Hangar 9 PowerPro HAN164 User manual

THIS IS NOT A UNIVERSAL UNIT.
IT WAS SPECIFICALLY DESIGNED TO FIT THE MOUNTING HOLES ON THE HANGAR 9®POWERPRO STARTERS.
PowerPro™Starter Source
Instruction Manual (HAN164)
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby,
LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.
MEANING OF SPECIAL LANGUAGE
The following terms are used throughout the product literature to indicate various levels of potential harm when operating
this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no pos-
sibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of
serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and
serious injury OR create a high probability of superficial injury.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and cause
serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the
product or other property. This product is not intended for use by children without direct adult supervision. Do not attempt
disassembly, use with incompatible components or augment product in any way without the approval of Horizon Hobby,
LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the
instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or
serious injury.
Age Recommendation: Not for children under 14 years. This is not a toy.
For your convenience, the Starter Source is available in three different options:
1. Includes a 12V 130mA gel cell (HAN163)
2. Includes a 10-cell 12V Ni-Cd battery pack (HAN164)
3. No battery included (HAN165).
The charger and replacement batteries are available separately.
Optional Parts
HAN167 12V 1.3Ah Gel Cell
HAN168 10-cell 12V Ni-Cd
HAN166 12V 130mA Overnight Charger: Starter Source
AttAching the stArter
1. Locate the following hardware:
• 4x10mm flat washers (8)
• 3x15mm Phillips machine screws (4)
• 3mm lock nuts (4)
2. Attach the starter to the upper half of the case, using the above hardware. The front mounting holes of the starter should
be attached to the front section of the upper case. This is considered to be the side with the two individual holes and not
the side with the four slotted holes. The screw with a washer should be inserted from inside the case and secured with the
washer and nut on the starter’s mounting holes. This will be a tight area to work in, and it may be best to use needle-nose
pliers to hold the washer and nut in place while using a screwdriver to secure the hardware.
3. Repeat this step for the other three mounting holes.
Diagram 1 Diagram 2
cOMPLeting FinAL AsseMBLY
1. Locate the following hardware:
• 3x18mm pan head Phillips self-taping screws ((4) black)
2. Place the upper half of the case onto the lower half. Be sure the rear of the starter lines up with the Tamiya connector
protruding through the rear of the lower case. There is a molded piece on the inside of the upper case that helps to secure
the Tamiya connector in place on the lower case.
3. While holding the entire unit in place, screw one 3x18mm pan head screw into each of the four holes on the bottom of the
lower case, making sure a secure attachment has been made with the upper case.
4. Tighten all four holes securely.
instALLing the BAtterY
1. Locate the included double-sided tape.
2. Peel the protective cover from one side and apply in the center of the lower half of the case. Remove the other side of the
protective cover when you are ready to mount the battery.
3. The lower case is molded to accept the gel cell battery and should be placed into the lower case according to Diagram 1.
The included wire with the female Tamiya connector should be connected to the terminal on the gel cell battery. Be sure
red is attached to the positive (+) and black is attached to the negative (–). The female Tamiya connector is used for
connection with the starter and for charging the battery. The Tamiya connector fits into the molded slot at the end of the
lower case.
4. If you are using the 10-cell 12V Ni-Cd battery, it also fits conveniently in the lower case. We have included an insert to
help secure the battery in place along with the tape. Please refer to Diagram 2 for proper placement.
CONTAINS NICKEL-CADMIUM BATTERY. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
This product is or contains a Nickel-Cadmium battery. Due to the harmful effects of heavy metals like Cadmium on the
environment, Federal and state law require Ni-Cd batteries to be recycled and not disposed of through household waste.
To find a local center where you may drop-off your Ni-Cd batteries, please call 1.877.2.RECYCLE (1.877.273.2925).*
* This information applies only to HAN168.

hOOKing UP the stArter Wires
1. It will be necessary to attach a male Tamiya connector to the starter wires. We have included this wire and connector with
the Starter Source for your convenience.
2. It will be necessary to cut back the starter wires to your desired length to attach to the Starter Source.
3. Keep in mind when attaching to the male Tamiya connector and wire that the black wire with the white stripe is positive
(+) and the solid black wire is negative (–).
4. After cutting through both starter wires at the desired length, strip each wire back 3/8”.
5. Slide one rubber battery terminal insulator over each wire.
6. Tin the starter wires, using a soldering iron.
7. Crimp the red lead wire attached to the male Tamiya connector to the white striped starter wire, then solder.
8. Crimp the black lead wire to the solid black starter wire, then solder.
9. After the solder joint cools, slide the rubber terminal insulator over the terminal.
10. Once you have completed assembly of the Starter Source, connect the male Tamiya connector from the starter to the
female Tamiya connector in the rear of the case.
11. After the battery has been charged (see below), attach together the Tamiya connectors. Push the Starter button and the
starter should engage and rotate in a clockwise direction when viewed from the cone end.
chArging the BAtterY
We recommend using a 12V 130mAh Overnight Charger (HAN166) for charging your PowerPro Starter Source. Normal charge
time is approximately 8–10 hours.
NOTICE: When using another charger source, consult the instruction manual so you charge the battery at the correct charge
rate, including fast charges. Charging the battery incorrectly can result in damage to the battery and serious injury and fire
may also result.
© 2014 Horizon Hobby, LLC. Hangar 9, PowerPro and the Horizon Hobby Logo are trademarks or registered trademarks of Horizon Hobby, LLC. Revised 04/2014 | 5383.1X
advised to return the Product immediately in new and unused
condition to the place of purchase.
Law - These terms are governed by Illinois law (without
regard to conflict of law principals). This warranty gives
you specific legal rights, and you may also have other rights
which vary from state to state. Horizon reserves the right to
change or modify this warranty at any time without notice.
WArrAntY serVices
Questions, Assistance, and Services - Your local hobby store
and/or place of purchase cannot provide warranty support
or service. Once assembly, setup or use of the Product has
been started, you must contact your local distributor or
Horizon directly. This will enable Horizon to better answer
your questions and service you in the event that you may
need any assistance. For questions or assistance, please
visit our website at www.horizonhobby.com, submit a
Product Support Inquiry at https://horizonhobby.quickbase.
com/db/bghj7ey8c?a=GenNewRecord, or call the toll free
telephone number referenced in the Warranty and Service
Contact Information section to speak with a Product Support
representative.
Inspection or Services - If this Product needs to be
inspected or serviced and is compliant in the country you
live and use the Product in, please use the Horizon Online
Service Request submission process found on our website
or call Horizon to obtain a Return Merchandise Authorization
(RMA) number. Pack the Product securely using a shipping
carton. Please note that original boxes may be included,
but are not designed to withstand the rigors of shipping
without additional protection. Ship via a carrier that provides
tracking and insurance for lost or damaged parcels, as
Horizon is not responsible for merchandise until it arrives
and is accepted at our facility. An Online Service Request is
available at http://www.horizonhobby.com/content/_service-
center_render-service-center. If you do not have internet
access, please contact Horizon Product Support to obtain
a RMA number along with instructions for submitting your
product for service. When calling Horizon, you will be asked to
provide your complete name, street address, email address
and phone number where you can be reached during business
hours. When sending product into Horizon, please include
your RMA number, a list of the included items, and a brief
summary of the problem. A copy of your original sales receipt
must be included for warranty consideration. Be sure your
name, address, and RMA number are clearly written on the
outside of the shipping carton.
NOTICE: Do not ship Li-Po batteries to Horizon. If you have
any issue with a Li-Po battery, please contact the appropri-
ate Horizon Product Support office.
Warranty Requirements - For Warranty consideration,
you must include your original sales receipt verifying the
proof-of-purchase date. Provided warranty conditions have
been met, your Product will be serviced or replaced free of
charge. Service or replacement decisions are at the sole
discretion of Horizon.
Non-Warranty Service - Should your service not be covered
by warranty, service will be completed and payment will
be required without notification or estimate of the expense
unless the expense exceeds 50% of the retail purchase
cost. By submitting the item for service you are agreeing to
payment of the service without notification. Service estimates
are available upon request. You must include this request
with your item submitted for service. Non-warranty service
estimates will be billed a minimum of ½ hour of labor. In
addition you will be billed for return freight. Horizon accepts
money orders and cashier’s checks, as well as Visa, Master-
Card, American Express, and Discover cards. By submitting
any item to Horizon for service, you are agreeing to Horizon’s
Terms and Conditions found on our website
http://www.horizonhobby.com/content/_service-center_ren-
der-service-center.
ATTENTION: Horizon service is limited to Product compli-
ant in the country of use and ownership. If received, a
non-compliant Product will not be serviced. Further, the
sender will be responsible for arranging return shipment of
the un-serviced Product, through a carrier of the sender’s
choice and at the sender’s expense. Horizon will hold non-
compliant Product for a period of 60 days from notification,
after which it will be discarded.
WArrAntY And serVice cOntAct inFOrMAtiOn
Country of Purchase Horizon Hobby Contact Information Address
United States of
America
Horizon Service Center
(Repairs and Repair Requests)
servicecenter.horizonhobby.
com/RequestForm/
4105 Fieldstone Rd
Champaign, Illinois, 61822 USA
Horizon Product Support
(Product Technical Assistance)
www.quickbase.com/db/
bghj7ey8c?a=GenNewRecord
888-959-2306
Sales [email protected]
888-959-2306
2-YeAr LiMited WArrAntY
What this Warranty Covers - Horizon Hobby, LLC, (Horizon)
warrants to the original purchaser that the product pur-
chased (the “Product”) will be free from defects in materials
and workmanship for a period of 2 years from the date of
purchase.
What is Not Covered - This warranty is not transferable and
does not cover (i) cosmetic damage, (ii) damage due to acts
of God, accident, misuse, abuse, negligence, commercial use,
or due to improper use, installation, operation or mainte-
nance, (iii) modification of or to any part of the Product, (iv)
attempted service by anyone other than a Horizon Hobby
authorized service center, (v) Product not purchased from an
authorized Horizon dealer, or (vi) Product not compliant with
applicable technical regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON
MAKES NO OTHER WARRANTY OR REPRESENTATION, AND
HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. THE PURCHASER ACKNOWLEDGES
THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT
WILL SUITABLY MEET THE REQUIREMENTS OF THE PURCHAS-
ER’S INTENDED USE.
Purchaser’s Remedy - Horizon’s sole obligation and
purchaser’s sole and exclusive remedy shall be that Horizon
will, at its option, either (i) service, or (ii) replace, any Product
determined by Horizon to be defective. Horizon reserves the
right to inspect any and all Product(s) involved in a warranty
claim. Service or replacement decisions are at the sole
discretion of Horizon. Proof of purchase is required for all
warranty claims. SERVICE OR REPLACEMENT AS PROVIDED
UNDER THIS WARRANTY IS THE PURCHASER’S SOLE AND
EXCLUSIVE REMEDY.
Limitation of Liability - HORIZON SHALL NOT BE LIABLE FOR
SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAM-
AGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL
LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM
IS BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE,
STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN
IF HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. Further, in no event shall the liability of Horizon
exceed the individual price of the Product on which liability is
asserted. As Horizon has no control over use, setup, final as-
sembly, modification or misuse, no liability shall be assumed
nor accepted for any resulting damage or injury. By the act of
use, setup or assembly, the user accepts all resulting liability.
If you as the purchaser or user are not prepared to accept the
liability associated with the use of the Product, purchaser is
