Hannlomax HX-1082BT User manual

CD MICRO WITH FM RADIO, BLUETOOTH
AND DUAL USB PORTS FOR CHARGING (2.4A and 1A)
Mod l : HX- 1082BT
(Blu tooth pairing cod : HX-1082BT HANNLOMAX)
INSTRUCTION MANUAL
Not : Please read and follow these instructions before using your unit
1 Read these instructions Keep these instructions Heed all warnings Follow all instructions
2 Do not use this apparatus near water
3 Clean only with dry cloth
4 Do not block any ventilation openings Install in accordance with the manufacturer’s instructions
5 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)
that produce heat
6 Do not defeat the safety purpose of the polarized or grounding-type plug A polarized plug has two blades with one
wider than the other A grounding type plug has two blades and a third grounding prong The wide blade or the third
prong are provided for your safety If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet
7 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus
8 Only use attachments/accessories specified by the manufacturer
9 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus When a cart is used, use caution when moving the cart/apparatus combination to
avoid injury from tip-over
10 Unplug this apparatus during lightning storms or when unused for long periods of time
11 Refer all servicing to qualified service personnel Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped
12 Grounding or Polarization – This product may be equipped with a polarized alternating-current line plug (a plug having
one blade wider than the other) This plug will fit into the power outlet only one way This is a safety feature If you are
unable to insert the plug fully into the outlet, try reversing the plug If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet Do not defeat the safety purpose of the polarized plug
-1-
13 Alternate Warnings – This product is equipped with a three-wire ground-type plug, a plug having a third (grounding)
pin This plug will only into a grounding-type power outlet This is a safety feature If you are unable to insert the plug
into the outlet, contact your electrician to replace your obsolete outlet Do not defeat the safety purpose of the
grounding-type plug
14 Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the
product and to protect it from overheating, and these openings must not be blocked or covered The openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar surface This product should not be
placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to
15 The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily
operable
16 回: CLASS II apparatus with double insulation, and no protective earth provided
17 Caution Marking and rating plate was located at bottom enclosure of the apparatus
18 To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture
19 The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall
be placed on apparatus
20 The mains plug is used as disconnect device The mains plug of apparatus should not be obstructed OR should be
easily accessed during intended use To be completely disconnect the power input, the mains plug or apparatus shall
be disconnected from the mains
21 Battery shall not be exposed to excessive heat such as sunshine, fire or the like
22 Excessive sound pressure from earphones and headphone can cause hearing loss
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential
installation This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications
However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna
– Increase the separation between the equipment and receiver
– Connect the equipment into an outlet on a circuit different from that to which the receiver is needed
– Consult the dealer or an experienced radio/TV technician for help
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
The lighting flash with
arrowhead symbol, with an
equilateral triangle is intended
to alert the user to the
presence of un-insulated
dangerous voltage within the
products enclosure that may
be of sufficient magnitude to
constitute a risk of electric
shock to persons
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK) NO USER
SERVICEABLE PARTS INSIDE
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important
operating and maintenance
(servicing) instruction in the
literature accompanying the
appliance
LASER SAFETY
This unit uses a laser Only a qualified service
person should remove the cover or attempt to
service this device to avoid possible eye injure
Caution: USE OF CONTROLS OR
ADJUSTMENT OF PERFORMANCE OF
PROCEDURE OTHER THAN SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE
DANGER:
INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCK FAILED OR DEFEATED
AVOID DIRECT EXPOSURE TO LASER BEAM
-2-

LOCATION OF CONTROLS
1 POWER/OFF/FUNC button 11 USB Charging port (2.4A)
2 TIME/P-MODE/PRO /MEM/+10
button 12
USB Port for MP3 playback and
Charging (1A)
3 VOL+ button 13 Remote Sensor
4 VOL- button 14 CD Door
5 Play/Pause/PAIR button 15 CD Door Open Button
6 STOP/M+ button 16 Right Speaker Jack (R)
7 TIME+/SKIP+/TU+ button 17 Left Speaker Jack (L)
8 TIME- /SKIP-/TU- button 18 Aux-in Jack
9 LCD display 19 AC Power Cord
10 Speakers 20 FM Antenna
SPECIFICATIONS
Frequency Range: FM 88 - 108 MHz
Power Supply: AC 120V ~ 60 Hz
USB Rated Output: DC5V 1A
DC 5V 2 4A
Specifications are subject to change without further notice
-3-
CONNECTING THE LOUDSPEAKERS
Connect the cables of the two loudspeakers to the corresponding input (R) for the right speaker
and input (L) for the left speaker, located at the back of the unit
ATTEMNTION:
 Connect the loudspeakers before powering the unit:
 The unit may not work properly or get damaged if you use speakers different than the ones
supplied with the unit
AC OPERATION
Connect the AC Power cord to a standard AC outlet
ATTENTION
1 Do not plug or unplug the power cable while you have wet hands;
2 When planning not to use this unit for a long time, disconnect the power cable from the wall
outlet;
3 When disconnecting the power cord from the wall outlet, do not pull on the cord in order to
avoid shock risks caused by damaged cable
SETTING THE CLOCK
1 Press TIME/P-MODE/PRO./MEM/10+ button to set the time The HOUR digit will begin to
flash on the display
2 Press TIME+/SKIP+/TU+ button or TIME- /SKIP-/TU- button to adjust the HOUR Press
TIME/P-MODE/PRO./MEM/10+ button to confirm HOUR
3 The MINUTE digit will begin to flash on the display Press TIME+/SKIP+/TU+ button or
TIME- /SKIP-/TU- button to adjust the MINUTE Press TIME/P-MODE/PRO./MEM/10+
button to confirm MINUTE
USB CHARGE YOUR DEVICES (2.4A and 1A)
Connect the standard size end of a USB cable (not included) to the USB ports on the unit and
connect the other end to the charging port of your devices
The unit contains two USB ports (2.4A and 1A)
R marks: Some devices may not support USB charging or
may require a higher power rating than this product provides
Observe the charging status on your device Ensure your
device is working properly before attempting to charge
Charging function may not be supported for all phones or
electronic devices
-4-

RADIO OPERATION
1 Press POWER/OFF/FUNC. button to select the FM Radio
2 MANUAL TUNNING: Press the TIME+/SKIP+/TU+ button or TIME- /SKIP-/TU- button step
by step to tune to the desired radio stations
3 DIGITAL TUNNING: Press and hold the TIME+/SKIP+/TU+ button or TIME- /SKIP-/TU-
button to search the next radio station in the direction of the search The search operation
finds stations with strong signals, Stations with weak signal can only tuned manually
4 Use the VOL+ or VOL- knob to adjust the volume to the desired listening level
5 To turn off the radio, press and hold POWER/OFF/FUNC. button to go to Clock mode
Note: For better FM reception, please fully extend the FM antenna located at the back of the
unit and rotate to obtain the best possible station reception
SAVING RADIO STATIONS IN THE MEMORY
Not : If you use this unit in the first time, or after plug off the power cord from a wall outlet, the
unit memory number will be starting from “P01”
1 Tune to the desired FM radio station
2 Press the TIME/P-MODE/PRO./MEM/10+ button, the display will show the memory station
number and “P01‘’ flash continuously
3 Press TIME/P-MODE/PRO./MEM/10+ button again to store the station into the memory
4 Repeat step 2 to 3 to store more radio stations in the memory
5 Up to 10 FM radio stations can be stored in the memory
TO LISTEN A STORED RADIO STATION IN THE MEMORY
Press the STOP/M+ button to skip to the next stored radio station
BLUETOOTH OPERATION
Conn cting BLUETOOTH
1 Press POWER/OFF/FUNC. button to select the BLUETOOTH mode,‘ bt‘ will show in the
display
2 Turn on the Bluetooth of your device and search the unit for connection Your Bluetooth
device should find “HX-1082BT HANNLOMAX” If password is needed for connection,
please enter “0000”
3 If connection is successful, your Bluetooth device may show Bluetooth is connected
4 Select and play the audio files though your Bluetooth device
5 You can use the TIME+/SKIP+/TU+ button to go to the next track or press the
TIME- /SKIP-/TU- button to go back to the previous track
6 Press the PLAY/PAUSE/PAIR button to pause playing To resume, press the
PLAY/PAUSE/PAIR button again
To Unpair th Blu tooth conn ction
Press and hold PLAY/PAUSE/PAIR button to unpair the Bluetooth connection
The CD Micro system will search for a new pairing
Turn Off th Blu tooth Op ration
To turn off the Bluetooth, press and hold POWER/OFF/FUNC. button to go to Clock mode
-5-
CD OPERATION
1 Press POWER/OFF/FUNC. Button to select the CD mode
2 Insert an audio CD disc (CD/CDR /CDRW) in the CD compartment and close the CD door,
the unit will start reading the disc and play automatically
3 During playing, press the PLAY/PAUSE/PAIR button to temporarily pause playing To
resume, press the PLAY/PAUSE/PAIR button again
4 To stop playing the disc, simply press the STOP/M+ button
5 To turn off the CD mode, press and hold POWER/OFF/FUNC. button to go to Clock mode
CD Programming
The CD programming can only be done in STOP/M+ mode
1 Press the TIME/P-MODE/PRO./MEM/+10 button, the LCD display will show “P01”
2 Use the TIME+/SKIP+/TU+ button or TIME- /SKIP-/TU- button to select the desired track
3 Press the TIME/P-MODE/PRO./MEM/+10 button again to store the selected track in the
memory, the LCD display will show “P02”.
4 Repeat steps 2 to 3 to store more tracks in the memory You can store up to 20 tracks in the
memory
5 Press the PLAY/PAUSE button to start playing the disc in the programmed order
6 To stop playing, press the STOP/M+ button
7 To cancel the programming list, press the STOP/M+ button again or open the CD door
PLAYING MP3 FILES WITH USB DEVICE
1 Press POWER/OFF/FUNC. Button to select the USB mode
2 Plug your USB device into the corr ct USB port on the unit, it will start reading the files in
the USB device and will play the tracks automatically
3 To pause playing the MP3 files, press the PLAY/PAUSE/PAIR button To resume playing
the MP3 files, press PLAY/PAUSE/PAIR button again
4 Use the VOL+ or VOL- knob to adjust the volume to the desired listening level
5 Press and hold TIME/P-MODE/PRO./MEM/+10 button to skip 10 tracks
6 To stop playing the MP3 files, press the STOP/M+ button
7 To turn off the USB mode, press and hold POWER/OFF/FUNC. button to go to Clock
mode
-6-

Skip Mod
1 In CD/USB/BLUETOOTH mode, press the TIME+/SKIP+/TU+ button to go to the next
track
2 In CD/USB/BLUETOOTH mode, press the TIME- /SKIP-/TU- button to go back to
beginning of the track
3 In CD/USB/BLUETOOTH mode, press the TIME- /SKIP-/TU- button twice to go back to the
previous track
Diff r nt Play Mod ( R p at 1 / R p at all / Random)
In CD/USB mode, press the TIME/P-MODE/PRO./MEM/+10 button repeatedly to select
different kinds of play mode with the following sequence
R p at 1  R p at ALL  Random Normal
- R p at 1 ( will flash on the display) – repeat the track being played
- R p at ALL ( will stay light on the display)– repeat all the tracks in the entire disc
- Random ( will flash rapidly on the display)– play the tracks in a random sequence
- Normal ( will disappear)– play the tracks in sequence
AUX-IN CONNECTION
1 At any mode ( RADIO / Bluetooth / CD / USB ) , you can insert one side of the audio cable
(not included) into the Line-Out or Phone Jack on your MP3 Player or audio device and the
other side into the AUX-IN jack of the unit
2 Turn on your MP3 player or audio device and follow its playback instructions
3 Use the VOL+ or VOL- knob to adjust the volume to the desired listening level
4 To turn off the Aux-in connection, turn off your MP3 player or remove the aux-in cable
-7-
REMOTE CONTROL OPERATION
R mind r: Take off the plastic sheet located at the battery compartment tray to activate the
remote control
Point the remote control at the remote sensor The functions of the buttons on the remote
control are same as the corresponding controls on the main unit
1 POWER  use this button to turn the unit ON/OFF
2 MUTE  use this button to turn off the sound
3 FUNC.  use this button to select the function
4 TUNE+/SKIP+  in CD/USB/BLUETOOTH mode, use this button to skip to the next track
In FM radio mode, use this button to search the next available station in forward direction
5  (STOP)  in CD/USB/BLUETOOTH mode, use this button to stop playing
6 VOL−  use this button to decrease the volume
7 (PLAY/PAUSE)  in CD/USB/BLUETOOTH mode, use this button to start or pause
playing
8 VOL+  use this button to increase the volume
9 REPEAT  in CD/USB mode, use this button to select the REPEAT function
10 TUNE−/SKIP−  in CD/USB/BLUETOOTH mode, use this button to skip back to the
previous track In FM mode, use this button search the next available station in backward
direction
11 RANDOM  in CD/USB mode, use this button to select the RANDOM function
12 M−  In FM radio mode, use this button to skip to the next stored radio station in backward
order
13 MEM  in FM radio mode, use this button to store the select radio station in the memory
14 M+  In FM radio mode, use this button to skip to the next stored radio station in forward
order
15 PROG. / +10  in CD mode, use this button to program the playback order In USB mode,
use this button to skip 10 tracks
16 TIME / MONO  in CLOCK mode, use this button to set the clock In radio mode, use this
button to select the Mono or Stereo mode
17 BT PAIR  Press this button to disconnect the Bluetooth pairing and go into pairing mode
-8-
