Harken WingMan IN404 Installation instructions

Please read these instructions carefully before installing,
servicing, or operating the equipment. This manual may be
modified without notice. In the event this manual is translated,
the English version is definitive. For latest manual revision go
to harkenindustrial.com/en/product-support/
PLEASE SAVE THESE INSTRUCTIONS
Intended for specialized personnel or expert users
Part Number: IN404
WINGMAN™
Table of Contents (English) Pg.
1. About this manual 2
2. Safety information 2-3
3. Product description and components 3-8
4. Intended use prerequisites and limitations 8
5. Use 9-13
6. Maintenance 14
7. Lifespan 14
8. Packaging, storage, transportation 14
9. Warranty 14
10. Equipment record 15
Pg.
English 1
Diagrams 16
Français 20
Deutsch 28
Italiano 36
Español 44
5441 10/22

2 WingMan
WARNING! Activities involving the use of this equipment are inherently
dangerous. You are responsible for your own actions and decisions.
WARNING! Before using this equipment, you must:
1. Read and understand all instructions for use
2. Get specific training in its proper use
3. Become acquainted with its capabilities and limitations
4. Understand and accept the risks involved
WARNING! Failure to heed any of these warnings
may result in severe injury or death.
1. About this manual
Before and after using the Harken WingMan read the instructions contained in this
manual thoroughly. This instruction manual is an integral part of the product, and
it supplies all the necessary information for its correct safe use, maintenance, and
storage. If you don’t understand some of the instructions, please contact Harken’s
authorized dealer. Harken shall not be liable for damages, injuries or death caused
by noncompliance of the safety and other instructions contained in this manual.
This manual is intended for specialized personnel or expert users.
Keep the user instructions/information after they are separated from manufactured
system and retain them in a permanent record. Copy the user instructions/information
and keep with the equipment.
WARNING! This product must only be used by competent persons or
skilled expert users.
b) Intended use:
The WingMan is a mechanical-advantage device for load lifting and releasing. It is used
in a fall protection or work at height system. It is intended for work at height, access,
and rescue use. It can be used for human suspension for up to a 3 kN load.
c) Improper use:
Use only with supplied rope. Never use with wire rope or steel cable. Never use as
a human suspension device when the WingMan is the sole support. Always have a
backup safety system.
2. Safety Information
a) General safety precautions:

WingMan 3
e) Risks:
WARNING! Rotating Parts Trapping Risk
Always wear clothing and protective gloves, if applicable, that are form
fitting. Avoid loose gloves or clothing.
2. Safety Information (continued)
3. Product Description and Components
b) Component materials
Anodized aluminum is used throughout the pulleys. The handle is glass reinforced
nylon. The rope is an 8 mm static polyester with a sewn termination and is not to be
substituted. Pulleys have stainless steel axles and fasteners. The ratchet mechanism
is stainless steel.
The IN404 WingMan is a mechanical advantage system consisting of two swivel pulleys
and a manufacturer supplied rope. One pulley is a double with a becket to dead end the
rope. The other pulley is a double with a ratchet and cammed sheave with a releasing
handle allowing gradual release of the mechanical advantage system under load. The
releasing handle is located at the operator end.
a) Description
WARNING! Injury or death from falling from height or from dropped
objects is possible.
d) Personal Protective Equipment:
Wearing gloves is recommended. All PPE must be certified and marked according to
the current relevant national regulations.

4 WingMan
3. Product Description and Components (continued)
d) Part number and load
rating (specifications) Part Number - IN404
Maximum rated load 3 kN 674 lbf
Minimum Break
Strength
45 kN 10116 lbf
The load limits above are based on using Harken supplied
rope. Any changes to rope specifications changes the limits.
e) Compatibility (Selecting other components for the system)
Connectors and components must also meet fall protection rules and regulations
for the presiding regulatory authorities.
Connection devices must be locking and must be capable of supporting at least
22 kN (5000 lb).
c) Certification
The WingMan is certified as a system including two pulleys, rope and rope connection.
System is certified to the following standards.
MEETS THE MANUFACTURED SYSTEM REQUIREMENTS OF NFPA 1983,
INCORPORATED IN THE 2022 EDITION OF NFPA 2500.
DO NOT DISASSEMBLE.
Additional information regarding manufactured systems can be found
in NFPA 1500 and NFPA 1858 and NFPA 1983, incorporated in the 2022
edition of NFPA 2500 / G general use MBS 45 kN.
Certication: EN 12278.2007
This pulley is designed to be used in a system for preventing a
fall from height. When required this product must be used with a
comprehensive fall protection system in accordance with EN 363
and a fall arrest harness that meets EN361.
Personal Protective Equipment Regulations (Regulation
2016/425) and the Personal Protective Equipment (Enforcement)
Regulations 2018, as amended.
For Declaration of Conformity, visit www.harkenindustrial.com
H-86666
H-86666 Double pulley with side becket
The H-86666 double becket block portion of the WingMan is CE and UKCA certified.
WARNING! Do not exceed maximum rated load.
Laboratory for PPE Certification
(Module B):
UL International (Netherlands) B.V.
Westervoortsedijk 60, 6827AT Arnhem,
The Netherlands
Laboratory for UKCA Certification (Module B):
UL International (UK) Ltd –
Kingsland Business Park, Unit 1-3 Horizon, Wade Rd,
Basingstoke RG24 8AH,
United Kingdom

WingMan 5
Part Number - IN404
Maximum rated load 3 kN 674 lbf
Minimum Break
Strength
45 kN 10116 lbf
The load limits above are based on using Harken supplied
rope. Any changes to rope specifications changes the limits.
f) Parts description
3. Product Description and Components (Continued)
Swivel eye
Sewn termination
Rope becket cover
Swivel eye
retaining screws
Swivel eye
Swivel eye retaining
screws
Ratchet sheave
Idler sheave
Rope (red with black
and white tracers)
Double pulley with releasing cam
Double pulley with side becket
H-86666
Riveted end of axle
Riveted end of axle
Rope bag
Haul/tailing rope
Stopper knot
Releasing handle

6 WingMan
FOR PROTOTYPING PURPOSES ONLY
FOR QUOTATION PURPOSES ONLY
SURFACE FINISH:
MATERIAL:
DRAWING NUMBER REV.
FINISH:
PART #
MFG. APR :
DRAWN BY :
TOLERANCES UNLESS OTHERWISE SPECIFIED:
DECIMAL:
ANGULAR:
SCALE:
ENG. APR :
INCORPORATED
N15 W24983 Bluemound Road
Pewaukee, Wisconsin 53072
Tel: [phone]
Fax: [phone]
www.harken.com
© The designs, constructions, arrangements, disclosures and devices
illustrated in presentations bearing this note are the property of Harken, Inc,
Pewaukee, WI and are submitted in confidence with the understanding
that such material shall not be utilized in any way by any party without prior
written consent from Harken, Inc.
DIMENSIONS IN OVALS ARE KEY
PRODUCT CHARACTERISTICS
UNLESS OTHERWISE SPECIFIED:
- DIMENSIONS IN INCHES
- ALL DIMENSIONS PRIOR TO FINISHING
- REMOVE ALL BURRS AND BREAK SHARP
EDGES WITH 0.010 MAX RADIUS OR
CHAMFER
DATE:
DATE:
DATE:
SHEET NUMBER:
DESIGN BY :
DATE:
NOTE:
REFER TO ELECTRONIC FILE FOR ALL DIMENSIONS NOT SHOWN. •
SEE TITLE BLOCK FOR TOLERANCE OF NON DIMENSIONED FEATURES. •
REFER TO HS-200 HARKEN THREAD STANDARD FOR ALL DIMENSIONS REGARDING THREADS. •
VARIOUS
LOAD TENDER
H-86666
-
ORLY
-
CJL 9/24/2021
0
-
-
MGK
DOUBLE BECKET BLOCK
10/15/2021
1:1
9/10/2021
1/1
JDM 9/9/2021
-
NFPA 2500 (1983),
2022 ED.
|
G
MBS: 45kN
3kN MRL
3kN MRL
EN12278.2007
S/N:
0000 0000
ROPE
Ø8mm
h) Dimensions
Minimum distance - The distance below is
the minimum distance the WingMan can close.
3. Product Description and Components (Continued)
g) Labeling - Double pulley with side becket
1 - Maximum rated load
2 - Minimum breaking strength
3 - Serial number
4 - Certification: Double pulley with side becket
5 - Certification: Entire system
6 - Manufacturer/address
5
xxxx
3
1
2
6
Refers to the max rated
load at 4:1 mechanical
advantage.
Haul/tailing rope
g) Labeling - Double pulley with releasing cam
7 - Required rope diameter
7
8" (200 mm)
Minimum distance
4
FOR PROTOTYPING PURPOSES ONLY
FOR QUOTATION PURPOSES ONLY
SURFACE FINISH:
MATERIAL:
DRAWING NUMBER REV.
FINISH:
PART #
MFG. APR :
DRAWN BY :
TOLERANCES UNLESS OTHERWISE SPECIFIED:
DECIMAL:
ANGULAR:
SCALE:
ENG. APR :
INCORPORATED
N15 W24983 Bluemound Road
Pewaukee, Wisconsin 53072
Tel: [phone]
Fax: [phone]
www.harken.com
© The designs, constructions, arrangements, disclosures and devices
illustrated in presentations bearing this note are the property of Harken, Inc,
Pewaukee, WI and are submitted in confidence with the understanding
that such material shall not be utilized in any way by any party without prior
written consent from Harken, Inc.
DIMENSIONS IN OVALS ARE KEY
PRODUCT CHARACTERISTICS
UNLESS OTHERWISE SPECIFIED:
- DIMENSIONS IN INCHES
- ALL DIMENSIONS PRIOR TO FINISHING
- REMOVE ALL BURRS AND BREAK SHARP
EDGES WITH 0.010 MAX RADIUS OR
CHAMFER
DATE:
DATE:
DATE:
SHEET NUMBER:
DESIGN BY :
DATE:
NOTE:
REFER TO ELECTRONIC FILE FOR ALL DIMENSIONS NOT SHOWN. •
SEE TITLE BLOCK FOR TOLERANCE OF NON DIMENSIONED FEATURES. •
REFER TO HS-200 HARKEN THREAD STANDARD FOR ALL DIMENSIONS REGARDING THREADS. •
VARIOUS
LOAD TENDER
H-86666
-
ORLY
-
CJL 9/24/2021
0
-
-
MGK
DOUBLE BECKET BLOCK
10/15/2021
1:1
9/10/2021
1/1
JDM 9/9/2021
-
NFPA 2500 (1983),
2022 ED.
|
G
MBS: 45kN
3kN MRL
3kN MRL
EN12278.2007
S/N:
0000 0000
ROPE
Ø8mm
2821 0843

WingMan 7
h) Dimensions (continued)
3. Product Description and Components (Continued)
12' 3" (3.75 m)
Maximum distance - The rope in the Wingman is
49' (15 m). The maximum distance depends on how
it is used. The two maximum lengths below are with
end of the haul/tailing rope as shown.
9' 10" (3 m)
End of haul rope
End of haul rope

8 WingMan
4. Intended use prerequisites and limitations
a) Atmospheric conditions
Temperature for operation between -10° C and +40° C (14° F and 104° F).
Wet and icy conditions can affect the function of the device. Prolonged exposure
to dust, ice or other particulates can result in damage to the WingMan and should
be removed before use.
3. Product Description and Components (Continued)
1.7"
(43 mm)
3.87"
(98 mm)
2.47"
(63 mm)
2"
(53 mm)
6.18"
(157 mm)
2.64" (67 mm)
h) Dimensions (continued)
3.84" (97.6 mm)

WingMan 9
5. Use
a) Inspection before each use
Inspect the following carefully before using the WingMan. Correct problems before using.
See part description on page 5 and inspection form on page 15.
Component Inspection Action if not correct
Swivel eyes Ensure swivel rotates freely. Lack of rotation
can indicate overload.
Remove from service. Send
to Harken service center.
Swivel eyes Check for wear on load bearing part of eye for
each pulley.
Remove from service. Send
to Harken service center.
Swivel eye retaining
screws
Check for loose screws. Remove from service. Send
to Harken service center.
Riveted end of axle Ensure rivet is secure and not loose. Remove from service. Send
to Harken service center.
Pulley body Inspect the aluminum body of the pulley for any
cracks wear or corrosion.
Remove from service. Send
to Harken service center.
Sheave operation Ensure sheaves roll freely. Ensure ratchet
sheave rolls one direction and stops in other
direction. The ratchet sheave should make a
clicking sound when rotating.
Follow maintenance
directed in this manual and
recheck. If still does not roll
freely remove from service.
Send to Harken service
center.
Releasing handle
Ensure that the releasing handle locks rope
when handle is released completely. Ensure
spring action closes the handle smartly.
Remove from service. Send
to Harken service center.
Inspect the handle for any cracks wear or
separation between halves.
Remove from service. Send
to Harken service center.
Rope sewn
termination
Check sewn loop for signs of unraveling or
damage. Inspect rope becket cover to ensure
screw is tight and locked using thread-locking
compound.
Remove from service. Send
to Harken service center.
Rope Check for any abrasion, UV damage, mold,
exposure to chemicals, grease or excessive
heat.
Remove from service. Send
to Harken service center.
Rope stopper knot Ensure there is a stopper knot on the free end
of the haul rope.
Tie barrel knot and cover
with clear shrink wrap.
Reeving of rope
Ensure the rope strands are not crossed or
tangled. This can happen if the pulley is flipped
during handling.
Flip the pulley through
the strands to correct the
problem. See diagram in
part 3.
Ensure the rope is reeved through all sheaves.
The haul/tailing end of rope must exit from the
double pulley with becket.
Lead rope through last
sheave and ensure the
sewn stop is in place.

10 WingMan
5. Use (continued)
b) Operation
4:1
Anchor
Load
4:1 mechanical advantage.
If the operator is the load,
the system becomes a 5:1.
5:1
Load
5:1 mechanical
advantage.
Anchor
Function test - Before each use, verify that the device is working properly. Always use a
backup safety system. Anchor one end and gradually apply load to the WingMan. Make
sure the rope is locked in the double pulley with releasing handle. Grip the running end
of rope with one hand and then with the other hand slowly open the handle to allow
the rope to pass through and load to begin lowering. Ease pressure on the handle so
it closes and make sure the rope locks. With a moderate load on the system, open the
handle and make sure the handle snaps closed. Pull on the haul/tailing rope and make
sure the sheaves turn freely and you hear a clicking sound.
Setup - Secure one end to an anchor or appropriate full strength anchor point on
harness. Keep the releasing handle within reach of the operator.
Depending on orientation the WingMan can be used as a 4:1 mechanical advantage
system or a 5:1 mechanical advantage system.
4:1 Mechanical advantage - If the double pulley with becket is attached to the anchor
so the double with releasing handle is the movable load, and if the operator is not the
moveable load, the system provides a 4:1 mechanical advantage. If the operator is the
moveable load, the system becomes a 5:1.
5:1 Mechanical advantage - If the double pulley with releasing handle is attached to
the anchor and the double with becket is the movable load, the system provides a 5:1
mechanical advantage. Note: the handle must be within reach of the operator.
