Hardi MARRO TWIN FORCE 1000 User manual

GB 01 03 01
Illustrations, technical information and data in this book are to the best of our belief correct at the time of printing. As
it is HARDI INTERNATIONAL A/S policy permanently to improve our products, we reserve the right to make
changes in design, features, accessories, specifications and maintenance instructions at any time and without
notice.
HARDI INTERNATIONAL A/S is without any obligation in relation to implements purchased before or after such
changes.
HARDI INTERNATIONAL A/S cannot undertake any responsibility for possible omissions or inaccuracies in this
publication, although everything possible has been done to make it complete and correct.
As this instruction book covers more models and features or equipment, which are available in certain countries
only, please pay attention to paragraphs dealing with precisely your model.
MARRO TWIN FORCE
Instruction book
674156-GB-2001/04
We congratulate you for choosing a HARDI plant protection product. The reliability and
efficiency of this product depend upon your care. The first step is to carefully read and
pay attention to this instruction book. It contains essential information for the efficient
use and long life of this quality product.
This book is to be read in conjunction with the “Spray Technique” book.

2

3
TT
TT
Taa
aa
abb
bb
ble ofle of
le ofle of
le of ContentsContents
ContentsContents
Contents
Declaration of Conformity .................................................... 4
Operator safety ...................................................................... 5
Description ............................................................................ 6
Identification plate .......................................................... 6
Sprayer use ............................................................................ 6
Unloading the sprayer from the truck ................................. 7
Parking stand for front tank (optional equipment) .......... 7
Before putting the sprayer into operation .......................... 7
MARRO set-up ....................................................................... 8
Connecting the front tank ............................................... 8
Connecting the MARRO lift ............................................ 9
Conversion between cat. II and cat. III .......................... 9
Set up - hoses .............................................................. 10
Transmission shaft ............................................................. 11
Operator safety ............................................................ 11
Transmission shaft installation ..................................... 11
Hydraulic system ................................................................. 12
Direct Acting Hydraylics, D.A.H. .................................. 12
Control boxes and power supply ...................................... 12
Transport position .............................................................. 13
Height setting ............................................................... 13
Transport lock .............................................................. 13
Transport brackets ....................................................... 13
Width setting ................................................................ 13
Boom transport safety chains (if fitted) ........................ 13
Roadworthyness ................................................................. 14
Rear lights............................................................................ 14
Head lamps (if fitted) .......................................................... 14
Connecting a trailer ............................................................ 14
Operating the HAZ boom ................................................... 15
Functions of the control box ......................................... 15
Unfolding the boom ..................................................... 15
Folding the boom ......................................................... 15
Hydraulic slanting control ............................................ 15
Boom tilt function ......................................................... 15
Air slot angling ............................................................. 15
Electric fan speed adjustment (if fitted) ....................... 15
Boom support wheels .................................................. 16
Boom suspension sensitivity ....................................... 16
MANIFOLD SYSTEM ........................................................... 17
Use of MANIFOLD valve system ................................ 17
Filling of water .............................................................. 18
Filling through tank lid .................................................. 18
Suction Filling Device (if fitted) .................................... 18
Fast Filling Device (if fitted) ......................................... 19
Filling of rinsing tank .................................................... 20
Filling of clean water tank (if fitted) .............................. 20
Adjustments of EC operating unit ................................ 21
By-pass valve ............................................................... 21
Remote pressure gauge .............................................. 21
Filters ........................................................................... 22
Filling of chemicals. ..................................................... 22
Filling through tank lid .................................................. 22
Filling by HARDI FILLER chemical inductor ................ 23
Filling by HARDI FILLER chemical inductor ................ 24
Use of rinsing tank and rinsing nozzles (if fitted) ........... 25
Technical Residue ............................................................... 25
Operation of the tank drain valve ...................................... 26
Rinsing tank drain valve............................................... 26
Safety precautions .............................................................. 26
Personal protection ...................................................... 26
Air technique ....................................................................... 27
Air speed / Air volume .................................................. 27
Blower adjustment ....................................................... 27
Angling of air and liquid. .............................................. 27
Adjusting the air assistance ......................................... 27
Water sensitive paper .................................................. 29
Disconnecting the MARRO ................................................ 33
Parking stand for front tank (Optionmal equipment) .... 33
Disconnecting the hoses ............................................. 34
Maintenance - rules of thumb ............................................ 35
Cleaning the sprayer ........................................................... 35
Lubrication .......................................................................... 37
Service and Maintenance ................................................... 40
10 hours service .......................................................... 40
50 hours service .......................................................... 40
250 hours service ........................................................ 40
500 hours service ........................................................ 40
1000 hours service ...................................................... 40
Occasional maintenance ............................................. 40
Off-season storage ............................................................. 51
Preparation after off-season storage ........................... 51
Fault-finding ........................................................................ 52
Operational problems ......................................................... 52
Liquid system ............................................................... 53
Hydraulic system ......................................................... 54
EC Operating unit ........................................................ 54
D.A.H. Hydraulic system .............................................. 55
Hydraulic fan transmission .......................................... 56
Emergency operation of the sprayer ................................. 57
The boom ..................................................................... 57
EC operating unit ......................................................... 57
Technical specifications ..................................................... 58
Overall dimensions ...................................................... 58
Weight .......................................................................... 58
Pump capacity ............................................................. 58
Filters and nozzles ....................................................... 58
Filter gauze width ......................................................... 58
Temperature and pressure ranges .............................. 58
Electrical connections .................................................. 59
Rear lights .................................................................... 59
Materials and recycling ................................................ 59
Disposal of the sprayer ................................................ 59
Conversion factors, SI to Imperial units ....................... 59
Boom hydraulic HAZ .................................................... 60
Electric chart HAZ ........................................................ 60
Junction box HAZ......................................................... 60
Transmissions HAZ ...................................................... 61

4GB 02 01
CE DecCE Dec
CE DecCE Dec
CE Declarlar
larlar
laraa
aa
ationtion
tiontion
tion
DecDec
DecDec
Declarlar
larlar
laraa
aa
ation oftion of
tion oftion of
tion of ConfConf
ConfConf
Conformityormity
ormityormity
ormity
Manufacturer, Importer,
HARDI INTERNATIONAL A/S
Helgeshøj Allé 38
DK 2630 Taastrup
DENMARK
declare that the following product;
_________________________________________________________________________________________
A. was manufactured in conformity with the provisions in the COUNCIL DIRECTIVE of 14 June 1989 on mutual
approximation of the laws of the Member States on the safety of machines (89/392/EEC as amended by directives
91/368/EEC and 93/368/EEC) with special reference to Annex 1 of the Directive on essential safety and health
requirements in relation to the construction and manufacture of machines.
B. was manufactured in conformity with the current standards implementing harmonised standards in accordance
with Article 5 (2) and other relevant standards.
Taastrup, October 2000
_____________________________________________
Mogens Nehen-Hansen
Managing Director
HARDI INTERNATIONAL A/S
Adhere extra shipping package labels in the Product Identification Certificate.

5
GB 03 01
SafSaf
SafSaf
Safety notesety notes
ety notesety notes
ety notes
OperOper
OperOper
Operaa
aa
ator saftor saf
tor saftor saf
tor safetyety
etyety
ety
Watch for this symbol.
It means WARNING, CAUTION,
NOTE. Your safety is involved so
be alert!
Note the following recommended precautions and safe
operating practices.
Read and understand this instruction book
before using the equipment. It is equally
important that other operators of this equip-
ment read and understand this book.
Local law may demand that the operator is
certified to use spray equipment. Adhere to
the law.
Pressure test with clean water prior to filling
with chemicals.
Wear protective clothing.
Rinse and wash equipment after use and
before servicing.
Depressurize equipment after use and before
servicing.
Never service or repair the equipment while it
is operating.
Disconnect electrical power before servicing.
Always replace all safety devices or shields
immediately after servicing.
If an arc welder is used on the equipment or
anything connected to the equipment, dis-
connect power leads before welding. Re-
move all inflammable or explosive material
from the area.
Do not eat, drink or smoke while spraying or
working with contaminated equipment.
Wash and change clothes after spraying.
Wash tools if they have become contami-
nated.
In case of poisoning, immediately seek
medical advice. Remember to identify chemi-
cals used.
Keep children away from the equipment.
Do not attempt to enter the tank.
Do not go under any part of the sprayer
unless it is secured. The boom is secure
when placed in the transport brackets.
If any portion of this instruction book remains unclear
after reading it, contact your HARDI dealer for further
explanation before using the equipment.

6GB 04 01 01
Identification plate
An identification plate fitted on the frame indicates model
and serial no. Boom centre frame, and inner/outer
sections also have identification plates indicating boom
type and part number of spare parts. If ordering spare
parts, inform your dealer of these, so the right model and
version are described.
DescriptionDescription
DescriptionDescription
Description
Frame
Strong and compact frame which has a strong chemical
and weather resistant electrostatic lacquer coat.
Screws, nuts, etc. have been DELTA-MAGNI treated to
be resistant to corrosion.
Front tank
UV-resistant Polyethylene in a suitable design with no
sharp corners for easy agitation, emptying, and cleaning.
Nominal contents: 1000 l or 1300 l.
Pump
Diaphragm pump with 6 diaphragms, model 463, with
easily accessible valves and diaphragms. Standard =
540 r.p.m, optional = 1000 r.p.m.
MANIFOLD SYSTEM
All functions of the spray circuits are operated via the
centrally situated MANIFOLD valves with colourcoded
plates and pictorial symbols for easy operation.
Operating unit
The operating unit is constructed of modules and con-
sists of main ON/OFF valve, pressure gauge, pressure
regulation with built-in HARDI-MATIC and distribution
valves with pressure equalization. HARDI-MATIC en-
sures a constant volume per hectare of the liquid (l/ha)
at varying forward speed within the same gear when the
number of P.T.O. revolutions are between 300-600 r/min
(for pump/540 r.p.m.) or 650-1100 r/min (for pump/1000
r.p.m.).
The operating unit is fully electrically controlled (EC) via
remote control box.
Filters
With the self-cleaning filter the impurities that exist in the
spray liquid will by-pass the filter and be recirculated
back to the tank via the return flow. Also suction filter
and nozzle filters are standard. In-line pressure filters
can be fitted as option.
Boom
The sprayer is equipped with a HAZ boom, avaliable in
18, 20, 21 and 24 m working width. The boom is sus-
pended in a strong, stable parallelogram boom lift and is
fully hydraulically operated, including boom slanting
control and air slot angling. The HAZ boom has Direct
Acting Hydraulics (D.A.H) and individual boom tilt
function as well.
All boom widths can spray 12 m with outer sections
folded.
The TWIN blowers are driven by a built-in hydrostatic
transmission, powered via the tractor P.T.O. Blower
speed can be adjusted stepwise from the tractor cabin.
T021-0018
T279-0002
SprSpr
SprSpr
Spraa
aa
ayy
yy
yer useer use
er useer use
er use
The HARDI COMMANDER sprayer is for the application
of crop protection chemicals and liquid fertilisers.
The equipment must only be used for this purpose. It is
not allowable to use the sprayer for other purposes.
If no local law demands that the operator must be
certified to usespray equipment, it is strongly recom-
mended to be trained in correct plant protection and in
safe handling of plant protection chemicals to avoid
unnecessary risk for persons and the environment when
doing your spray job.

7
GB 04 01 01
Unloading the sprUnloading the spr
Unloading the sprUnloading the spr
Unloading the spraa
aa
ayy
yy
yer frer fr
er frer fr
er from the trom the tr
om the trom the tr
om the trucuc
ucuc
uckk
kk
k
For the unloading of the sprayer, you need a crane or a
fork lift.
When loading with a crane please observe the lifting
points as shown on the sketches, and make sure that
the straps or belts used for lifting are strong enough.
PP
PP
Parar
arar
arkk
kk
king stand fing stand f
ing stand fing stand f
ing stand for fror fr
or fror fr
or front tank (optionalont tank (optional
ont tank (optionalont tank (optional
ont tank (optional
equipment)equipment)
equipment)equipment)
equipment)
A stand for parking the front tank when not used is
available (ref. no. 833269).
BefBef
BefBef
Beforor
oror
ore putting the spre putting the spr
e putting the spre putting the spr
e putting the spraa
aa
ayy
yy
yer intoer into
er intoer into
er into
operoper
operoper
operaa
aa
ationtion
tiontion
tion
Although the sprayer has been applied with a strong and
protective surface treatment on steel parts, bolts etc. in
the factories, it is recommended to apply a film of
anticorrosion oil (e.g. CASTROL RUSTILLO or SHELL
ENSIS FLUID) on all metal parts in order to avoid
chemicals and fertilisers discoloring the enamel.
If this is done before the sprayer is put into operation for
the first time, it will always be easy to clean the sprayer
and keep the enamel shiny for many years.
This treatment should be carried out every time the
protection film is washed off.
T021-0016x
MARRO
Front tank
T021-0004x
T021-0004x

8GB 05 01 02
MARRO set-upMARRO set-up
MARRO set-upMARRO set-up
MARRO set-up
WARNING! Note these recommendations:
1. Add front tank to the tractor before mounting the
MARRO lift.
2. Adjust tyre pressure (see tractor’s instruction book)
3. Be careful when filling/lifting the sprayer for the first
time
4. Ensure that the operating unit and the tractor do not
touch
Front tank
T021-0020x
T021-0021x
Connecting the frConnecting the fr
Connecting the frConnecting the fr
Connecting the front tankont tank
ont tankont tank
ont tank
Tractor with front lift
Quick hitch 3-point linkage frame (ref. no. 732319) must
be mounted to the front tank; fasten it by two bolts
(M16 x 55).
Standard = cat. II wide. If conversion to cat. III is neces-
sary, please see the part “Connecting the MARRO lift”
for further information.
Fit the two reinforcement mountings on the linkage
frame as shown on
the drawing. Fasten
each with two bolts
(M16 x 50).
Tractor without front lift
A base plate for hook-on attachment (ref. no. 161594)
must be used as interface between tractor and front
tank.
This plate needs to be welded to two longitudinal bear-
ers, which subsequently can be bolted to each side of
the tractor.
NOTE! The two longitudinal bearers should be extended
as far as possible towards the rear axle of the tractor.
It is strongly recommended to leave this job to your
tractor dealer, who is familiar with tractor manufacturing
recommendations.
To connect the front tank:
1. Lift the front tank, e.g. by a small crane, and lower it
onto the mounting, fastened on the tractor. The two
jags A on the tank frame must catch hold on the
mounting as shown on the drawing.
2. Secure the set up by two bolts ( M16 x 55).
T021-0022x
A
T021-0023

9
GB 05 01 02
B
C
T021-
Connecting the MARRO liftConnecting the MARRO lift
Connecting the MARRO liftConnecting the MARRO lift
Connecting the MARRO lift
The MARRO is designed for three point suspension and
is equipped with semi automatic hitch for the tractor lift
arms (cat. II wide).
1. Fit the carrier rod in tractor lift arms and secure with
10 mm pins A.
2. Lower tractor lift arms
3. Reverse tractor till carrier rod
is under the sprayer hitch
4. Lift the lift arms carefully till
the locking devices “clicks”
and the carrier rod is locked
to the sprayer frame
5. Fit the top bar, secure with
pins
6. Lift the sprayer
7. Retract each of the four
support legs
Retraction of support legs
1. Remove the lock pin.
2. Push up the support leg till the lower hole B in the
inner profile matches the hole C in the outer profile.
3. Fasten this position by the pin A.
4. Position the tractor lift so the boom can be lowered to
45-50 cm in lowest position, and adjust top bar until
the gantry is perpendicular to the ground.
støtteben mega
Conversion between cat. II and cat. III
Both the semi automatic hitch and the 3-point linkage
frame for front tank are standard cat. II wide. For use
with cat. III use bushes A (ref. no. 147575). Secure with
lock pin.
The clevis for top bar is standard cat III. For use with cat.
II use bushes B (ref. no. 147576).
T021-023x
A
B

10 GB 05 01 02
Set up - hosesSet up - hoses
Set up - hosesSet up - hoses
Set up - hoses
marro2
The hoses must be secured with
straps each 20 cm between MANI-
FOLD valves and front tank
Distance: 20 cm
Attach the hoses with fittings to the
fronttank
1: Self Cleaning Filter
2: Suction
3: HARDI Filler
4: Agitation
Pull out the step at front to get acces
to the top of the tank
The hoses are led from the MANI-
FOLD valves along the side of the
tractor to the front tank as shown
on the drawing. Routing of hoses
will vary depending on tractor
model.
1
2
3
4

11
GB 05 03 03
TT
TT
Trr
rr
ransmission shaftansmission shaft
ansmission shaftansmission shaft
ansmission shaft
OperOper
OperOper
Operaa
aa
ator saftor saf
tor saftor saf
tor safetyety
etyety
ety
To avoid accidents and personal injuries, note the
following recommended precautions and safe operation
practices.
Always STOP ENGINE before attaching the transmis-
sion shaft to tractor P.T.O. - most tractor P.T.O. shafts
can be rotated by hand to facilitate spline alignment,
when engine is stopped.
When attaching the shaft, make sure that the snap lock
is FULLY ENGAGED - push and pull shaft until it locks.
WARNING! ROTATING TRANSMISSION
SHAFTS WITHOUT PROTECTION GUARDS
ARE FATAL.
Always keep protection guards and chains intact and
make sure that it covers all rotating parts, including CV-
joints at each end of the shaft. Do not use without
protection guard.
Do not touch or stand on the transmission shaft when it
is rotating - safety distance: 1.5 meter.
Prevent protection guards from rotating by attaching the
chains allowing sufficient slack for turns.
Make sure that protection guards around tractor P.T.O.
and implement shaft are intact.
Always STOP ENGINE and remove the ignition key
before carrying out maintenance or repairs to the trans-
mission shaft or implement.
TT
TT
Trr
rr
ransmission shaft installaansmission shaft installa
ansmission shaft installaansmission shaft installa
ansmission shaft installationtion
tiontion
tion
First installation of the transmission shaft is done the
following way:
1. Attach sprayer to tractor and set sprayer height in the
position with shortest distance between the tractor
and sprayer pump P.T.O. shafts.
2. Stop engine and remove ignition key.
3. If transmission shaft must be shortened, the shaft is
pulled apart. Fit the two shaft parts at tractor and
sprayer pump and measure how much it is necessary
to shorten the shaft. Mark the protection guards.
NOTE! The shaft must always have an overlap of
minimum 1/3 of the length.
4. The two parts are shortened equally. Use a saw, and
file the profiles afterwards to remove burrs.
5. Grease the profiles, and assemble male and female
parts again.
6. Grease the tractor P.T.O. and pump shafts.
7. Fit the shaft to tractor P.T.O. and sprayer pump shaft.
Note: Female part marked with a tractor towards
tractor! Twist the collar and slide the yoke onto the
P.T.O. shaft. Make sure
that the lock engages by
pushing and pulling the
shaft forwards and
backwards. Fit the
chains to prevent the
protection guards from
rotating with the shaft.
8. When operating,
ensure that joint
angles are equal.
Disengage the
P.T.O. when the
angle of the joints
exceeds 35o
T259-0004
T259-0001
T259-0005 T259-0007
T259-0003
T259-0010

12
GB 05 06 02 01
HyHy
HyHy
Hydrdr
drdr
draulic syaulic sy
aulic syaulic sy
aulic systemstem
stemstem
stem
DirDir
DirDir
Direct Acting Hyect Acting Hy
ect Acting Hyect Acting Hy
ect Acting Hydrdr
drdr
draa
aa
aylicsylics
ylicsylics
ylics, D, D
, D, D
, D.A.H..A.H.
.A.H..A.H.
.A.H.
The D.A.H. system requires a double acting hydraulic
outlet. The hydraulic hoses are marked with arrows to
indicate direction of oil flow.
The D.A.H. system requires an oil flow between 10 and
90 l/min (19.8 Imp. gal/min.) and a min. pressure of 130
bar (1886 psi.). The system has a built-in flow regulator
that maintains constant speed on hydraulic movements.
Before operating the hydraulics, the clip at the distribu-
tion valve (situated under the platform behind the pump)
should be set for OPEN CENTRE or CLOSED CENTRE
tractor hydraulics, depending on tractor model.
1. Unlocked = Open centre hydraulics (Constant Flow)
2. Locked = Constant Pressure (Closed Centre) and
Load-Sensing hydraulics
If you doubt which type of hydraulic system your tractor
is equipped, ask your tractor dealer.
WARNING! Hydraulic leaks: Never use your
fingers to locate a leakage in any part of the
hydraulic system. Due to high pressure, hydraulic
oil may penetrate the skin.
ContrContr
ContrContr
Control bool bo
ol bool bo
ol boxx
xx
xes and powes and pow
es and powes and pow
es and power supplyer supply
er supplyer supply
er supply
12V power sockets are required for the control boxes.
Note polarity!
For EC: Brown pos. (+), Blue neg. (-)
For D.A.H.: White pos. (+), Black neg. (-)
The control boxes for EC
operating unit and D.A.H.
are to be fitted in the tractor
cabin at a convenient place.
Tapping screws can be
used for mounting.
The wires must have a cross-sectional area of at least
4.0 mm2 (#10 awg) to ensure sufficient power supply.
The boxes must be fused according to the table.
Use the HARDI Electric distribution box (No. 817925) if
the tractor has a doubtful power supply.
rofxoblortnoC )ruoloceriw(ytiraloP deriuqeR
pmA,esuF
)+(evitisoP)-(evitageN
tinugnitarepoCEnworBeulB8
riAcirtcelE+.H.A.D
nafdnaelgnatol
tnemtsujdadeeps
etihWkcalB02
evlavDLOFINAMnworBeulB8
chart 005
T165-0013
11
11
122
22
2
T020-0024

13
GB 05 08 03
TT
TT
Trr
rr
ransporanspor
ansporanspor
ansport positiont position
t positiont position
t position
The height and width of the transport brackets can be
set in different positions. Choose a setting which gives
sufficient clearance from the tractor cabin.
IMPORTANT! Make sure that max. transport height and
width are not exceeded.
Height settingHeight setting
Height settingHeight setting
Height setting
NOTE! The rear settings must correspond to the front
settings so the boom is resting on the front as well as
rear brackets.
WARNING! The max. transport height must
never exceed 4.0 m (13.1 ft) Always measure the
actual total height, and choose settings not
exceeding 4.0 metre.
Transport lock
The setting of the transport lock determines the bearing
point of the boom when it rests in the transport brackets.
The setting is adjustet by means of the hole combination
in the brackets A + B.
1. Lift and unfold
inner sections till
lock is disen-
gaged.
2. Loosen and
remove the two
bolts, which
keep the parts A
and B
assembled.
3. Reassemble A
and B according
to the desired
hole combina-
tion.
NOTE! Always use both
bolts to assemble the lock
Transport brackets
The height of the transport brackets can be adjusted up
and down as shown on the drawing.
Simply loosen the bolts in
both sides, adjust the
height of the brackets
and fasten the bolts
again according to new
position.
Width settingWidth setting
Width settingWidth setting
Width setting
The width of the sprayer can be independently adjusted
for each side, Be aware of the risk of
sideway movements of the folded
boom during transportation and
make sure to leave suffi-
cient room for such
in the width
setting.
Boom trBoom tr
Boom trBoom tr
Boom transporanspor
ansporanspor
ansport saft saf
t saft saf
t safety cety c
ety cety c
ety chains (ifhains (if
hains (ifhains (if
hains (if ff
ff
fitted)itted)
itted)itted)
itted)
Fit the safety chains as shown before transport on public
road.
A
T021-0017x
B
T021-0023x
T101-0031
T021-0017x
T030-0001

14 GB 05 08 03
RR
RR
Roadwoadw
oadwoadw
oadworor
oror
orthynessthyness
thynessthyness
thyness
When driving on public roads and other areas where the
highway code applies, or areas where there are special
rules and regulations for marking and lights on imple-
ments, you should observe these and equip implements
accordingly.
RR
RR
Rear lightsear lights
ear lightsear lights
ear lights
Connect plug for rear lights to the tractor’s 7-pin socket
and check the functions of rear lights, stop lights and
direction indicators on both sides ot the sprayer before
driving.
The wiring is in accordance with ISO 1724 (See section
on Technical Specifications).
Head lamps (ifHead lamps (if
Head lamps (ifHead lamps (if
Head lamps (if ff
ff
fitted)itted)
itted)itted)
itted)
Head lamps can be mounted on the front tank. Please
see the part “Occasional maintenance - Adjustment of
head lamps” for the correct positioning of the lamps.
Connecting a trConnecting a tr
Connecting a trConnecting a tr
Connecting a trailerailer
ailerailer
ailer
A coupling can be mounted on the MARRO lift for the
purpose of connecting a trailer.
NOTE! Only connect 4-wheeled trailers.
Load limits
Max horizontal load: 1000
kg
Max. vertical load: 50 kg
For further information, please refer to instructions given
by the coupling manufacturer.
T202-0010x
T274-0003x

15
GB 07 02 02
OperOper
OperOper
Operaa
aa
ating the HAZ boomting the HAZ boom
ting the HAZ boomting the HAZ boom
ting the HAZ boom
WARNING! Be cautious with initial use of the
hydraulic systems. If there is air in the system,
this may cause violent movements of the boom.
Therefore, take care that no persons or objects are hurt
or damaged in the process of testing.
DANGER!
When folding
and unfolding
the boom, be sure
that no persons or
objects are in the
operating area of the
boom, and that the
boom cannot touch
any electrical conductors!
Functions ofFunctions of
Functions ofFunctions of
Functions of the contrthe contr
the contrthe contr
the control bool bo
ol bool bo
ol boxx
xx
x
1. Raising and lowering of boom
2. Unfolding/folding of inner sections
3. Unfolding/folding of outer sections
4. Slanting of boom
5. Angling of air slot/nozzle assembly
6. Boom tilt, RH
7. Boom tilt, LH
8. Fan speed adjustment
Unfolding the boom
NOTE! Ensure that the transport safety chains are
removed and that the booms are clear from the trans-
port brackets before unfolding.
1.Push switch 1upwards to lift the boom clear of the
transport brackets.
2.Push switch 2upwards to unfold the inner sections.
Rear transport hooks disengage automatically.
3.Push switsches 6 and 7 downvards to lower individual
tilt rams.
4.Push switch 3upwards to unfold outer sections.
5.Push switch 4to correct slant angle.
6.Push switch 1downwards to lower the boom to correct
height above crop or ground level.
7.In order to reduce wind drift and/or increase penetra-
tion of spray liquid in the crop, the slot angle can be
changed backwards and forwards with switch 5.
IMPORTANT! The two upper functions in the red rectan-
gle with STOP signs must only be operated when
sprayer is stationary! Failure to do so will damage the
boom.
Folding the boom
1.Check that the slanting function is midway 4.
2.Set slot angle at midway 5.
3.Raise boom 1to upper position.
4.Fold outer sections 3
5.Lift individual boom tilt 6and 7
6.Fold inner sections 2. Rear transport hooks
engage automatically.
7.Lower boom 1until boom rests on transport
brackets.
Hydraulic slanting control
The hydraulic slanting control 4enables slanting of the
entire boom hydraulically. This is advantageous when
spraying across hillsides.
Reset position to neutral (midway) before folding the
boom.
Boom tilt function
The boom tilt function control 6and 7enables you to
adjust the boom height individually in right and left-hand
side.
Air slot angling
The air slot and nozzle assembly can be angled approx.
40º forwards and 30° backwards compared to vertical
position. Regarding adjustments - see section on
“Air technique”.
Electric fan speed adjustment (if fitted)
Increasing of fan speed
Decreasing of fan speed
The max. revolutions for the fan are 3100 r.p.m., which
will give full air speed of approx. 40 m/sec (90 mph).
The fan speed is indicated by the transmission working
pressure by means of a pressure gauge. (Please see
the part “Air Technique”).
Conversion table between pressure and fan speed - see
the part “Air Technique”
T029-0010
T030-0003
T030-0003

16
GB 07 02 02
IMPORTANT! To avoid shock starting the fans always
set fan speed to 0 before engaging the P.T.O.
Boom support wheels
The boom is equipped with two support wheels. When
spraying with low boom heights on bare ground or plants
in the first growth stage it is recommended to fold down
the support wheels. In later growth stages the wheels
should remain folded up.
IMPORTANT! When driving on public roads the support
wheels should be folded up and secured in order to keep
the machine overall width according to the regulations!
Boom suspension sensitivity
The boom suspension would normally suit most condi-
tions and would not require any adjustment. The sus-
pension will keep the boom parallel to the ground and
compensate for uneven ground.
However special conditions or situations can require the
suspension to react less or more slowly.
When the RH and LH guide rods are parallel to each
other (factory setting) the boom suspension will react
immediately, and the boom will move independently of
the trailer or tractor.
If the boom should follow the movements or inclinations
of the trailer the guide rods should be inclined towards
each other at the rear.
Add 1-4 pcs. of 10 mm spacers as shown at each rod
until the decired function is reached.
T030-0005

17
GB 08 03
The diagram shows examples of options. These are
individual for each sprayer.
Use ofUse of
Use ofUse of
Use of MANIFOLD vMANIFOLD v
MANIFOLD vMANIFOLD v
MANIFOLD valvalv
alvalv
alve sye sy
e sye sy
e systemstem
stemstem
stem
The following pictograms and colours are used for
visualizing the function of the MANIFOLD valves:
Green disc = Pressure valve
Black disc = Suction valve
Green disc = Pressure valve
To Self-Cleaning
Filter/operating unit
To Fast Filling Device
To HARDI FILLER
To Tank Flushing Nozzle
To main tank
Agitation
Black disc = Suction valve
From main tank (suction filter)
From Rinsing Tank
From Filling Device
OperOper
OperOper
Operaa
aa
ating instrting instr
ting instrting instr
ting instructionsuctions
uctionsuctions
uctions
MANIFOLD SYMANIFOLD SY
MANIFOLD SYMANIFOLD SY
MANIFOLD SYSTEMSTEM
STEMSTEM
STEM
The MANIFOLD SYSTEM is located at the right side of
the sprayer and permits operation of all HARDI optional
extras from one position. The modular system facilitates
the addition of one optional extra (equal to two functions)
on the suction side.
Function diagram
1. Suction filter
2. Suction MANIFOLD
3. Pump
4. Rinsing tank
5. Pressure MANIFOLD
6. By pass valve
7. Safety valve
8. On/off
9. HARDI-MATIC
10. HARDI Filler
11. Pressure agitator
12. Self-clellaning filter
13. Ball valve
14. Distribution valves
15. Sprayer boom
16. Pressure gauge
T050-0011T050-0011
T050-0011T050-0011
T050-0011

18
GB 08 03
TT
TT
To opero oper
o opero oper
o operaa
aa
ate the sprte the spr
te the sprte the spr
te the spraa
aa
aying functions:ying functions:
ying functions:ying functions:
ying functions:
• Turn the handle on a green pressure valve towards the
function desired
• Turn the handle on a black suction valve towards the
desired function
• Close all remaining valves by setting the handle(s)
on “O”
IMPORTANT! The valves and functions may vary from
machine to machine depending on optional equipment
fitted. Only the functions to be used must be open -
Always close remaining valves.
Electric operated MANIFOLD valves (if fitted)
One or more MANIFOLD valves can be electrically
operated via a control box in the tractor cab. These can
only be operated manually when the power to the valve
motor is disconnected first.
FF
FF
Filling ofilling of
illing ofilling of
illing of ww
ww
waa
aa
aterter
terter
ter
Water can be filled into the main tank in following ways:
1. Filled through tank lid.
2. Filled by diaphragm pump through a suction side fitted
filling device (optional extra) using normal pump
capacity directly to the tank.
3. Filled by diaphragm pump through a pressure side
fitted injector/venturi type Fast Filling Device (optional
extra) using up to 3 times normal pump capacity.
4. Combination of 2 and 3.
The tank should normally be filled 1/3 with water, before
adding the chemicals.
Always read instruction on chemical container!
NOTE! Max. permitted tank contents:
Filling through tank lid
Remove tank lid and fill water through strainer to prevent
rust or other particles to enter the tank.
An overhead tank can be used in order to obtain high
filling capacity.
It is recommended to use as clean water as possible for
spraying purposes.
WARNING! DO NOT LET FILLING HOSE ETC.
ENTER THE TANK. KEEP IT OUTSIDE THE
TANK, POINTING TOWARDS THE FILLING
HOLE.
IF THE HOSE IS LEAD TO THE BOTTOM OF THE
TANK, AND THE WATER PUMP AT THE WATER
SUPPLY PLANT STOPS, CHEMICALS CAN BE SI-
PHONED BACK AND CONTAMINATE THE WATER
SUPPLY LINES.
Suction Filling Device (if fitted)
WARNING! Avoid contamination or personal
injury. Do not open suction valve towards
Suction Filling Device unless pump is run-
ning and filling hose is connected. If this valve is
opened without pump running, liquid will stream out
of the MANIFOLD.
The Suction Filling Device is operated as follows:
1. Remove cover A, and connect suction hose Bto
Suction Manifold.
2. Engage diaphragm pump and set P.T.O. revolutions at
540 r/min or 1000 r/min depending on pump model.
Turn handle on Suction Manifold towards Filling
Device.
T021-0012
T041-0001
ledoM
retaw,emuloV*sresilitrefdiuqil,emuloV
ertiL lag.pmI lagU ertiL lag.pmI lagU
l000100010224620774.9613.302
l003100316822.3430001022462
3.1ytivargcificepshtiwsresilitrefdiuqilnodesaB*

19
GB 08 03
only to fill from closed reservoirs (mobile water
tanks etc.) to avoid contamination.
WARNING! If suction hose/filter is carried on the
sprayer during spraying, it can be contaminated by spray
drift which will be transferred to lake/river when filling!
Fast Filling Device (if fitted)
The Fast Filling Device is operated as follows:
1. Ensure spray liquid tank
contains at least 50 litres
of water.
2. Remove cover (A) and
connect suction hose (B).
3. Turn handle on Pressure
Manifold towards Fast
Filler. With the P.T.O. at
540 r/min, the pressure
gauge should indicate
about 10 bar.
4. If water is not seen in
transfer tube, prime by
turning valve (C).
5. Keep eye on liquid level
indicator.
6. Turn handle on Pressure
Manifold away from Fast
Filler to discontinue filling
process.
NOTE: Turn handle towards EC-operating unit before
turning away from Fast Filler in order to avoid peak
pressure blowing the safety valve!
7. Disconnect suction tube (B) and replace cover.
3. The tank is now filled with water. Keep an eye on
liquid level indicator.
4. Turn handle on Suction Manifold away from Filling
Device to discontinue filling process. Then disengage
pump.
5. Disconnect suction tube Band replace cover.
NOTE! Observe local legislation regarding use of Filling
Device. In some areas it is prohibited to fill from open
water reservoirs (lakes, rivers etc.). It is recommended
only to fill from closed reservoirs (mobile water tanks
etc.) to avoid contamination.
WARNING! If suction hose/filter is carried on the
sprayer during spraying, it can be contaminated
by spray drift which will be transferred to lake/
river when filling!
1. Remove cover A, and connect suction hose Bto
Suction Manifold.
2. Engage diaphragm pump and set P.T.O. revolutions at
540 r/min. Turn handle on Suction Manifold towards
Filling Device.
3. The tank is now filled with water. Keep an eye on
liquid level indicator.
4. Turn handle on Suction Manifold away from Filling
Device to discontinue filling process. Then disengage
pump.
5. Disconnect suction tube B
and replace cover.
NOTE! Observe local legislation regarding use of Filling
Device. In some areas it is prohibited to fill from open
water reservoirs (lakes, rivers etc.). It is recommended
A
B
C
T041-0002
T055-0014
T020-0003
T020-0005

20
GB 08 03
FF
FF
Filling ofilling of
illing ofilling of
illing of rinsing tankrinsing tank
rinsing tankrinsing tank
rinsing tank
The tank has a capacity of 200 l.The rinsing tank is
situated just above the pump. Access to the tank is
possible from the back of the MARRO lift. Only fill with
clean water.
FF
FF
Filling ofilling of
illing ofilling of
illing of cc
cc
clean wlean w
lean wlean w
lean waa
aa
ater tank (ifter tank (if
ter tank (ifter tank (if
ter tank (if ff
ff
fitted)itted)
itted)itted)
itted)
The clean water tank has a capacity of 15 l. The water
from this tank is for hand washing, cleaning of clogged
nozzles etc. Only fill this tank with clean water from the
well.
The tank can
be fitted on a
mounting
next to the
MANIFOLD
valves.
WARNING! Although the clean water tank is only
filled with clean water, it must never be used for
drinking.
The Filling Device and the Fast Filling Device can be
used simultaneously - this gives even bigger filling
capacity.
WARNING: Do not leave the sprayer whilst
refilling the tank, and keep an eye on the level
gauge in order NOT to overfill the tank!
NOTE! Observe local
legislation regarding use
of Filling Device. In some
areas it is prohibited to fill
from open water reser-
voirs (lakes, rivers etc.). It
is recommended only
to fill from closed
reservoirs
(mobile water
tanks etc.) to
avoid contami-
nation.
WARNING! If suction hose/filter is carried on the
sprayer during spraying, it can be contaminated
by spray drift, which will be transferred to lake/
river when filling!
T055-0015
T020-0004
T060-0106
T060-0107
