Harman JBL PARTYBOX ON-THE-GO User manual

PARTYBOX ON-THE-GO
OWNER’S MANUAL

22
IMPORTANT SAFETY INSTRUCTIONS
For all products:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not block any ventilation openings. Install this apparatus
in accordance with the manufacturer’s instructions.
6. Do not install this apparatus near any heat sources such as
radiators, heat registers, stoves or other apparatus (including
ampliers) that produce heat.
7. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and
a third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
8. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles and the point
where they exit from the apparatus.
9. Use only attachments/accessories specied by the
manufacturer.
10. Use only with the cart, stand, tripod, bracket or
table specied by the manufacturer or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination
to avoid injury from tip-over.
11. Unplug this apparatus during lightning storms or when
unused for long periods of time.
12. To disconnect this apparatus from the AC mains completely,
disconnect the power-supply cord plug from the AC
receptacle.
13. The mains plug of the power-supply cord shall remain readily
operable.
14. Do not expose batteries to excessive heat such as sunshine,
re or the like.
15. This apparatus is intended to be used only with the power
supply and/or charging cable provided by the manufacturer.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
THE LIGHTNING FLASH WITH AN ARROWHEAD SYMBOL,WITHIN AN
EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE
PRESENCE OF UNINSULATED "DANGEROUS VOLTAGE"WITHINTHE
PRODUCT'S ENCLOSURETHAT MAY BE OF SUFFICIENT MAGNITUDETO
CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS
INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE PRODUCT.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSETHIS
APPARATUS TO RAIN OR MOISTURE.
Caution FCC and IC statement for users (USA and
Canada only)
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
CAN ICES-3(B)/NMB-3(B)
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Caution: Changes or modications not expressly approved
by HARMAN could void the user’s authority to operate the
equipment.
For Products That Transmit RF Energy
FCC AND IC INFORMATION FOR USERS
This device complies with Part 15 of the FCC rules and Industry
Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause
harmful interference; and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
FCC/IC Radiation Exposure Statement
This equipment complies with FCC/IC RSS-102 radiation
exposure limits set forth for an uncontrolled environment.
FCC Caution:
High power radars are allocated as primary users of the 5.25 to
5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations
can cause interference with and/or damage this device. No
conguration controls are provided for this wireless equipment
allowing any change in the frequency of operations outside the
FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.

33
www.jbl.com
English
IC Caution:
User should also be advised that:
(i) The device for operation in the band 5150-5250 MHz is only
for indoor use to reduce the potential for harmful interference to
co-channel mobile satellite systems; (ii) the maximum antenna
gain permitted for devices in the bands 5250-5350 MHz and
5470-5725 MHz shall comply with the e.i.r.p. Limit: and (iii)
The maximum antenna gain permitted for devices in the band
5725-5825 MHz shall comply with the e.i.r.p. Limits specied for
point-to-point and non-point-to-point operation as appropriate.
(iv) Users should also be advised that high-power radars are
allocated as primary users (i.e. priority users) of the bands 5250-
5350 MHz and 5650-5850 MHz and that these radars could
cause interference and/or damage to LE-LAN devices.
Exposure of humans to RF fields (RSS-102)
The computers employ low gain integral antennas that do not
emit RF eld in excess of Health Canada limits for the general
population; consult Safety Code 6, obtainable from Health
Canada’s Website at http://www.hc-sc.gc.ca/
The radiated energy from the antennas connected to the wireless
adapters conforms to the IC limit of the RF exposure requirement
regarding IC RSS-102, Issue 5 clause 4. SAR tests are conducted
using recommended operating positions accepted by the FCC/
RSS with the device transmitting at its highest away from the
body. Non-compliance with the above restrictions may result in
a violation of FCC RF exposure guidelines.
Use Restriction: Attention in France, the operation is limited to
indoor use within the band 5150-5350 Mhz.
For Products with Radio Receivers That Can
Use an External Antenna (USA ONLY)
CATV (Cable TV) or Antenna Grounding
If an outside antenna or cable system is connected to this
product, be certain that it is grounded so as to provide some
protection against voltage surges and static charges. Section
810 of the National Electrical Code (NEC), ANSI/NFPA No. 700-
1984, provides information with respect to proper grounding of
the mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes
and requirements of the electrode.
Note to CATV System Installer
This reminder is provided to call the CATV(cable TV) system
installer’s attention to article 820-40 of the NEC, which provides
guidelines for proper grounding and, in particular, as close to the
point of cable entry as possible.
Caution: This product uses a laser system. To prevent direct
exposure to the laser, do not open the cabinet enclosure or defeat
any of the safety mechanisms provided for your protection. Do
NOT START INTO THE LASER BEAM. To ensure proper use of
this product, please read the owner’s manual carefully and retain
it for future use. Should the unit require maintenance or repair,
please contact your local JBL service. Refer servicing to qualied
personnel only.
FOR ALL EU COUNTRIES
For products that include audio out
Prevention of hearing loss
Caution: Permanent hearing loss may occur
if earphones or headphones are used at high
volume for prolonged periods of time.
For France, the products have been tested to
comply with Sound Pressure Level requirement
laid down in the applicable NF EN 50332 L.5232-1.
Note:
– To prevent possible hearing damage, do not listen to high volume
levels for long periods.
WEEE Notice
The Directive on Waste Electrical Equipment (WEEE), which
entered into force as European law on 14/02/2014, resulted in
a major change in the treatment of electrical equipment at end-
of-life.
The purpose of this Directive is, a rst priority, the prevention of
WEEE, and in addition, to promote the reuse, recycling and other
forms of recovery of such wastes as so as to reduce disposal.
The WEEE logo on the product or on its box indicating collection
for electrical and electronic equipment consists of the crossed-
out wheeled bin, as shown below.
This product must not be disposed of or dumped with
your other household waste. You are liable to dispose
of all your electronic or electrical waste equipment by
relocating over to the specied collection point for
recycling of such hazardous waste. Isolated collection
and proper recovery of your electronic and electrical waste
equipment at the time of disposal will allow us to help conserving
natural resources. Moreover, proper recycling, and collection
points, please contact your local city center, household waste
disposal service, shop from where you purchased the equipment,
or manufacturer of the equipment.
RoHS Compliance
This product is in compliance with Directive 2011/65/EU of the
European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical
and electronic equipment.

44
For All Products Except Those with Wireless
Operation
HARMAN International hereby declares that this equipment is in
compliance with EMC 2014/30/EU Directive, LVD 2014/35/EU
Directive. The declaration of conformity may be consulted in the
support section of our Web Site, accessible from www.jbl.com.
For All Products with Wireless Operation
HARMAN International hereby declares that this equipment
is in compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU. The declaration of
conformity may be consulted in the support section of our Web
Site, accessible from www.jbl.com.
For Products that includes Batteries
EU Batteries Directive 2013/56/EU
A new battery directive 2013/56/EU on Battery and Accumulator
replacing directive entered into force on the 01/07/2015. The
directive applies to all types of batteries and accumulator
(AA, AAA, button cells, rechargeable packs) including those
incorporated into appliances except for military, medical
and power tool applications. The directive sets out rules for
collection, treatment, recycling and disposal of batteries, and
aims to prohibit certain hazardous substances and to improve
environmental performance of batteries and all operators in the
supply chain.
Instructions for Users on Removal, Recycling and
Disposal of Batteries
The remove the batteries from your equipment or remote control,
reverse the procedure described in the owner’s manual for
inserting batteries. For products with a built-in battery that lasts
for the lifetime of the product, removal may not be possible for
the user. In this case, recycling or recovery, it becomes necessary
to replace such a battery, this procedure must be performed by
authorized services centers. In the European Union and other
locations, it is illegal to dispose of any battery with household
trash. All batteries must be disposed of in an environmentally
sound manner. Contact your local waste-management ofcials
for information regarding the environmentally sound collection,
recycling and disposal of used batteries.
WARNING: Danger of explosion if battery is incorrectly replaced.
To reduce risk of re or burns, don’t disassemble, crush,
puncture, short external contact, expose to temperature above
60°C (140°F), or dispose of in re or water. Replace only with
specied batteries. The symbol indicating ‘separate collection’
for all batteries and accumulators shall be crossed-out wheeled
bin shown below:
In case of batteries, accumulators and button cells containing
more than 0.0005 mercury, more than 0.002% cadmium or more
than 0.004% lead, shall be marked with the chemical symbol for
the metal concerned: Hg,Cd or Pb respectively. Please Refer to
the below symbol:
WARNING: DO NOT INGEST BATTERIES, CHEMICAL BURN
HAZARD [the remote supplied with] This product contains a coin/
button cell battery. If the coin/button cell battery is swallowed, it
can cause severe international burns in just 2 hours and can lead
to death. Keep new and used batteries away from children. If you
think batteries might have been swallowed or placed inside any
part of body, seek immediate medical attention.

55
www.jbl.com
English
9. SPECIFICATIONS 14
10. TROUBLESHOOTING 15
11. COMPLIANCE 15
12. TRADEMARK 16
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 2
1. INTRODUCTION 6
2. WHAT’S IN THE BOX 6
3. PRODUCT OVERVIEW 7
3.1 TOP PANEL 7
3.2 BACK PANEL 7
4. PLACEMENT 8
5. POWER ON 8
6. USING YOUR PARTYBOX 9
6.1 BLUETOOTH CONNECTION 9
6.2 USB CONNECTION 9
6.3 AUX CONNECTION 10
6.4 MUSIC CONTROL 10
6.5 MIXING SOUND WITH A MICROPHONE AND /
OR GUITAR 10
6.6 CHARGING YOUR MOBILE DEVICE 12
7. CARRYING YOUR PARTYBOX 12
8. ADVANCED USAGE 13
8.1 LIGHT EFFECT 13
8.2 TWS MODE 13
8.3 FACTORY RESET 13
8.4 IPX4 14

66
2. WHAT’S IN THE BOX
1
45
2 3
6
*
JBL PARTYBOX ON-THE-GO
Bluetooth
BASS
TREBLE
BASS
BOOST
1) Main unit
2) Wireless microphone (with two Alkaline AA batteries)*
3) Microphone pouch
4) Shoulder strap
5) Power cord*
6) Quick Start Guide, Safety Sheet, Warranty Card
*Power cord quantity, plug type and microphone quantity vary
by regions.
1. INTRODUCTION
Congratulations on your purchase! This manual includes
information about speakers. We
encourage you to take a few minutes to read this manual, which
describes the product and includes step-by-step instructions to
help you to set up and get started. Read and understand all the
safety instructions before using your product.
If you have any questions about these products, their installation
or their operation, please contact your retailer or customer
service, or visit us at www.jbl.com.

77
www.jbl.com
English
3. PRODUCT OVERVIEW
3.1 Top Panel
MIC2 /
GUITAR
BASS
TREBLE
BASS
BOOST
1011121315 1417 16
1 2 65 7 8 93 4
BASS
TREBLE
BASS
BOOST
1)
• Enhances the bass level: level 1, level 2, or off.
2) /
• Adjust main volume.
3) volume
• Adjust microphone volume (if connected).
4) volume
• Adjust guitar volume (if connected).
5)
• Turn the power on or off.
6)
• Battery level indicator
7)
• Press to switch between different light patterns.
8) Mobile device dock
9) Shoulder strap hooks
10) input
• : Connect to a guitar.
• : Adjust the guitar gain.
11)
• Press to enter Bluetooth pairing mode.
• Press and hold for more than 5 seconds to enter True
Wireless Stereo (TWS) pairing mode.
• Press and hold for more than 20 seconds to forget all
paired devices.
12)
• Adjust the bass level.
13)
• Adjust the treble level.
14) LED ring
15)
• Adjust the echo level.
16)
• Play, pause or resume.
17) MIC input
• Microphone socket: Connect to a microphone.
• : Adjust the microphone gain.
Caution:
– Do not look directly at the light-emitting parts when the speaker
lights are turned on.
LED behavior
Solid white Power on
Solid amber Standby
Off Power off
Flashing white
quickly Pairing
White (Constant) Connected
Off Not connected
Solid white On
Off Off
Flashing red
quickly Low battery
Flashing white
slowly Charging
Solid white
The speaker is fully
charged when all
the ve indicators
turn solid white.
3.2 Back Panel
2 31
1) (AC)
• Connect to AC power supply.
2) (USB)
• Connect to a USB storage device.
• Charge your mobile device.
3) (AUX)
• Connect to an external audio device through a 3.5 mm
audio cable (not supplied).

88
4. PLACEMENT
Caution:
– Do not sit on the speaker or push it. Otherwise, it may result in
malfunction and cause personal injury and /or property damage.
Place the speaker on a at, stable surface and ensure that the
rubber feet side is down.
5. POWER ON
Cautions:
– Use the provided power cord only.
– You can use either AC power or the built-in battery as power
supply to the speaker.
2
1
OFF
ON
<15%
15% - 80%
>80%
1. Connect AC power.
• To use the built-in battery, disconnect AC power after
charging the speaker.
2. Press to power on.
Tips:
– Fully charge the speaker before rst-time use to prolong the
lifespan of the built-in battery.
– To protect battery lifespan, fully charge at least once every
3 months. Battery life will vary due to usage patterns and
environmental conditions.
– You can check the battery level by pressing any button on the
speaker.
– The speaker switches to standby mode automatically after 20
minutes of inactivity. You can press on the speaker to switch to
normal operation.

99
www.jbl.com
English
6. USING YOUR PARTYBOX
Notes:
– Only one sound source can be played at a time. The priority order
is USB -> Bluetooth -> AUX.
– Starting a source with higher priority will always interrupt a source
with lower priority.
– To start a source with lower priority, stop the source with higher
priority rst.
6.1 Bluetooth Connection
You can use the speaker with your Bluetooth enabled smartphone
or tablet.
x 1
BASS
TREBLE
BASS
BOOST
DEVICES
JBL PARTYBOX ON-THE-GO
Bluetooth
Bluetooth
2
< 10 m (33 ft)
1
1. Press on the speaker to enter Bluetooth pairing mode.
2. Choose “ ” on your Bluetooth
device to connect.
3. Once successfully connected, you can stream audio from
your Bluetooth device to this speaker.
Notes:
– This speaker can memorize a maximum of 8 paired devices. The
ninth paired device will replace the rst one.
– Enter “0000” if a PIN code is requested for connection to a
Bluetooth device.
– Bluetooth performance can be affected by the distance between
this product and your Bluetooth device and the environment of
operation.
To terminate the Bluetooth-enabled device:
• Turn off this speaker, or
• Disable Bluetooth on your device.
To reconnect the Bluetooth enabled device:
• When you turn on this speaker next time, it tries to reconnect
the last connected device automatically.
• If not, manually select “ ” on
your Bluetooth device to connect.
6.2 USB Connection
BASS
BOOST
Plug a USB storage device that contains playable audio contents
into the USB port of the speaker.
JAudio playback will start automatically.
Tip:
– The speaker plays audio les on the USB storage device from the
root folder to the last level of subfolders in alphabetical sequence.
Up to 8 levels of subfolders are supported.
Supported audio formats
Extension Codec Sample rate Bitrate
WAVE PCM 44.1KHz ~ 192KHz < 5Mbps
LPCM 44.1KHz ~ 192KHz < 5Mbps
IMA_
ADPCM
44.1KHz ~ 192KHz < 5Mbps
MPEG 44.1KHz ~ 192KHz < 5Mbps
MULAW 44.1KHz ~ 192KHz < 5Mbps
MP3 MPEG1
layer1/2/3
32KHz ~ 48KHz 32Kbps ~
320Kbps
MPEG2
layer1/2/3
16KHz ~ 24KHz 8Kbps ~
160Kbps
MPEG2.5
layer3
8KHz ~12KHz 8Kbps ~
160Kbps
WMA ≤ 320Kbps 8Kbps ~
48Kbps

1010
6.3 AUX Connection
1
1. Connect an external audio device to the speaker through a
3.5 mm audio cable (not supplied).
2. Start audio playback on the external device.
6.4 Music Control
BASS
TREBLE
BASS
BOOST
x 1
x 1
x 1
x 2
x 3
x 1
1
2
• Press once to pause or resume playback.
• Press twice to skip to the next track.
• Press three times to skip to the previous track.
• Press +/- to increase or decrease main volume.
• Hold the +and -buttons simultaneously to mute or unmute sound
output.
Note:
– The skip operation is unavailable in AUX mode.
6.5 Mixing Sound with a Microphone and /
or Guitar
By using a microphone or electric guitar (not supplied), you can
mix sound with an audio source.
Notes:
– Always set the guitar or microphone volume to the minimum level
before guitar or microphone connection / disconnection.
– Always disconnect the guitar or microphone when you are not
using them.

1111
www.jbl.com
English
6.5.1 Connecting a Microphone
To connect the supplied wireless microphone
By default, the wireless microphone comes pre-paired with the
speaker at factory.
GUITAR
BASS
TREBLEECHO
GUITAR
MIC
MIC
BASS
BOOST
2
1
CH1 CH2... CH6
x 1
< 10 m (33 ft)
1. Load the two Alkaline AA batteries with correct polarity.
2. Turn on the speaker and supplied wireless microphone
successively.
JWireless connection will be set up automatically.
Notes:
– The microphone powers off automatically after 10 minutes of
inactivity.
– A maximum of two wireless microphones are supported. Contact
your dealer for how to purchase more.
To connect a wired microphone (not supplied)
BASS
TREBLE
BASS
BOOST
To connect a new wireless microphone
1. Turn off the speaker.
2. Turn on the new wireless microphone and place it on the top
of the speaker.
3. Turn on the speaker.
JThe microphone will pair and connect with the speaker
automatically within 3 minutes.
To replace wireless microphone batteries
Cautions:
– Do not mix batteries (old and new or carbon and alkaline, etc.).
– Remove batteries if they are exhausted or if the microphone is not
to be used for a long time.
– Batteries contain chemical substances, they should be disposed of
properly.
1. Check the battery level.
100%
<5%
2. If the battery level is low, replace the old batteries with new
ones.

1212
6.5.2 Connecting a Guitar
MIC2 /
GUITAR
BASS
TREBLE
BASS
BOOST
6.5.3 Mixing Sound
Sing through the microphone or play guitar.
• To adjust the volume of the audio source, press .
• To adjust the volume of the microphone or guitar, rotate the
or volume knob.
• To adjust the gain of the wired microphone or guitar, rotate
the control beside the or
socket respectively.
• To adjust the echo, treble and bass level of the microphone
(either wireless or wired), rotate the , and
knob respectively.
6.6 Charging Your Mobile Device
BASS
TREBLE
7. CARRYING YOUR PARTYBOX
Cautions:
– Before carrying the speaker, ensure that all the cords are
disconnected.
– To avoid personal injury and/or property damage, hold the product
rmly while carrying, and while it is not being used, remove the
strap.
1
2
Use the supplied shoulder strap to carry the speaker on the go.

1313
www.jbl.com
English
8. ADVANCED USAGE
8.1 Light Effect
x 1
Press to select your preferred light effect: rock, neon, club,
or off.
8.2 TWS Mode
You can connect two PARTYBOX speakers to each other via
TWS mode.
12
2S
ON
BASS
TREBLE
BASS
BOOST
< 10 m (33 ft)
5S
1
2
BASS
TREBLE
BASS
BOOST
5S
Hold on both speakers simultaneously for more than 5 seconds.
To exit TWS mode:
Power off or hold on either speaker for more than 5 seconds.
Tips:
– It may be necessary to forget the PARTYBOX on the source device
in order to reconnect to Bluetooth.
– By default, the speaker connected to your Bluetooth device acts as
the primary speaker (left channel), while the other one acts as the
secondary speaker (right channel).
8.3 Factory reset
To restore the factory settings, hold and for more than 10
seconds.

1414
9. SPECIFICATIONS
Product name:
AC power input: 100 - 240 V ~ 50/60 Hz
Built-in Battery: 18 Wh
Power consumption: 60 W
Total output power: 100 W RMS (AC powered)
50 W RMS (battery powered)
Standby power
consumption:
< 2 W with Bluetooth
connection;
< 0.5 W without Bluetooth
connection
USB output: 5 V 2.1 A
Speaker drivers: 1 x 5.25 in (133 mm) woofers +
2 x1.75 in (44 mm) tweeters
Signal-to-noise (S/N) ratio: > 80 dBA
Frequency response: 50 Hz - 20 kHz
Battery charge time: < 3.5 hrs
Battery play time: > 6 hrs
Bluetooth version: 4.2
Bluetooth prole: A2DP v1.3, AVRCP v1.6
Bluetooth transmitter
frequency range: 2.4 - 2.48 GHz
Bluetooth maximum
transmitter power: 10 dBm (EIRP)
Bluetooth transmitter
modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth range: Approx. 10 m (33 ft)
USB format: FAT 16, FAT 32
USB le format: .mp3, .wma, .wav
Digital input: Bluetooth / USB -9 dBFS
Input sensitivity: AUX in: 370 mV rms
Microphone: 20 mV
Guitar: 100 mV
Product Dimension
(W x H x D):
490 x 245 x 228 mm /
19.3 x 9.6 x 9.0 in
Net weight: 7.5 kg / 16.5 lbs
Wireless microphone spec
Frequency response: 65 Hz - 15 kHz
Signal-to-noise (S/N) ratio: > 60 dBA
UHF frequency band: 470 ~ 960 MHz (depends on
SKU) (EU 657 ~ 662 MHz)
Transmitter transmitting
power: < 10 mW
Microphone battery play
time: < 10 hrs
Distance between
transmitter and receiver: < 10 m
8.4 IPX4
Caution:
– Always keep the charging port dry before connecting AC power.
– To ensure splash resistance, always keep the protective covers
closed securely.
The speaker is IPX4 splash resistant.
x 1

1515
www.jbl.com
English
11. COMPLIANCE
The product is in compliance with the European Union energy
legislation.
Bluetooth connection mode
The product is intended to be used for streaming music via
Bluetooth connection. A consumer can stream Bluetooth
audio to the speaker. When the product is connected through
Bluetooth, the Bluetooth connection must remain active at all
times to ensure proper operation.
The product will enter sleep mode (networked standby) after
20 minutes without operation. The power consumption in sleep
mode is less than 2.0 Watts, after which it can be re-activated
via Bluetooth connection.
Bluetooth disconnection mode
The product will enter standby mode after 20 minutes without
operation. The power consumption in standby mode is less than
0.5 Watts.
10. TROUBLESHOOTING
Caution:
– Never try to repair the product by yourself. If you have any
problems while using this product, check the following points
before you request service.
System
The speaker will not turn on.
• Ensure that the speaker battery is not drained. If not, use the
AC power instead.
No response from some buttons
• The product may be in demo mode. In demo mode, all the
input sources and buttons except / / / / are
disabled. Hold and simultaneously for more than 5
seconds to exit demo mode.
Sound
No sound from the speaker.
• Ensure that the speaker is powered on.
• Adjust volume.
• Ensure that a sound source is active and not muted.
Bluetooth
A device cannot connect with the speaker.
• Ensure that the Bluetooth function of the device is enabled.
• The speaker is already connected with another Bluetooth
device. Hold on the speaker for more than 20 seconds to
disconnect and pair with a new device.
Poor audio quality from a connected Bluetooth
device
• The Bluetooth reception is poor. Move the device closer to
the speaker, or remove any obstacle between the device and
speaker.
Wireless microphone
No response from the microphone.
• Power on the microphone.
• Replace batteries if the battery level is low.
• Pair the microphone with the speaker manually (see 6.5.1
Connecting a Microphone).

1616
Este produto está homologado pela Anatel, de acordo com os
procedimentos regulamentados para avaliação da conformidade
de produtos para telecomunicações e atende aos requisitos
técnicos aplicados.
Para maiores informações, consulte o site da Anatel –
www.anatel.gov.br
Este equipamento não tem direito à proteção contra interferência
prejudicial e não pode causar interferência em sistemas
devidamente autorizados.
12. TRADEMARK
The Bluetooth®word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
HARMAN International Industries, Incorporated is under license.
Other trademarks and trade names are those of their respective
owners.

Торговая марка: JBL
Назначение товара: Активная акустическая система
Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит
400, офис 1500
Страна происхождения: Китай
Импортер в Россию: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к 1
Гарантийный период: 1 год
Информация о сервисных центрах: www.harman.com/ru тел. [phone]
Срок службы: 5 лет
Товар сертифицирован
Дата производства: Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы
символов серийного номера изделия, следующих после разделительного знака «-». Кодировка
соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000, где
«M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства (A - 2010, B -
2011, C - 2012 и т.д.).
Используйте устройство только по прямому назначению в соответствии с предоставленной инструкцией. Не пытайтесь самостоятельно
вскрывать корпус товара и осуществлять ремонт. В случае обнаружения недостатков или дефектов, обращайтесь за гарантийным
обслуживанием в соответствии с информацией из гарантийного талона. Особые условия хранения, реализации и (или) транспортировки
не предусмотрены. Избегайте воздействия экстремальных температур, долговременного воздействия влаги, сильных магнитных полей.
Устройство предназначено для работы в жилых зонах. Срок годности не ограничен при соблюдении условий хранения. Пожалуйста, не
утилизируйте устройства с литий-ионными аккумуляторами вместе с бытовыми отходами.
HARMAN International Industries,
Incorporated 8500 Balboa
Boulevard, Northridge, CA 91329
USA
www.jbl.com
© 2020 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark
of HARMAN International Industries, Incorporated, registered in the United States and/or other
countries. Features, specications and appearance are subject to change without notice.
