Hanwha Vision SMT-2731PV User manual

PUBLIC VIEW MONITOR
SMT-2731PV
SMT-3231PV

SAFETY INSTRUCTIONS
1. WARNING
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
Do not insert any metallic object through the ventilation grills or other openings on the equipment.
Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
To prevent injury, this apparatus must be securely attached to the Wall/ceiling in accordance with the installa-
tion instructions.
2. CAUTION
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE REAR COVER. NO USER SERVICEABLE
PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
3. EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of “dangerous voltage: within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
ATTENTION
IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UNE BATTERIE DE TYPE INCORRECT.
METTRE AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS.
※This device has been verified using STP cable. The use of appropriate GND grounding and STP cable
is recommended to effectively protect your product and property from transient voltage, thunderstroke,
communication interruption.
※Select an installation site that can hold at least 4 times the monitor weight.

English _3
CONTENTS
OVERVIEW
4
4Package Contents
4Separately sold product
5Names and functions of each part
8Remote control
CONNECTING WITH OTHER DEVICE
9
9Things to check before connection
9Connecting with external devices
MENU SETTINGS
11
11 OSD Menu setting
NETWORK CONNECTION AND SETUP &
WEBVIEWER
18
18 Connecting the PVM Directly to Local Area
Networking
19 Connecting the PVM Directly to a DHCP
Based DSL/Cable Modem
20 Using Device Manager
20 Automatically searching camera
20 Configuring IP address
22 Manually registering camera
23 Automatically configuring IP
23 Port Range Forward (Port Mapping) Setup
25 Connecting to the Camera from a Shared
Local PC
25 Connecting to the Camera from a Remote
PC via the Internet
25 Connecting to the Camera
27 Password setting
27 Login
27 Camera Web Viewer Setup
SETUP SCREEN
28
28 Setup
28 Creating a text overlay
29 Setting slide show
30 Setting alarm input
APPENDIX
33
33 Mechanical
35 Troubleshooting

4_ overview
overview
PACKAGE CONTENTS
Please check the following contents are included in addition to the main unit.
Public View Monitor Quick Start Guide Alarm terminal block
COLORTEMP
CAMERA
HDMI2 INPUTHDMI1
PIP.SIZEPIP.INPUT
PIP.SWAPPIP.LOC
ASPECT MODE
VOL- VOL+
Remote Controller Battery Power Inverter Harness
SEPARATELY SOLD PRODUCT
Appearance Item Name Description Model Name
HPoE Injector Connects power supply
and network SPO-8315
Adpater DC 24V power supply SPU-60240
overview

English _5
NAMES AND FUNCTIONS OF EACH PART
Front
ab c d
Name Description of functions
a
Camera Lens IP camera is installed.
b
ALARM LED Displayed when an alarm output occurs.
c
IR Receiver Receive IR signal from Remote Controller.
d
LED
Displays the power ON/OFF status.
ON – GREEN
OFF – RED

6_ overview
overview
Back
a b c d e f
*COVER OPEN
g h

English _7
Name Description of functions
a
24V This is the DC 24V Power input terminal.
b
ALARM ALARM signal input / output
c
HPoE Used to connect the HPoE or Ethernet cable for network connection.
d
USB Connect the USB Devices for Monitor F/W update.
e
HDMI1
PIP/PBP HDMI Input terminal for PIP/PBP
f
HDMI2 HDMI Input terminal (Not support PIP/PBP)
g
RESET Resets the camera installed in the monitor to its factory default settings.
` If you forget your password, use the RESET button.
h
Micro SD card slot Compartment for the Micro SD card.
M ` Detach the terminal cover by rotating the fastening screw in a counterclockwise direction to loosen it, then
connect the cable.
` This product is intended to be supplied by a UL Listed Power Supply Unit marked “Class 2” or “LPS” or
“PS2”.
` This product dose not support LLDP.

8_ overview
overview
REMOTE CONTROL
M ` Those buttons without specific description are deprecated buttons.
COLOR TEMP
CAMERA
HDMI2 INPUTHDMI1
PIP.SIZEPIP.INPUT
PIP.SWAPPIP.LOC
ASPECT MODE
VOL- VOL+
HDMI1
Select HDMI1 mode
HDMI2
Select HDMI2 mode
CAMERA
Select internal IP camera
ASPECT
Changes the screen size.
MENU/EXIT
Activate and exit the OSD menu
MUTE
Press to mute the sound temporarily.
POWER
Turn ON / OFF the monitor
INPUT
Select the input signal of the main
screen. (HDMI1/HDMI2/CAMERA)
COLOR TEMP
Select the color temperature Warm/Normal/
Cool/USER.
PIP.SIZE
Adjust the size of the sub-screen in PIP mode.
PIP.SWAP
Swaps the Main/sub screens when PIP mode
active.
PIP.LOC
Adjust the position of the sub-screen
in PIP mode.
MODE
Pressing the button swaps the multiscreen in
the order of SINGLE > PIP > PBP.
_+$%buttons
Moves from one menu item to another
horizontally, vertically or adjusts selected
menu values.
ENTER
Activates a highlighted menu item.
VOL -, +
Adjusts the volume.

English _9
connecting with other device
THINGS TO CHECK BEFORE CONNECTION
Check before connecting
J ` When connecting, refer to the instruction manual of the product to be connected. The number and position
of external devices may differ depending on the product.
` Do not connect the power until all connections are complete. Connecting the power supply during
connection may damage the product.
` Check the type of terminal behind the product you want to connect.
CONNECTING WITH EXTERNAL DEVICES
HDMI cable connection method
HDMI
or

10_ connecting with other device
connecting with other device
Powering and networking
HPoE
Router or switching hub
(HPoE supported)

English _11
menu settings
OSD MENU SETTING
Selecting OSD menu
You can select the OSD menu by pressing the [MENU/EXIT] button on the remote controller.
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%buttons to select the main menu, and then press the ENTER or +button.
3. Press the $/%buttons to select the sub-menu, and then press the ENTER or +button.
4. Press the $/%buttons to adjust the adjustment value.
5. Press the MENU/EXIT button to exit.
Input Source
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Input Source>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
HDMI1
HDMI2
•CAMERA
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
Window2:
InputSource:
Resolution:
~HDMI 1 : Select external HDMI1 input
~HDMI 2 : Select external HDMI2 input
~CAMERA : Select internal Camera input

12_ menu settings
menu settings
Brightness/Contrast
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Brightness/Contrast>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
Brightness
Contrast
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
80
50
Window2:
InputSource:
Resolution:
~Brightness : Adjusts the brightness of the screen. (Adjust 0 ~ 100)
~ Contrast : Adjusts the difference in brightness between the object and the environment. (Adjust 0 ~ 100)
Color Setting
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Color Setting>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
Gamma
Picture Mode
Color Temperature
Hue
Saturation
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
2.2
Standard
Normal
50
50
Window2:
InputSource:
Resolution:

English _13
~Gamma : Adjust the mid-range brightness (Gamma) of the screen.(1.8/2.0/2.2/2.4/2.6)
~
Picture Mode : Select a screen mode appropriate for your viewing environment. (Standard/Photo/
Movie/Game)
~Color Temp. : The color temperature can be adjusted and used depending on the monitor color.
(Warm/Normal/Cool/USER)
~Hue : Adjusts the color of the screen. (Adjust 0 ~ 100)
~Saturation : Adjusts the saturation of the screen. (Adjust 0 ~ 100)
Picture Quality Setting
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Picture Quality Setting>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
Sharpness
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
30
Window2:
InputSource:
Resolution:
~Sharpness : Adjusts the sharpness of the screen. (Adjust 0 ~ 100)

14_ menu settings
menu settings
Display
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Display>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
Aspect Ratio
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
Wide Screen
Window2:
InputSource:
Resolution:
~Aspect Ratio : You can select a screen size you want. (Wide Screen/4:3/1:1/Auto)
Audio
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Audio>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
Mute
Volume
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
off
50
Window2:
InputSource:
Resolution:
~Mute : You can set whether to use the mute function. (On/Off)
~Volume : You can adjust the volume. (Adjust 0 ~ 100)

English _15
Multi-Window
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Multi-Window>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
Multi-Window
Sub Win2 Input
PIP Size
PIP Position
Swap
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
Off
CAMERA
Large
BottomRight
Window2:
InputSource:
Resolution:
~Multi-Window : You can select Picture in Picture (PIP) or Picture by Picture (PBP) mode.
(Off/PIP Mode/PBP 2Win)
~Sub Win2 Input : Displays the currently output Sub Win2 Input. (HDMI1/CAMERA)
~PIP Size : You can adjust the size of the sub-screen in PIP mode. (Small/Medium/Large)
~PIP Position : You can adjust the position of the sub-screen in PIP mode. (TopRight/TopLeft/
BottomRight/BottomLeft)
~Swap : You can switch between the main screen and sub-screen in PIP or PBP mode.

16_ menu settings
menu settings
OSD
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <OSD>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
Language
OSD H-Position
OSD V-Position
OSD Transparency
OSD Time Out
OSD Rotatio
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
English
50
50
50
20
Normal
Window2:
InputSource:
Resolution:
~Language : Select the screen language. (English/Español/Français)
~OSD H-Position : Moves the screen of the menu to the left or right. (Adjust 0 ~ 100)
~OSD V-Position : Moves the screen position of the menu up or down. (Adjust 0 ~ 100)
~OSD Transparency : Sets the transparency of the menu screen. (Adjust 0 ~ 100)
~OSD Time Out : The menu screen disappears if the screen does not change for a certain period of
time. (Adjust 0 ~ 100)
~OSD Rotation : You can rotate the menu screen. (Normal/90/180/270)

English _17
Other
1. Press the MENU/EXIT button to enter the main menu.
2. Press the $/%button to select <Other>, and then press the ENTER or +button.
CAMERA
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
USB Update FW
Reset
Window1:
InputSource: CAMERA
Resolution: 1920x1080@60Hz
Resolution: 1920x1080@60Hz
Idle
Window2:
InputSource:
Resolution:
~USB Update FW : The monitor can be updated by connecting a USB to the USB port. (Idle/Writing)
~Reset : Resets the monitor settings to default.

18_ network connection and setup & webviewer
network connection and setup & webviewernetwork connection and setup & webviewer
You can set up the network settings according to your network configurations.
CONNECTING THE PVM DIRECTLY TO LOCAL AREA NETWORKING
Connecting to the PVM from a local PC in the LAN
1. Launch an Internet browser on the local PC.
2. Enter the IP address of the PVM in the address bar of the browser.
<Local Network>
Local PC
INTERNET
External Remote PC
DDNS Server
(Data Center, KOREA)
M ` A remote PC in an external Internet out of the LAN network may not be able to connect to the PVM installed
in the intranet if the port-forwarding is not properly set or a firewall is set.
In this case, to resolve the problem, contact your network administrator.
` By factory default, the IP address will be assigned from the DHCP server automatically.
If there is no DHCP server available, the IP address will be set to 192.168.1.100.
To change the IP address, use the Device Manager.
For further details on Device Manager use, refer to “Using Device Manager”. (Page 20)

English _19
CONNECTING THE PVM DIRECTLY TO A DHCP BASED DSL/CABLE MODEM
External Remote PC
DDNS Server
(Data Center, KOREA)
DSL/Cable Modem
INTERNET
1. Connect the user PC directly with the PVM.
2. Run the Device Manager and change the IP address of the PVM so that you can use the web
browser on your desktop to connect to the Internet.
3. Use the Internet browser to connect to the web viewer.
4. Move to [Setup] page.
5. Move to [Network] – [DDNS] and configure the DDNS settings.
6. Move to [Basic] – [IP & Port], and set the IP type to [DHCP].
7. Connect the PVM, which was removed from your PC, directly to the modem.
8. Restart the camera.
M ` For information on how to set DDNS, refer to the online help of Web Viewer.
` For information on how to set the IP format, refer to the online help of Web Viewer.

20_ network connection and setup & webviewer
network connection and setup & webviewer
USING DEVICE MANAGER
M `
Device manager program can be downloaded from <Support>-<Online Tools> menu at Hanwha Vision
website (https://www.HanwhaVision.com).
` More instructions of Device Manager can be found at <Help> menu of the main page.
AUTOMATICALLY SEARCHING CAMERA
If a camera is connected to the same network of the PC where device manager is installed, you can find
network camera by using search function.
1. Click <Search> at the main page of device manager.
2. Check the camera from the list.
~Check MAC address at the sticker attached to the camera.
CONFIGURING IP ADDRESS
If you want to change camera network setting, <Login OK> sign must be displayed at <Status>. Click
<Authentication> at the main page to log in.
Configuring Static IP
Manually insert and configure IP address & port information.
1. Click the camera from the list that you want the change the
IP setting.
2. Click <IP Assign> at the main page of device manager.
3. Select <Assign the following IP address>.
~IP information of the camera will be displayed as previously
set.
4. Fill in IP & Port related categories.
If not using a Broadband Router
For setting <IP Address>, <Subnet Mask>, and <Gateway>, contact your network administrator.
~HTTP Port : Used to access the camera using the Internet browser, defaulted to 80.
~RTSP Port: A port that controls real-time streaming. The initial value is 554.
