harman/kardon
AVR7000
A/V DOLBY DIGITAL RECEIVER
SERVICE MANUAL
CONTENTS
ESD WARNING…………………..….……….2
LEAKAGE TESTING……………….…..…....3
BASIC SPECIFICATIONS…………………..4
DETAILED SPECIFICATIONS…….………..5
FRONT PANEL CONTROLS………..….…..13
REAR PANEL CONNECTIONS……..….…15
REMOTE CONTROL FUNCTIONS……….17
SERVICE BULLETINS/TECH TIPS…...….20
IDLE CURRENT ADJUST…………….…...28
TUNER ALIGNMENT…………………..…..29
TROUBLESHOOTING GUIDE…...…….…32
PROCESSOR RESET……………………..32
UNIT EXPLODED VIEW……………………33
EXPLODED VIEW PARTS LIST………….34
BLOCK DIAGRAM……………….…………35
PCB DRAWINGS……………….……..……36
MECHANICAL PARTS LIST………..………52
PACKAGING PARTS LIST………....………54
REVISIONS - ELECTRICAL PARTS LIST.55
ELECTRICAL PARTS LIST…….………….56
SEMICONDUCTOR PINOUTS……..….….76
SCHEMATICS…………………..…..……..137
AVR7000 TRANSFORMER………..…….161
WIRING DIAGRAM………………………..162
PACKAGE……………………...……...…..163
harman/kardon, Inc.
250 Crossways Park Dr.
Woodbury, New York 11797 Rev4 – 7/2005

Each precaution in this manual should be followed during servicing.
Components identified with the IEC symbol in the parts list are special significance to safety. When replacing a component identified with
, use only the replacement parts designated, or parts with the same ratings or resistance, wattage, or voltage that are designated in the
parts list in this manual. Leakage-current or resistance measurements must be made to determine that exposed parts are acceptably
insulated from the supply circuit before retuming the product to the customer.
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field effect transistors and
semiconductor "chip" components.
The following techniques should be used to help reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any electrostatic charge on
your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging wrist strap device,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to
prevent electrostatic charge build-up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can generate electrical charges
sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical change sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement
ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material.)
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the
chassis or circuit assembly into which the device will be installed.
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together
or your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient to damage an ES devices.
CAUTION :
AVR7000 harman/kardon
2

1. Inspect all lead dress to make certain that
leads are not pinched or that hardware is not
lodged between the chassis and other metal
parts in the unit.
2. Be sure that any protective devices such as
nonmetallic control knobs, insulating fish-
papers, cabinet backs, adjustment and
compartment covers or shields, isolation
resistor-capacity networks, mechanical
insulators, etc. Which were removed for the
servicing are properly re-installed.
Before returning the unit to the user, perform the following safety checks :
3. Be sure that no shock hazard exists ; check for leakage
current using Simpson Model 229 Leakage Tester, standard
equipment item No. 21641, RCA Model WT540A or use
alternate method as follows : Plug the power cord directly
Into a 120 volt AC receptacle (do not use an Isolation
Transformer for this test). Using two clip leads, connect a
1500 ohms, 10watt Resistor paralleled by a 0.15uF capacitor, in series with all exposed metal cabinet parts and a known earth ground, such
as a water pipe or conduit. Use a VTVM or VOM with 1000 ohms per volt, or higher sensitivity to measure the AC voltage drop across the
resistor. (See diagram) Move the resistor connection to each exposed metal part having a return path to the chassis (antenna, metal,
cabinet, screw heads, knobs and control shafts, escutcheon, etc.) and measure the AC voltage drop across the resistor. (This test should be
performed with the 0.35 volt RMS or more is excessive and indicates a potential shock hazard which must be corrected before returning the
unit to the owner.
AVR7000 harman/kardon
3

TECHNICAL SPECIFICATIONS
Technical Specifications
Audio Section
Stereo Mode
ContinuousAverage Power (FTC)
110Watts per channel, 20Hz–20kHz,
@ < 0.07%THD, both channels driven into 8 ohms
Five-Channel Surround Modes
Power Per Individual Channel
Front L&R channels:
100Watts per channel,
@ < 0.07%THD, 20Hz–20kHz into 8 ohms
Center channel:
100Watts, @ < 0.07% THD, 20Hz–20kHz into 8 ohms
Surround channels:
100Watts per channel,
@ < 0.07%THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 95dB
Surround SystemAdjacent Channel Separation
Analog Decoding 40dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55dB
DTS 55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz–100kHz
High Instantaneous
Current Capability (HCC) ±75Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
RiseTime 16µsec
Slew Rate 40V/µsec
FM Tuner Section
Frequency Range 87.5–108MHz
Usable Sensitivity IHF 1.3 µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo 70/68dB
Distortion Mono/Stereo 0.2/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz, 65dB
Image Rejection 80dB
IF Rejection 90dB
Tuner Output Level 1kHz, ±75kHz Dev 500mV
AM Tuner Section
Frequency Range 520–1720kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop 500µV
Distortion 1kHz, 50% Mod 0.8%
Selectivity ±10kHz, 30dB
Video Section
Video Format NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency 5Hz–10MHz (–3dB)
Response
General
Power Requirement AC 120V/60Hz
Power Consumption 125W idle, 1100W maximum
(2 channels driven)
Dimensions (Max)
Width 17.3 inches (440mm)
Height 7.62 inches (193mm)
Depth 20.43 inches (519mm)
Weight 49 lb (22.3 kg)
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon is a registered trademark,and Power for the digital revolution is a
trademark,of Harman International Industries, Inc.
*Manufactured under license from Dolby Laboratories.
“Dolby,”“Pro Logic,”“AC-3”and the Double-D symbol are
trademarks of Dolby Laboratories.Confidential Unpublished
Works. ©1992–1999 Dolby Laboratories, Inc.All rights reserved.
†DTS and DTS Surround are trademarks of DigitalTheater Systems, Inc.
††UltraStereo is a trademark of UltraStereo Corp.
VMAx is a trademark of Harman International Industries, Inc., and is an
implementation of Cooper BauckTransaural Stereo under patent license.
Logic 7 is a registered trademark of Lexicon,Inc.
HDCD is a registered trademark of Pacific Microsonics.
Crystal is a registered trademark of Cirrus Logic Corp.
AVR7000 harman/kardon
4

DETAILED SPECIFICATION FOR RECEIVER AVR7000 (120V)
PARAMETERS
Measuring methods are based on IHF and IEC standard 268-3
Measurement conditions,unless otherwise noted :
Output resistive load = (8) ohms / All channels loaded.
Tone Off or Tone(Bass,Treble), Balance, EQ control : Center Position , Other SW's : OFF, Volume:Max
Nominal input level : 200mV for general purpose inputs
Power figures should be kept minimum 10min., between 15 and 35oC.
Terminator : 1kohm for general purpose inputs
All Voltage Measurements are made with RMS detector, unless otherwise specified.
Filter : IHF-A filter
R/O = Rated Output, which is 100 W into 8 ohm resistive load, for both Stereo and 6 CH DIRECT inputs.
UUT= Unit Under Test.
Power supply : 120 V , 60 Hz
D
FRONT AMP SECTION
*SUB-WOOFER SPKR:NO *SPKR LEVEL:ALL 0dB
NO
DESCRIPTION
Y/N
INPUT
FREQ.
REMARK
UNIT
LIMIT
NOMINAL
1INPUT SENSITIVITY YCD 1kHz To obtain rated Power mV 200+/-30 200+/-20
Y6 CH DIRECT 1kHz To obtain rated Power mV
2
CHANNEL BALANCE
Y
6 CH DIRECT 1kHz
Vin=100mV, Vol at Max TO -40dB
dB +/-3 +/-2
Y1kHz Vin=100mV, Volt at -40 TO -60dB dB +/-6 +/-4
3
DAMPING FACTOR Y6 CH DIRECT 1kHz Zout at a current level equivalent to 10
dB below rated Power current level. 20-
20kHz, 8 ohm load >100
4
HICC Y6 CH DIRECT 10 KHz 10 KHz single cycle sine impulse. 1 impulse/sec. Using 0.1 ohm, 1%, 250
W, non inductive load A>60 >65
5RESIDUAL NOISE YShould be met
by all Stereo
Inputs
1kHz VOL at min. 10Hz-22KHz BW, peak
detector, all inputs terminated w/ 1
Kohm
mVpk <1.2mV <1.0mV
YShould be met by all Stereo
Inputs 1kHz VOL at max. 10Hz-22KHz BW, peak
detector, all inputs terminated w/ 1
Kohm mVpk <3mVrms <1.5mVrms
YShould be met by all Stereo
Inputs 1kHz
VOL at max. 10Hz-22KHz BW, RMS ,
non-weighted, all inputs terminated w/
1 Kohm mVrms <1mVrms <0.75mVrms
YShould be met by all Stereo
Inputs 1kHz
VOL at max. 10Hz-22KHz BW, RMS ,
'A Weighted', all inputs terminated w/ 1
Kohm mVrms <0.7mVrms <0.5mVrms
YShould be met by all Stereo
Inputs 1kHz
VOL at max. 10Hz-22KHz BW, RMS ,
'A Weighted', all inputs left un-
terminated mVrms <0.7mVrms <0.5mVrms
RESIDUAL NOISE Y6 CH DIRECT 1kHz VOL at min. 10Hz-22KHz BW, peak detector, all inputs terminated w/ 1
Kohm mVpk <1.2mVrms <1.0mVrms
Y6 CH DIRECT 1kHz VOL at max. 10Hz-22KHz BW, peak detector, all inputs terminated w/ 1
Kohm mVpk <3mVrms <1.5mVrms
Y6 CH DIRECT 1kHz
VOL at max. 10Hz-22KHz BW, RMS,
non-weighted, all inputs terminated w/
1 Kohm mVrms <1mVrms <0.75mVrms
Y6 CH DIRECT 1kHz
VOL at max. 10Hz-22KHz BW, RMS,
'A Weighted', all inputs terminated w/ 1
Kohm mVrms <0.7mVrms <0.5mVrms
Y6 CH DIRECT 1kHz
VOL at max. 10Hz-22KHz BW, RMS,
'A Weighted', all inputs left un-
terminated mVrms <0.7mVrms <0.5mVrms
6TOTAL HARMONIC
DISTORTION YShould be met
by all Stereo
Inputs
20Hz-20 KHz, Power
out =Rated Power - 1
dB Vol at Max, 10 Hz-80KHz Meas BW. %<0.08 <0.05
TOTAL HARMONIC
DISTORTION Y6 CH DIRECT 20Hz-20 KHz, Power
out =Rated Power - 1
dB Vol at Max, 10 Hz-80KHz Meas BW. %<0.08 <0.05
TOTAL HARMONIC
DISTORTION YShould be met
by all Stereo
Inputs
20Hz-10 KHz, Power
out =1 W Vol at Max, 10 Hz-22 KHz Meas BW. %<0.08 <0.05
TOTAL HARMONIC
DISTORTION Y6 CH DIRECT 20Hz-10 KHz, Power out =1 W Vol at Max, 10 Hz-22 KHz Meas BW. %<0.08 <0.05
7CONTINUOUS AVERAGE
POWER: A) Stereo, 8
Ohm load, Fl and FR driven.
YCD 20 Hz at 0.1% THD, 10 Hz-80 KHz
measurement BW. Volume at Max. W>110 >115
YCD 1kHz at 0.1% THD, 10 Hz-80 KHz
measurement BW. Volume at Max. W>110 >115
AVR7000 harman/kardon
5

YCD 20 KHz at 0.1% THD, 10 Hz-80 KHz
measurement BW.Volume at Max. W>110 >115
CONTINUOUS AVERAGE
POWER: B) All 5
Channels Driven, 8 ohms Y6 CH DIRECT 20 Hz at 0.1% THD, 10 Hz-80 KHz
measurement BW.Volume at Max. W>100 >105
Y6 CH DIRECT 1kHz at 0.1% THD, 10 Hz-80 KHz
measurement BW.Volume at Max. W>100 >105
Y6 CH DIRECT 20 KHz at 0.1% THD, 10 Hz-80 KHz
measurement BW.Volume at Max. W>100 >105
8IMD(SMPTE) Y6 CH DIRECT
Sine wave # 1 f
=60Hz. Ampl=4, sine
wave # 2 f= 7 KHz.
Ampl=1
30 step Sweep of Gen to Drive to Pk-
Pk value of sine rated power %< 0.15 < 0.09
9DIM Y6 CH DIRECT
Square wave f
=3.15KHz. Ampl=4,
sine f=15 KHz.
Ampl=1
30 step Sweep of Gen to Drive to Pk-
Pk value of sine rated power %< 0.15 < 0.09
10 S/N RATIO,IHF-A FILTER YAll Stereo Inputs 1kHz Referred to Rated Output Power, Vol
at max, all inputs terminated w/ 1
Kohm. dB >92 >95
YAll Stereo Inputs 1kHz Referred to 1W Out. Vol at max, all
inputs terminated w/ 1 Kohm. dB >72 >75
YAll Stereo Inputs 1kHz Referred to Rated Output Power, Vol
at max, all inputs left un-terminated dB >92 >95
Y6 CH DIRECT 1kHz Referred to Rated Output Power, Vol
at max, all inputs terminated w/ 1
Kohm.
dB >92 >95
Y6 CH DIRECT 1kHz Referred to Rated Output Power, Vol
at max, all inputs left un-terminated. dB >92 >95
Y6 CH DIRECT 1kHz Referred to 1W Out. Vol at max, all
inputs terminated w/ 1 Kohm. dB >74 >77
11
CHANNEL SEPARATION:
Zterm = 1KW/1000pF YCD 100Hz
Vol at Max, Gen amplitude adjusted to
obtain R/O-3dB, measured w/ AP's
Xtalk mode. Driving every channel
individually. Undriven channels should
be terminated w/ 1 kOhm.
dB >65 >70
Y1kHz
Vol at Max, Gen amplitude adjusted to
obtain R/O-3dB, measured w/ AP's
Xtalk mode. Driving every channel
individually. Undriven channels should
be terminated w/ 1 kOhm.
dB >65 >70
Y10kHz
Vol at Max, Gen amplitude adjusted to
obtain R/O-3dB, , measured w/ AP's
Xtalk mode. Driving every channel
individually. Undriven channels should
be terminated w/ 1 kOhm.
dB >55 >65
CHANNEL SEPARATION:
Zterm = 1KW/1000pF Y6 CH DIRECT 100Hz
Vol at Max, Gen amplitude adjusted to
obtain R/O-3dB, measured w/ AP's
Xtalk mode. Driving every channel
individually. Undriven channels should
be terminated w/ 1 kOhm.
dB >65 >70
Y1kHz
Vol at Max, R/O-3dB, measured w/
AP's Xtalk mode. Driving every
channel individually. Undriven channels
should be terminated w/ 1 kOhm.
dB >65 >70
Y10kHz
Vol at Max, Gen amplitude adjusted to
obtain R/O-3dB, , measured w/ AP's
Xtalk mode. Driving every channel
individually. Undriven channels should
be terminated w/ 1 kOhm.
dB >55 >65
12 FUNCTION CROSSTALK,
(Measured on all Channels)
YAll Analog
Stereo and 6 CH
DIRECT Inputs 1 kHz
Volume at Max. Apply Sinewave
Signal Gen amplitude to the tested
input, to obtain R/O-3dB at the speaker
outputs. Record the output level as the
reference output. Then, scroll thru the
other possible stereo inputs, and
measure the output level. Compute t
dB >70 >75
6

YAll Analog
Stereo and 6 CH
DIRECT Inputs 10 kHz
Volume at Max. Apply Sinewave
Signal Gen amplitude to the tested
input, to obtain R/O-3dB at the speaker
outputs. Record the FL and FR speaker
output level as the reference output.
Scroll thru other stereo inputs, and
measure the output level. Compute th
dB > 55 >75
YAM/FM Tuner
Input 1 KHz
Apply an FM Stereo RF input thru a 50-
>75 ohm dummy antenna (98 MHz
carrier, 75 KHz modulation, 1 KHz
tone, 72 dBuV level). Then set UUT to
FM Stereo , 98 MHz. Set Volume
control to 10 dB below Max. Record
the FL and FR speaker output level as
the refere
Full scale Digital
Input TBD
19
FTC POWER 20Hz~20kHz,
0.08 % THD, 8 ohm load YCD 20 Hz-20 KHz
1 hour preconditioning by driving all
channels to 1/3 rated power. 25 oC. 10
Hz-80KHz Meas BW.
ACV=117VRMS, 60 Hz
W>100 >105
21 DYNAMIC POWER
OUTPUT YCD 1kHz 20 cycle burst- 480 msec off. Sweep ampl to reach clipping point. W>130 > 135
22
FREQUENCY RESPONSE (-
3dB) YAll Analog
Stereo and 6 CH
DIRECT Inputs Ref to 1W, 1KHz Hz 10 Hz-100 KHz 5 Hz-150 KHz
23 POWER BANDWIDTH -
3dB YCD THD 0.08% Hz~kHz 20-60Khz
24 SLEW RATE YCD 20 KHz Square Wave Drive unit to 40 Vpp. Mesure delta amplitude and delta time. Compute
V/usec V/usec >12 >13
25 SLEW-FACTOR Y
6 CH
DIRECT/ALL
STEREO
INPUTS
1 KHz reference
Volume at Max. Drive channel to R/O.
Then sweep frequency until finding 1 %
THD+N reading. Record frequency.
Ratio of freq @ 1 % THD+N / 20 KHz
is the Slew Factor
>5 >5.5
26 INPUT IMPEDANCE Y
6 CH
DIRECT/ALL
STEREO
INPUTS
1kHz kohm 47 Kohm
27 HEADPHONE OUTPUT YCD 1kHz Volume at Max mV 1.2 +/- 0.4 1.2 +/- 0.2
H/P = 32ohms (200)mV 1kHz mV
?
VIDEO SECTION
NO
DESCRIPTION
INPUT
FREQ.
REMARK
UNIT
LIMIT
NOMINAL
VIDEO
1OUTPUT LEVEL at 75ohms VCR1(1Vp-p) 1MHz Vp-p 1?.20 1?.10
2
FREQUENCY RESPONSE(-
3dB)
VCR1(1Vp-p)
Hz~MHz
DC~6 DC~6,3
3S/N RATIO VCR1(1Vp-p) 1MHz dB 40 45
4CROSSTALK VCR1(1Vp-p) 1MHz dB 40 45
S-VIDEO
1OUTPUT LEVEL at 75ohms
"Y" LEVEL VCR1(1Vp-p) 1MHz Vp-p 1 +/- 20mV 1 +/- 10mV
"C" LEVEL VCR1(0.286Vp-p) 1MHz 0.286 +/- 5mV 0.286 +/- 3mV
2
FREQUENCY RESPONSE (-
3dB)
VCR1(1Vp-p) Hz~MHz 5Hz~6.3Mhz DC-10Mhz
7

3S/N RATIO VCR1(1Vp-p) 1MHz dB 40 45
COMPONENT VIDEO
1OUTPUT LEVEL at 75ohms
"Y" LEVEL(GREEN) VCR1(1Vp-p) 1 +/- 20mV 1 +/- 10mV
"Cb" LEVE(BLUE) VCR1(0.678Vp-p) Vp-p 0.678+/-10mV 0.678+/-5mV
"Cr" LEVE(RED) VCR1(0.678Vp-p) 0.678+/-10mV 0.678+/-5mV
AVR7000 harman/kardon
8

TUNER Section
TUNER SECTION
Measuring methods in confirmity with IEC standard 315
Measurements condition FM : Radio frequency = 98.1MHz, Audio frequency = 1kHz
Reference level = 1mV on ( 75ohms , 300ohms )
Deviation : MONO = ?5kHz, Stereo = ?7.5kHz?.5kHz
MONO = ?0kHz, Stereo = ?0kHz?.5kHz
Test Point : TP 1 = 90.1MHz, TP 2 = 98.1MHz, TP 3 = 106.1MHz
Filter = B.P.F at STEREO
FM SECTION
NO
DESCRIPTION
UNIT
LIMIT L/R
NOMINAL L/R
MEAS.
NEEDED
*1TUNING RANGE LOW ~ HIGH MHz 87.5~107.9M
STEP AUTO/Man. kHz 100
*2USABLE SENSITIVITY TP 1 dBf > 17.2 > 14.2
S/N = (26,30)dB TP 2 dBf > 17.2 > 14.2
TP 3 dBf > 17.2 > 14.2
3FULL LIMITING SENSE OUTPUT = -3dB dBf > 15.2 > 12.2
*4AUTO STOP LEVEL dBf 33.2 +/- 6 33.2 +/- 5
*5AUTO SCAN ERROR kHz +/- 15/20 +/- 20/25
*6S/N RATIO MONO dB > 65 > 70
IHF-A FILTER STEREO dB > 63 > 68
*7TOTAL HARMONIC DISTORTION MONO % > 0.5 > 0.3
STEREO % > 0.8 > 0.5
8(50,46)dB QUIETING SENS. MONO dBf > 23.2 > 20.2
STEREO dBf > 48.3 > 45.3
*9CHANNEL SEPARATION 100Hz dB > 35 > 40
1kHz dB > 40 > 45
10kHz dB > 30 > 35
10 FREQUENCY RESPONSE AT ?1,-3dB Hz 20~15K 10~15.3K
11 SPURIOUS RESPONSE dB > 80 > 90
12 IF REJECTION TP 1 dB > 70 > 80
13 IMAGE REJECTION TP 3 dB > 65 > 70
14 AM REJECTION RATIO dB > 50 > 55
15 RF INTERMODULATION dB
16 CAPTURE RATIO dB > 25. > 2
17 ALTERNATIVE CH SELECTIVITY ?(400)kHz dB > 65 > 70
*19 OUPUT LEVEL MONO mV 500 +/- 150 500 +/- 100
AM SECTION
Measuring methods in confirmity with IEC standard 315
Measurements condition AM - MW : Radio frequency = 1000/999kHz, Audio frequency = 400Hz
LW : Radio frequency = 207kHz, Audio frequency = 400Hz
Reference level = 5mV/m,10mV/m on 50ohms
Modulation = 30%
Test Point : MW
TP1 = (600)kHz
TP2 = (1000)kHz
TP3 = (1400)kHz
LW TP1 = 162kHz, TP2 = 207kHz, TP3 = 252kHz
NO
DESCRIPTION
UNIT
LIMIT L/R
NOMINAL L/R
* 1 TUNING COVER RANGE LOW ~ HIGH MW kHz 520~1710
LW kHz
STEP AUTO/Man. kHz 10
* 2 USABLE SENSITIVITY MW TP 1 uV/m > 800 > 500
TP 2 uV/m > 800 > 500
S/N = 20dB TP 3 uV/m > 800 > 500
LW TP 1 uV/m
TP 2 uV/m
TP 3 uV/m
AVR7000 harman/kardon
9

TUNER Section
3 S/N RATIO MW dB > 40 > 45
INPUT=10mV/m LW dB
4 TOTAL HARMONIC DISTORTION % > 1.5 > 0.8
5 OVER LOAD DISTORTION 5mV 80% MOD % > 10 > 5
6 FREQUENCY RESPONSE at -6dB MW Hz 100~2K 80~2.3K
LW Hz
7 SELECTIVITY 10kHz/9kHz MW dB > 20 > 25
LW dB
8 AGC FIGURE OF MERIT INPUT 100mV dB > 50 > 55
9 IMAGE REJECTION MW = TP 3 dB > 30 > 35
LW = TP 3 dB
10 WHISTLE MODULATION 2IF%> 15 > 10
INPUT = 1mV/m 3IF%> 15 > 10
11 AUTO STOP LEVEL MW uV/m 800 (+/- 6dB) 800 (+/- 5dB)
LW uV/m
* 12 TUNED LEVEL MW uV/m 800 (+/- 6dB) 800 (+/- 5dB)
LW uV/m
* 13 OUTPUT LEVEL mV 120 +/- 40 120 +/- 30
10
