Happy Beds SNOWDON User manual

Title of Product
Assembly Instructions
www.happybeds.co.uk
Important before assembly:
.
Health & Safety:
.
Read these instructions carefully before assembling or using the product.
Please check the contents of the boxes before attempting to assemble this product. The instructions will
have a checklist of parts and fittings.
It would be sensible to lay a rug or a carpet on the floor where you intend to assemble the product, to avoid
scratches and damaging the product or the floor.
Assemble the product as close to its intended final location/room as possible.
Do NOT use any power tools as this may damage the frame.
This product or some parts of this product will be heavy. Please use an assistant when lifting.
Please keep small parts out of reach of children.
Always use on a level, even surface.
DO NOT jump on the product or any of its parts.
DO NOT use this product if any parts are missing, damaged or worn.
DO NOT use this product unless all fixings are secured.
Please keep these instructions for future reference.
SNOWDON Bunk Bed

@
This product or some parts of this product will be heavy. Please use an assistant
when lifting.
Never drag or push the pieces across a hard or stone floor as this will cause
damage to the joints. Use a carpet or a rug for extra care.
If you have problems assembling or have damaged or missing pieces, please
contact us by visiting:
https://www.happybeds.co.uk/customer-service
(Not metal)
These tools are not
necessary, but may
help to assemble
certain parts of the
product.
Do NOT use any power
tools as this may
damage the frame.

1/15
A8x40x80
B7x60x12
C7x50x28
DD35x12
E M6x75 x16
F M6x10x13 x16
G6,3x70x2
H 55/12,2x5 x14
J3,5x40x90
K4,2x35x2
L 20x42x70 x2
M4x30x4
N7x34x4
P D15x13,5 x4
R D4x13 x28
S D8x13 x8
T D15x18 x18
UD35x12
V D4x17 x4
XD13x4
Y D25x3 x4
Z4mmx1
NR879-106/108
15
5
15
8
9
97
7
7
7
7
7
6
6
5
3
3
1
15
14 14
13
12
11
2
4
4
810
B
A
Batch nr:

2/15
Assembling instructionsMontageanleitung
DEN
ITFR Istruzioni per montaggioNotice de montage
WICHTIG ‐ AUFMERKSAM LESEN ‐ ZUR SPATEREN
EINSICHTNAHME AUFZUBEWAHREN
a) WARNUNG Hochbetten und das obere Bett bei Etagenbetten sind wegen
des Verletzungsrisikos durch Stürze nicht für Kinder unter sechs Jahren
geeignet.
b) WARNUNG Wenn sie nicht richtig verwendet werden, können Hochbetten
und Etagenbetten ein schweres Verletzungsrisiko durch Strangulierung
darstellen. Es dürfen niemals Elemente an Teilen des Hochbetts befestigt oder
aufgehängt werden, die nicht zur Verwendung mit besagtem Bett bestimmt
sind. Diese Elemente umfassen, sind aber nicht beschränkt auf, Seile, Fäden,
Schnüre, Haken, Gürtel und Taschen.
c) WARNUNG Kinder k nnen sich zwischen dem Bett und einer Wand, einer
gekippten Wandstelle, der Decke, M beln in der Nähe (zum Beispiel
Schränke) oder anderem einklemmen. Um jedes Risiko einer schweren
Verletzung zu vermeiden, darf der Abstand zwischen der oberen
Sicherheitsschranke und den Elementen in der Umgebung 75 mm nicht
uberschreiten oder muss gr ßer als 230 mm sein.
d) WARNUNG Das Hochbett oder das Etagenbett darf nicht verwendet
werden, wenn ein Teil des Aufbaus fehlt oder beschadigt ist. Ersatzteile
mussen beim Hersteller oder im Laden bestellt werden.
e) Die Montage‐ und Gebrauchsanweisungen des Herstellers mussen
unbedingt immer befolgt werden.
Die empfohlene Gr ße der mit dem Bett zu verwendenden Matratze betragt
k) Die Montagevorrichtungen mussen immer angemessen festgezogen und
regelmäßig uberprüft werden. W enn nötig, erneut festziehen.
l) Entspricht den europaischen Sicherheitsanforderungen der Norm
EN 747+A1 : 2015.
m) Wenn ein Nachtlicht vorhanden ist, kann dies dem im oberen Bett
schlafenden Kind mehr Sicherheit geben.
IMPORTANT ‐ READ CAREFULLY ‐ KEEP FOR
FUTURE REFERENCE
a) WARNING Raised beds and the upper bed in a bunk bed assembly are
not good for children under 6 years old
because of the risk of injury from falling from such beds,
b) WARNING If the raised and bunk beds are not used correctly, they can
present a serious risk of injury from strangulation. Never attach or suspend
things from the upper bunk bed that are not going to be used with that bed.
Such things include ‐ but are not limited to ‐ cords, string, sashes, hooks,
belts and bags.
c) WARNING Children can find themselves trapped between the bed and
wall, or inclined roof wall, ceiling, adjacent pieces of furniture (such as
cupboards) or other items. To avoid any risk of serious injury, the distance
between the upper safety barrier and surrounding items should not exceed
75 mm ‐ or the distance should be greater than 230 mm.
d) WARNING Do not use the upper bunk bed or a raised bed if a part of the
structure is missing or broken. Spare parts should be requested from the
manufacturer or shop.
e) It is essential that the manufacturer's instructions on assembly and use
are followed.
f) The recommended size of the mattress to be used with the bed is 1900
mm x 900, Maximum mattress thickness: 164mm,
g) Mattresses must be aired to maintain a low humidity and to stop moisture
building up in the bed and its surroundings.
k) The fastenings put in place on assembly should all be properly tightened
and regularly checked. Retighten the fastenings as necessary.
l) This complies with the requirements of the European Safety Standard
EN 747+A1: 2015.
m) The presence of a night light could give more safety for a child sleeping
in an upper bed.
IMPORTANT ‐ LIRE ATTENTIVEMENT ‐ A
CONSERVER POUR REFERENCE ULTERIEURE
a) AVERTISSEMENT Les lits suréleves et le lit supérieur des lits
superposés ne conviennent pas pour les enfants
de moins de six ans en raison du risque de blessures liées à des chutes,
b) AVERTISSEMENT S'ils ne sont pas utilisés correctement, les lits
superposés et les lits surélevés peuvent présenter un sérieux risque de
blessure par étranglement. Ne jamais attacher ou suspendre des éléments
à des parties du lit superposé qui ne sont pas destinés à être utilisés avec
ledit lit. Ces éléments comprennent, sans toutefois s'y limiter, les cordes,
les ficelles, les cordons, les crochets, les ceintures et les sacs,
c) AVERTISSEMENT Les enfants peuvent se retrouver coincés entre le lit
et un mur, une partie d'un toit incliné, le plafond, des meubles adjacents
(par exemple, des placards) ou autre. Pour éviter tout risque de blessure
grave, la distance entre la barrière de sécurité superieure et les éléments
environnants ne doit pas dépasser 75 mm ou doit être supérieure a 230
mm,
d) AVERTISSEMENT Ne pas utiliser le lit superposé ou le lit surélevé si
une pièce de la structure est manquante ou
cassée. Les pièces de rechange doivent être demandés auprès du
fabricant ou du magasin.
e) Il est impératif de toujours suivre les instructions de montage et
d'utilisation du fabricant,
f) La taille recommandée du matelas à utiliser avec le lit est de 1900mm x
900mm, Epaisseur du matelas maximum : 164mm,
g) Il est nécessaire de ventiler la pièce afin de maintenir un niveau peu
élevé d'humidité et d'empêcher le
développement de moisissure dans le lit et sa périphérie,
k) Les dispositifs d'assemblage doivent toujours être convenablement
serrés et régulièrement vérifié. Les resserrer
si nécessaire.
l) Conforme aux exigences européenne de securité de la norme
EN 747+A1 : 2015.
m) la présence d'une veilleuse de nuit peut procurer plus de sécurité à
l'enfant couchant dans le lit haut
IMPORTANTE ‐ LER ATENTAMENTE ‐ A
GUARDAR PARA REFERENCIA FUTURA
a) AVVERTENZE I letti a soppalco ed il letto superiore dei letti a castello
non sono adatti ai bambini di età inferiore ai sei anni per i rischi di lesioni
dovute a cadute,
b) AVVERTENZE Se non utilizzati correttamente, i letti a castello ed i letti
a soppalco possono rappresentare un importante rischio di lesioni da
strangolamento. Non legare o sospendere mai elementi a delle parti del
letto a castello che non siano previsti per essere utilizzati con il suddetto
letto. Questi elementi comprendono, senza tuttavia esserne limitati, le
corde, gli spaghi, i cordoncini, i ganci, le cinghie ed i sacchi,
c) AVVERTENZE I bambini possono ritrovarsi bloccati tra il letto ed un
muro, la parte di un tetto inclinato, il soffitto, i mobili adiacenti (per
esempio gli armadi) o altro. Per evitare qualsiasi rischio di lesione grave,
la distanza tra la sponda di sicurezza superiore e gli elementi circostanti
non deve superare 75 mm o deve essere superiore a 230 mm,
d) AVVERTENZE Non utilizzare il letto a castello o il letto a soppalco se
un pezzo della struttura manca o se è rotto. I pezzi di ricambio devono
essere richiesti al fabbricante o al negozio.
e) Seguire rigorosamente le istruzioni di montaggio e d'uso del
fabbricante,
f) La misura consigliata del materasso da usare con il letto è di 1900mm x
900mm, Spessore massimo del materasso: 164mm,
g) Per mantenere un livello poco elevato di umidità, e per impedire lo
sviluppo di muffa nel letto e intorno al letto, ventilare la stanza,
k) I dispositivi d'assemblaggio devono sempre essere adeguatamente
stretti e regolarmente verificati. Ristringerli se necessario.
l) Conforme alle esigenze europee di sicurezza della norma
EN 747+A1: 2015.
m) la presenza di una luce notturna può dare più sicurezza al bambino
che dorme nel letto superiore
ö
ö
ö
ö
f)
1900 mm x 900 mm. Höchstdicke der Matratze: 164mm,
g) Es ist notwendig, den Raum zu lüften, um einen geringen Feuchtigkeitsgrad
aufrechtzerhalben und die
Entwicklung von Schimmel im Bett und seiner Umgebung zu verhindern.
164mm

3/15
