Hannlomax HX-300CD User manual

CD Alarm Clock Radio
With USB Ports for Charging
Model : HX-300CD
INSTRUCTION MANUAL
Note: Please read and follow these instructions before operating your unit.
SAFETY INSTRUCTION
TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
THIS APPLIANCE SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING WATER AND
THAT NO OBJECT FILLED WITH LIQUIDS SUCH AS VASES SHALL BE PLACED ON
APPARATUS.
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is
intended to alert the user to
the presence of uninsulated
“dangerous voltage” within
the products enclosure that
may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
CAUTION
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning: To reduce the rise of
electric shock, do not remove
cover (or back) no
user-serviceable parts inside.
Refer servicing to qualified service
personnel.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
-1 -

11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of
time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. Grounding or Polarization – This product may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarized plug.
16. Alternate Warnings – This product is equipped with a three-wire ground-type plug, a
plug having a third (grounding) pin. This plug will only into a grounding-type power
outlet. This is a safety feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the grounding-type plug.
17. Ventilation – Slots and openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and to protect it from overheating, and
these openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions have been
adhered to.
18. The MAINS plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
19. 回: CLASS II apparatus with double insulation, and no protective earth provided.
20. Caution Marking and rating plate was located at bottom enclosure of the apparatus.
21. WARNING : To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture.
22. The apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on apparatus.
23. The mains plug is used as disconnect device. The mains plug of apparatus should
not be obstructed OR should be easily accessed during intended use. To be
completely disconnect the power input, the mains plug or apparatus shall be
disconnected from the mains. - 2 -
24. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
25. Excessive sound pressure from earphones and headphone can cause hearing loss.
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is needed.
– Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions :
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
- 3 -

LOCATION OF CONTROLS
1 CD Compartment 16 FM Wire Antenna
2 TIME Button 17 AUX-IN Jack
3 REPEAT Button 18 Back-up Battery Compartment
4 AL1 Button (ALARM 1) 19 LED Display
5 AL2 Button (ALARM 2) 20 PM Indicator
6 /M+ Button 21 AL1-Buzz Indicator
7 / TIME ZONE Button 22 AL1-Music Indicator
8 VOL+Button 23 REP Indicator
9 VOL−Button 24 AL2-Buzz Indicator
10 TUNE/SKIP+Button 25 AL2-Music Indicator
11 TUNE/SKIP−Button 26 USB charging port (1A)
12 SOURCE/AL OFF Button 27 USB charging port (2.1A)
13 SNOOZE/SLEEP/DIMMER Button
14 PROG/MEM Button
15 DC Jack
- 4 -
CONNECTING THE UNIT TO POWER
AC OPERATION
Plug one end of the AC adaptor into the DC power Input, and then plug the other end
into AC wall outlet. Before switching on the unit, make sure that the voltage of your
electricity supply is the same as that indicated on the rating plate.
BACK-UP BATTERY
The unit has pre-installed a CR-2032 lithium battery inside the back-up battery
compartment. In case of power failure or interrupted AC power, the current time, alarm
time and the stored radio stations are preserved in the memory of the unit by means of
battery back-up function.
OPERATE THE CLOCK
When the clock is plugged in, the correct time will be displayed after a few seconds.
(Note : The default Time Zone is set on Zone 2 - Eastern Time). The clock will
automatically indicate the AM or PM time. When the PM indicator is on, the time display
is PM.
SELECT THE TIME ZONE
There are 7 time zones programmed as follows:
ZONE 1 – Atlantic Time
ZONE 2 – Eastern Time (Default Setting)
ZONE 3 – Central Time
ZONE 4 – Mountain Time
ZONE 5 – Pacific Time
ZONE 6 – Yukon Time
ZONE 7 – Hawaiian Time
CHANGE THE TIME ZONE
Make sure that the unit is in CLOCK mode. To confirm, Press and hold the SOURCE/AL
OFF button for one second until “OFF” appears on the display.
While the unit is in CLOCK mode, press the TIME ZONE button, the display will show the
current time zone number.
Press the TIME ZONE button repeatedly to select your time zone. When the desire time
zone is selected, release the button, the time zone will store in the memory after 1-2
seconds.
When you moved to a different time zone, simply change the time zone to the new time
zone, the unit will store the new time zone in the memory.
- 5 -

DISPLAY THE DATE
1. Press the TIME button, the year will show on the display (eg 2018 )
2. Press the TIME button again to show the month and date (e.g. “3 ' 21” means
March 21).
3. In a few seconds the time will be displayed.
SETTING THE CLOCK AND DATE
1. With the unit in CLOCK mode, press and hold the TIME button for about 1 second,
the HOUR digit will begin to flash on the display.
2. Press the TUNE/SKIP+or TUNE/SKIP−button to adjust the hour.
3. When the hour is selected, press the TIME button again, the MINUTE digit will begin
to flash on the display.
4. Press the TUNE/SKIP+or TUNE/SKIP−button to adjust the minute.
5. When the minute is selected, press the TIME button again, the YEAR will show on
the display and flash.
6. Press the TUNE/SKIP+or TUNE/SKIP−button to adjust the year.
7. When the year is selected, press the TIME button again, the MONTH and DATE will
show on the display and flash.
8. Press the TUNE/SKIP+button to adjust the MONTH and press the TUNE/SKIP−to
adjust the DATE.
9. When the month and date is selected, press the TIME button again to confirm and
the display will back to the CLOCK mode.
SETTING THE ALARMS
1. With the unit in CLOCK mode, press and hold the AL1 or AL2 button. The AL1 or
AL2 indicator and the ALARM time will begin to show on the display with hour digit
flashing..
2. Press the TUNE/SKIP+or TUNE/SKIP−button to select the alarm hour.
3. When the desired alarm hour is selected, press the AL1 or AL2 button again, the
alarm minute digit will start flashing.
4. Press the TUNE/SKIP+or TUNE/SKIP−button to select the alarm minute.
5. When the desired alarm is selected, press the AL1 or AL2 button to confirm.
6. Press the AL1 or AL2 button to select the ALARM wake up sound mode –BUZZ or
MUSIC from CD or last listened radio station. The alarm buzzer indicator (AL1-Buzz
or AL2-Buzz) or alarm music indicator (AL1-Music or AL2-Music) will light up to show
your selection.
7. The alarm music source (CD or radio) depends on the last source mode before the
unit turned off.
Note : If you choose CD as the alarm wake up source, please make sure that a CD
disc had placed in the CD compartment.
- 6 -
If you choose FM as the alarm wake up source, when alarm activate, it will go to
the last radio station that you listened.
Please be sure that you have set the alarm wake up time by observing the PM
indicator, If the PM indicator is ON, the alarm wake up time is PM, otherwise the
alarm wake up time is AM.
SNOOZE FUNCTION
1. Whenever the alarm activates, it can be temporarily suspended for a short period of
9 minutes by pressing the SNOOZE/SLEEP/DIMMER button once. The alarm
source indicator will flash continuously.
2. The alarm will then automatically activate again after the 9 minutes SNOOZE period
has ended.
3. This procedure can be repeated for up to approximately one hour.
TURN OFF THE ALARM
When the Alarm activate, press the SOURCE/AL.OFF button to turn off the Alarm.
The alarm will activate at the same time next day. To remove the alarm completely, press
the AL.1 or AL.2 button until all the AL.1 indicators (AL.1-Buzz and AL.1-Music) or all the
AL.2 indicators (AL.2-Buzz and AL.2-Music) turned off.
RADIO OPERATION
1. Press the SOURCE/AL OFF button to select FM mode. The radio frequency will be
shown on the display.
2. Press the TUNE/SKIP+or TUNE/SKIP−button for approx.1 second, it will start to
search the next radio station in the direction of the search. The search operation
simply finds stations with strong signals. Stations with weak signal can only be tuned
in manually.
3. Use the VOL+or VOL−button to adjust the volume to the desired listening level.
ANTENNA
For best reception, fully extend the FM wire antenna to receive FM stations. .
SAVING RADIO STATIONS IN THE MEMORY
1. Tune to the desired stations.
2. Press and hold the PROG/MEM button for approx. 1 second, the display will show
‘PXX’ and flashing, where ‘XX’ is the next memory station number. Press the
TUNE/SKIP+or TUNE/SKIP−button to select the memory station number.
3. Press the PROG/MEM button again to store the station in the memory.
4. Repeat step 1 to 3 to store more radio stations in the memory.
5. Up to maximum 10 FM radio stations can be stored in the memory.
- 7 -

TO SELECT A STORED RADIO STATION IN THE MEMORY
Use the /M+ button to skip to the next stored radio station.
CD OPERATION
1. Press the SOURCE/AL OFF button to select CD mode.
2. Insert a CD disc in the CD compartment and close the CD door, the unit will start
reading the disc, it will show the total number of tracks in the entire disc.
3. Press the button to start playing the disc.
4. During playing, press the button to temporarily pause playing. To resume, press
the button again.
5. Press the
/M+ button to stop playing the CD
Skip Mode
During playing or in pause mode
1. Press the TUNE/SKIP+button to go to the next track.
2. Press the TUNE/SKIP−button to go back to the beginning of the track.
3. Press the TUNE/SKIP−button twice to go back to the previous track.
4. Press and hold the TUNE/SKIP+button, it will search the track with audible high
speed forward.
5. Press and hold the TUNE/SKIP−button, it will search the track with audible high
speed backward.
Different Play Mode
Press the REPEAT button to select the repeat mode.
If the REP. indicator keep blinking means that the repeat mode is REPEAT 1, it will
repeat the track being played continuously..
If the REP. indicator stay lighted means that the repeat mode is REPEATALL, it will
repeat the whole disc continuously.
To cancel the repeat function, press the REPEAT button until the REP. indicator
turned off
.
Programming
The programming should be done during STOP mode. To make sure you are in STOP
mode, press the STOP button to stop CD and total tracks of the CD will display.
1. Press the PROG/MEM button, the display will show 1:XX. “1” refers to the first
programe track and XX refers to the desired track in CD
2. Use the TUNE/SKIP+or TUNE/SKIP−button to select the desired track in CD.0
3. Press the PROG/MEM button again to store the selected track in the memory, the
LCD display will show 2:XX. It is going to grogram the second track.
4. Repeat steps 2 to 3 to store more tracks in the memory. You can store up to 20
tracks in the memory. - 8 -
5. Press the button to start playing the disc in the programmed order.
6. To stop playing, press the /M+ Button.
7. To cancel the programming list, press the /M+ button twice or open the CD
compartment door or press the SOURCE/AL OFF button to select a different mode.
SLEEP TO MUSIC FUNCTION
1. This function allows you to listen to the radio while you fall asleep.
2. Press the SNOOZE/SLEEP/DIMMER button, the display will show the default sleep
time of 90 minutes.
3. Press the SNOOZE/SLEEP/DIMMER button repeatedly to set the desired sleep time.
(The options are : 90-80-70-60-50-40-30-20-10 min. or OFF)
4. After the pre-set time has elapsed, the radio will turn off automatically.
MP3/AUX IN CONNECTION
1. Insert one side of the audio cable (requires 3.5mm stereo plug, not supplied) into the
line-out jack or phones jack on your MP3 player and the other side to the aux-in jack
on the unit.
2. Press the SOURCE/AL OFF button to select AUX mode.
3. Turn on your MP3 player and follow the playback instruction.
4. To stop this function, simply turned off your MP3 player.
TO TURN OFF THE UNIT
Press and hold the SOURCE/AL OFF button for approx.1 second, the unit will turned off
with current time displayed.
DIMMER
Press and hold the SNOOZE/SLEEP/DIMMER button to select the brightness of the
display.
CHARGE YOUR DEVICES
Connect the standard size end of a USB cable (not included) to the USB port on the unit
and connect the other end to the charging port of your mobile phone or USB device.
The unit contains 2 USB ports for charging, one for 5V ~ 1A charging and one for
5V ~ 2.1A charging. Please refer to the silkscreen on the unit.
Remarks: Some devices may not support USB charging or may require a higher power
rating than this product provides. Observe the charging status on your device. Ensure
your device is working properly before attempting to charge. Charging function may not
be supported for all phones or electronic devices
- 9-

CARE AND MAINTENANCE
Precautions
Always turn off the unit after use.
Keep the unit away from magnetic objects, water or heat sources.
Use a clean soft cloth moistened with lukewarm water to clean the cabinet. Never
use chemical cleaners that could damage the finish of the unit.
Never touch the CD pickup and lens. If fingerprints get on the pickup lens, clean it
gently with a commercial lens cleaner.
Disconnect the unit from any power sources before cleaning.
To remove a disc from its storage case, press down on the centre of the case and
lift the disc out, holding it carefully by the edges.
Fingerprints and dust should be carefully wiped off the disc’s recorded surface with
a soft cloth. Unlike conventional records, compact discs have no grooves to collect
dust and microscopic debris so gently wiping with a soft cloth should remove most
particles. Wipe in a straight line from the inside to the outside of the disc. Small dust
particles and light stains will have absolutely no effect on reproduction quality.
Never use chemicals such as record sprays, anti-static sprays, benzene or thinners
to clean compact discs. These chemicals can irreparably damage the disc’s
surface.
Discs should be returned to their cases after use. This avoids serious scratches that
could cause the Laser pickup to skip.
Do not expose discs to direct sunlight, high humidity, or high temperatures for
extended periods. Long exposure to high temperatures can warp the disc.
Do not stick paper or write anything with a ballpoint pen on the label side of the disc.
SPECIFICATIONS
Frequency Range: FM 87.5 - 108 MHz
Power Supply: AC 100-240V ~ 50/60 Hz
Rated Output : DC 5V - 3.5A
Maximum Load Rating : 1 USB 5V ~ 2.1A
1USB5V~1A
Back-Up Battery: 1 pc. CR-2032
Specifications are subject to change without further notice.
- 10 -

1 sec
SOURCE / AL OFF
/ M+
TIME
ZONE
REPEATTIME
REPEATTIME
Make sure that the unit is in CLOCK mode. To confirm, press and hold the SOURCE/AL OFF
button for one second until “OFF” appears on the display.
Setting Time Zone
1) Press the TIME button, the year will show on the display (e.g. 2018).
2) Press the TIME button again to show the month and date (e.g. “3 ' 21” means March 21).
3) In a few seconds the time will be displayed.
Press the TIME ZONE button, the display will show the current
time zone number.
Press the TIME ZONE button repeatedly to select your time zone.
When the desire time zone is selected, release the button, the
time zone will store in the memory after 1-2 seconds.
Display The Date
- 1 -

1 sec
REPEATTIME
TUNE / SKIP+
TUNE / SKIP-
REPEATTIME
TUNE / SKIP+
TUNE / SKIP-
Setting The Clock and Date
1) With the unit in CLOCK mode, press and hold the TIME button for about 1 second,
the HOUR digit will begin to flash on the display.
2) Press the TUNE/SKIP+ or TUNE/SKIP− button to adjust the hour.
3) When the hour is selected, press the TIME button again, the MINUTE digit will begin
to flash on the display.
4) Press the TUNE/SKIP+ or TUNE/SKIP− button to adjust the minute.
- 2 -

REPEATTIME
TUNE / SKIP+
TUNE / SKIP-
REPEATTIME
TUNE / SKIP+(Month)
(Date)
TUNE / SKIP-
5) When the minute is selected, press the TIME button again, the YEAR will show on
the display and flash.
6) Press the TUNE/SKIP+ or TUNE/SKIP− button to adjust the year.
7) When the year is selected, press the TIME button again, the MONTH and DATE will
show on the display and flash.
8) Press the TUNE/SKIP+ button to adjust the MONTH and; press the TUNE/SKIP− to
adjust the DATE.
9) When the month and date is selected, press the TIME button again to confirm and the
display will back to the CLOCK mode.
- 3 -

1 sec
AL2AL1
AL2AL1
SNOOZE / SLEEP / DIMMER
9
mins
SOURCE / AL OFF
TUNE / SKIP+
TUNE / SKIP-
Setting The Alarms
1) With the unit in CLOCK mode, press and hold the AL1 or AL2 button. The AL1 or AL2
indicator and the ALARM time will begin to show on the display with hour digit flashing.
2) Press the TUNE/SKIP+ or TUNE/SKIP− button to select the alarm hour.
3) When the desired alarm hour is selected, press the AL1 or AL2 button again, the alarm
minute digit will start flashing.
4) Press the TUNE/SKIP+ or TUNE/SKIP− button to select the alarm minute.
5) When the desired alarm is selected, press the AL1 or AL2 button to confirm.
6) Press the AL1 or AL2 button to select the ALARM wake up sound mode BUZZ or MUSIC
from CD or last listened radio station. The alarm buzzer indicator (AL1-Buzz or AL2-Buzz)
or alarm music indicator (AL1-Music or AL2-Music) will light up to show your selection.
7) The alarm music source (CD or radio) depends on the last source mode before the unit
turned o.
E.g. Wake up sound mode : AL1-Music
Snooze Function
Whenever the alarm activates, it can be temporarily
suspended for a short period of 9 minutes by pressing
the SNOOZE/SLEEP/DIMMER button once.
Turn Off the Alarm
When the Alarm activate, press the SOURCE/AL.OFF button to turn
o the Alarm. The alarm will activate at the same time next day. To
remove the alarm completely, press the AL1 or AL2 button until all the
AL.1 indicators (AL.1-Buzz and AL.1-Music) or all the AL.2 indicators
(AL.2-Buzz and AL.2-Music) turned o.
- 4 -
