HK 3370
STEREO RECEIVER
Sonic purity beyond compare.
Harman Kardon pioneered the high-
fidelity stereo receiver more than forty-five
years ago, and we’ve never abandoned
the faith. As evidenced by the HK 3370,
which understands that “dancing lights”
are no substitute for technical substance.
This receiver houses a 2 x 70-watt,
high-current, ultrawide-bandwidth
amplifier in an elegantly simple package.
And with remote A/B speaker selection
and a Harman Kardon system remote,
as well as infrared extension jacks,
it’s one of the easiest to use receivers
we’ve ever offered. The HK 3370.
Where pure sonic enjoyment lives on.
high-current capability
ultrawide bandwidth
phono input
tape monitor loop
A/B speaker selection
subwoofer output

Harman Kardon is a registered trademark, and Power for the Digital Revolution is a trademark, of Harman Kardon, Inc. Part No.: HK3370PI2/01
HK 3370
STEREO RECEIVER
Specifications
• Continuous Average Power
(FTC): 70 watts x 2 @ 8 ohms
(20Hz –20kHz, <0.07% THD,
both channels driven); High-
Current Capability: ±42 amps
•Tuner –Usable Sensitivity: IHF
1.12µV/13.5dBf; THD at 1kHz
with 100% Modulation: (Mono)
0.3%, (Stereo) 0.4%; FM Adjacent
Channel Selectivity: ±400kHz, 65dB;
Ultimate (Maximum) S/N Ratio
(measured at 1mV RF Input Level):
(Mono) 73dB, (Stereo) 72dB
•General –Dimensions (H x W x D):
6-1/8" x 17-3/8" x 16-5/16"
(156mm x 442mm x 415mm);
Weight: 24.6 lb (11.2kg)
[NOTE: Depth measurement includes
knobs, buttons and terminal connections;
height measurement includes feet and
chassis.] All features and specifications
are subject to change without notice.
Features
70W x 2 Into 8 Ohms,
20Hz –20kHz at <0.07%
THD, Both Channels Driven
Simultaneously •High-Current
(±42 Amps) Capability
Amplifier •Ultrawide-Bandwidth
Amplifier Design •Five Audio
Inputs •High-Quality Phono
Input •Tape Monitor Loop •
Preamp Out/Main Amp Input
Jacks for Use With Outboard
Equalizers •Subwoofer
Output •Remote A/B Speaker
Switching •FM Stereo/FM/AM
Tuner With 30 Station
Presets and Direct-Access
Tuning •IR Remote Extension
Jacks •Harman Kardon
System Remote
