H&S POWER BOX Installation and maintenance instructions

OPERATOR’S MANUAL
and
PARTS LIST
READ AND UNDERSTAND THIS
MANUAL BEFORE OPERATING
THIS EQUIPMENT.
UNSAFE OPERATION OR
MAINTENANCE OF THIS
EQUIPMENT CAN RESULT
IN SERIOUS INJURY
OR DEATH.
H&S
REAR UNLOAD
POWER BOX
3-11-09
WARNING
Manufactured By
H&S MANUFACTURING CO., INC.
P.O. BOX 768 • [phone] FAX [phone]
MARSHFIELD, WISCONSIN 54449

H&S
REAR UNLOAD
POWER BOX
CONTENTS
Warranty & Warranty Registration Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Dealer Pre-Delivery & Delivery Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Be Alert Symbol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ExplanationofSafetySigns ....................................................6
Warning-DangerDecals......................................................7
Warning - Owner Must Read and Understand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
BeforeOperation-Adjustments.............................................. 9-10
Lubrication Guide ...........................................................11
FieldOperation-RearDoorLatches ............................................12
DecalLocation&Identification.............................................. 13-14
OrderingParts-AboutImprovements ...........................................14
Figure 1 - Light Assembly - Wiring Code - Description...............................15
Figure 2 - Rear Unloading Assembly - Description............................... 16-17
Figure 3 - Box Component Parts - Description .................................. 18-19
Figure4-Tie-Down .........................................................20
SPECIFICATIONS...........................................INSIDE BACK COVER

AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS
H&S
DEALER PRE-DELIVERY CHECK LIST
After the Power Box has been completely set-up, check to be certain it is in correct running order before
delivering to the customer. The following is a list of points to inspect. Check off each item as you have made
the proper adjustments and found the item operating satisfactorily.
 qAll Shields and Guards are in place and fastened.
oAll Grease Fittings have been lubricated.
See lubrication guide in this manual.
 oAll Mechanisms are operating trouble free.
 oAll Roller Chains are at proper tension.
oApron Chains are adjusted properly.
oAll Bolts and Fasteners are tight.
oAll Decals are in place and legible.
(Remove Dealers File Copy At Perforation)
(Dealer’s Name) Model Number
(Signature of Pre-Delivery Inspector) (Inspection Date)
Serial Number
DEALER DELIVERY CHECK LIST
This check list that follows is an important reminder of valuable information that should be passed on to the
customer at the time this Power Box is delivered.
Check off each item as you explain it to the customer.
This pre-delivery check list, when properly filled out and signed assures the customer that the pre-delivery
service was satisfactorily performed.
 oExplain to the customer that the pre-delivery inspection was made.
 oExplain to the customer all the safety precautions they must exercise when operating this unit.
 oExplain recommended loads for different types of materials.
 oExplain to customer that regular lubrication is required for proper operation and long life of
machine. Show customer the lubrication section of Owner’s Manual.
 o Give the customer Owner’s Manual and make sure he reads and understands all operating and
service instructions.
qRecord Serial Number on Page 14 of this Manual.
oHave customer sign a completed “Warranty Registration,’’ and mail it promptly.
Date Delivered ________________________ Dealer’s Name ______________________________
By ________________________________________
Note: Warranty is not valid until warranty card is completed and returned to H&S Mfg. Co., Inc.
-3-
Signature of Original Buyer

THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS
INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST
OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST
BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.
TRACTORS
This operator’s manual uses the term “Tractor” when identifying the power source for the Rear
Unload Power Box. However, the same safety and operating practices apply to other power
sources.
H&S MANUFACTURING CO. INC.
BE
ALERT! YOUR SAFETY
IS INVOLVED.
-5-

RECOGNIZE SAFETY INFORMATION
This is the safety-alert symbol. When you see this symbol
on your machine or in this manual, be alert to the potential
for personal injury.
Follow recommended precautions and safe operating
practices.
UNDERSTAND SIGNAL WORDS
A signal word—DANGER, WARNING, or CAUTION—is
used with the safety-alert symbol. DANGER identifies the
most serious hazards.
Safety signs with signal word DANGER or WARNING are
typically near specific hazards.
General precautions are listed on CAUTION safety signs.
FOLLOW SAFETY INSTRUCTIONS
Carefully read all safety messages in this manual,
and all safety signs on your machine. Follow all
recommended precautions and safe operating pro-
cedures.
Keep signs in good condition. Immediately replace
any missing or damaged signs.
-6-
CAUTION
WARNING
CAUTION

-7-
DO NOT GO NEAR LEAKS
•High pressure oil easily punctures skin causing
serious injury, gangrene or death.
•If injured, seek emergency medical help.
Immediate surgery is required to remove oil.
•Do not use finger or skin to check for leaks.
•Lower load or relieve hydraulic pressure
before loosening fittings. 11599

H&S REAR UNLOAD POWER BOX
W A R N I N G
TO PREVENT SERIOUS INJURY OR DEATH
BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING
INFORMATION. IN ADDITION, MAKE SURE THAT EVERY INDIVIDUAL WHO OPERATES OR WORKS
WITH THIS EQUIPMENT, WHETHER FAMILY MEMBER OR EMPLOYEE, IS FAMILIAR WITH THESE
SAFETY PRECAUTIONS.
KNOW HOW TO STOP UNLOADING MECHANISM BEFORE STARTING IT.
If the machine becomes clogged, disengage tractor hydraulics, stop the tractor engine and allow all
mechanisms to stop before cleaning or working on the machine.
DO NOT attempt to perform maintenance or repair with tractor running and hydraulics hooked to the trac-
tor.
DO NOT step up on machine at any time.
DO NOT get off the tractor when box is in operation. Operator position is in the tractor seat.
DO NOT ALLOW PERSONNEL OTHER THAN THE QUALIFIED OPERATOR NEAR THE MACHINE.
DO NOT allow minors to operate or be near the machine.
STAY CLEAR or rear of Power Box at all times.
DO NOT clean, adjust, or lubricate the machine when any part is in operation.
BE SURE the machine is clear of people, tools, and other objects before engaging tractor hydraulics.
NEVER start power box until all guards and safety shields are secured in place.
STAY CLEAR of hydraulic lines, they may be under extreme pressure or heat.
Loose or floppy clothing should not be worn by the operator.
CAUTION – BEWARE OF LOW ELECTRICAL WIRES.
H&S Mfg. Co. always takes the operator and his safety into consideration and guards exposed moving
parts for his protection. However, some areas cannot be guarded or shielded in order to assure proper
operation. In addition, the operators manual and decals on the machine itself warn you of further danger
and should be read and observed closely.
Study The Above Safety Rules
ATTENTION - BE ALERT - YOUR SAFETY IS INVOLVED
-8-

-9-
BEFORE OPERATION
Check entire unit carefully before first operation. Tighten bolts, set screws, and chains which might have
come loose in handling. Lubricate as explained in the lubrication guide. Run the unloading mechanism for
several minutes. This will serve as a break-in and as a check that all parts are assembled and lubricated
properly. Successful operation will be achieved by periodic adjustments and experience of the operator.
Make sure to read and understand the main feeder apron adjustments.
Located on the front of the Power Box is a convenient hanger (Item A) for the hydraulic hoses. When the
Power Box is not being unloaded, hoses should be securely wrapped around this holder, with ends inserted
into Block Holder (Item B).
C
WHEN TRANSPORTING ON THE
HIGHWAY OR ROADS, PLACE SMV
SIGN IN SOCKET (D) PROVIDED AND
REGULARLY CLEAN THE REFLECTIVE
TAPE (C) AT THE REAR OF THE POWER
BOX.
D
NOTE: Obey all state and local laws, con-
cerning towed equipment, on public roads.
For light information (See Page 15).
B
A

-10-
MAIN FEEDER APRON ADJUSTMENT
Main feeder apron adjustment bolts are located behind the convenient
access door located in the bottom portion of front gate. Remove handle
nuts (A) to open access door and swing door downward.
All apron chains must be taken up evenly before you use the power box.
Check again after the first few loads. The Main Feeder Aprons should be
at proper tension at all times. Tighten the full threaded bolts (B) to adjust
aprons. Aprons are properly adjusted when two Cross Slats, or about
three feet of chain lift off the Chain Return Slides from the front of the box.
Maintain this tension when operating the box.
PRIMARY DRIVE
The roller chain between the hydraulic motor
and large reduction sprocket is adjusted by
loosening the four bolts holding the motor.
Slide motor downward in slots in panel until
roller chain is tight. Retighten four bolts holding
hydraulic motor.
FINAL DRIVE
A roller type chain tightener is provided to
adjust tension on the roller chain between drive
sprocket and sprocket on main apron drive
shaft. Chain is properly adjusted when there is
slight deflection at the center of the chain.
A
B
MOTOR MOUNTING BOLTS
TIGHTENER

LUBRICATION GUIDE
-11-
C D
The operator should become familiar with all lubrication points and estab-
lish a systematic routine to insure complete and quick lubrication of the
machine.
DRIVE CHAINS
Lubricate the drive chains with a light machine oil. Keep chains aligned with
sprockets. This will lengthen the life of the sprockets and chain. Lubricate
chains often.
GREASE ZERKS
There are nine (9) grease fittings on your new H&S REAR UNLOAD POWER
BOX. Grease daily during normal use and before and after storage. Use a
good grade of high quality grease.
Listed below is location and quantity of zerks.
A. (4) one on each main apron front idler sprocket.
B. (3) one on left hand, center, and right hand rear main apron drive shaft
brackets.
C. (1) one on gear reduction sprocket at left rear of box.
D. (1) one on drive shaft end of brace for rear main apron drive shaft.
A B

-12-
FIELD OPERATION OF REAR UNLOAD POWER BOX
After you have idled your H&S Rear Unload Power Box for several minutes, and checked it over thoroughly
as suggested in earlier recommendations, and have properly adjusted and lubricated it, you are ready to
place your Power Box into operation.
UNLOADING
1. Park Power Box on level ground whenever possible during unloading.
2. Connect hydraulic hoses from Power Box to the tractor.
3. With operator in the tractor seat and all others well clear of Power Box, engage the tractor hydraulics.
NOTE: Rear unload operates in only one direction. If tractor hydraulic system stalls, check for
obstruction, reverse the lever on the tractor or switch the hydraulic hoses at the ports on the tractor. If
stalling persists, the problem may be insufficient tractor hydraulic pressure.
OPERATOR’S POSITION
POWER
BOX TRACTOR
4. During unloading, move the Power Box forward to allow material to fall away from rear of box.
5. When box is empty, disengage tractor hydraulics, disconnect hoses from tractor, and securely wrap
hoses on convenient holder on the front of the Power Box.
6. Check rear door to make sure it is securely latched.
REAR DOOR LATCHES
Located at the bottom left and right hand side of the
rear door are the door latches. These latches lock
against knurled gears on rear drive shaft to hold
door closed when loading Rear Unload Power Box.
When tractor hydraulics are activated and rear drive
shaft turns, knurled gears flip latches open to allow
rear door to swing free. Upon completion of unload-
ing check rear door to insure that door latches are
securely in place for next load.
DOOR LATCH
KNURLED GEAR

-13-
DECAL LOCATION
Your H&S Rear Unload Power Box was manufactured with operator safety in mind. Located on the Power
Box are various decals to aid in operation, and warn of danger or caution areas. Pay close attention to all
the decals on your Power Box.
DO NOT REMOVE ANY OF THESE DECALS. IF DECALS ARE LOST, DAMAGED, OR
IF THE POWER BOX IS REPAINTED, REPLACE DECALS. REMEMBER: DECALS ARE
FOR YOUR PROTECTION AND INFORMATION.
Listed below are the decals on your Rear Unload Power Box. These decals may be ordered individually by
part number or by ordering complete set.
ITEM PART NO. DESCRIPTION
A 71293 Field Operation
B (2) H&S Metal Sign (12’’x 24’’)
C 1494C (4) Warning - Moving Parts Under
D 106-3185 Serial Number
E 1494J Warning - Do Not Clean or Work
F 1494K Warning - Do Not Remove Shields
G (2) Red Reflector
H 1494A (3) Warning - Do Not Operate (P.14)
I 2495 Warning - Keep Children Away
J 11599 Warning - Do Not Go Near Leaks
K Amber Reflector
L 1494B Warning - Do Not Remove Shields
M 93366 Manual Holder
42804-PB Complete Set of Decals
Paint - H&S Red
ZX21 Gallon
ZX22 Quart
ZX23 Pint
C E F G G
B K
(Continued on Page 14)
I J A L

DECAL LOCATION (Continued)
-14-
H
H M
INSTRUCTIONS FOR ORDERING PARTS
All service parts should be ordered through your authorized H&S Dealer. He will be able to give you faster
service if you will provide him with the following:
1. Model & Serial Number – Both can be located on the rear, left side of your unit.
2. All reference to left or right apply to the machine as viewed from the rear.
3. Parts should not be ordered from illustration only. Please order by complete parts numbers.
4. If your dealer has to order parts - give shipping instructions:
VIA truck - large pieces (please specify local truck lines)
VIA United Parcel Service (include full address)
PLEASE RECORD NUMBERS FOR YOUR UNIT FOR QUICK REFERENCE
ABOUT IMPROVEMENTS
H&S MFG. CO. IS CONTINUALLY STRIVING TO IMPROVE ITS’ PRODUCTS.
We must therefore, reserve the right to make improvements or changes whenever it becomes practical to
do so, without incurring any obligation to make changes or additions to the equipment previously sold.

FIGURE 1
REAR UNLOAD POWER BOX
LIGHTING ASSEMBLY
ITEM PART NO. DESCRIPTION
1. S308 Rubber Light Mount
2. S309 Amber Light
3. S310 Red Light
4. PB232 Light Harness (6-WIRE)
5. S443 18’ Longitudinal Cord (4-WIRE)
S442 20’ Longitudinal Cord (4-WIRE)
6. PB111 Taillight Brackets
7. S317 Optional Tractor Cord
8. S441 Light Module
* PB237 18’ Complete Light Assembly
Less Optional Tractor Cord
* PB238 20’ Complete Light Assembly
Less Optional Tractor Cord
NOTE: * (Means Not Shown)
-15-
WIRING CODE
White - Ground
Yellow - LH Flashing & Turn Signal
Green - RH Flashing & Turn Signal
Brown - Tail Lamp
Red - Tail Lamp (Flash LH/RH)

-16-
FIGURE 2

FIGURE 2
REAR UNLOAD ASSEMBLY
BOX SIZE
ITEM 18’ 20’ DESCRIPTION
1. PB72 ” Back Door Top Panel
2. PB23 ” Back Door Top Steel
3. PB24 ” Back Door Bottom Steel
4. S288 ” Seal Strap
5. PB54 ” Rubber Seal
6. PB74 ” Drive Shaft Panel
7. PB80 ” LH Drive Shaft Mount
8. PB81 ” Center Bearing Bracket
9. PB82 ” RH Drive Shaft Mount
10. S233 ” 667H Pintle Slat W/Attachment Links
11. 11S51 ” 667H Pintle Connector Links
11A. 11S50 ” 667H Pintle Attachment Links RH or LH
12. PB77 PB78 667H Complete Pintle Apron
13. 23N122 ” Drive Shaft Sprockets
14. PB57 ” Latch Bracket RH
15. PB58 ” Latch Bracket LH
16. PB83 ” Latch Sprocket
17. PB60 ” Rear Door Latch Mount
18. 23N17 ” Drive Shaft Bushing
19. PB61 ” Latch Pivot
20. A34 ” Latch Washer
21. PB87 ” Key 3/8’’ x 2’’ Square
22. PB133 ” Key 3/8’’ x4-3/8’’ Square
23. PB136 ” Key 3/8’’ x 2 Square w/Round Ends
24. PB194 ” Drive Shaft
25. PB73 ” Back Door Framework
26. PB65 ” Hinge
27. 3G22 ” Expansion Pin
28. PB66 ” Guard
29. PB129 ” Hinge Pin
30. S63 ” Idler Shaft
31. PB99 ” Rear Drive Shield
32. PB260 ” Hydraulic Motor Mount Washer
33. PB261 ” Hydraulic Motor Mount Spacer
34. DF1 ” Hydraulic Motor
35. PB107 ” Idler Shaft
36. PB105 ” 1/2’’ Pipe Coupling
37. PB41 ” Hydraulic Hose 60’’
38. HE58 ” Elbow
39. PB235 ” Sprocket (2000 Series)
40. PB97 ” #50 Chain 90 Pitches
41. PB114 ” #80 Chain 73 Pitches
42. PB95 ” 11T-84T Sprocket
43. PB94 ” 52T Sprocket
44. DF18 ” Check Valve
45. S41 ” Bushing 1-3/4’’ OD x 1-1/2’’ ID x 1-1/8’’
46. PB98 ” Drive Shaft Brace
47. PB130 ’’ Collar
48. L10R35 ” Chain Tightener Bracket
49. 23N238 ” Roller Chain Tightener
50. 10R32 ” Snap Ring
51. S192 ” Handle
52. T37 ” Cotter Pin
53. PB100 ” Hinge Pin
54. 23N67 ” Hose Holder
55. PB18 PB102 Hydraulic Pipe
56. S60 ” Idler Sprocket
57. S61 ” Idler Spacer
58. S62 ” RH Idler Bracket
59. S64 ” Center Idler Bracket
60. S65 ” LH Idler Bracket
61. A7 ” Idler Bolt
62. PB141 ” Washer
63. PB108 ’’ Bushing 1-1/4’’ IDx1-1/2’’ODx1-3/4’’
-17-

-18-
FIGURE 3

FIGURE 3
BOX AND COMPONENT PARTS
BOX SIZE
ITEM 18’ 20’ DESCRIPTION
1. S147 S297 Top Rail
2. S144 S298 Top Rail
3. *S150PB **S299PB Side Steel
4. S153 S300 Roof Steel
5. ST61 ’’ Branch Guard
6. ST60 ’’ Roof Support
7. ST49 ’’ Side Stake
8. PB67 ’’ LH Rear Stake
9. PB68 ’’ RH Rear Stake
10. S164 S301 Apron Chain Center Spacer
11. S167 S302 Apron Chain Side Spacer
12. S170 S303 Floor Assembly
13. S269 ’’ Stake Pocket Front
14. ST50 ’’ RH Front Stake
14A. ST51 ’’ LH Front Stake
15. PB71 ’’ Brace
16. PB12 ’’ Door Hinge Bracket
17. PB29 ’’ Hydraulic Hose Holder
18. S268 ’’ Stake Pocket
19. PB70 ’’ Front Door Bottom Steel
20. PB43 ’’ Top Rail
21. PB19 ’’ Power Box Shelf Angle RH
22. PB20 ’’ Power Box Shelf Angle LH
23. PB69 ’’ Expanded Metal Screen
24. PB131 ’’ Front LH Side Piece
25. PB132 ’’ Front RH Side Piece
26. S191 ’’ Brace
27. S192 ’’ Handle Nut
28. S193 ’’ RH Hinge Top Piece
29. S194 ’’ RH Hinge Bottom Piece
30. S195 ’’ RH Side Piece
31. S196 ’’ LH Side Piece
32. S197 ’’ Back Door Tailgate Section
33. S198 ’’ LH Hinge Bottom Piece
34. S199 ’’ LH Hinge Top Piece
35. PB42 ’’ Front Slant Panel
36. JB105 ’’ Hose Coupling Holder
37. S236 ’’ Rear Roof Support
38. S399 ’’ Rear Branch Guard
39. S522 ’’ Manual Holder
* CHM38 ’’ Plug Storage
*S150PB - 214-1/2’’ x 41’’
**S299PB - 238-1/2’’ x 41’’
NOTE: * (Means Not Shown)
-19-

FIGURE 4
TIE DOWN KIT
ITEM PART NO. DESCRIPTION
1. 12V45 1/2’’ x 1-1/2’’ GR.5 Bolt
2. K68 1/2’’ Flat Washer
3. R11 1/2’’ Top Lock Nut GR.5
4. S322 1/4’’ Chain 30-1/4’’ Long
5. S323 Tie Down Bracket
6. T9B Tie Down Kit - Complete
-20-
