Harman AMX DVX Series User manual

AV FOR AN IT WORLD
INSTRUCTION MANUAL
DVX
ALL-IN-ONE PRESENTATION SWITCHERS
DVX-3266-4K
DVX-2265-4K

Important Safety Instructions
READ these instructions.
KEEP these instructions.
HEED all warnings.
FOLLOW all instructions.
DO NOT use this apparatus near water.
CLEAN ONLY with dry cloth.
DO NOT block any ventilation openings. Install in accordance with the manufacturer's instructions.
DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
The wider blade or the third prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
ONLY USE attachments/accessories specified by the manufacturer.
USE ONLY with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
UNPLUG this apparatus during lightning storms or when unused for long periods of time.
REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Use the mains plug to disconnect the apparatus from the mains.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOSITURE.
DO NOT EXPOSE THIS APPARATUS TO DRIPPING OR SPLASHING AND ENSURE THAT NO OBJECTS FILLED
WITH LIQUIDS, SUCH AS VASES, ARE PLACED ON THIS APPARATUS.
THE MAINS PLUG OF THE POWER SUPPLIER CORD SHALL REMAIN READILY OPERABLE.

TO PREVENT ELECTRIC SHOCK DO NOT REMOVE TOP COVER. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
TO COMPLETELY DISCONNECT THIS APPARATUS FROM THE AC MAINS. DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE. THE MAINS PLUG OF THE POWER
SUPPLY CORD SHALL REMAIN READILY OPERABLE.
WATCH FOR THESE SYMBOLS:
The exclamation point triangle is used to alert the user to important operating or maintenance
instructions.
The lightning bolt triangle is used to alert the user to the risk of electrical shock。
ESD Warning: The icon to the left indicates text regarding potential danger associated with the
discharge of static electricity from an outside source (such as human hands) into an integrated circuit, often
resulting in damage to the circuit.
WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture.
WARNING: No naked flame sources – such as lighted candles – should be placed on the product.
WARNING: Equipment shall be connected to a MAINS socket outlet with a protective earthing connection.
6. Clean this apparatus
only with dry cloth.
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
3. To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.

WARNING: This product is intended to be operated ONLY from the voltages listed on the back panel or the
recommended, or included, power supply of the product. Operation from other voltages other than those
indicated may cause irreversible damage to the product and void the products warranty. The use of AC
Plug Adapters is cautioned because it can allow the product to be plugged into voltages in which the
product was not designed to operate. If you are unsure of the correct operational voltage, please contact
your local distributor and/or retailer. If the product is equipped with a detachable power cord, use only the
type provided, or specified, by the manufacturer or your local distributor.
WARNING: Do Not Open! Risk of Electrical Shock.
Voltages in this equipment are hazardous to life. No
user-serviceable parts inside. Refer all servicing to qualified
service personnel.
MAGNETIC FIELD
CAUTION! Do not locate sensitive high-gain equipment such as preamplifiers or tape decks directly above
or below the units. Because this amplifier has a high-power density, it has a strong magnetic field which can
induce hum into unshielded devices that are located nearby. The field is strongest just above and below the
unit.
If an equipment rack is used, we recommend locating the amplifier(s) in the bottom of the rack and the
preamplifier or other sensitive equipment at the top.
WEEE Notice
The Directive on Waste Electrical and Electronic Equipment (WEEE), which entered into force as European
law on 14/02/2014, resulted in a major change in the treatment of electrical equipment at end-of-life.
The purpose of this Directive is, as a first priority, the prevention of WEEE, and in addition, to promote the
reuse, recycling and other forms of recovery of such wastes so as to reduce disposal. The WEEE logo on the
product or on its box indicating collection for electrical and electronic equipment consists of the
crossed-out wheeled bin, as shown below.
This product must not be disposed of or dumped with your other household waste. You are liable for the
disposal of all your electronic or electrical waste equipment by relocating over to the specified collection
point for recycling of such hazardous waste. Isolated collection and proper recovery of your electronic and
electrical waste equipment at the time of disposal will allow us to help conserving natural resources.
Moreover, proper recycling of the electronic and electrical waste equipment will ensure safety of human
health and environment. For more information about electronic and electrical waste equipment disposal,
recovery, and collection points, please contact your local city center, household waste disposal service, shop
from where you purchased the equipment, or manufacturer of the equipment.
RoHS Compliance
This product is in compliance with Directive 2011/65/EU and (EU) 2015/863 of the European Parliament and
of the Council of 31/03/2015 on the restriction of the use of certain hazardous substances in electrical and
electronic equipment.

REACH
REACH (Regulation No 1907/2006) addresses the production and use of chemical substances and their
potential impacts on human health and the environment. Article 33 (1) of REACH Regulation requires
suppliers to inform the recipients if an article contains more than 0.1% (per weight per article) of any
substance(s) on the Substances of Very High Concern (SVHC) Candidate List (‘REACH candidate list’).
This product contains the substance ‘’lead’’ (CAS-No. 7439-92-1) in a concentration of more than
0.1% per weight.
At the time of release of this product, except for the lead substance, no other substances of REACH
candidate list are contained in a concentration of more than 0.1% per weight in this product.
Note: on June 27, 2018, lead was added to the REACH candidate list. The inclusion of lead in the REACH
candidate list does not mean that lead-containing materials pose an immediate risk or results in a
restriction of permissibility of its use.
CAUTION FCC AND IC STATEMENT FOR USERS (USA AND CANADA ONLY)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAN ICES-3 (B)/NMB-3(B)
FCC SDOC SUPPLIER’S DECLARATION OF CONFORMITY
HARMAN International hereby declares that this equipment is in compliance with the FCC part 15 Subpart
B.
The declaration of conformity may be consulted in the support section of our web site, accessible from www.
AMX.com.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures;
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by Harman could void the user’s authority to
operate the equipment .

1
CONTENTS
INTRODUCTION .................................................................................................................................................................................. 3
OVERVIEW...............................................................................................................................................................................................................3
COMMON APPLICATION ..............................................................................................................................................................................3
AUDIO PROCESSING .......................................................................................................................................................................................3
INTEGRATED CONTROL.................................................................................................................................................................................3
BATTERY LIFE......................................................................................................................................................................................................3
FEATURES ................................................................................................................................................................................................................4
PACKAGE CONTENTS .........................................................................................................................................................................................4
SPECIFICATIONS ...................................................................................................................................................................................................5
TRANSMISSION DISTANCE...........................................................................................................................................................................7
INSTALLATION .................................................................................................................................................................................... 8
WIRING AND DEVICE CONNECTORS ............................................................................................................................................ 9
OVERVIEW...............................................................................................................................................................................................................9
FRONT PANEL CONTROLS AND INDICATORS....................................................................................................................................... 10
LEDS ................................................................................................................................................................................................................... 10
LCD DISPLAYS................................................................................................................................................................................................. 11
TAKE PUSHBUTTON ..................................................................................................................................................................................... 11
VIDEO MENU PUSHBUTTON..................................................................................................................................................................... 11
AUDIO MENU PUSHBUTTON.................................................................................................................................................................... 12
NAVIGATION PUSHBUTTONS .................................................................................................................................................................. 12
STATUS PUSHBUTTON ................................................................................................................................................................................ 13
EXIT PUSHBUTTON ....................................................................................................................................................................................... 13
VIDEO/AUDIO MUTE PUSHBUTTONS.................................................................................................................................................... 13
PROGRAM PORT............................................................................................................................................................................................ 13
USB PORT ......................................................................................................................................................................................................... 14
REAR PANEL AUDIO INPUTS AND AUDIO OUTPUTS .......................................................................................................................... 14
AUDIO INPUTS ............................................................................................................................................................................................... 14
HDMI INPUTS.................................................................................................................................................................................................. 15
MIC/LINE INPUTS........................................................................................................................................................................................... 15
AMP OUTPUTS ............................................................................................................................................................................................... 16
AUDIO OUTPUTS ........................................................................................................................................................................................... 17
DANTE INPUTS/OUTPUTS.......................................................................................................................................................................... 17
REAR PANEL VIDEO INPUTS AND OUTPUTS .......................................................................................................................................... 18
HDMI INPUTS.................................................................................................................................................................................................. 18
DXLINK INPUTS .............................................................................................................................................................................................. 19
DXLINK/HDMI OUTPUTS ............................................................................................................................................................................ 19
TWISTED PAIR CABLE PINOUTS ............................................................................................................................................................... 20
IMPORTANT TWISTED PAIR CABLING REQUIREMENTS AND RECOMMENDATIONS.......................................................... 20
REAR PANEL CONTROL AND POWER ....................................................................................................................................................... 20
RS232 PORTS .................................................................................................................................................................................................. 20
RELAY PORTS .................................................................................................................................................................................................. 21
I/O PORTS ........................................................................................................................................................................................................ 21
IR/SERIAL PORT: CONNECTION AND WIRING ................................................................................................................................... 21
CONFIGURATION DIP SWITCH................................................................................................................................................................. 22

2
ICS LAN PORT................................................................................................................................................................................................. 22
USB PORT ......................................................................................................................................................................................................... 23
USB A/B PORTS .............................................................................................................................................................................................. 23
ID PUSHBUTTON ........................................................................................................................................................................................... 24
LAN 100/1000................................................................................................................................................................................................. 24
POWER CONNECTOR .................................................................................................................................................................................. 25
AUDIO/VIDEO CONFIGURATIONS ............................................................................................................................................... 26
OVERVIEW............................................................................................................................................................................................................ 26
USING THE FRONT PANEL BUTTONS ........................................................................................................................................................ 26
VIDEO SETTINGS............................................................................................................................................................................................ 26
AUDIO SETTINGS........................................................................................................................................................................................... 28
SWITCH MENU ............................................................................................................................................................................................... 31
STATUS MENU................................................................................................................................................................................................ 31
DVX WEBCONSOLE .......................................................................................................................................................................................... 32
ACCESSING THE WEBCONSOLE .............................................................................................................................................................. 32
MASTER CONTROLLER CONFIGURATION OPTIONS ....................................................................................................................... 33
USING A WEB BROWSER ............................................................................................................................................................................ 34
FIRMWARE UPGRADE ..................................................................................................................................................................... 49
BEFORE YOU START.......................................................................................................................................................................................... 49
REQUIRED ORDER OF FIRMWARE UPDATES FOR DVX CONTROLLERS........................................................................................ 49
SENDING FIRMWARE (*.KIT) FILES TO THE DVX .................................................................................................................................... 49
PROGRAMMING.................................................................................................................................................................................. 50
OVERVIEW............................................................................................................................................................................................................ 50
NETLINX CHANNELS ........................................................................................................................................................................................ 50
NETLINX LEVELS................................................................................................................................................................................................. 51
PORT FUNCTIONALITY MAPPING ............................................................................................................................................................... 52
SEND_COMMANDS .......................................................................................................................................................................................... 54
WARRANTY TERMS AND CONDITIONS ...................................................................................................................................134

3
Introduction
Overview
The All-In-One Presentation Switchers combine all of the components you need to control/automate any
environment into a simple, flexible, comprehensive solution including control, analog and digital
audio/video inputs, audio and video switching, video scaling, local and remote distribution, plus audio
mixing, and amplification - all in a single box.
The All-in-One Presentation Switchers covered in this manual include:
All-in-One Presentation Switchers
Name
Description
DVX-3266-4K
8 x 4 All-In-One Digital Video Presentation Switcher
DVX-2265-4K
6 x 2 All-In-One Digital Video Presentation Switcher
Common Application
Enova DVX All-in-One Presentation Switchers are ideal solutions when used to simplify A/V control and
distribution in sophisticated presentation environments and conference rooms, including those supporting
audio and video conferencing. It also fits well in classrooms and auditoriums that need multiple displays, or
video previewing.
Audio Processing
Enova DVX All-in-One Presentation Switchers feature built-in audio mixing and equalization for four
independent, assignable audio output groups to accommodate the size, furnishings, surfaces, and
functional requirements in every room. The amplified audio output, two-line level audio outputs, 4 stereo
Dante audio outputs and all HDMI audio outputs can be assigned individually to any of the four audio
output groups. The amplifier outputs two channels at 120 Watts each into 8-ohms or 120 Watts into a
single mono channel at 70 or 100 Volts.
Integrated Control
The Enova DVX-3266-4K and DVX-2265-4K have built-in NX-Series NetLinx Integrated Controllers. All DVX
models include two (2) RS-232 ports, two (2) IR/Serial ports, two (2) Digital I/O ports and two (2) relay ports
for control of third-party equipment. All DVX models also include a front control panel for an added level of
convenience.
Battery Life
Enova DVX-3266-4K and DVX-2265-4K All-in-One Presentation Switchers use a combination lithium battery
and clock crystal package. The battery is a commonly available CR2032 lithium battery. The battery has an
average shelf life of 10 years. In normal use, the time will be shorter than the average shelf life depending
on the amount of time the unit has no external power for the clock circuit.
Typical useful life of the battery is 8 years under the specified temperature range. (see Operating
Environment in the Specifications table for each type of DVX in next two chapters for more information.)

4
Features
Video/Audio matrix switcher;
Built in NetLinx Master Controller;
Built-in scalers;
Supports HDMI 2.0 with resolution up to 4K@60Hz 4:4:4 In/Out;
Supports HDCP 2.2;
Supports HDR when scaler is in bypass mode;
Supports audio breakaway and embedding, audio DSP, mic mixer, 120W amplifier, Dante inputs and
outputs
Supports multiple control methods such as Front Panel buttons, ICSP Commands and mobile-friendly
web interface.
Package Contents
The following items are included with the DVX-3266-4K:
[1] DVX-3266-4K
[1] AC Power Cord with US Pins
[1] AC Power Cord with UK Pins
[1] AC Power Cord with EU Pins
[8] 3-Pin, 3.5mm Phoenix Male Connector
[3] 4-Pin, 3.5mm Phoenix Male Connector
[4] 5-Pin, 3.5mm Phoenix Male Connector
[1] 3-Pin, 5.08mm Phoenix Male Connector
[1] 4-Pin, 5.08mm Phoenix Male Connector
[2] IR Emitters
[2] Front Rack Mounting Brackets (Attached)
[4] Rubber Feet (Attached)
[1] Quick Start Guide
The following items are included with the DVX-2265-4K:
[1] DVX-2265-4K
[1] AC Power Cord with US Pins
[1] AC Power Cord with UK Pins
[1] AC Power Cord with EU Pins
[8] 3-Pin, 3.5mm Phoenix Male Connector
[3] 4-Pin, 3.5mm Phoenix Male Connector
[4] 5-Pin, 3.5mm Phoenix Male Connector
[1] 3-Pin, 5.08mm Phoenix Male Connector
[1] 4-Pin, 5.08mm Phoenix Male Connector
[2] IR Emitters
[2] Front Rack Mounting Brackets (Attached)
[4] Rubber Feet (Attached)
[1] Quick Start Guide

5
Specifications
The following table lists the specifications for the Enova DVX-3266-4K/DVX-2265-4K All-in-One
Presentation Switchers:
Specifications
Power
AC 100-240V 50/60Hz, 10A
Power Consumption
DVX-3266-4K: 90 Watts typical without amplifier, 130 Watts typical average
with amplifier
DVX-2265-4K: 63 Watts typical without amplifier, 103 Watts typical average
with amplifier
Memory
NVRAM: 1 MB
Memory Card: 16 GB SD
DDRAM: 512MB
Note: Supports external USB Solid State Drive
Front Panel Components
PROGRAM (To PC) Port
1 Type-B USB port. Connect to a USB port on a PC and access the NetLinx
Studio program for controller configuration
USB Port:
1 Type-A USB port for connecting a mass storage device for loading .tkn files,
reading or writing configuration files and log files, or updating the firmware
on the unit.
LEDs
LINK/ACT LED: On indicates that the Ethernet cables are connected and
terminated correctly, and blinking indicates receiving Ethernet data
packets.

STATUS LED: Blinking indicates that the system is programmed and
communicating properly.
OUTPUT LED: Blinking indicates that the Controller is transmitting data.
INPUT LED: Blinking indicates that the Controller is receiving data.
ICSLAN LED: Blinking when the category cable to port 1 is connected and
terminated correctly.
SERIAL LEDs: Two set of LEDs indicate that the RS-232 port (1-
2) is
transmitting or receiving data.

IR/SERIAL LEDs: Two LEDs, On indicates that IR/SERIAL channels are
transmitting control data on Port (11-12).
RELAY LEDs: Two LEDs, On indicates that relay channels are active on Port
(21).
I/O LEDs: On indicates that I/O channels are active on Port (22).
LCD Displays
Liquid crystal display (2 lines with 20 characters per line) indicates current
volume level and displays the Video, Audio, and Status menus.
SWITCH Pushbutton
Press to access the Switch menu on the LCD display. Use the menu to choose
to switch audio, video or both from any input to any output.
TAKE Pushbutton
While in the Switch menu, press to implement an audio/video switch.
V
IDEO MENU
Pushbutton
Press to access the Video menu on the LCD display. There are two video
menus (VIDEO OUTPUT and VIDEO INPUT) and both are accessible by using
this button. Multiple presses cycle through the various VIDEO menus.
A
UDIO MENU
Pushbutton
Press to access the Audio menu on the LCD display. There are three audio
menus (AUDIO OUTPUT, AUDIO INPUT, and MIC) and all are accessible by
using this button. Multiple presses cycle through the various AUDIO menus.
Navigational
Pushbuttons
4 directional buttons for navigating the options in the Switch, Video, Audio,
and Status menus (on the LCD display).
VIDEO MUTE Pushbutton
Press to mute/un-mute (enable/disable) all video output displays.
Video Mute results in a blank screen on the output displays.
AUDIO MUTE
Pushbutton
Press to mute/un-mute all audio outputs. The Pushbuttons light to indicate
that Video muting is active.
STATUS Pushbutton
Press to access the STATUS menu on the LCD display on which you can view
system status and other system information.
EXIT Pushbutton
Press to exit the current menu and return to the default menu page, Main Amp
Output/Volume.
Rear Panel Components
HDMI INPUTs
4 HDMI Type-A Female Connector. Connect to HDMI Sources.
DXLINK INPUTs
DVX-3266-4K: 4 RJ-45 inputs provide support for digital video, audio,
Ethernet, bi-
directional control, USB, and power over Category Cable
from any DXLink transmitter.
DVX-2265-4K: 2 RJ-45 inputs
provide support for digital video, audio,
Ethernet, bi-
directional control, USB, and power over Category Cable
from any DXLink transmitter.
HDMI OUTPUTs
DVX-3266-4K: 4 HDMI Type-A Female Connector. Connect to HDMI
displays.
DVX-2265-4K: 2 HDMI Type-
A Female Connector. Connect to HDMI
displays.

6
Specifications
DXLINK OUTPUTs
DVX-3266-4K: 2 RJ-45 outputs provide digital video, audio, Ethernet,
bi-directional control, USB, and power over Twisted Pair Cable to DXLink
Receivers.
DVX-2265-4K: 1 RJ-
45 outputs provide digital video, audio, Ethernet,
bi-directional control, USB, and power over Twisted Pair Cable to DXLink
Receivers.
USB A/B Ports
DVX-3266-4K: 6 USB-Mini-AB multi-use Connectors to allow the
connected endpoints device to pass through USB 2.0 Host/Device control
over the corresponding HDBT connection.
DVX-2265-4K: 3 USB-Mini-AB multi-
use Connectors to allow the
connected endpoints device to pass through USB 2.0 Host/Device control
over the corresponding HDBT connection.
RS-232 Port
2 3.5mm Pluggable Phoenix Terminal Block. Bi-directional RS-232,
300-115,200 baud.
CONFIG
DIP Switch allows for certain operations to occur during boot-time. (see the
Configuration DIP Switch section on page 22 for more information.)
USB A Port
1 Type-A USB port for connecting a mass storage device for loading .tkn files,
reading or writing configuration files and log files, or updating the firmware
on the unit.
ICSLAN Port
1 RJ-45 connector for ICSLAN interface.
LAN 100/1000 Port
1 RJ-45 connector provides TCP/IP communication at up to 1000 Mbps.
AUDIO INPUTs
2 3.5mm 5-pin captive-wire connector provides for fixed or variable, balanced
or unbalanced line-level audio inputs.
MIC/LINE INPUTs
6 3.5mm 3-pin captive-wire connectors receive up to 6 mono microphones
(balanced or unbalanced audio and switchable Phantom Power).
AUDIO OUTPUTs
2 3.5mm 5-pin captive-wire connector provides for balanced or unbalanced,
mono or stereo line-level audio output.
AMP OUTPUTs
Connect to integrated Crown DriveCore Amplifier. 8 Ohm stereo / 70 V / 100 V
mono selectable amplifier. 2 x 120W into 8 Ohms Class D stereo amplifier, 70
V or 100 V at 120W amplified variable mono audio.
DANTE Ports
2 RJ-45 connector, 2-port 1 Gbps Ethernet switch to Dante/AES67 Interface.
100m/328ft on Category 5 (100Mbps) or Category 5e/Category 6 (Gigabit)
cable between devices
POWER Connector
IEC Power cord connector: ~100-240V AC, 50/60Hz, 10A
Operating Environment
Operation Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -20°C to 70°C (4°F to 158°F)
Humidity: 5% to 85%, non-condensing
Altitude: 2km
Input Resolutions
Supported
VESA:
800x6008, 1024x7688, 1280x7688,1280x8008, 1280x9608, 1280x10248,
1360x7688, 1366x7688, 1440x9008, 1600x9008, 1600x12008, 1680x10508,
1920x12008
SMPTE:
1280x7206,7,8, 1920x10806,7,8, 3840x21602,3,5,6,8, 4096x21602,3,5,6,8
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz,
6 = at 50 Hz, 7 = at 59.94 Hz, 8 = at 60 Hz
Established Timing including interlaced formats:
1280 x 1024 @ 75 Hz, 1152 x 870 @ 75 Hz
1024 x 768 @ 60 Hz, 70 Hz, 75 Hz, 87 Hz, 832 x 624 @ 75 Hz
800 x 600 @ 56 Hz, 60 Hz, 75 Hz, 720 x 400 @ 70 Hz, 88 Hz
640 x 480 @ 60 Hz, 67 Hz, 72 Hz, 75 Hz
CEA Video Information Code (VIC) Formats:
VIC = 1, 640 x 480p 59.94/60 Hz 4:3
VIC = 2, 720 x 480p 59.94/60 Hz 4:3
VIC = 3, 720 x 480p 59.94/60 Hz 16:9
VIC = 4, 1280 x 720p 59.94/60 Hz 16:9
VIC = 5, 1920 x 1080i 59.94/60 Hz 16:9
VIC = 6, 720(1440) x 480i 59.94/60 Hz 4:3
VIC = 7, 720(1440) x 480i 59.94/60 Hz 16:9
VIC = 14, 1440 x 480p 59.94/60 Hz 4:3
VIC = 15, 1440 x 480p 59.94/60 Hz 16:9
VIC = 16, 1920 x 1080p 59.94/60 Hz 16:9
VIC = 17, 720 x 576p 50 Hz 4:3
VIC = 18, 720 x 576p 50 Hz 16:9
VIC = 19, 1280 x 720p 50 Hz 16:9
VIC = 20, 1920 x 1080i 50 Hz 16:9
VIC = 21, 720(1440) x 576i 50 Hz 4:3
VIC = 22, 720(1440) x 576i 50 Hz 16:9

7
Specifications
VIC = 29, 1440 x 576p 50 Hz 4:3
VIC = 30, 1440 x 576p 50 Hz 16:9
VIC = 31, 1920 x 1080p 50 Hz 16:9
VIC = 32, 1920 x 1080p 23.97/24 Hz 16:9
VIC = 33, 1920 x 1080p 25 Hz 16:9
VIC = 34, 1920 x 1080p 29.97/30 Hz 16:9
VIC = 39, 1920 x 1080i 50 Hz 16:9
VIC = 41, 1280 x 720p 100 Hz 16:9
VIC = 42, 720 x 576p 100 Hz 4:3
VIC = 43, 720 x 576p 100 Hz 16:9
VIC = 44, 720(1440) x 576i 100 Hz 4:3
VIC = 45, 720(1440) x 576i 100 Hz 16:9
VIC = 47, 1280 x 720p 119.88/120 Hz 16:9
VIC = 48, 720 x 480p 119.88/120 Hz 4:3
VIC = 49, 720 x 480p 119.88/120 Hz 16:9
Output Resolutions
Supported
VESA:
800x6008, 1024x7688, 1280x7688, 1280x8008, 1280x9608, 1280x10248,
1360x7688, 1366x7688, 1400x10508, 1440x9008, 1600x9008, 1600x12008,
1680x10508, 1920x12008
SMPTE:
1280x7206,8, 1920x10806,8, 3840x21602,3,5,6,8, 4096x21602,3,5,8
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 =
at 50 Hz, 7 = at 59.94 Hz, 8 = 60 Hz, 9 = 75 Hz
NOTE:
Scaler Mode: 3840x2160@60Hz RGB/YCbCr 4:4:4,
4096x2160@60Hz RGB/YCbCr 4:4:4;
Bypass Mode: 3840x2160@60Hz RGB
Dimensions (W x H x D)
440mm x 88mm x 380.2mm /17.32’’ x 3.46’’ x 14.97’’
(Without Mounting Brackets)
Weight
9.56kg/21.08lb
Certification
CE/FCC/ETL/PSE/RCM
Audio Format Supported
•Bypass Mode: Fully supports audio formats in HDMI 2.0 specification,
including PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD Master
Audio and DTS:X;
•Scaler Mode: PCM 2.0
•Analog AUDIO: stereo
Transmission Distance
Note: The use of straight-through category cables wired to T568B standard recommended.
Cable Type
Range
Supported Video
Cat 6/6a/7 100m/330ft
1080P@60Hz, 48bpp
1080P@60Hz,3D
4K@30Hz, 4:4:4, 32bpp
4K@60Hz, 4:2:0, 32bpp
4K@60Hz, 4:4:4, 24bpp
HDMI
Input:15m/50ft
Output:10m/33ft
1080p@60Hz, 24bpp
Input/ Output: 10m/33ft
4K@30Hz 4:4:4 24bpp
Input/Output: 3m/10ft
4K@60Hz, 4:4:4 24bpp

8
Installation
Note: Before installation, please ensure the device is disconnected from the power source.
Steps to install the device into an equipment rack:
The DVX occupies two rack units in a standard equipment rack. The following steps apply to mounting the
DVX.
1. Discharge any static electricity from your body by touching a grounded metal object.
2. Position and install the mounting brackets, as shown in the following picture, using the supplied
mounting screws (the brackets are installed when you first open the box).
NOTE:
The left and right mounting brackets are not identical. Please install in the orientation shown.
Brackets attach at the side
toward the front of the unit
3. Install the DVX in the mounting rack by using the mounting screws to affix the unit to the rack.
4. Connect any applicable wires to the DVX.
CAUTION: DO NOT stand other units directly on top of the DVX when it is rack mounted, as this will place
excessive strain on the mounting brackets.
Ventilation
ALWAYS ensure that the rack enclosure is adequately ventilated. Do not block any ventilation openings.
Sufficient airflow must be achieved (by convection or forced-air cooling) to satisfy the ventilation
requirements of all the items of equipment installed within the rack.
NOTE: The maximum operating ambient temperature is 40°C (104°F).
CAUTION: When installing equipment into a rack, distribute the units evenly. Otherwise, hazardous
conditions may be created by an uneven weight distribution.
Reliable earthing (grounding) of rack-mounted equipment should be maintained.
The DVX should not be installed in enclosed spaces. It is recommended that you leave 1 RU of space above
the DVX when you install it in a rack.

9
Wiring and Device Connectors
Overview
This chapter provides functional details for each item on the front and rear panel of the DVX. Wiring
specifications are also provided, when applicable.
Front View
SERIAL LEDs IR/SERIAL LEDs LCD Displays
TAKE Pushbutton
STATUS Pushbutton
VI DEO MENU
Navigational pushbu ttons
AUDI O MENU
EXIT Pushbutton
VI DEO MUTE
AUDIO MUTE
LINK/ACT LED SWITCH Pushbutton
STATUS LED INPUT LED
ICSLAN LEDOUTPUT LED
RELAY LEDs
USB Port
PROGRAM Port
I/O LEDs
Fig 1 DVX-3266-4K&DVX-2265-4K Front panel
Rear View
HDMI INPUTS USB-A/ B Ports
USB Port
RS-232 Ports
HDMI OUTPUTS (1&2)
RELAYPorts CONFIG
HDMI OUTPUT (3) DXLINK OUTPUT (3)
HDMI OUTPUT (4)
DXLINK OUTPUT (4)
DXLINK INPUTS
MIC/LINE INPUTS AUDIO INPUTS AUDIO OUTPUTS AMP OUTPUTS I R/ SERI AL PortID Pushbutton
DANTE Ports
LAN 100/1000
I/OPort
USB-A/B
Power Connector
ICSLAN
Fig 2 DVX-3266-4K Rear panel
HDMI INPUTS USB-A/ B Ports
USB Port
RS-232 Ports
HDMI OUTPUTS (1)
RELAYPorts CONFIG
HDMI OUTPUT (2) DXLINK OUTPUT (2)
DXLINK INPUTS
MIC/LINE INPUTS AUDIO INPUTS AUDIO OUTPUTS AMP OUTPUTS I R/ SERI AL PortID Pushbutton
DANTE Ports
LAN 100/1000
I/OPort
USB-A/B
Power Connector
ICSLAN
Fig 3 DVX-2265-4K Rear panel

10
Front Panel Controls and Indicators
The following sub-sections describe each component on the front panel of the DVX. Refer to FIG. 1 for the
component layout of the front panel.
LEDs
The LEDs on the front panel indicate the communications status of several different connections.as
described in the table below:
SERIAL LEDs
IR/SERIAL LEDs
LINK/ACT LED
STATUS LED INPUT LED
ICSLAN LEDOUTPUT LED
RELAY LEDs I/O LEDs
Front Panel LEDs
Label Color Description
LINK/ACT Green
On indicates that the Ethernet cables are connected and terminated
correctly;
Blinking indicates receiving Ethernet data packets.
STATUS Green Blin
king indicates that the system is programmed and communicating
properly
INPUT Yellow Blinking indicates that the Controller is receiving data.
OUTPUT Red Blinking indicates that the Controller is transmitting data.
ICSLAN Red Blinking when the category cable to port 1 is connected and terminated
correctly.
SERIAL Red/Yellow Two LEDs indicate that the RS-232 port (1-2) is transmitting or receiving
data.
RELAY Red On indicates that relay channels are active on Port (21).
IR/SERIAL Red On indicates that IR/SERIAL channels are transmitting control data on Port
(11-12).
I/O Yellow On indicates that I/O channels are active on Port (22).

11
LCD Displays
During normal operation, the 2 x 20 line LCD display indicates output volume information. The LCD
backlight on the display turns off after 35 seconds of inactivity.
Mai n Amp Out put
VOLUME: 20
SWITCH Pushbutton
Press the SWITCH pushbutton to access the SWITCH menu on the LCD display. Press this button to switch
the audio, video, or both from any input to any output. Press the TAKE pushbutton to implement the switch.
TAKE Pushbutton
Press the TAKE pushbutton to implement an audio/video switch while you are in the Switch menu on the
LCD display. When in an audio or video menu, press the TAKE pushbutton to cycle through audio and video
inputs or outputs (depending on the menu.) This button does not access the menus or change the currently
selected menu.
VIDEO MENU Pushbutton
Press the VIDEO MENU pushbutton to access the video options, displayed on the LCD display. There are two
video menus (VIDEO OUTPUT and VIDEO INPUT) and both are accessible by using this button. Multiple
presses cycle through the various VIDEO menus.
The Video menu enables you to see and adjust most parameters of the video input and output signals.
Use the UP and DOWN navigational buttons to traverse the various configuration parameters.
Use the LEFT and RIGHT navigational buttons to adjust the selected video parameter.
Adjustments take effect immediately (some parameter changes may exhibit a slight delay) and are saved
when you advance to another option or exit the menu. The menu exits automatically after no user

12
interaction on the front panel for 30 seconds.
See the Video Settings section for a listing of all available options and instructions on how to change the
settings.
AUDIO MENU Pushbutton
Press the AUDIO MENU pushbutton to access the audio options, displayed on the LCD display. There are
three audio menus (AUDIO OUTPUT, AUDIO INPUT, and MIC) and all are accessible by using this button.
Multiple presses cycle through the various AUDIO menus.
The Audio menu enables you to see and adjust most parameters of the audio input and output signals.
Use the UP and DOWN navigational buttons to traverse the various parameters.
Use the LEFT and RIGHT navigational buttons to adjust the selected audio parameter.
Adjustments take effect immediately and are saved when you advance to another option or exit the menu.
The menu exits automatically after no user interaction on the front panel for 30 seconds.
See the Audio Settings section on page 59 for a listing of all available options and instructions on how to
change the settings.
Navigation Pushbuttons
The four directional navigation buttons (Left/Right/Up/Down) enable you to navigate through and adjust
the configurable parameters shown on the LCD display. The UP and DOWN navigation buttons are used to
move between configurable parameters within a menu. Pressing UP takes you to the previous configuration
parameter. Pressing DOWN takes you to the next configuration parameter. These buttons do not change
the currently selected menu.
The LEFT and RIGHT navigation buttons are used to change the setting of the displayed parameter. If the
parameter is read-only the value cannot change. Pressing LEFT decreases the value displayed if the setting
is numeric or goes to the previously set item if the setting is a set selection. Pressing RIGHT increases the
value displayed if the setting is numeric or goes to the next set item if the setting is a set selection. These
buttons do not change the currently selected menu.
Move up to next menu configu ration parameter
Move down to next menu configu ration parameter
Decrease value, or
change the state
of the selected
parameter
Increase value, or
change the state
of the selected
parameter

13
STATUS Pushbutton
Press the STATUS pushbutton to access the STATUS menu on the LCD display.
The STATUS menu enables you to see status information such as IP address and installed firmware versions
as well as adjust LCD and LED backlight intensity.
Use the UP and DOWN navigational buttons to traverse the various options.
Use the LEFT and RIGHT navigational buttons to adjust the selected LCD and LED backlight intensity
(when selected).
Adjustments take effect immediately and are saved when you advance to another option or exit the menu.
The menu exits automatically after no user interaction on the front panel for 30 seconds.
See the Status Menu section for a listing of all available options and instructions on how to change the
settings.
EXIT Pushbutton
Press the EXIT pushbutton to exit any menu on the LCD display.
VIDEO/AUDIO MUTE Pushbuttons
Press the VIDEO MUTE button to enable or disable video on all output displays.
Press the AUDIO MUTE button to enable or disable audio for all audio outputs.
Program Port
The front panel of all models features one Type-B USB port for connecting the controller to a PC via USB
cable.

14
The Program port uses a standard Type-A-to-Type-B USB cable to connect to a PC. When connected, you
can view your DVX among the listed Masters connected via USB in NetLinx Studio. See the Initial
Configuration chapter in the NX-Series Controllers WebConsole and Programming Guide for more
information.
USB Port
The front panel of all models features one Type-A USB port you can use to connect a mass storage device
for loading .tkn files, reading or writing configuration files and log files, or updating the firmware on the
unit.
NOTE:
This USB port only supports a FAT32 file system.
This USB port uses standard USB cabling to connect to any mass storage or peripheral devices.
NOTE:
USB hubs are not supported on this port.
Rear Panel Audio Inputs and Audio Outputs
The following sub-sections describe each component on the rear panel of the DVX. Refer to FIG. 2 & 3 on
“Overview” section for the component layout of the rear panel.
AUDIO INPUTs
The AUDIO INPUTs connectors are 3.5 mm 5-position captive-wire terminals that can be wired for either
balanced (differential) or unbalanced (single-ended) stereo audio. Since the DVX allows independent
switching of video and audio, video and audio inputs of the same number do not have to be connected to
the same source equipment. These connectors feature the following specifications:
Nominal input level: +4 dBu (1.228 Vrms) or -10 dBu (0.3262 Vrms) unbalanced
Maximum input level: 2 Vrms
Input impedance: >12k ohms unbalanced, >12k ohms balanced, DC coupled
Source devices require either balanced (differential) or unbalanced (single-ended) connections. The
following picture illustrates options for wiring between sources and input connectors. More than one
option can be used in the same system.

15
+ - + -
L R
+ - +-
L R
DVX
Source device
+ - +-
L R
+ - +-
L R
Balanced Wiring
Unbalanced Wiring
The following picture provides details for wiring from an audio input to an unbalanced source device that
has RCA connectors. Positive and ground wires connect to the source. You also can use an RCA Female to
5-Pin Phoenix Cable for this type of connection.
+ - +-
L R
L R
DVX
Source device
RCAStereo Audio Source Wiring
RCA Stereo Audio Source Wiring
CAUTION: Do not connect the negative terminals to the source connector. Doing so can cause damage to
your device.
HDMI INPUTs
The HDMI INPUT connectors on the rear panel routes digital audio (and video) from connected source input
devices to the connected output devices. These inputs support the following audio formats:
Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 CH L-PCM, 6 CH L-PCM, 8 CH L-PCM Dolby
Digital and DTS support up to 48kHz, 5.1 channels.
For more information about these connectors, including wiring, see the “HDMI INPUTs” of Rear Panel
Video Inputs and Outputs section.
The DVX models have DXLink input ports, which support embedded audio, in place of HDMI input ports.
See the “DXLINK INPUTs” section for more information.
MIC/LINE INPUTs
Six 3.5mm 3-pin captive-wire MIC/LINE INPUT connectors allow up to six mono microphones to be
connected to the DVX. Each microphone input supports balanced and unbalanced audio. Each input
supports up to 48V of phantom power.
