample,iftheapplianceissetasindicated
in one of the figures but the connector is too
close, move the stove until the correct clear-
ance to the connector is obtained.
This appliance may be installed only with the
clearancesasshowninthesituationspictured.
Do not combine clearances from one
type of installation with another in order
to achieve closer clearances.
Thisunitcanbeinstalledonasolidcombustible
surfacelikeawoodfloor.Thisunitcanalsobe
installed directly on carpeting or vinyl.
Use the minimum clearances shown in the
diagrams below:
H15-NG & H15-LP Clearances
ALeft Side Wall to Unit*6" /150 mm
*BBack Wall to Unit 0" /0 mm
CVertical Vent Pipe to Back Wall
2" /50 mm
EUnit Corner to Wall 2" /50 mm
Unit Top to Alcove Ceiling 24" /610 mm
Minimum ceiling height is 24" /610 mm from top
of unit.
*IMPORTANT
Itisrecommendedthatunitismovedawayfrom
the wall, if installing the blower option, so the
fan can be easily installed and/or serviced.
Emissions from burning wood or gas could
contain chemicals known to the State of
California to cause cancer, birth defects or
other reproductive harm.

Hampton H15 Direct Vent Freestanding Gas Stove 7
LOCATING YOUR
GAS STOVE
When selecting a location for your stove, en-
surethattheclearanceslistedabovearemetas
wellas ensuring that thereis adequate acces-
sibility for servicing and proper operation.
MANUFACTURED
MOBILE HOME
ADDITIONAL
REQUIREMENTS
1) Ensurethatstructuralmembersarenotcut
or weakened during installation.
2) Ensure proper grounding using the #8
ground lug provided.
3) Appliance must be anchored to the floor
with the supplied anchoring methods.
COMBUSTION AND
VENTILATION AIR
Thecombustionairfromthisapplianceisdrawn
fromoutsidethebuildingthroughtheouterflue.
Extraprovisionforcombustionairinside
the room is not required.
A) Cross Corner
B) Room Divider
C) Island
D) Flat on Wall
E) Flat on Wall Corner
F) Flush with Wall/Alcove
For Vent Termination requirements,
see page 10.
INSTALLATION
OPTIONAL FAN
INSTALLATION
Fan Kit Contains:
Qty. Description
1Fan Assembly c/w green wire attached
1Thermodisc
1Fan Speed Control
1Grommet
1) Removetherearaccesspanelontheback
of the stove by removing the 2 screws
undertherearpanel,thenliftrearpaneloff
of 2 bolts at the top. Take care not to cut
wires when lowering the panel.
2) Disconnect the red and grey wires.
Top Control Panel Assembly
Fan Speed
Controller
4) Removethenylonholeplugfromthecontrol
panel.
5) Install the fan speed controller onto the
control panel and secure with nut and
washer. Connect the red and black wires
fromthewireharnesstospeedcontroller.
NOTE:Speedcontrolwiresmustbein
thedown positionwhen controlpan-
el is in place.
6) Push black knob onto speed control.
screw screw
Lift Rear Panel off of the 2 top bolts.
bolt
3) Remove theTopControlPanelAssemblyby
removing the three screws.
7) Re-attach control panel with 3 screws,
reversing step 3.
8) SlideThermodiscintothebracketontheleft
side of the rear firebox.
ThermodiscThermodisc
Bracket
* 12' max. only if vertical height is achieved.

8Hampton H15 Direct Vent Freestanding Gas Stove
INSTALLATION
9) Remove 2 screws from unit.
10)Place grommet in rear plate through the
bottom of the opening as shown below.
11)Placetheblowerclosetothebaseoftheunit
and feed the wires through the grommet in
the rear plate.
16)Slide the Rear Access Panel back into
position and secure with 2 screws.
WARNING: Electrical Grounding Instructions
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be
pluggeddirectlyintoaproperlygroundedthree-prongreceptacle.Donotcutorremove thegroundingprongfromthisplug.
12)Slidefanintoplaceandsecurewiththetwo
screws removed in step 9.
GrommetRear Plate
Wires
13)Connect long black & red wires to thermo-
disc and secure wires.
14)Connectfangroundwiretolugnutatbase
of unit.
15)Beforere-attachingtherearaccesspanel,
the valve wires and the fan wires need to
be connected.
Re-connect the red and grey valve wires
removed in step 2.
Connect the black and white fan wires as
per the wiring diagram below.
Lug Nut

Hampton H15 Direct Vent Freestanding Gas Stove 9
INSTALLATION
PRECAUTIONS
These venting systems are engineered prod-
ucts that have been designed and tested for
usewiththeH15-NG,andH15-LP.Thewarran-
tywillbevoidedandseriousfire,healthorother
safety hazards may result from any of the
following actions:
1) Installation of any damaged Direct Vent
component
2) UnauthorizedmodificationoftheDirectVent
System
3) Installationofanycomponentpartnotman-
ufactured or approved by Simpson Dura-
VentorFPIFireplaceProductsInternational
Ltd.
4) InstallationotherthanasinstructedbySimp-
son Dura-Vent and FPI Fireplace Products
International Ltd.
Warning: Alwaysmaintainrequired
clearances (air spaces) to nearby
combustibles to prevent a fire haz-
ard. Do not fill air spaces with insu-
lation.
Besuretochecktheventterminationclearance
requirements from decks, windows, soffits,
gas regulators, air supply inlets and public
walkways as specified in the Exterior Vent
TerminalLocationsonpage10andinyourlocal
building codes.
Thegasapplianceandventsystemmust
be vented directly to the outside of the
building,andneverbeattachedtoachim-
ney serving a separate solid fuel or gas-
burning appliance. Each direct vent gas
appliance must use it's own separate vent
system.Commonventsystemsareprohibited.
VENTING
INTRODUCTION
TheHorizontalTerminationKitandtheSimpson
Dura-Vent Direct Vent System Model DV-GS
ventingsystems,incombinationwiththeDirect
Vent Freestanding Gas Stoves, H15-NG, and
H15-LP, have been tested and listed as direct
vent heater systems by Warnock Hersey.
These units use the "balanced flue" technol-
ogy Co-Axial system. The inner liner vents
productsofcombustiontotheoutsidewhilethe
outer pipe draws outside combustion air into
the combustion chamber thereby eliminating
theneedtouseheatedroomairforcombustion
and losing warm room air up the chimney.
Note: These flue pipes must not be
connected to any other appliance.
The gas appliance and vent system must be
vented directly to the outside of the building,
and never be attached to a chimney serving a
separate solid fuel or gas burning appliance.
Each direct vent gas appliance must use it's
ownseparateventsystem.Commonventsys-
tems are prohibited.
IMPORTANT
Read all instructions carefully before starting
theinstallation.Failuretofollow these instruc-
tionsmaycreate a fireorothersafetyhazard,
andwillvoidthewarranty.Besuretocheckthe
ventingandclearancetocombustiblerequire-
ments.Consultyourlocalbuildingcodesbefore
beginning installation.
The location of the termination cap must con-
form to the requirements in the Exterior Vent
Terminal Locations on page 10.
SAFETY
PRECAUTIONS FOR
THE INSTALLER
1) Wear gloves and safety glasses for pro-
tection.
2) Exerciseextremecautionwhenusinglad-
ders or on roof tops.
3) Be aware of electrical wiring locations in
walls and ceilings.
VENT RESTRICTOR
POSITION
To set the Vent restriction as indicated in the
Venting Arrangement diagrams on pages 13-
16, simplyloosenthescrewsandpushthevent
restrictor plate to the correct position. Tighten
the screws. This will be located inside the
firebox.
INSTALLATION
ROTATING ELBOW
1) Remove top casting.
2)Removeall4screwsthatsecure
the elbow to the unit using a 1/4"
magnetic nut driver.
3) Rotate the elbow 180o
4)Securetheelbowbysecuring
it with the 4 screws.
Remove all 4 screws
and washers

10 Hampton H15 Direct Vent Freestanding Gas Stove
EXTERIOR VENT TERMINAL LOCATIONS
A= Clearance above grade, veranda, porch, deck, or balcony *(min. 12"/30cm) B= Clearance to window or door that may be opened *(12"/30cm) C= Clearance to permanently closed window *(min. 12"/30cm) D= Vertical clearance to ventilated soffit located above the terminal within a horizontal
distance of (24"/60cm) from the centerline of the terminal (min. 22"/55cm) check with local code.
E= Clearance to unventilated soffit (min. 12"/30cm) F= Clearancetooutsidecorner:withAstroCapTerminationCap(min.6"/15cm),withDura-
Vent Termination Cap (min.12"/30cm), with Riser Vent (min. 6"/15cm)
G= Clearancetoinsidecorner:withAstroCapTerminationCap(min. 6"/15cm),withDura-
Vent Termination Cap (min.12"/30cm), with Riser Vent (min. 6"/15cm)
H= Nottobeinstalledaboveameter/regulatorassemblywithin(3'/90cm)horizontallyfrom
the centerline of the regulator.
J= Clearance to service regulator vent outlet *(min. 36"/90cm) K= Clearance to non-mechanical air supply inlet to building or the combustion air inlet to
any other appliance *(12"/30cm)
L= Clearance to a mechanical air supply inlet *(min. 72"/1.8m) M= **Clearanceabove paved sidewalk or apaved driveway located on publicproperty
*(min. 84"/2.1m)
N= Clearance under veranda, porch, deck, or balcony *(min. 12"/30cm)*** Note:*AsspecifiedinCGAB149InstallationCode. Note:Localcodesor regulationsmay require different clearances. **Aventshallnotterminatedirectlyaboveasidewalkorpaveddrivewaywhichislocated between two single family dwellings and serves both dwellings. ***Only permitted if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor.
INSTALLATION

Hampton H15 Direct Vent Freestanding Gas Stove 11
INSTALLATION
946-506/P Vent Guard (Optional)
640-530/P Riser Vent Terminal
946-205 Vinyl Siding Shield for Riser Vent Terminal
946-208/P Vent Guard (Optional) - Riser Vent Terminal
946-523/P AstroCap Horizontal Cap
946-206 Vinyl Siding Standoff - AstroCap
RIGID PIPE VENTING COMPONENTS LIST
All Simpson Dura-Vent components are available directly from FPI.
Description Simpson Dura-Vent Selkirk AmeriventR
Direct VentGSRDirect-TempTM Direct Vent
6" Pipe Length, Galvanized 908 4DT-6 N/A
6" Pipe Length, Black 908B 4DT-6B N/A
7" Pipe Length, Galvanized N/A N/A 4D7
7" Pipe Length, Black N/A N/A 4D7B
9" Pipe Length, Galvanized 907 4DT-9 N/A
9" Pipe Length, Black 907B 4DT-9B N/A
12" Pipe Length, Galvanized 906 4DT-12 4D12
12" Pipe Length, Black 906B 4DT-12B 4D12B
18" Pipe Length, Galvanized N/A 4DT-18 N/A
18" Pipe Length, Black N/A 4DT-18B N/A
24" Pipe Length, Galvanized 904 4DT-24 4D2
24" Pipe Length, Black 904B 4DT-24B 4D2B
36" Pipe Length, Galvanized 903 4DT-36 4D3
36" Pipe Length, Black 903B 4DT-36B 4D3B
48" Pipe Length, Galvanized 902 4DT-48 4D4
48" Pipe Length, Black 902B 4DT-48B 4D4B
Adjustable Length, 11"-14", Galv. 911 4DT-AJ N/A
Adjustable Length, 11"-14", Black 911B 4DT-AJB N/A
Adjustable Length, 17"-24", Black 917B N/A N/A
Adjustable Length, 7" Galvinized N/A N/A 4D7A
Adjustable Length, 7" Black N/A N/A 4D7AB
Adjustable Length, 12" Galvinized N/A N/A 4D12A
Adjustable Length, 12" Black N/A N/A 4D12AB
45OElbow, Galvinized 945 4DT-EL45 4D45L
45OElbow, Black 945B 4DT-EL45B 4D45LB
45OElbow, Swivel, Galvinized 945G N/A N/A
45OElbow, Swivel, Black 945BG N/A N/A
90OElbow, Galvinized 990 4DT-EL90S 4D90LS
90OElbow, Black 990B 4DT-EL90SB 4D90LBS
90OElbow, Swivel, Galvinized 990G N/A N/A
90OElbow, Swivel, Black 990BG N/A N/A
Ceiling Support 949 - n/a from FPI 4DT-CS 4DFSP
Cathedral Support Box 941 4DT-CSS 4DRSB
Wall Support/Band 988 4DT-WS/B 4DWS
Offset Support 989 - n/a from FPI 4DT-OS N/A
Wall Thimble, Black 942 4DT-WT 4DWT
Wall Thimble Support Box/Ceiling Support 940 N/A N/A
Firestop Spacer 963 4DT-FS 4DFSP
Trim Plate, Black N/A 4DT-TP 4DFPB
Brass Trim for Wall Thimble/Ceiling Support 3951 N/A N/A
Attic Insulation Shield 12" N/A N/A 4DAIS12
Attic Insulation Shield - Cold Climates 36" N/A N/A 4DAIS36
Basic Horizontal Termination Kit (A) 970 4DT-HKA 4DHTK2
Horizontal Termination Kit (B) 971 4DT-HKB 4DHTK1
Vertical Termination Kit 978 4DT-VKC 4DVTK
High Wind Vertical Cap 991 N/A N/A
High Wind Horizontal Cap 985 N/A N/A
Horizontal Square Termination Cap 984 4DT-HHC 4DHC
Verical Termination Cap 980 4DT-HVC 4DVC
Storm Collar 953 4DT-SC 4DSC
Adjustable Flashing, 0/12-6/12 943 4DT-AF6 4DF
Adjustable Flashing, 6/12-12/12 943S 4DT-AF12 4DF12
Vinyl Siding Standoff 950 4DT-VS N/A
Vinyl Siding Shield Plate N/A 4DT-VSP N/A
Snorkel Termination 14" 982 4DT-ST14 4D12S
Snorkel Termination 36" 981 4DT-ST36 4D36S

12 Hampton H15 Direct Vent Freestanding Gas Stove
RIGID PIPE VENTING SYSTEMS
Horizontal or Vertical Terminations
Alternate
Horizontal
Termination
Caps
INSTALLATION
The FPI AstroCapTMand FPI Riser Vent terminal is certified for installations using FPI venting systems as well as Simpson Dura-Vent®, Direct Vent
GS, American Metal Products, Ameri Vent Direct vent and Selkirk Direct-Temp. FPITM, and FPI AstroCapTM are the proprietary trademarks of FPI
Fireplace Products International Ltd. Dura-Vent®and Direct Vent GS are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc.
ThisproducthasbeenevaluatedbyIntertekfor
using a Dura-Vent Flue Adaptor in conjunction
withSelkirkDirect-TempandAmeriVentDirect
venting systems. Use of these systems with
the Direct Vent GS starting collar is deemed
acceptableanddoesnotaffecttheIntertekWHI
listing of components.
WARNING:
Do not combine venting components from
different venting systems.
However use of the the AstroCapTM and FPI
Riser is acceptable with all systems.
When using piping other than Simpson
Dura-Vent, 3 screws must be used to
secure rigid pipe to adaptor.

Hampton H15 Direct Vent Freestanding Gas Stove 13
Horizontal Venting with Two (2) 90oElbows
Option V H + H1
A) 1' Min. 3' Max.
B) 2' Min. 4' Max.
C) 3' Min. 5' Max.
D) 4' Min. 6' Max.
E) 5' Min. 7' Max.
F) 6' Min. 8' Max.
Horizontal Venting with Two (2) 90oElbows
Option H V H + H1
A) 1' Max. 1' Min. 3' Max.
B) 2' Max. 2' Min. 5' Max.
C) 3' Max. 4' Min. 6' Max.
D) 4' Max. 6' Min. 7' Max.
E) 5' Max. 8' Min. 8' Max.
With these options, max.
total pipe length is 30 feet
with min. of 8 feet total
vertical and max. 8 feet
total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
With these options, maxi-
mum total pipe length is 30
feetwithminimumof6feet
total vertical and maximum
8 feet total horizontal.
Pleasenote minimum1
footbetween 90oelbows
is required.
INSTALLATION
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
Vent restrictor position A (fully open), refer to page 9
Vent restrictor position A (fully open), refer to page 9
Lengths do not include elbow indicated
Lengths do not include elbow indicated

14 Hampton H15 Direct Vent Freestanding Gas Stove
Vertical Venting with Two (2) 90oElbows
Option VH V + V1
A) 1' Min. 4' Max. 2' Min.
B) 2' Min. 5' Max. 3' Min.
C) 3' Min. 6' Max. 4' Min.
D) 4' Min. 7' Max. 5' Min.
E) 5' Min. 8' Max. 6' Min.
Vertical Venting with Two (2) 90oElbows
Withtheseoptions, max. total
pipelengthis30feetwithmin.
of6feettotalverticalandmax.
8 feet total horizontal.
Please note min. 1 foot
between 90oelbows is re-
quired.
Option H + H1 V
A) 2' Max. 2' Min.
B) 3' Max. 3' Min.
C) 4' Max. 4' Min.
D) 5' Max. 5' Min.
E) 6' Max. 6' Min.
Withtheseoptions,max.total
pipelengthis30feetwithmin.
of 6 feet total vertical and
max. 6 feet total horizontal.
Please note min. 1 foot
between 90oelbows is re-
quired.
INSTALLATION
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
Vent restrictor position A (fully open), refer to page 9
Vent restrictor position A (fully open), refer to page 9
Lengths do not include elbow indicated
Lengths do not include elbow indicated

Hampton H15 Direct Vent Freestanding Gas Stove 15
INSTALLATION
Offset to Vertical Terminations
Venting Arrangements - Horizontal Terminations
VENTING ARRANGEMENTS
Vertical Terminations Systems for
Residential Manufactured and Mobile Homes
The shaded area in the diagram below shows all allowable combinations of
straight vertical and offset to vertical runs with vertical terminations.Maxi-
mum two 45oelbows.
If the vent is ENCLOSED in a chase (min. size 9" x 9") maintain a 1-1/4" clearance to
combustibles.
May be installed in Manufactured (Mobile) Homes after first sale.
Horizontal Terminations for
All Venting Systems
Theshadedareasinthediagrambelowshowall
allowable combinations of vertical runs with
horizontal terminations. Maximum one 90Oel-
bow (two 45o elbows equal one 90oelbow).
Propane and Natural Gas:
Residential, Manufactured and Mobile
Homes Installations
May be installed in Manufactured (Mobile)
Homes after first sale.
The two diagrams show all allowable
combinationsofstraighthorizontal ter-
minationwithone45oelbowofftheunit.
Restrictor position "A".
12" max. w/AstroCap & Simpson Duravent
Horizontal Square Termination Cap.
24" max. w/FPI Riser & Simpson Duravent
Snorkel Termination Cap.

16 Hampton H15 Direct Vent Freestanding Gas Stove
Venting Arrangements - Vertical Terminations
with Co-linear Flex System for both
Residential & Manufactured Homes
into Masonry Fireplaces
The shaded area in the diagram shows the allowable
vertical terminations.
VERTICAL TERMINATION WITH CO-LINEAR FLEX SYSTEM
THE APPLIANCE MUST NOT BE
CONNECTED TO A CHIMNEY FLUE
SERVING A SEPARATE SOLID FUEL
BURNING APPLIANCE.
Thisapplianceisdesignedtobeattachedtotwo
3" (76mm) co-linear aluminium flex running the
full length of the chimney. See the Venting
Arrangements chart below for minimum and
maximum flue lengths. See chart below for
minimumdistancesfromroof.Periodicallycheck
that the vent is unrestricted.
Masonry chimneys may take various contours which the flexible liner will accommodate.
However, keep the flexible liner as straight as possible, avoid unnecessary bending.
The Air Intake pipe must be attached to the inlet air collar of the termination cap.
Straight Vertical Terminations
INSTALLATION
Required Parts:
Part # Description
946-529 Co-linear DV Vertical
Termination Cap
948-305 3" Flex - 35 ft.
946-563 Co-AxialtoCo-Linear Adapter Kit
which contains the following:
Co-linear Flex Adapter (270-585)
Outer Pipe (946-257)
Inner Pipe Adapter (946-219)
Alternate Approved Caps
980 Vertical Termination Cap
991 High Wind Cap
923GK 3" Co-linear Adapter with flashing
Vent Restrictors
set at fully closed,
Position "B"

Hampton H15 Direct Vent Freestanding Gas Stove 17
DV STOVE HORIZONTAL VENT KIT (#946-116 & #946-216) INSTALLATION
Reviewthefollowingsequenceofinstructions
which are typical of most installations. The
sequence may vary depending on wall thick-
ness. Refer to pages 10 to 16 for vent
location and clearance dimensions, and
page 9 to set the Vent Restrictor to the
correct position.
1) Settheunit in itsdesiredlocation.Checkto
determineifwallstudswillbeinthewayof
the venting system, adjust location until all
clearances are met and there are no ob-
structions.
Note: A 1-1/2"(38mm) clearance around
theouterpipemustbemaintained
exceptthatonlya1"(25mm)clear-
ance is needed at the termination
end.
IMPORTANT:
Do not locate termination hood
where excessive snow or ice build-
upmayoccur.Besuretocheckvent
termination area after snow falls,
and clear to prevent accidental
blockage of venting system. When
using snow blowers, make sure
snow is not directed towards vent
termination area.
b) Install wall thimbles on both interior
andexteriorwallwith4woodscrews
(#8 x 1") per thimble.
c) Attach the 2 piece adjustable pipe
section to the vent terminal and slide
into position from the exterior. The
larger diameter end of the ad-
justable pipe goes to the vent
terminal.
d) Installthe90oelbowontotheadjusta-
ble pipe to determine the vertical
centerline.
Note: if the centerline cannot be
met,theadjustablesectionswill
have to be cut.
e) Cut the 4 ft. section of rigid pipe to
length. Attach the 45oelbow to the
rigid pipe, and ensure that the pipe
lengthwhencut (withthe45oelbow)
will seat onto both the starter collar
and the 90oelbow. Crimped sec-
tionofrigidpipeseatsintothe90o
elbow. Only cut the uncrimped
side of pipe.
Dismantle all pipe sections including vent
terminal.
2) Assemble a trial fit to determine the ver-
tical center-line for the vent termination.
a) Cuta9-1/2"x9-1/2"(241mmx241mm)
square hole on both the interior and
exterior wall.
INSTALLATION
DV STOVE HORIZONTAL VENT KIT
DV 2 ft. Stove Vent Kit (Part # 946-116) and DV 4 ft. Stove Vent Kit (946-216) includes all the parts needed
to install the H15 Direct Vent unit with up & out horizontal and vertical vent dimensions. For installations that
require longer vertical and/or horizontal vents use the Dura-Vent system as shown on page 16.
Qty. Description
1) 1Rigid Pipe Section (Kit # 946-116: 2 ft. (1.2m) length,
Kit # 946-216: 4 ft. (1.2m) length), 6-1/2" (165mm)
inside diameter
2) 1Flex Liner, compressed aluminium 2 ply liner, 4" (102mm)
inside diameter
3) 4spring spacers
4) 190 deg. Elbow
5) 1Adjustable pipe section 13-1/2" to 24" (343mm x 610mm), 2 pcs.
6) 1Thimble Cover
7) 1Wall Thimble (2 pcs.)
8) 1Adapter
9) 1AstroCapTermination Cap
10) 2Trim Collars
11) 1tube of Mill-Pac, high temperature sealant
12) 12 Screws, #8 x 1/2" Self tapping, Stainless Steel
13) 14 Screws, #8 x 1/2" Self tapping, Black
14) 4Screws #8 x 1-1/2" Drill Point, Black
15) 4Screws #8 x 1-1/2" Drill Point, Stainless Steel
16) 8Wood screws #8 x 1"
Note:
a) Linersectionsshouldbecon-
tinuous without any joints or
seams.
b) This is an approved system,
thereforecomponentsinthis
system must not be substi-
tuted for any other manufac-
turer's products.

18 Hampton H15 Direct Vent Freestanding Gas Stove
INSTALLATION
Note: The pipe
seam
shouldbe
facing
down.
Note: Tomaketheinstallationmoreaes-
thetically pleasing, we recom-
mend framing out a square that
the cap can be mounted on.
Note: If installing ter-
mination on a
siding covered
wall, a vinyl sid-
ing standoff or
furring strips
mustbe usedto
ensure that the
termination is
not recessed into the siding. For
vinyl siding standoff installation
refer to the Dura-Vent Termina-
tion instructions.
3) Attach the 4" dia. flex liner to the vent
terminalensuringthattheflexoverlapsthe
collar of the vent terminal by a minimum of
1-3/8"(35mm). Use Mill-Pac to seal and
secure with 3 of the #8 x 1/2" screws
(stainless steel).
4) Attach the adjustable pipe section to the
vent terminal using Mill-Pac and/or high
temperature silicone and attach with 3 of
the #8 x 1/2" screws (stainless steel).
Hint: Apply the sealant (Mill-Pac and/or high
temperaturesilicone)totheouterpipebefore
connecting the inner pipe.
5) Slidethepartiallyconnectedpipeandvent
terminal assembly through the wall thim-
bles(fromtheexteriorintotheinterior)and
secure the cap to the exterior wall with 4
of the supplied screws (#8 x 1-1/2" drill
point,stainlesssteel).Note:pilotholeswill
need to be drilled through the wall thimble
on all 4 corners.
Note: Thefourscrewsprovidedforthe
ventcap shouldbe replacedwith
appropriatefastenersforstucco,
brick,concrete, orother typesof
sidings.
6) Abeadofnon-hardeningmasticshouldbe
run around both the termination and vinyl
siding standoff to prevent water from
enteringandtomake a tightsealbetween
the cap and the standoff.
7) Stretchthe4"dia.flexlineroutfullyandget
atrial fit of the liner onto the4" dia. starter
collar.
8) Cutthe4"dia.flexlinertothedesiredsize.
Hint:leaveanextra12"to16"oflength,this
willmakethefinalassemblyeasiertowork
with.
9) Securethe4"dia.flexlinertothe4"adapter
withMill-Pacand3ofthe#8x1/2"screws
(stainless steel).
10)Slide the decorative Thimble Cover over
thepipesectionsandsecurewith4screws
(#8 x 1-1/2" drill point, black) to the wall.
11)Slidethe90oelbow(crimpendup),the45o
elbowandthe4ft.pipesection(crimpend
up) over the 4" dia. flex liner.
12)Install the spring spacers onto the pipe
sections.
13)Secure the 4" dia. flex liner with adapter
ontothestovecollar.PutabeadofMill-Pac
around the appliance adapter and secure
with 3 screws (#8 x 1/2, stainless steel).
14)Attachthe45oelbowontothestartercollar
by sealing with Mill-Pac and/or high tem-
peraturesiliconeandsecuringwith3ofthe
#8 x 1/2" (black) screws.
15)Attachthepipesectiontothe45oelbowby
sealingwithMill-Pacand/orhightempera-
turesiliconeand securing with3ofthe#8
x1/2"screws(black).Pipe seams should
be facing the wall.
16)Attach the 90oelbowontothepipesection
by sealing with Mill-Pac and/or high tem-
peraturesiliconeandsecuringwith3ofthe
#8 x 1/2" screws (black).
17)Slide the adjustable pipe section onto the
90oelbow. Slide the trim collar over the
adjustable pipe sections to cover the joint
of the telescopic section.) The flex may
have to be compressed back in order for
theadjustable pipe to properlymate to the
elbow. Seal with Mill-Pac and/or high
temperaturesiliconeandsecurewith 3 of
the #8 x 1/2" screws (black). Pipe seams
facing down.
18)Install the trim collar over the starter collar
andsecurewitha#8x1/2"screw(black).
If the pipe needs to be touched up, use only
Stove Brite High Temperature Metallic Black
Stove Paint.
NOTE: All inner joints must be sealed
with Mill-Pac. All outer joints may
be sealed with high temperature
silicone.

Hampton H15 Direct Vent Freestanding Gas Stove 19
INSTALLATION
RESIDENTIAL AND MANUFACTURED HOMES / MOBILE HOMES
MINIMUM HORIZONTAL TERMINATION INSTALLATIONS
Planning Your venting Installation
See page 10 for Exterior Vent Termina-
tion requirements.
When planning your installation, it will be nec-
essarytoselect the proper length of ventpipe
foryourparticularrequirements.Determinethe
minimum clearance to combustibles from the
rearoftheunittothewall.Itisalsoimportantto
notethewallthickness.Beforecuttingthevent
holethroughthewallensurethatALLventand
termination clearances (see page 10) will be
met.
*If this is an outside corner, the minimum dis-
tancebetweentheventandtheoutsidecorner
is6"(15cm).See"F"onthediagramonpage10.
NOTE:Ensurecompliancewiththeoutsidevent
terminal location before cutting hole as both
dimensions must be met.
Minimum components for a Horizontal Installation:
640-944 Horizontal Termination Kit which includes:
16-5/8" Dia. x 18" Black Pipe
14" Dia. x 18" Aluminum Vent
1946-202 Wall Penetration Heat Shield (Wall Thimble) (2 pcs)
1640-530/P Riser Vent Terminal
1640-545/P Decorative Wall Trim (Black)
1948-128 Tube Mill-Pac Screws
380-946 Horizontal Termination Kit which includes:
16-5/8" Dia. x 12" Black Pipe
14" Dia. x 12" Aluminum Vent
1946-202 Wall Penetration Heat Shield (Wall Thimble) (2 pcs)
1946-523/P AstroCap
1640-545/P Decorative Wall Trim (Black)
1948-128 Tube Mill-Pac Screws
Optional Components:
946-204 45oElbow - 6-5/8" Black pipe 946-523/P AstroCap
and 4" Aluminum Vent 946-206 VinylSidingStandoff (AstroCap)
946-205 Vinyl Siding Shield for Riser Vent 946-506/P Vent Guard (AstroCap)
Terminal
946-208/P Vent Guard (Riser Vent Terminal)
940 Square Wall Thimble Cover*
981 Snorkel Termination (36")*
982 Snorkel Termination (14")*
942 Wall Penetration
Heat Shield*
* Simpson Dura-Vent Components
YouwillrequirethefollowingcomponentswithyournewHampton DirectVentFreestandingGas
Stove.Pleasereviewyourproducttomakesureyouhaveeverythingyouneed.Intheeventthat
youaremissing any part,contactyourdealer.Decorativebrass or chrometrimkitsareavailable
from Simpson Dura-Vent for their wall thimbles, as well as a square wall thimble cover.
Note: Thesearetheminimumpiecesrequired.Otherpartsmayberequiredforyour
particular installation.
Kit #640-944
Kit #380-946

20 Hampton H15 Direct Vent Freestanding Gas Stove
Dura-Vent Basic
Horizontal Kit # 970
1 90oElbow
1Wall Thimble Cover
1Horiz. Sq. Term. Cap
DURA-VENT TERMINATION KIT
Planning Your Dura-Vent
Installation
Therearetwobasic types ofDura-VentDirect
Vent System installations: horizontal termina-
tion and vertical termination. Confirm the max-
imum horizontal run and maximum vertical rise
from the diagrams on page 13-16.
When planning your installation, it will be nec-
essary to select the proper length of vent pipe
foryourparticularrequirements.Forhorizontal
installations, determine the minimum clearance
from the rear of the unit to the wall. It is also
important to note the wall thickness. (The wall
thimble is suitable for 2 x 4 or 2 x 6 wall
construction.) Select the amount of vertical
rise desired for "vertical-to-horizontal" type
installations.
Warning: Alwaysmaintainrequired
clearances (air spaces) to nearby
combustibles to prevent a fire haz-
ard. Do not fill air spaces with insu-
lation.
Theminimumclearancerequirementsbetween
the outer wall of the vent pipe and nearby
combustiblesurfacesis1-1/4inch.Besureto
check the vent termination clearance require-
mentsfromdecks,windows,soffits,gasreg-
ulators, air supply inlets and public walkways
as specified in the Exterior Vent Terminal Lo-
cations on page 10 and in your local building
codes.
To determine the length of vent pipe required
forverticalinstallations,measurethedistance
fromtheunitflueoutlettotheceiling,theceiling
thickness,theverticalriseinanatticorsecond
storey, and allow for sufficient vertical height
above the roof line.
For multi-storey applications, fire stops are
required at each floor level. If an offset is
needed, additional pipe, elbows and supports
will be required.
Donotexceedthemaximumnumberofelbows.
One90oforhorizontalterminationsandtwo45o
for vertical termination.
AstroCap
Part# 946-523/P
Alternate Horizontal
Termination Caps
Alternate
Horizontal
Riser Vent
Terminal
Part# 640-530/P
INSTALLATION
The FPI AstroCapTM is certified for installations using FPI venting
systems as well as Simpson Dura-Vent® and Direct Vent GS.
The FPI AstroCapTM is a proprietary trademark of FPI Fireplace
Products International Ltd.
Dura-Vent®and Direct Vent GS are registered and/or proprietary
trademarks of Simpson Dura-Vent Co. Inc.
