Hardi SARITOR 4000 User manual

The Sprayer
Operator’s Manual
SARITOR
4000/5000
Instruction book
67023003 - Version 1.10
US - 10.2016

SARITOR
4000/5000
Instruction book
67023003 - Version 1.10
US - 10.2016
HARDI® reserves the right to make changes in design, material, or specification without notice thereof.
HARDI® and other product names are registered trademarks of HARDI® Inc. in the U.S. and in other countries.

Table of Contents
3
1 - Welcome
Welcome letter ......................................................................................................................................7
2 - Safety notes
Operator safety .....................................................................................................................................9
Symbols ........................................................................................................................................................................................................................ 9
General info ............................................................................................................................................................................................................... 9
Important guidelines ........................................................................................................................................................................................... 9
Operator's skill ....................................................................................................................................................................................................... 10
Driving on public roads ................................................................................................................................................................................... 10
Driving in fields ..................................................................................................................................................................................................... 10
Lights, working at night .................................................................................................................................................................................. 10
Recommendations to users of crop protection chemicals ...................................................................................................... 11
Personal safety equipment ........................................................................................................................................................................... 11
Explanation of symbols on safety decals .............................................................................................12
Safety decals ........................................................................................................................................................................................................... 12
Mandatory ............................................................................................................................................................................................................... 12
Prohibited ................................................................................................................................................................................................................ 12
Danger ....................................................................................................................................................................................................................... 13
Local poison information center .........................................................................................................14
3 - Description
General information ............................................................................................................................15
General View .......................................................................................................................................................................................................... 15
Sprayer use .............................................................................................................................................................................................................. 15
Sprayer identification plates ......................................................................................................................................................................... 15
Frame .......................................................................................................................................................................................................................... 15
Tanks ........................................................................................................................................................................................................................... 15
Liquid system ......................................................................................................................................16
General information - valve system ......................................................................................................................................................... 16
Pump .......................................................................................................................................................................................................................... 16
Valves and symbols ............................................................................................................................................................................................ 16
Suction valve .......................................................................................................................................................................................................... 16
Pressure valve ........................................................................................................................................................................................................ 16
Diagram - Liquid system with optional extras .................................................................................................................................. 17
External controls .................................................................................................................................................................................................. 18
TurboFiller ................................................................................................................................................................................................................ 18
Filters ........................................................................................................................................................................................................................... 19
CycloneFilter .......................................................................................................................................................................................................... 19
External Cleaning Device ............................................................................................................................................................................... 20
Cabin ....................................................................................................................................................21
Access to the cab ................................................................................................................................................................................................ 21
Emergency Exit ..................................................................................................................................................................................................... 21
Steering column .................................................................................................................................................................................................. 21
Instrument panel ................................................................................................................................................................................................. 22
Cabin roof instrumentation .......................................................................................................................................................................... 23
Start-up and diagnostics of the engine ................................................................................................................................................ 23
The seat ..................................................................................................................................................................................................................... 24
Lighting and cab lights .................................................................................................................................................................................... 24
The multifunction display .............................................................................................................................................................................. 25
Display of functions ........................................................................................................................................................................................... 25
Horizontal Menus ................................................................................................................................................................................................ 25
Vertical Menus ....................................................................................................................................................................................................... 26
Messages in normal operating mode .................................................................................................................................................... 27
Messages in selection mode ........................................................................................................................................................................ 28
Alarm Messages - priority ............................................................................................................................................................................... 28
Alert Messages - Operation limited ......................................................................................................................................................... 29
Alert Messages - Maintenance .................................................................................................................................................................... 29
Boom ...................................................................................................................................................30
Boom Operator’s Manual ............................................................................................................................................................................... 30
Table of Contents

Table of Contents
4
4 - Sprayer setup
General information ............................................................................................................................31
Unloading the sprayer from the truck ................................................................................................................................................... 31
Access to the engine ........................................................................................................................................................................................ 31
Check engine ......................................................................................................................................................................................................... 31
Filling the fuel tank ............................................................................................................................................................................................. 32
Hydraulic Oil Level .............................................................................................................................................................................................. 32
Oil Level in the wheel gear boxes ............................................................................................................................................................. 33
Air Suspension ...................................................................................................................................................................................................... 33
Selection of temperature unit ..................................................................................................................................................................... 33
Boom ...................................................................................................................................................34
Check boom operator’s manual ................................................................................................................................................................ 34
5 - Operation
Starting the SARITOR ..........................................................................................................................35
General information .......................................................................................................................................................................................... 35
Powering the electrical system .................................................................................................................................................................. 35
Lighting the path to the cab ........................................................................................................................................................................ 35
Starting the engine ............................................................................................................................................................................................ 36
Air Suspension ...................................................................................................................................................................................................... 36
Drive Modes .........................................................................................................................................37
Driving mode selector ..................................................................................................................................................................................... 37
[Road] mode controller ................................................................................................................................................................................... 37
Driving .................................................................................................................................................38
[Road] mode using the multi-function Grip handle ..................................................................................................................... 38
[Road] mode using the foot pedal (automotive) ............................................................................................................................ 39
[Field] driving modes ........................................................................................................................................................................................ 40
Parking brake ......................................................................................................................................................................................................... 41
Shutting off the engine ................................................................................................................................................................................... 41
Drive Settings ......................................................................................................................................42
Drive mode behavior ........................................................................................................................................................................................ 42
Traction Control System ................................................................................................................................................................................. 42
Restricting travel speed in [road] mode ............................................................................................................................................... 43
Restricting travel speed in [field] mode ................................................................................................................................................ 43
Preset the speed of the engine .................................................................................................................................................................. 43
Limitation of engine speed in [Field] mode ....................................................................................................................................... 44
Limitation of engine speed - hydraulic oil temperature too low .......................................................................................... 44
Limitation of engine speed - hydraulic oil temperature too high ........................................................................................ 44
Engine management ........................................................................................................................................................................................ 45
Track width adjustment .................................................................................................................................................................................. 46
Cabin ceiling controls ..........................................................................................................................47
Control Module of the ATC air conditioning ..................................................................................................................................... 47
Fan Speed Control .............................................................................................................................................................................................. 47
Selecting ATC mode ......................................................................................................................................................................................... 48
Window defogging ........................................................................................................................................................................................... 48
Operational problems ...................................................................................................................................................................................... 48
Windshield Wiper ................................................................................................................................................................................................ 48
Windshield Washer ............................................................................................................................................................................................ 49
Boom ...................................................................................................................................................50
Safety info ................................................................................................................................................................................................................ 50
Operating the boom ......................................................................................................................................................................................... 50

Table of Contents
5
Liquid system ......................................................................................................................................51
Filling/washing location requirements ................................................................................................................................................. 51
Filling of water ...................................................................................................................................................................................................... 51
Main Tank Filling .................................................................................................................................................................................................. 51
Filtered Fast Fill System ................................................................................................................................................................................... 52
Filling of Rinse tank ............................................................................................................................................................................................ 52
Filling of clean water tank .............................................................................................................................................................................. 53
Agitation ................................................................................................................................................................................................................... 53
Agitation before re-starting spraying ..................................................................................................................................................... 53
Parking the sprayer ............................................................................................................................................................................................ 54
Safety precautions - crop protection chemicals .............................................................................................................................. 54
Chemical Filling .................................................................................................................................................................................................... 54
Filling chemicals via the TurboFiller ........................................................................................................................................................ 55
Rinsing TurboFiller .............................................................................................................................................................................................. 55
Prepare sprayer for Spraying ........................................................................................................................................................................ 55
Spraying controls from the cab .................................................................................................................................................................. 56
Electrically controlled end nozzle (optional) ...................................................................................................................................... 56
Cleaning ...............................................................................................................................................57
General information .......................................................................................................................................................................................... 57
Guidelines ................................................................................................................................................................................................................ 57
Use of rinse tank and rinsing nozzles ..................................................................................................................................................... 57
A. Full internal rinsing ....................................................................................................................................................................................... 58
B: External cleaning ............................................................................................................................................................................................ 59
C. Flushing spraying circuit without diluting main tank contents ....................................................................................... 59
D: Full internal cleaning (Soak wash) ...................................................................................................................................................... 60
Use of detergents ............................................................................................................................................................................................... 61
Technical residue ................................................................................................................................................................................................ 61
Cleaning and maintenance of filters ....................................................................................................................................................... 61
6 - Maintenance
Lubrication ..........................................................................................................................................63
General information .......................................................................................................................................................................................... 63
Table of recommended lubricants .......................................................................................................................................................... 63
Display of the frequency of maintenance ........................................................................................................................................... 63
Service and Maintenance intervals .....................................................................................................64
Daily ............................................................................................................................................................................................................................. 64
Maintenance intervals ...................................................................................................................................................................................... 64
10 hours service ................................................................................................................................................................................................... 65
10 hours service - CycloneFilter ................................................................................................................................................................. 65
50 hours service - Compressed air tank ................................................................................................................................................ 65
50 hours service - Engine radiators .......................................................................................................................................................... 66
150 hours service - Coolant level .............................................................................................................................................................. 66
250 hours service - Maintenance operations on the engine ................................................................................................... 66
500 hours service ................................................................................................................................................................................................ 67
500 hours service - Replace engine air filters .................................................................................................................................... 67
500 hours service - Auxiliary hydraulic filter ....................................................................................................................................... 68
500 hours service - Hydraulic filters in the tank ............................................................................................................................... 69
500 hours service - Replace activated charcoal filter .................................................................................................................... 70
Every 1000 hours ................................................................................................................................................................................................. 70

Table of Contents
6
Occasional maintenance ......................................................................................................................71
General information .......................................................................................................................................................................................... 71
Compressed air pressure adjustment .................................................................................................................................................... 71
Air suspension adjustment ........................................................................................................................................................................... 71
Charging the Optima AGM battery ......................................................................................................................................................... 72
Cone check/replacement for EFC distribution valve .................................................................................................................... 72
Level indicator adjustment ........................................................................................................................................................................... 73
Level indicator wire replacement ............................................................................................................................................................. 73
Drain valve seal replacement ...................................................................................................................................................................... 73
Adjustment of 3-way-valves ......................................................................................................................................................................... 74
ParaLift Lock ........................................................................................................................................................................................................... 74
ParaLift wear bushing replacement ........................................................................................................................................................ 75
Off-season storage ..............................................................................................................................76
Off-season storage program ........................................................................................................................................................................ 76
Preparing the sprayer for use after storage ........................................................................................................................................ 76
7 - Fault finding
Error messages ....................................................................................................................................77
Cabin error codes ................................................................................................................................................................................................ 77
Transmission error codes ............................................................................................................................................................................... 77
CUMMINS engine error codes .................................................................................................................................................................... 78
Electrical incidents ..............................................................................................................................82
Main circuit fuses and relays (U100163B) ............................................................................................................................................. 82
Position Lights Fuse ........................................................................................................................................................................................... 84
Fuse test .................................................................................................................................................................................................................... 84
8 - Technical Specifications
Specifications ......................................................................................................................................85
Dimensions ............................................................................................................................................................................................................. 85
Weight ....................................................................................................................................................................................................................... 85
Tire pressures ...........................................................................................................................85
Identification plates ........................................................................................................................................................................................... 86
9 - Warranty
Warranty policy and conditions ..........................................................................................................87
Index
Index ....................................................................................................................................................89

1 - Welcome
7
1 - Welcome
Welcome letter
Dear New HARDI® Owner,
Thank you for purchasing your new HARDI® product and welcome to the ever-increasing family of proud HARDI® owners.
HARDI® is the leading sprayer company in offering growers strong, reliable products made for the widest range of
applications worldwide. Quality, reliability, and resale value make the HARDI® product line the preferred product line of
customers both in North America as well as worldwide. Our guiding principle is to provide the highest level of customer
satisfaction and long term value in the marketplace today. We have developed a very high level of customer loyalty in the
marketplace which we are very proud of and strive every day to maintain and to continue to grow.
HARDI® is your specialist in spraying and we spend all of our time and keep all of our focus on spraying. We do not share our
resources between other types of products or compromise on anything in providing the best quality sprayers to the market
today. We can provide the latest in technology with our products if desired, or allow them to operate with the technology
that you already use on other products in most cases. You get to decide that, and what best suits your needs. We feel that
you, our customer, are the best suited to answer that question for your operation. Either way, you decide, and we will try and
help make it happen for you.
Our broad spectrum of product offerings, from the ruggedly simple models we build to our highly sophisticated models,
the built-in HARDI® strength and reliability ensures a low cost of ownership. HARDI® sprayers are all based on a functional
design concept of being as simple to operate as possible and to meet our customers’requirements for all their application
needs.
Please take the time to thoroughly read the Operator’s Manual before using your equipment.You will find many helpful hints
as well as important safety and operation information.
Some of the features on your HARDI® sprayer were suggested by growers. There is no substitute for “on farm” experience
and we invite your comments and suggestions. If any portion of this instruction book remains unclear after reading it,
contact your HARDI® dealer or service personnel for further explanation before using the equipment.
For Product, Service or Warranty Information please contact your local HARDI® dealer.
- Please use the HARDI® Customer Service number: 1-866-770-7063
- Or send your email to [email protected]
HARDI® NORTH AMERICA INC.
Visit us online at: www.hardi-us.com
1500 West 76th St.
Davenport, Iowa 52806
Phone: [phone]
Fax: [phone]
Sincerely,
Wayne Buchberger
President

1 - Welcome
8

2 - Safety notes
9
Operator safety
Symbols
These symbols are used throughout the book to designate where the reader needs to pay extra attention.
€This symbol means DANGER. Be very alert as your safety is involved!
±This symbol means WARNING. Be alert as your safety can be involved!
This symbol means ATTENTION. This guides you to better, easier and safer operation of your sprayer!
÷This symbol means NOTE.
General info
Before using the sprayer, read the following recommendations and safety instructions.
•Read this instruction book carefully before using the equipment. It is equally important that other operators of this
equipment also read this book.
•If any portion of this instruction book remains unclear after reading it, contact your HARDI® dealer for further
explanation before using the equipment.
•Local law may demand that the operator is certified to use spray equipment. Adhere to the law.
•The driver's seat is the intended working place during operation.
•Wear protective clothing. Clothing may differ according to the plant protection chemicals used. Comply to any
applicable local legislation.
•After spraying, the operator should wash and change his clothes.
•Rinse and wash equipment after use and before servicing. Wash tools if they have become contaminated.
•Do not eat, drink or smoke during the use and maintenance of your sprayer.
•In case of poisoning, immediately seek medical advice. Remember to identify chemicals used. Follow instructions
indicated on the label(s) of the products used.
•Never service or repair the equipment while it is operating.
•Replace all safety devices or shields immediately after servicing.
•Do not go under the machine unless it is secured. The boom is secure when placed in the transport brackets.
•Do not attempt to enter the tank.
•Keep children away from the sprayer.
Important guidelines
•Comply with all recommendations for installation, carrying out adjustments, maintenance and repair contained in this
instruction book.
•Use only original spare parts and accessories conforming to the manufacturer's recommendations.
•Do not modify or have your machine and it’s accessories modified by someone else (mechanical, electrical, hydraulic
and pneumatic characteristics) and, more generally, the parts of the machine affecting user safety, without first
requesting written agreement from the manufacturer.
•Failure to respect these rules may make your machine dangerous. In the event of damage or injury, HARDI® shall not
be held liable in any way.
2 - Safety notes

2 - Safety notes
10
Operator's skill
The machine should be used and maintained by people who are aware of its special use and safety characteristics. Before
using your machine, familiarize yourself with all the commands. When working, it will be too late to do so. Ensure that you
have the skills required for protecting crops and the environment, and for handling and spraying plant protection chemicals.
Driving on public roads
When driving on public roads, obey all traffic regulations. Pay particular attention to those regarding mandatory equipment
such as lights, indicators, hazard lights, etc.
You should be aware of the vehicle's size and weight, particularly the overall width and height.
±WARNING! You must in all circumstances adapt your driving on the road, particularly by reducing your speed during
turns or when road conditions demand. Also reduce speed when meeting or being passed by another vehicle.
Driving in fields
Be very careful to avoid the risk of overturning when driving at speeds
greater than 9 mph (15 km/h) or when driving on a slope.
ATTENTION! As a general rule:
•Adapt your speed and driving to suit the terrain you are driving on.
Be aware and take care!
•Slow down when driving on uneven terrain as the sprayer may become unbalanced and overturn.
•No persons are allowed in the operational area of the sprayer. Take care not to harm people or surroundings when
maneuvering the sprayer, especially while backing up.
•In all circumstances and particularly on uneven and sloping terrain, drive the machine at a low speed, especially on
curves and avoid sudden changes of direction.
•Do not brake or accelerate suddenly when going up or down a slope, bearing in mind the variable volume of liquid in
the sprayer tank.
€DANGER! Boom maneuvers should be carried out with the sprayer stationary and on flat ground. Ensure that there
are no obstacles nearby (electrical lines, people, poles etc.).
Lights, working at night
If there is insufficient light for working at night, the spraying boom should be equipped with boom lights. For more
information on this equipment, contact your HARDI® dealer.

2 - Safety notes
11
Recommendations to users of crop protection chemicals
This sprayer has been designed and manufactured by HARDI® for the application of crop protection chemicals. For your
safety and the proper functioning of the sprayer, it is important to read and understand all instruction books delivered with
this sprayer.
It is also the sole responsibility of the operator to strictly comply with all recommendations given by the manufacturers of
all crop protection chemicals used with this sprayer.
In particular, it is strongly recommended that any operator of this sprayer:
•Carefully read the label(s) of the manufacturer(s) of the treatment products used with this sprayer and follow the
instructions given (measuring, personal protective equipment, etc.);
•Mix only products whose compatibility was expressly recognized by the manufacturer(s) of the crop protection
chemicals being mixed;
•Avoid introducing air while filling the tank to prevent the formation of foam and cause problems with overflow;
•Follow the manufacturer(s) instructions and warnings for all crop protection chemicals regarding proper storage,
processing and keeping chemicals out of the reach of children and animals;
•Observe all precautions relating to the disposal/recycling of packaging, in accordance with the recommendations of
the manufacturer(s) of the products used;
•Contact the manufacturer(s) of the plant protection product (or their representative) if any doubt remains after reading
the label(s) of their product(s).
Personal safety equipment
Depending on which type of chemical is used, some or all of the following protective
clothing and equipment will be required:
1. Ear muffs
2. Safety goggles or face shield
3. Respirator
4. Chemical resistant coveralls
5. Chemical resistant gloves
6. Chemical resistant boots
Contaminated clothing
Contaminated clothing should be removed and safely stored and laundered. Do not
contaminate the inside of the cab with soiled clothing.
1
2
3
4
5
6

2 - Safety notes
12
Explanation of symbols on safety decals
Safety decals
The orange triangle decals on your sprayer will caution you in regards to hazards that may be encountered in various areas
of the sprayer.
This manual contains explanations for the decals which are found on your sprayer.
Mandatory
Read manual
•Consult Operator’s Manual, located inside the black manual holder or in manual slot in the cab.
Remove key
•Used in conjunction with ‘Read Manual’ symbol to warn that manual must be read before
operating the sprayer.
Personal protective equipment
•Overalls, face screen, mask and gloves must be worn to operate in this area.
Maintenance
•A regular inspection and maintenance schedule is needed to keep this part operating safely.
•Consult Operator’s Manual for maintenance schedule.
Tire pressure check
•A regular inspection and maintenance schedule is needed to keep tires operating safely.
•Consult Operator’s Manual for recommended pressure levels
Prohibited
Speed limit
•Maximum speed limit while operating the sprayer.
•Extra care must be taken on hills and when cornering.
No passengers on sprayer
•Do not climb onto tank or into it.
•Danger of injury or death.
35

2 - Safety notes
13
Do not drink
•Water from clean water tank is for hand washing, cleaning of clogged nozzles, etc. This water
must never be used for drinking.
Do not overfill tank
•Risk of contamination.
•Risk of tank damage.
Danger
Overhead wires
•Take care when operating near wires to prevent entanglement or electrocution.
Fluids under pressure
•Wear gloves and face screen.
Chemical hazards
•Read manufacturer’s labels.
•Wear personal protective equipment, including face screen and gloves, when handling these.
•Provide adequate ventilation.
Danger overhead
•Do not enter paralift area or stand under booms.
•Take care when opening doors/covers - loose items may be present in them.
Danger, toxic fumes may be present
•Take care when opening lids - fumes may be present.
•Do not inhale tank fumes.
Danger of toppling over on hillside or slope
•Drive with extreme caution.
•Widen axle track width to minimize risk.

2 - Safety notes
14
Local poison information center
€If you live anywhere in the United States, the following toll free number will connect you to your Local Poison
Information Center.
PHONE NO. 1 - 800 - 222 - 1222
€If you live outside the United States, find the number for the poison control center in your phone book and write it
in the space below:
PHONE NO._______ - _______ - __________
€Keep a list, in the space provided below, of all the chemicals that you have in use.
1. _______________________________________________________________________________________________
2. _______________________________________________________________________________________________
3. _______________________________________________________________________________________________
4. _______________________________________________________________________________________________
5. _______________________________________________________________________________________________
6. _______________________________________________________________________________________________
7. _______________________________________________________________________________________________
8. _______________________________________________________________________________________________
9. _______________________________________________________________________________________________
10. ______________________________________________________________________________________________

15
General information
General View
The SARITOR is divided into 3 zones: a Clean zone, a Working zone and a
Spraying zone, referring to the level of possible chemical contamination.
The functions and features are listed by zones below. Please note that
some of the features are optional equipment.
Sprayer use
The HARDI® sprayer is for the application of crop protection chemicals and liquid fertilizers. The equipment must only be
used for this purpose. It is not allowable to use the sprayer for other purposes. If no local law demands that the operator
must be certified to use spray equipment, it is strongly recommended to be trained in correct plant protection and in safe
handling of plant protection chemicals to avoid unnecessary risk for persons and the environment when doing your spray
job.
Sprayer identification plates
Frame
Very strong and compact frame which also has a strong chemical and weather resistant electrostatic lacquer coat. The
hardware is either stainless steel or treated to be resistant to corrosion. The front and rear suspension is provided by a
pneumatic system.
Tanks
The main tank is made of impact-proof, UV-resistant and chemical resistant polyethylene. It has a purposeful design with no
sharp corners for easy cleaning. Nominal content: 1100 gallons (4000 liters) or 1300 gallons (5000 liters). A large, easy to read
tank level indicator is placed beside the platform and is visible from the cabin. The filling hole is placed so it can be accessed
from the platform. The SARITOR is standard equipped with a 150 gallon (575 liter) rinse tank, and a 26 gallon (100 liter) clean
water tank (hand washing tank).
A. Clean Zone Engine
Working platform with ladder
Cabin
Valve for hand washing
Access to Main tank
B. Working Zone Tank level indicator
Multipath Valves
FastFiller coupler
ChemFiller
C. Spraying Zone Boom lift, up/down
Boom
Nozzles
Mudguards
Suspension
3 - Description

3 - Description
16
Liquid system
General information - valve system
All of the spray functions are operated via centrally located valves with color coded pictorial symbols for easy operation. The
fluid system is located on the sprayer’s left side under the cover. To access the Fluid Working Zone, open the cover. Most
valves can be operated from both the Fluid Working Zone or from the cab.
Pump
The SARITOR uses the HARDI® 650 WetSeal run dry centrifugal pump.
Valves and symbols
The valves are identified by colored symbols according to their function. They correspond to the different possible functions
of the valves, thus facilitating their use. A function is activated by turning the handle towards the desired function.
Suction valve
Suction valve = blue symbols
Turn the handle towards the symbol for the desired function
Pressure valve
Pressure valve = green symbols
Turn the handle towards the symbol for the desired function.
Filling chemicals
via the TurboFiller
Side Banjo Filtered Fast
Filling System
Clean Water Induction
Chemical Induction
(Fast filling)
Quick Fill for Rinse Tank Quick Fill for Main Tank
Chemical Filler
Ejector
Boom Nozzles
SIDE
FILLING

3 - Description
17
Diagram - Liquid system with optional extras
1. Main Tank
2. Rinse Tank
3. Main Fluid Pump
4. TurboFiller Tank
5. TurboFiller controls
6. Main Tank Valve
7. Rinse Tank Valve
8. Agitation Valve
9. Rinse Nozzles Valve
10. Cyclone Filter
11. Filling Filter
12. Main Tank Fill Valve
13. Rinse Tank Fill Valve
14. Rinse Nozzles
15. Agitation Nozzles
16. Ejector
17. Filter Bypass Return
18. Pressure Sensor
19. Flow Meter
20. Spray Boom
21. Section Valves
22. Chemfiller Valve
23. Wash Down Hose
24. Electric Pump
Filtered Fill
11
43
5
6
7
8
9
10
13
24
19
20
18
17
16
23
21
22
12
1
14 14
15
15
2

3 - Description
18
External controls
A panel equipped with push buttons provides external control of the
main functions of spraying and engine speed. The commands are
grouped together by color to simplify their use. LEDs indicate
function activation.
1. Suction from main tank
2. Suction from rinse tank
3. Not used
4. Spray pump control
5. Tank rinsing nozzles
6. Spray nozzles On/Off
7. Engine throttle increase
8. Engine throttle decrease
9. Start agitation of main tank
10. Stop agitation of main tank
TurboFiller
TurboFiller = yellow symbols
The TurboFiller is located in the Fluid Working Zone on the sprayer’s left side.
When being used, it should be unlocked by pulling out the lock pin (2) (located
to the right of the TurboFiller) and pushed down by grabbing the handle (1) on
the TurboFiller until it clicks into the locked down-position.
After use, the TurboFiller is retracted by pulling the handle (1) back up until it
clicks into the locked storing position.
±WARNING! Before releasing the lock (2) always keep a hand on the grip to
avoid abrupt movement of the TurboFiller!
TurboDeflector valve
This TurboDeflector valve activates the vortex flushing of the TurboFiller.
The valve is the bottom valve located to the left side of the TurboFiller
and is activated in two ways. Push the valve lever down to get a quick
flush in the hopper. Lift the lever to lock it in the open position for
continuous liquid rotation in the hopper.
Chemical container cleaning lever
The upper lever located to the left of TurboFiller is used for two
purposes:
When TurboFiller lid is open: For cleaning empty containers. Put
container over the rotating rinsing nozzle in the middle of the
TurboFiller to rinse inside of the container.
When TurboFiller lid is closed: Use the Chemical Container Cleaning
lever to rinse the hopper after filling of chemicals has ended.
€DANGER! Do not press lever unless the multi-hole nozzle is covered by a container or the TurboFiller lid is closed to
avoid spray liquid hitting the operator.
0
6
3
10
9
1
4
8
7
2
5
1
2
