AVR 130 Audio/VideoReceiver
SERVICE MANUAL
DIGITAL LOGIC 7 VID 1 DVD
CD
FMAM
TAPE
6 CH
VID 2
VID 3
PRO LOGIC
3 STEREO DSP
5 CH. STEREO
SURR. OFF
Surr. Select
Coaxial
RDS
Power for the Digital Revolution™
®

TECHNICAL SPECIFICATIONS
Technical Specifications
Audio Section
Stereo Mode
Continuous Average Power (FTC)
50 Watts per channel, 20Hz–20kHz,
@ < 0.07% THD, both channels driven into 8 ohms
Five-Channel Surround Modes
Power Per Individual Channel
Front L&R channels:
40 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Center channel:
40 Watts, @ < 0.07% THD, 20Hz–20kHz into 8 ohms
Surround channels:
40 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 95dB
Surround System Adjacent Channel Separation
Analog Decoding 40dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55dB
DTS 55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz–100kHz
High Instantaneous
Current Capability (HCC) ±25 Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
Rise Time 16 µsec
Slew Rate 40V/µsec
FM Tuner Section
Frequency Range 87.5–108MHz
Usable Sensitivity IHF 1.3 µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo: 70/65dB (DIN)
Distortion Mono/Stereo: 0.15/0.3%
Stereo Separation 35dB @ 1kHz
Selectivity ±400kHz: 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 522–1720kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop: 500µV
Distortion 1kHz, 50% Mod: 0.8%
Selectivity ±10kHz: 30dB
Video Section
Video Format PAL/NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency
Response 10Hz–8MHz (–3dB)
General
Power Requirement AC 220-240V/50Hz
Power Consumption 72W idle, 580W maximum
(2 channels driven)
Dimensions (Max)
Width 440mm
Height 168mm
Depth 390mm
Weight 10.9 kg
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon is a registered trademark, and Power for the digital revolution is a
trademark, of Harman International Industries, Inc.
*Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the Double-D symbol are
trademarks of Dolby Laboratories, Inc.
Confidential Unpublished Works. ©1992–1999 Dolby Laboratories, Inc.
All rights reserved.
†“DTS” and “DTS Digital Surround” are registered trademarks of
Digital Theater Systems, Inc.
††UltraStereo is a trademark of UltraStereo Corp.
VMAx is a trademark of Harman International Industries, Inc., and is an
implementation of Cooper Bauck Transaural Stereo under patent license.
Logic 7 is a registered trademark of Lexicon, Inc.
Crystal is a registered trademark of Cirrus Logic Corp.

1/1
Pos Part number 1st part name 2nd part name
CQXAVR130 INSTRUCTION MANUAL ASS'Y
CPG1A732ZBOX , OUT CARTON
CPP1A081Z BAG,POLY SET
CPS4A564 PAD , SNOW L
CPS4A565 PAD , SNOW R
CPB1061Y BAG , POLY
CQE1A180Z BOOKLET , IMFORMATIONS AVR2550/3550
CQX1A861zMANUAL , INSTRUCTION AVR130
CQX1A865Y MANUAL , SETUP AVR130
CSA1A018Z FM 1 POLE ANT
CSA3A012Z AM LOOP ANTENNA ASS'Y LUG WIRE TYPE
HABAAAM1.5VHK BATTERY
HARTAVR130cc REMOCON ASS'Y AVR130
KPL0905 STAPLE
CRE1A037 LOCKER SH08M790BO
KHE154 CLAMPER , ARM
KPL6500 STAPLE
K4FC240CL TAPE , P.P
K4FC500CL TAPE , OPP CLEAR 50M/M
1/2
Pos Part number 1st part name 2nd part name
AVR 130 SET SET , AV SURROUND RECEIVER
KBN1A174MBC22 KNOB , ROTARY
KGB1A111X BADGE , HARMAN/KARDON
KGX1A338MBC22 CAP , VOLUME
CGL1A222 INDICATOR , VOLUME
CGU1A317ZWINDOW , FIP
CGU1A318Z ORNAMENT , VOLUME
CGWAVR2600 FRONT PANEL ASS'Y
CBT1A819K128 KNOB , DELAY
CGL1A221 INDICATOR , POWER
CGW1A366RDZH43 PANEL , FRONT
CMC1A200 PLATE , SHIELD
CMD1A443 BRACKET , SIDE
CMH1A215 HOLDER , LED
CMK1A010 BRACKET , PCB
CMX1A148 INSULATOR , FUBCTION
CMX1A149 INSULATOR , SET
CMZ1A088 FILTER , FIP
CUAAVR505 BOTTOM CHASSIS ASS'Y
CHD1A012Z SCREW , SPECIAL
CHD1A023 SCREW , TRANS M4X10(SP/WA)
CHD2A012 SCREW , TR
AVR130 PACKING
AVR130 MECH

2/2
Pos Part number 1st part name 2nd part name
CB13 CWC1C4A13B080B CABLE , CARD 13pins FFC TUNER - DSP
CB15 CWC1C4A09B100B CABLE , CARD 9pins FFC VIDEO DSP
CHE170 HOLDER , PCB
CHG1A104 CUSHION , EVA H=9.5(15X20)
CHG1A157 CUSHION , RUBBER
CJA2B043ZA CORD , POWER(EUR) QDR-7100CC
CKF4A254Y PANEL , REAR AVR505
CKL1A069H43 FOOT
CLZ9W003Z FERRITE , RING 29X7.7X19
CMD1A487 BRACKET , TRANS
CNVKSTM9014MS17 TUNER MODULE(EUR)
CTB3+10G SCREW
CTB3+16GFZ SCREW
CTWS3+10G SCREW
KBC1A147MBZC22 KNOB , MOMS
KBT1A903MMZC22 KNOB , POWER
KBT1A904MBZC22 KNOB , SET
KBT1A905MBYC22 KNOB , FUNCTION
KHR301 CLAMPER
BN72 CWZAVR230BN72 WIRE ASS'Y
CKC1B145S46 CABINET , TOP
CLZ9Z028Z FERRITE CORE(21.2X6.4X12.7)
CMH1A214 HOLDER , VOLUME
CMZ1A090 SHEET , VOLUME
CTB3+8JFC SCREW
CTB4+6FFC SCREW
1/10
Pos Part number 1st part name 2nd part name
COP11578EFRONT PCB ASS'Y
C712 HCEA1HH1R0T CAP , ELECT 1UF 50V
C713 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C714 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C716 HCEA1CH331T CAP , ELECT
C717 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C718 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C719 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C720 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C721 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C722 HCEA1CH101T CAP , ELECT 100UF 16V
C723 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C724 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C725 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C726 HCEA0JH102T CAP , ELECT 1000UF 6.3V
AVR130 MECH
AVR130 FRONT BD

2/10
Pos Part number 1st part name 2nd part name
C727 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C728 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C729 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C730 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C731 HCEA1HH100T CAP , ELECT 10UF 50V
C732 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C733 HCEA1EH470T CAP , ELECT 47UF 25V
C735 HCEA1VH100T CAP , ELECT 10UF 35V
C736 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C737 HCBS1H180JT CAP , CERAMIC
C738 HCBS1H180JT CAP , CERAMIC
C770 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C771 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C773 HCEA1VH100T CAP , ELECT 10UF 35V
C774 HCEA1VH100T CAP , ELECT 10UF 35V
C775 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C776 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C777 HCEA1VH100T CAP , ELECT 10UF 35V
C778 HCEA1VH100T CAP , ELECT 10UF 35V
C779 HCEA1CKS470T CAP, ELECT
C780 HCEA1CKS470T CAP, ELECT
C781 HCEA1CKS100T CAP , ELECT
C782 HCEA1CKS100T CAP , ELECT
C785 HCBS1H470JT CAP , CERAMIC 47PF 50V J
C786 HCBS1H470JT CAP , CERAMIC 47PF 50V J
C787 HCEA1CKS100T CAP , ELECT
C788 HCEA1CKS100T CAP , ELECT
C789 HCEA1CKS100T CAP , ELECT
C790 HCEA1CKS100T CAP , ELECT
C791 HCEA1CKS470T CAP, ELECT
C792 HCEA1CKS470T CAP, ELECT
C793 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C794 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C795 KCFE1J823JBT CAP , FILM 0.082UF 63V J
C796 KCFE1J823JBT CAP , FILM 0.082UF 63V J
C797 KCFE1J332JBT CAP , FILM 0.0033UF 63V J
C798 KCFE1J332JBT CAP , FILM 0.0033UF 63V J
C799 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C800 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C805 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C806 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C807 CCKT1H104ZF CAP , CERAMIC 50V 0.1UF
C808 CCKT1H181KB CAP , CERAMIC 180PF 50V KB
C809 HCEA1AH471T CAP , ELECT 470UF 10V
AVR130 FRONT BD

3/10
Pos Part number 1st part name 2nd part name
C810 HCEA1CH101T CAP , ELECT 100UF 16V
C811 HCEA1CH101T CAP , ELECT 100UF 16V
C812 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C813 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C814 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C850 HCBS1H471KBT CAP , CERAMIC
C851 HCBS1H471KBT CAP , CERAMIC
C852 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C855 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C856 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C857 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C858 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C859 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C860 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C861 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C862 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C863 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C864 HCEA1VH100T CAP , ELECT 10UF 35V
C865 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C866 HCEA1CKS100T CAP , ELECT
C867 HCEA1CKS100T CAP , ELECT
C868 HCEA1CKS470T CAP, ELECT
C869 HCEA1CKS470T CAP, ELECT
C870 HCBS1H681KBT CAP , CERAMIC
C871 HCBS1H681KBT CAP , CERAMIC
C872 HCEA1CH331T CAP , ELECT
C873 HCEA1CH331T CAP , ELECT
C874 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C875 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C876 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C877 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C878 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C880 HCEA1AH221T CAP , ELECT
C882 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C886 HCEA0JH102T CAP , ELECT 1000UF 6.3V
C889 HCBS1H220JT CAP , CERAMIC
C890 HCBS1H220JT CAP , CERAMIC
C891 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C892 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C893 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C894 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C895 HCEA1AH471T CAP , ELECT 470UF 10V
C896 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C897 HCEA1AH471T CAP , ELECT 470UF 10V
AVR130 FRONT BD

4/10
Pos Part number 1st part name 2nd part name
C900 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
D724 HVD1SS133MT DIODE 1SS133T-77
D728 HVD1SS133MT DIODE 1SS133T-77
D729 HVD1SS133MT DIODE 1SS133T-77
D730 HVD1SS133MT DIODE 1SS133T-77
D761 HVD1SS133MT DIODE 1SS133T-77
D774 HVD1SS133MT DIODE 1SS133T-77
D775 HVD1SS133MT DIODE 1SS133T-77
D776 KVD1N4003ST DIODE 1N4003
D777 HVD1SS133MT DIODE 1SS133T-77
D778 KVD1N4003ST DIODE 1N4003
D779 HVD1SS133MT DIODE 1SS133T-77
D783 HVD1SS133MT DIODE 1SS133T-77
D784 HVD1SS133MT DIODE 1SS133T-77
D785 HVD1SS133MT DIODE 1SS133T-77
D786 HVDMTZJ5.6BT DIODE , ZENER
D787 HVDMTZJ5.6BT DIODE , ZENER
IC87 HVIRE5VL28CATZ IC , RESET
L702 HLQ02C100KT COIL , AXAIL
Q701 HVTKRC107MT T.R KRC107M
Q702 HVTKRC107MT T.R KRC107M
Q703 HVTKRC107MT T.R KRC107M
Q705 HVTKRC107MT T.R KRC107M
Q706 HVTKRC107MT T.R KRC107M
Q722 HVTKRA107MT T.R KRA107M
Q724 HVTKRC107MT T.R KRC107M
Q725 HVTKRC107MT T.R KRC107M
Q726 HVTKRC107MT T.R KRC107M
Q727 HVTKRC107MT T.R KRC107M
Q728 HVTKRC107MT T.R KRC107M
Q729 HVTKRC107MT T.R KRC107M
Q734 HVTKTC2874BT T.R , MUTE KTC2874B
Q735 HVTKTC2874BT T.R , MUTE KTC2874B
Q736 HVTKTC2874BT T.R , MUTE KTC2874B
Q737 HVTKTC2874BT T.R , MUTE KTC2874B
Q738 HVTKRC107MT T.R KRC107M
Q739 HVTKTA1271YT T.R KTA1271Y
Q743 HVTKRA107MT T.R KRA107M
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R702 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R705 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R706 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R707 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
AVR130 FRONT BD

5/10
Pos Part number 1st part name 2nd part name
R708 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R709 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R710 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R712 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R713 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R714 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R715 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R716 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R717 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R718 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R719 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R721 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R723 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R724 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R725 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R726 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R727 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R728 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R730 CRD20TJ112T RES,CABON
R731 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R732 CRD20TJ202T RES , CARBON
R733 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R734 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R735 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R736 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R737 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R744 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R745 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R746 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R747 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R749 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R750 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R751 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R753 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R754 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R755 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R756 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R757 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R758 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R759 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R760 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R761 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R762 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
AVR130 FRONT BD

6/10
Pos Part number 1st part name 2nd part name
R763 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R764 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R765 CRD20TJ752T RES , CARBON 7.5K OHM 1/5W J
R766 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R767 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R768 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R769 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R771 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R772 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R773 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R774 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R775 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R776 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R777 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R810 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R811 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R813 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R814 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R822 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R824 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R825 CRD20TJ181T RES , CARBON 180 OHM 1/5W J
R826 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R827 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R829 CRD20TJ184T RES , CARBON
R830 CRD20TJ184T RES , CARBON
R831 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R832 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R833 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R834 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R835 CRD20TJ184T RES , CARBON
R836 CRD20TJ184T RES , CARBON
R837 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R838 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R839 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R840 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R841 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R842 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R843 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R844 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R845 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R846 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R847 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R848 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R849 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
AVR130 FRONT BD

7/10
Pos Part number 1st part name 2nd part name
R850 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R851 CRD20TJ392T RES , CARBON
R852 CRD20TJ392T RES , CARBON
R853 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R854 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R855 CRD20TJ681T RES , CARBON 680 OHM 1/5W J
R856 CRD20TJ681T RES , CARBON 680 OHM 1/5W J
R857 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R858 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R864 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R865 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R866 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R868 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R869 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R871 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R872 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R873 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R874 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R875 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R876 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R877 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R878 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R881 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R882 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R883 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R884 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R885 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R886 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R887 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R888 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R889 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R890 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R891 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R892 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R893 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R895 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R896 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R897 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R898 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R899 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R900 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R901 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R902 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R903 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
AVR130 FRONT BD

8/10
Pos Part number 1st part name 2nd part name
R904 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R905 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R906 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R907 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R908 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R909 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R910 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R911 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R912 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R913 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R914 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R915 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R917 CRD20TJ123T RES , CARBON 12K OHM 1/5W J
R918 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R919 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
S701 HST1A020ZT SW , TACT
S702 HST1A020ZT SW , TACT
S703 HST1A020ZT SW , TACT
S704 HST1A020ZT SW , TACT
S705 HST1A020ZT SW , TACT
S706 HST1A020ZT SW , TACT
S707 HST1A020ZT SW , TACT
S708 HST1A020ZT SW , TACT
S709 HST1A020ZT SW , TACT
S710 HST1A020ZT SW , TACT
S711 HST1A020ZT SW , TACT
S712 HST1A020ZT SW , TACT
S713 HST1A020ZT SW , TACT
S714 HST1A020ZT SW , TACT
S715 HST1A020ZT SW , TACT
S716 HST1A020ZT SW , TACT
S717 HST1A020ZT SW , TACT
S718 HST1A020ZT SW , TACT
S719 HST1A020ZT SW , TACT
S720 HST1A020ZT SW , TACT
BAT1 HABGP40BVH3A3H BATTERY , RECHARGEABLE GP40BBVH3A3H
BK71 CMD1A209 BRACKET , FLT A4-92-1739
BK72 CMD1A209 BRACKET , FLT A4-92-1739
BK73 CMD1A387 BRACKET , PCB
BK74 CMD1A209 BRACKET , FLT A4-92-1739
BN10 CWZAVR230BN10 WIRE ASS'Y (SHIELD)
BN15 CWB2B906150EN WIRE ASS'Y
BN16 CWZAVR2550BN16 WIRE ASS'Y (SHIELD)
BN18 CWZAVR125BN18 WIRE ASS'Y (SHIELD)
AVR130 FRONT BD

9/10
Pos Part number 1st part name 2nd part name
BN41 CWZAVR130BN41 WIRE ASS'Y (SHIELD)
BN80 CWB2B911420EW WIRE ASS'Y
BN81 CWB2B908250BM WIRE , ASS'Y
BN84 CWB2B905080EN WIRE ASS'Y
BN85 CWB2B902090EN WIRE ASS'Y
BN87 CWZAVR2550BN87 WIRE ASS'Y (SHIELD)
BN88 CWB2B904070EN WIRE ASS'Y
BN89 CWB2B905080EN WIRE ASS'Y
BN90 CWB2B902090EN WIRE ASS'Y
BN94 KJP13GB99ZM CONNECTOR MOLEX35237-1310
BN95 KJP08GB99ZM CONNECTOR , HOUSING MOLEX35237-0810
CN10 KJP04GB46ZM WAFER MOLEX 53015
CN11 KJP15GA98ZM WAFER MOLEX35336-1510
CN12 KJP15GA98ZM WAFER MOLEX35336-1510
CN15 KJP06GA19ZM WAFER MOLEX53014-0610
CN16 KJP08GB46ZM WAFER
CN72 KJP32GA161ZY WAFER YD200 SERIES
CN82 KJP06HA37ZM WAFER MOLEX42140-2206
CN84 KJP05GA19ZM WAFER MOLEX53014-0510
CN85 KJP02GA19ZM WAFER
CN86 KJP02GA89ZM WAFER MOLEX35328-02
CN87 KJP06GA19ZM WAFER MOLEX53014-0610
CN88 KJP04GA19ZM WAFER
CN89 KJP05GA19ZM WAFER MOLEX53014-0510
CN90 KJP02GA19ZM WAFER
CN91 KJP06HA37ZM WAFER MOLEX42140-2206
C853 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV
D702 CVD52CSBBCEAB2 BLUE L.E.D
D703 CVD52CSBBCEAB2 BLUE L.E.D
D704 CVD52CSBBCEAB2 BLUE L.E.D
D706 CVD52CSBBCEAB2 BLUE L.E.D
D707 CVD52CSBBCEAB2 BLUE L.E.D
D723 CVD50BOGDWGA L.E.D , 2 COLOR
FIP1 HFLHCA18ML01 F.I.P
IC71 BVISAA6579TV1 I.C , RDS FILTER TW SAA6579T/V1
IC72 BVIMB90F482APFG IC , FLASH U-COM FUJITSU
IC73 HRVRPM6938H4 SENSOR , REMOTE RPM6938-H4
IC74 HVIS3F84BB I.C , FLASH U-COM S3F84BB
IC75 HVI74ACT04MTR I.C , HEX
IC76 HVITC74HCU04AFN IC , INVERTER TC74HCU04AFN
IC80 HVIHCF4053M013T I.C
IC81 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
IC82 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
IC83 HVI74ACT04MTR I.C , HEX
AVR130 FRONT BD

10/10
Pos Part number 1st part name 2nd part name
IC84 HVI74ACT04MTR I.C , HEX
IC85 HVIRH5VT18C I.C , RESET
IC86 HVINJM4556AL I.C NJM4556AL
IC88 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
JK81 CJJ4M041Y JACK , BOARD (COAX)
JK82 HJSTORX179L MODULE , OPTICAL(RX) TORX179L
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE)
JK85 CJJ9M003Z JACK , S-VIDEO
JK86 CJJ4S023Y JACK , BOARD
JW82 CWZAVR2550JW82 WIRE , ASS'Y
JW84 CWE8202110RV WIRE, ASS'Y
JW85 CWE8202070AA WIRE ASS'Y
SW01 CSH1A008ZV SW , PUSH (MOMS)
VR71 CVV2X05M104Z RES , VARIABLE(BALANCE) RK14128030214Y
VR72 CVV2X07C104Z RES , VARIABLE(TONE) RK14128030214C
VR73 CVV2X07C104Z RES , VARIABLE(TONE) RK14128030214C
VR74 HSR2A026Z VR , ENCODER
X701 HOX05000E160C CRYSTAL
X702 HOX04332E200C CRYSTAL
X703 HOX10000E220C CRYSTAL
1/11
Pos Part number 1st part name 2nd part name
COP11579EMAIN PCB ASS'Y
C501 HCEA1VH100T CAP , ELECT 10UF 35V
C502 HCEA1VH100T CAP , ELECT 10UF 35V
C503 HCEA1VH100T CAP , ELECT 10UF 35V
C504 HCEA1VH100T CAP , ELECT 10UF 35V
C505 HCEA1VH100T CAP , ELECT 10UF 35V
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C507 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C508 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C510 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C561 HCEA1CH101T CAP , ELECT 100UF 16V
C562 HCEA1CH101T CAP , ELECT 100UF 16V
C563 HCEA1CH101T CAP , ELECT 100UF 16V
C564 HCEA1CH101T CAP , ELECT 100UF 16V
C565 HCEA1CH101T CAP , ELECT 100UF 16V
C566 HCEA1CH101T CAP , ELECT 100UF 16V
C567 HCEA1CH101T CAP , ELECT 100UF 16V
C568 HCEA1CH101T CAP , ELECT 100UF 16V
C569 HCEA1CH101T CAP , ELECT 100UF 16V
C570 HCEA1CH101T CAP , ELECT 100UF 16V
AVR130FRONT BD
AVR130 MAIN BD

2/11
Pos Part number 1st part name 2nd part name
C571 HCBS1H681KBT CAP , CERAMIC
C572 HCBS1H681KBT CAP , CERAMIC
C573 HCBS1H681KBT CAP , CERAMIC
C574 HCBS1H681KBT CAP , CERAMIC
C575 HCBS1H681KBT CAP , CERAMIC
C601 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C602 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C603 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C604 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C605 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C606 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C607 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C608 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C609 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C610 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C681 HCEA1HH100T CAP , ELECT 10UF 50V
C682 HCEA1HH100T CAP , ELECT 10UF 50V
C683 HCEA1HH100T CAP , ELECT 10UF 50V
C684 HCEA1HH100T CAP , ELECT 10UF 50V
C685 HCEA1HH100T CAP , ELECT 10UF 50V
C726 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C900 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C901 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C905 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF
C907 HCEA1CH101T CAP , ELECT 100UF 16V
C908 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF
C910 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C911 HCEA1CH471T CAP , ELECT
C912 HCEA1CH221T CAP , ELECT
C913 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF
C918 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C919 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C923 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C924 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C925 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C939 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C940 HCEA1AH471T CAP , ELECT 470UF 10V
C971 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C973 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C974 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C980 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C981 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C990 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C991 HCEA1HH1R0T CAP , ELECT 1UF 50V
AVR130 MAIN BD

3/11
Pos Part number 1st part name 2nd part name
C992 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C993 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C995 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C997 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C999 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF
D501 HVD1SS133MT DIODE 1SS133T-77
D502 HVD1SS133MT DIODE 1SS133T-77
D503 HVD1SS133MT DIODE 1SS133T-77
D504 HVD1SS133MT DIODE 1SS133T-77
D505 HVD1SS133MT DIODE 1SS133T-77
D581 HVD1SS133MT DIODE 1SS133T-77
D582 HVD1SS133MT DIODE 1SS133T-77
D583 HVD1SS133MT DIODE 1SS133T-77
D584 HVD1SS133MT DIODE 1SS133T-77
D585 HVD1SS133MT DIODE 1SS133T-77
D901 KVD1N4003ST DIODE 1N4003
D902 HVD1SS133MT DIODE 1SS133T-77
D911 HVD1SS133MT DIODE 1SS133T-77
D912 HVD1SS133MT DIODE 1SS133T-77
D914 HVD1SS133MT DIODE 1SS133T-77
D917 HVD1SS133MT DIODE 1SS133T-77
D953 HVD1SS133MT DIODE 1SS133T-77
D954 KVD1N4003SRT DIODE TW 1N4003
D955 KVD1N4003SRT DIODE TW 1N4003
D961 KVD1N4003ST DIODE 1N4003
D962 KVD1N4003ST DIODE 1N4003
D963 KVD1N4003ST DIODE 1N4003
D977 HVD1SS133MT DIODE 1SS133T-77
D978 HVD1SS133MT DIODE 1SS133T-77
Q501 HVTKTA1268GRT T.R KTA1268GR
Q502 HVTKTA1268GRT T.R KTA1268GR
Q503 HVTKTA1268GRT T.R KTA1268GR
Q504 HVTKTA1268GRT T.R KTA1268GR
Q505 HVTKTA1268GRT T.R KTA1268GR
Q511 HVTKTC3200GRT T.R KTC3200GR
Q512 HVTKTC3200GRT T.R KTC3200GR
Q513 HVTKTC3200GRT T.R KTC3200GR
Q514 HVTKTC3200GRT T.R KTC3200GR
Q515 HVTKTC3200GRT T.R KTC3200GR
Q516 HVTKTC3200GRT T.R KTC3200GR
Q517 HVTKTC3200GRT T.R KTC3200GR
Q518 HVTKTC3200GRT T.R KTC3200GR
Q519 HVTKTC3200GRT T.R KTC3200GR
Q520 HVTKTC3200GRT T.R KTC3200GR
AVR130 MAIN BD

4/11
Pos Part number 1st part name 2nd part name
Q541 HVTKTC3198YT T.R
Q542 HVTKTC3198YT T.R
Q543 HVTKTC3198YT T.R
Q544 HVTKTC3198YT T.R
Q545 HVTKTC3198YT T.R
Q556 HVTKTC3200GRT T.R KTC3200GR
Q557 HVTKTC3200GRT T.R KTC3200GR
Q558 HVTKTC3200GRT T.R KTC3200GR
Q559 HVTKTC3200GRT T.R KTC3200GR
Q560 HVTKTC3200GRT T.R KTC3200GR
Q561 HVTKTC3200GRT T.R KTC3200GR
Q562 HVTKTC3200GRT T.R KTC3200GR
Q563 HVTKTC3200GRT T.R KTC3200GR
Q564 HVTKTC3200GRT T.R KTC3200GR
Q565 HVTKTC3200GRT T.R KTC3200GR
Q601 HVTKTA1268GRT T.R KTA1268GR
Q602 HVTKTA1268GRT T.R KTA1268GR
Q603 HVTKTA1268GRT T.R KTA1268GR
Q604 HVTKTA1268GRT T.R KTA1268GR
Q605 HVTKTA1268GRT T.R KTA1268GR
Q681 KVTKSC2785YT T.R KSC2785Y
Q682 KVTKSC2785YT T.R KSC2785Y
Q683 KVTKSC2785YT T.R KSC2785Y
Q684 KVTKSC2785YT T.R KSC2785Y
Q685 KVTKSC2785YT T.R KSC2785Y
Q706 HVTKTC2874BT T.R , MUTE KTC2874B
Q901 KVTKSC2785YT T.R KSC2785Y
Q938 HVTKRA107MT T.R KRA107M
Q939 HVTKRA107MT T.R KRA107M
Q942 KVTKSC2785YT T.R KSC2785Y
Q943 KVTKSC2785YT T.R KSC2785Y
Q951 HVTKRC107MT T.R KRC107M
Q952 HVTKRA107MT T.R KRA107M
Q960 HVTKRC107MT T.R KRC107M
Q961 HVTKTA1024YT T.R
Q969 HVTKTC2874BT T.R , MUTE KTC2874B
Q970 HVTKTC2874BT T.R , MUTE KTC2874B
Q971 HVTKTC2874BT T.R , MUTE KTC2874B
Q972 HVTKTC2874BT T.R , MUTE KTC2874B
Q973 HVTKTC2874BT T.R , MUTE KTC2874B
Q991 HVTKRC107MT T.R KRC107M
Q992 HVTKRA107MT T.R KRA107M
R501 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R502 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
AVR130 MAIN BD

5/11
Pos Part number 1st part name 2nd part name
R503 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R504 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R505 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R506 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R507 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R508 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R509 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R510 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R511 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R512 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R513 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R514 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R515 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R516 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R517 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R518 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R519 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R520 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R521 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R522 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R523 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R524 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R525 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R531 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R532 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R533 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R534 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R535 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R536 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R537 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R538 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R539 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R540 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R541 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R542 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R543 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R544 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R545 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R556 CRD20TJ273T RES , CARBON 27K OHM 1/5W J
R557 CRD20TJ273T RES , CARBON 27K OHM 1/5W J
R558 CRD20TJ273T RES , CARBON 27K OHM 1/5W J
R559 CRD20TJ273T RES , CARBON 27K OHM 1/5W J
R560 CRD20TJ273T RES , CARBON 27K OHM 1/5W J
R561 CRD20TJ202T RES , CARBON
AVR130 MAIN BD

6/11
Pos Part number 1st part name 2nd part name
R562 CRD20TJ202T RES , CARBON
R563 CRD20TJ202T RES , CARBON
R564 CRD20TJ202T RES , CARBON
R565 CRD20TJ202T RES , CARBON
R566 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R567 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R568 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R569 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R570 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R571 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R572 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R573 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R574 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R575 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R576 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R577 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R578 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R579 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R580 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R581 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R582 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R583 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R584 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R585 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R586 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R587 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R588 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R589 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R590 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R591 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R592 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R593 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R594 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R595 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R596 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R597 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R598 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R599 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R600 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R601 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R602 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R603 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R604 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R605 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
AVR130 MAIN BD

7/11
Pos Part number 1st part name 2nd part name
R606 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R607 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R608 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R609 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R610 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R631 KRD25FJ180T RES , CARBON
R632 KRD25FJ180T RES , CARBON
R633 KRD25FJ180T RES , CARBON
R634 KRD25FJ180T RES , CARBON
R635 KRD25FJ180T RES , CARBON
R636 KRD25FJ180T RES , CARBON
R637 KRD25FJ180T RES , CARBON
R638 KRD25FJ180T RES , CARBON
R639 KRD25FJ180T RES , CARBON
R640 KRD25FJ180T RES , CARBON
R646 KRD25FJ3R3T RES , CARBON
R647 KRD25FJ3R3T RES , CARBON
R648 KRD25FJ3R3T RES , CARBON
R649 KRD25FJ3R3T RES , CARBON
R650 KRD25FJ3R3T RES , CARBON
R651 KRD25FJ3R3T RES , CARBON
R652 KRD25FJ3R3T RES , CARBON
R653 KRD25FJ3R3T RES , CARBON
R654 KRD25FJ3R3T RES , CARBON
R655 KRD25FJ3R3T RES , CARBON
R666 CRD25TJ470T RES , CARBON
R667 CRD25TJ470T RES , CARBON
R668 CRD25TJ470T RES , CARBON
R669 CRD25TJ470T RES , CARBON
R670 CRD25TJ470T RES , CARBON
R671 CRD20TJ911T RES , CARBON 910 OHM 1/5W J
R672 CRD20TJ911T RES , CARBON 910 OHM 1/5W J
R673 CRD20TJ911T RES , CARBON 910 OHM 1/5W J
R674 CRD20TJ911T RES , CARBON 910 OHM 1/5W J
R675 CRD20TJ911T RES , CARBON 910 OHM 1/5W J
R676 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R677 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R678 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R679 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R680 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R681 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R682 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R683 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R684 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
AVR130 MAIN BD
