Hargrove RGA 2-72 Operating instructions

RGA 2-72
INSTALLATION AND OPERATION GUIDE FOR
HARGROVE GAS LOGS
PROPANE GAS
ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY.
GAS LOGS MUST BE INSTALLED BY PERSONNEL QUALIFIED FOR
INSTALLING GAS APPLIANCES.
NOTE! READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING.
INSTALLERS LEAVE THESE INSTRUCTIONS WITH THE CONSUMER!
Hargrove Manufacturing Corporation uses refractory material to create ceramic logs. Each log is hand
finished to assure the most realistic, detailed log available. The gas log burner system is designed to
burn like wood with a yellow smoky flame. For this reason the gas log set must be burned only in a
fully vented, non-combustible fireplace with the damper completely open and the chimney free of
any obstructions or restrictions. The fireplace must be designed and approved to burn wood. The
minimum permanent, free opening provided by the fireplace chimney must be 8” in diameter (50
square inches). The realistic yellow flame produces carbon monoxide and soot. Under normal
conditions these products are exhausted up the chimney. If fumes or soot from the gas burning are
evident in the room when the damper is fully open, it indicates that the fireplace draft is defective. Do
not operate your gas log set until the fireplace draft is corrected.
ADEQUATE VENTILATION IS REQUIRED.
IT IS THE HOMEOWNERS RESPONSIBILITY TO ASSURE
THEIR FIREPLACE HAS ADEQUATE DRAFT.
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A
FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
IF YOU SMELL GAS:
1. OPEN WINDOWS
2. DON’T TOUCH ELECTRICAL
SWITCHES
3. EXTINGUISH ANY OPEN FLAMES
4. IMMEDIATELY CALL YOU GAS
SUPPLIER
THE SIZE CHART BELOW INDICATES THE
MINIMUM SIZE FIREPLACE OPENINGS IN,
WHICH DIFFERENT SIZE GAS LOG SETS
CAN BE INSTALLED.
FLAMMABLE VAPORS MAY BE DRAWN
BY AIR CURRENTS FROM OTHER AREAS
OF YOUR HOUSE TO THIS APPLIANCE.
FIREPLACE SIZES
GAS LOG
SET SIZE DEPTH
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS AND LIQUIDS
IN THE VACINITY OF THIS
OR ANY OTHER
APPLIANCE.
FRONT
WIDTH
16” 13” 20”
18” 13” 22”
24” 14” 28”
30” 14” 34”
36” 15” 40”
For models tested through OMNI
-
Test Laboratories,
Inc., to RGA2-72. For model number and O-TL seal
refer to attached name plate.
fire-parts.com

DO NOT USE A NATURAL GAS SET FOR PROPANE OR A PROPANE SET FOR NATURAL GAS.
WHEN USING PROPANE (LPG) GAS AN AUTOMATIC PILOT SYSTEM MUST BE INSTALLED.
This appliance is shipped with an air mixer containing a specific orifice size for the unit. The
appliance must use the air mixer. Manipulation or modification of the air mixer will void the
manufacturer’s warranty.
1. There are many different local codes for gas fire logs. The installation of this set must conform with
local codes or, in the absence of local codes, to the National Fuel Gas Code ANSI Z223.1 1999.
2. This log set is designed for use with PROPANE Gas.
3. When glass fireplace doors are used, always operate gas log set with the doors fully open to allow for
proper combustion air.
4. A fire screen must be in place when the log set is in use.
5. The appliance and its individual shut off valve must be disconnected from the gas supply piping
system at test pressures in excess of ½ psig. The appliance must be isolated from the gas supply
piping system by closing its individual manual shut off valve during any pressure testing of gas supply
system at test pressures equal to or less than ½ psig.
6. Minimum inlet supply pressure for Natural Gas is 7” water column. Maximum inlet supply pressure for
Natural Gas is 10 ½” water column.
7. After burning, the logs become fragile and should not be handled. Knocking or rubbing logs can cause
concrete to crumble and is not covered under the warranty.
8. Use a soft, dry paintbrush for periodic dusting of the gas fire logs. Special care must be taken to clean
the birch logs. Rubbing will remove soot but will also remove the white pigments.
9. Do not burn wood with this set.
INSTALLING YOUR HARGROVE GAS LOGS
Remove all the parts from the shipping container. Your set includes the following parts:
Number by Set 16”-21” Sets24” Sets 28”-30 Sets 36” Sets
1. Pedestal Grate PG-16 PG-20 PG-25 PG-30
2. Ember Burner EM-14 EM-18 EM-22 EM-26
3. Vermiculite VM-1 VM-1 VM-1 (2) VM-1
4. Fire Embers RW RW RW (2) RW
5. Safety Pilot Control CPC CPC CPC CPC
6. Aluminum Connector AC-18 AC-18 AC-18 AC-18
7. Fire Logs *Number of logs are determined by the set size. Logs not illustrated.
8. Damper Stop (optional) DS DS DS DS
9. Volcanic Cinders VC VC VC VC
10. Black Cap CAP-8 CAP-8 CAP-8 CAP-8
11. Brass Elbow 50-6-8 50-6-8 50-6-8 50-6-8
12. AM/AM-N AM-48 AM-48 AM-42 AM-42
GENERAL INFORMATION
NOTE: PERSONNEL QUALIFIED TO INSTALL GAS APPLIANCES MUST INSTALL GAS LOGS.
3
4
5
6
8
9
10
11
12
1
2
3
4
5
6
8
9
10 11 12
fire-parts.com

DAMPER STOP
(Optional)
Attach the damper stop clamp to the
fireplace damper blade. Position the clamp
to prevent full closure of the fireplace
damper blade.
(See Figure 1)
If the damper stop provided does not fit, the
installer shall install a permanent damper
stop that will keep the damper open a
minimum of 3”.
EMBER BURNER POSITIONING
1. Turn gas off.
2. Remove old log lighter, ashes, and other
material from the firebox.
3. Center the ember burner on the fireplace floor
with the burner pipe completely visible from the
front. For best results, the ember burner
should be directly under the flue opening with a
minimum of 4” from the front edge of the ember
burner to the fireplace opening.
4. Place the grate over the ember burner so the
front legs of the grate are just in front of the
burner pipe. Once the final positioning is
established, mark the burner and grate position
on the floor of the fireplace for reference
points. Remove the grate and proceed with
the gas connection
(See Figure 2)
GAS CONNECTION
1. The gas supply line should be ½” inside diameter (ID) up to 30 feet and ¾” for longer distances.
2. Tighten the black pipe cap on the end of the burner pan pipe.
3. Use the aluminum connector to connect the gas supply to the ember burner. When bending the
aluminum tubing use proper bending procedures to avoid kinking the tube. (If a safety pilot control is
used follow the instructions included for connecting the gas to the pilot control)
4. Check all connections for leaks using a soapy water solution.
5. Damper must remain fully open during operation. Place a lighted match next to the burner pipe. Do
not hold the match in your hand while lighting the gas. Turn the gas supply on slowly until the gas
ignites. Check the flame for even distribution, flame height, and gas pressure. After checking the
flame, turn off the fire. (Turn the gas valve to the off position to turn the fire off.) Do not close the
damper until all the flames have died. Keep the glass doors fully open during all burning.
Figure 1
Figure 2
fire-parts.com

BURNER PAN MEDIA
1. Fill the burner pan with vermiculite. Vermiculite
level should be sloped evenly with the sides of the
ember burner.
2. Embers (RW) are placed over the vermiculite to
simulate glowing embers. For best results pinch
off pieces of the embers material to the size of a
dime and feather it out. Place as much as desired
over the area the gas comes through. Burner
should be completely full and level.
3. Light the gas and observe flame for even
distribution. (See Figure 3)
GRATE PLACEMENT
Place the grate over the ember burner using the
reference marks made on fireplace floor earlier.
LOG PLACEMENT
1. The longest log is the front log. It should be placed on the
front of the grate with the flat, unfinished side facing the
back. It is essential for this log to be positioned with the flat,
unfinished side being straight up and down. (If the logs are
laid flat on the grate the safety pilot control parts will
overheat and shut the system off.)
2. The second longest log is the back log. It is positioned on
the back pedestal of the grate with the flat side down.
3. The remaining logs are top logs. These logs are placed
diagonally across the bottom logs and can be arranged to
create the most realistic flame patterns.
(See Figure 4.)
VOLCANIC CINDERS
The black volcanic cinders are used to cover the fireplace floor, fittings and tubing around the burner
system. Although not functional, the black cinders act as a picture frame to show off the glowing embers
and yellow flame.
FOR YOUR SAFETY
Do not use this appliance if any part has been under water. Immediately call a qualified
service technician to inspect the appliance and to replace any part of the system or gas
control that has been under water.
Keep this appliance clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
VERMICULITE
EMBERS
Figure 3
Figure 4
fire-parts.com

LIMITED WARRANTY
Refractory Logs
Hargrove gas logs carry a limited lifetime warranty against any manufactured defect or breakage when installed indoors. A
replacement will be available from the dealer at which the appliance was purchased. This warranty does not cover breakage
caused by excessive handling once installed and fired. Outdoor applications carry a one (1) year limited warranty.
Burner & Grate
If the burner or grate fails due to deterioration within five (5) years of the verified purchase date, a free replacement will be made
available from the dealer at which the appliance was purchased.
Valves, Remote Controls, & Switching Devices
Hargrove warrants all valves, remote controls and switching devices against manufacturing defects, which appear within two (2)
years of the verified purchase date. Warranty does not cover products that have been damaged by misuse from overheating.
Before any product is returned a Return Goods Authorization number (RGA) must be issued by Hargrove’s Customer Service
Department. All returns must be accompanied by an explanation of the problem and all necessary parts.
All Other Parts
If any assembled part should fail to operate or be found defective which appear within two (2) years of the verified purchase date, a
replacement will be available from the dealer at which the appliance was purchased.
Buyer shall notify Hargrove Mfg Corp. of any defect covered by this warranty no later than thirty (30) days after defect is
discovered. Failure to provide notice within thirty (30) days shall void the limited warranty.
WHAT IS NOT COVERED
1. Removal and reinstallation costs.
2. Labor costs for replacement or repairs.
3. Transportation or shipping cost.
4. The cost of a service call to diagnose trouble.
5. Painted Surfaces.
6. Damage or defect caused by improper installation, accident, misuse, abuse, alteration, or authorized service technician.
7. Replacement of burner or combustion chamber resulting from improper storage of the appliance.
LIMITATIONS AND EXCLUSIONS
1 . No one has authority to add to or vary this limited warranty, or to create for Hargrove Manufacturing Corporation any other
obligation or liability in connection with this appliance.
2. Any implied warranty applicable to this appliance is limited in duration to the same period of time as this written
Warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to
you.
3. HARGROVE MANUFACTURING CORPORATION WILL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, SPECIAL
OR CONTINGENT DAMAGES YOU MIGHT SUFFER AS A RESULT OF A CLAIM UNDER THIS WRITTEN WARRANTY OR ANY
IMPLIED WARRANTY. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusion may not apply to you.
4. This warranty applies only to the original purchaser and may not be transferred or assigned.
5. If you cannot verify the purchase date of the appliance, the warranty period will begin on the date of which the appliance was
manufactured.
6. Replacement or repair parts are warranted for the remaining period of the original part warranty. Warranty parts must be
obtained through authorized dealers of this product who will provide original factory replacement parts. Failure to use original
factory replacement parts voids this warranty.
7. The maximum liability of Hargrove Mfg Corp. in connection with this limited warranty shall not in any case exceed the contract
price paid for the product claimed to be defective or unsuitable.
8. Purchaser or user agrees to hold Hargrove Mfg Corp. harmless from any and all claims by the buyer as a result of injury or
damage to an ultimate user or other person caused by the product sold herein by the seller to the buyer, whether the injury or
damage results from the assembly, installation, operation, shipment, storage, or manufacture of this product. Hargrove Mfg Corp.
makes no warranties, expressed or implied, other than those expressly stated herein.
YOUR DUTIES
This appliance must be installed by a qualified installer, operated and maintained in accordance with all applicable codes and the
instructions furnished with the appliance. You must provide a receipt verifying the purchase date of the appliance when making a
warranty claim with the dealer from which the appliance was purchased.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state.
To register your Hargrove product, please visit our website at http://www.hargrovegaslogs.com/reg.htm.
