BenQ InstaShare User manual

InstaShare™ Button Solution
User Manual
TZY31 V 1.01

2
Copyright
Copyright © 2021 by BenQ Corporation. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of BenQ Corporation.
Disclaimer
BenQ Corporation makes no representations or warranties, either expressed or implied, with
respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for
any particular purpose. Further, BenQ Corporation reserves the right to revise this publication and
to make changes from time to time in the contents hereof without obligation of BenQ Corporation
to notify any person of such revision or changes.
This user manual aims to provide the most updated and accurate information to customers, and thus
all contents may be modified from time to time without prior notice. Please visit www.benq.com for
the latest version of this manual.
The illustrations and the images in this guide are for your reference.

3
Table of contents
Copyright ......................................................................................................................................2
Disclaimer .....................................................................................................................................2
Introduction ..................................................................................................................................4
Product features .............................................................................................................................................. 5
Package contents ............................................................................................................................................. 6
Product specifications ..................................................................................................................................... 7
Overview ........................................................................................................................................................... 8
Button .............................................................................................................................................................................................. 8
LED indicator for the Button ..................................................................................................................................................... 8
Using InstaShare Wireless Solution ........................................................................................9
Installing the Wireless Adapter .................................................................................................................... 9
Pairing a Button to the Wireless Adapter ................................................................................................. 9
Starting a presentation .................................................................................................................................12
Split-screen presentations ...........................................................................................................................14
Starting a split-screen presentation ........................................................................................................................................ 14
Enlarging a split-screen ..............................................................................................................................................................15
Touch back ......................................................................................................................................................16
Using a display’s webcam, speakers, and/or microphone ....................................................................17
Storing Buttons in the InstaShare Dock ...................................................................................................18
10/14/

4 Introduction
Introduction
InstaShare Wireless Solution is a wireless device for corporate meeting rooms and education-based
classrooms. It is a unique wireless presentation solution without complex software and web settings.
Users expect devices to respond instantly with the power to control them at their fingertips, instead
of having to read user manuals and install extraneous apps on their devices. This product allows these
users to bypass complicated steps such as configuring IP addresses, installing drivers and apps,
configuring settings, and so on, to quickly deliver stable and professional-quality video which allows
teams to collaborate freely and confidently.
A standard product set consists of a Wireless USB Adapter, two InstaShare Buttons, and one
InstaShare Dock. The software for the base unit may differ depending on the location where you buy
the product. You can also buy additional InstaShare kits if needed.
• “InstaShare Wireless Solution will hereinafter be referred to as “the product” in this document.
• “InstaShare Button/Buttons” will hereinafter be referred to as “Button”/“Buttons” in this document.
• “Wireless USB Adapter” will hereinafter be referred to as “Wireless Adapter” in this document.
Your product complies with the local wireless regulations and the warranties are valid in the country/region
where the product is purchased. Using the product outside the purchased country/region does not guarantee the
wireless functionalities. And modification of any part of the product will void the warranties.

5Introduction
Product features
The product is equipped with the following features:
Features Description
True Plug & Play Simply connect the product to your Type-C USB port, then push the
button to start presenting immediately.
No Software
The product doesn't need any software installation or execution. There's
no setup, configuration, or waiting for pop-ups to launch. Just plug into
your Windows, macOS, Chrome device - or any other devices with a full-
featured Type-C interface port - and start presenting immediately.
Split-Screen
Presentations
Up to nine users can simulaneously project their screen via the product in
different split-screen configurations, so that you can view and reference
multiple documents/videos at the same time during your presetation.
Auto Channel Selection The product automatically selects the best wireless channel upon boot-
up, ensuring smooth presentations in any environment.
Touch Back
You can use touchscreens to control the screen of the PC that is
presenting, allowing you to actively engage with the content that is being
presented.
Wireless 802.11 ac/n The latest 802.11 ac/n Wi-Fi guarantees extremely smooth wireless
streaming without lag or buffering.
Ultra HD 4K Video The product supports up to Ultra HD 4K video and stereo sound without
cable clutter or complicated driver selection.
Assured Performance Peace of mind for consistent wireless presentation performance without
relying on your PC.
Extended Desktop
Keep your presenter view, notes, and backup data on your laptop screen
while presenting to the wireless screen with extended desktop in both
Windows and OS X.
Wireless Camera and
Audio
The IFP’s speakers, microphones, and any connected webcam can be
utilized by the user's laptop wirelessly via the Button, allowing users to
integrate them into their video conference apps (Zoom, Skype, Teams,
Google Meeting, etc.).
• InstaShare Wireless Solution does not work on all displays. To check which displays support InstaShare
Buttons, go to the following URL: https://www.benq.com/en-us/business/search-
result.html?q=InstaShare%20Button.
• T
ouch back via USB port is only supported for Windows-based PCs. Macs and mobile devices cannot be
controlled via touch screens.
• Transmission distance depends on actual environment. Stated distance is based on line-of-sight measurement.
Structures constructed of steel, wood, concrete, or brick may decrease transmission distance.
•According to regulatory restrictions in different regions of the world, Wi-Fi channels cannot be used in
countries outside the purchased region.

6 Introduction
Package contents
Wireless USB Adapter InstaShare Buttons
InstaShare Dock Type-C-to-Type-A USB Adapters
Quick Start Guide Regulatory Statements
• Available accessories and the pictures shown here may differ from the actual contents and the product
supplied for your region.
• Use original accessories to ensure compatibility.
• Always keep the product and accessories out of reach of children.

7Introduction
Product specifications
InstaShare Button
Model InstaShare Button
Color Silver
Wireless transmission frame rate Up to 60 fps depending on environment (1080P60 / 4K30P)
Button input resolution Up to 4K30P
Audio rate Stereo, Radio quality 16bits 48KHz
Wi-Fi standard IEEE 802.11ac 5GHz, 2T2R MIMO
Authentication protocol WiFi Standard
Wireless security (encryption) WPA2/3 Personal/WPA2 Enterprise Support AES-256
Wireless coverage reach Max. 15m (between Button and IFP)
Temperature range Operating: 0°C to +45°C (+32°F to +104°F)
Storage: -10°C to +60°C (+14°F to +140°F)
Cable USB Type-C
Power supply DC 5V±10%, Minimum 0.9A
Power consumption Max 4.5W Full Loading
Dimensions (WxHxD) 67mm x 67mm x23.2mm
Wireless USB Adapter
Color Black
Wi-Fi standard 802.11 a/b/g/n/ac
Interface USB 3.0
Wi-Fi band Dual Band 2.4GHz / 5GHz
MU-MIMO Yes
Wi-Fi performance 2.4 GHz Band: up to 400 Mbps
5 GHz Band: up to 867 Mbps
External antennas 2
Supported OS Android / Windows
Wireless coverage reach Max. 15m (between Wireless Adapter and IFP)
Security WPA-PSK/WPA2-PSK WPA/WPA2/WEP
Dimension (LxHxW) 137 x 41 x 12mm
Net weight 0.025kg
Operation temperature 0°C – 45°C
Operation humidity 10% – 90%
Storage temperature -40°C – 70°C
Storage humidity 5% – 90%
InstaShare Dock
Color Black
Dimension (LxHxW) 143x82x106 mm
Product material PC+ABS & Aluminum alloy 6063 & Silica gel
Weight 455g
InstaShare Button loading quantity 4 pcs
(TWY31)
(TDY31)
(TCY31)

8 Introduction
Overview
Button
LED indicator for the Button
Please refer to the table below for detailed indicator and status descriptions for the Button.
1. Present key with LED indicator
Press to start or stop presenting.
2. Split-screen key
Press to toggle between enlarged view or regular
view during split-screen presentations.
3. USB-C connector
Connect to a computer or laptop.
LED Behavior Status description
Off The Button is powered off.
Solid white The Button is in standby mode.
Flashing green The Button is in the process of connecting to the Wireless Adapter.
Solid green The Button is connected and ready to present.
Breathing green
The Button is waiting for approval to present.
The InstaShare 2 app on BenQ Smart Displays allows you to configure
presentations to require approval before a button can begin presenting.
When this setting is enabled, the LED on the button will exhibit this
behavior once the present key on the Button is pushed until approval is
granted.
Flashing blue The Button is in the process of pairing.
Solid blue The Button is presenting.
Breathing blue
The Button is currently unable to present (e.g. the Button is in do-
not-disturb mode, max. number of presenters has been reached,
etc).
Flashing red The Button is unable to connect to the Wireless Adapter.
Quick flashing red The Button has not been activated.
Breathing red
The Button is inserted into its device but the USB Type-C port is
not transmitting a signal (the USB Type-C port does not support
ALT mode)
3
1
2

9Using InstaShare Wireless Solution
Using InstaShare Wireless Solution
Installing the Wireless Adapter
To begin using InstaShare Button, you must first install the Wireless Adapter to a Type-A USB port
on your display. Though the Wireless Adapter is compatible with USB 2.0 ports, it is recommended
that you install it to a USB 3.0 or above port (if available) on your display.
Pairing a Button to the Wireless Adapter
A product set includes two Buttons, which are already paired with the supplied Wireless Adapter
before shipment. If you want to use a newly purchased Button or a Button that has already been
paired with another Wireless Adapter, you will need to follow the instruction below in order to pair
the Button with the current Wireless Adapter.
To pair a Button with the Wireless Adapter:
1. Make sure that the Wireless Adapter is installed on your display and that the display is powered
on.
2. In the Network tab of the OSD settings menu on the display, enable WLAN Hotspot.
USB-A
WLAN
Hotspot

10 Using InstaShare Wireless Solution
3. Open the InstaShare 2 app on the display.
4. Install the Button you want to pair to either a Type-C USB port or Type-A USB port (using the
supplied Type-C-to-Type-A USB adapter) on your display, and then confirm that you want to pair
the Button in the pop-up message that appears.
5. The Button will begin pairing with the Wireless Adapter as the LED indicator on the Button
flashes blue.
If it is your first time using the Button, you will be able to change the name of the button prior to the pairing
process.
InstaShare 2
USB-C™
USB-A

11Using InstaShare Wireless Solution
6. Once the pairing process is finished the display will show a confirmation notification.
7. Remove the Button from the display.
8. Repeat the process for any additional Buttons.

12 Using InstaShare Wireless Solution
Starting a presentation
Once a Button is paired to the Wireless Adapter you can use it with any device with a full-functioning
Type-C USB port to start presentations.
To start a presentation:
1. Make sure that the Wireless Adapter is installed on your display and that the display is powered
on.
2. Insert an already paired Button to your device’s Type-C USB port.
3. The LED on the Button will flash green while it connects to the Wireless Adapter. Wait about
ten seconds for the Button to connect.
Make sure the display/Wireless Adapter is still set to hotspot mode before starting a presentation. The Button
will not be able to connect to the Wireless Adapter if it is set to normal Wi-Fi mode.
The Button does not support connecting to a device’s Type-A USB port using the supplied Type-C-to-Type-A
adapter. The adapter is only meant for connections to the display during the pairing process.
USB-C™

13Using InstaShare Wireless Solution
4. Once the LED stops flashing and turns solid green, the button is successfully connected to the
Wireless Adapter. Press the present key to begin presenting.
When the presentation starts, the LED on the Button will turn solid blue.
• Make sure the Type-C USB port on your device supports video output.
• Make sure the transmission distance between the Button and Wireless Adapter is within 15M and with no
obstacles in between.
• The product supports MacBooks and Windows laptops to mirror an extended desktop.

14 Using InstaShare Wireless Solution
Split-screen presentations
The product allows up to nine users to present simultaneously in a split-screen orientation.
Starting a split-screen presentation
1. Connect a Button to each computer that will be presenting in the split-screen presentation.
2. Start a normal presentation using one of the Buttons. See Starting a presentation on page 12 for
more information.
3. Press the present key on the second Button. The second device’s screen will be added into the
presentation in a split-screen format.
Make sure that all Buttons have already been paired to the Wireless Adapter connected to the display. See Pairing
a Button to the Wireless Adapter on page 9 for more information.

15Using InstaShare Wireless Solution
4. Repeat step 4 for all other users that want to join the split-screen presentation.
Enlarging a split-screen
Once in a split-screen presentation, you can enlarge any of the participant’s individual screens by
pressing the split-screen key on the Button of the participant that wants to enlarge their screen.
To return to the normal split-screen presentation format press the split-screen key again on the
Button of the participant with the enlarged screen.
• Only up to 9 users are simultaneously supported in a split-screen presentation.
• The layout of the split-screen presentation will be dictated by the amount of users in the presentation.

16 Using InstaShare Wireless Solution
Touch back
When the Wireless Adapter is connected to a touchscreen display and a PC is presenting via a
Button, you can control the interface of the PC remotely via touch gestures on the display’s screen.
The product only supports touch back for Windows-based PCs. It does not support touch back for MacBooks or
Chromebooks.

17Using InstaShare Wireless Solution
Using a display’s webcam, speakers, and/or microphone
When a Button is connected to a device and presenting, the device will also be able to make use of
any combination of the display’s speakers, microphone, or webcam (connected externally) in the
programs/applications it is running. This feature gives users the ability when using video software to
easily switch between the audio/video channels of either their device or the display based on what is
suitable for their setting, without the need for any further physical connections or additional
installation processes.
Think of a situation in which a group of meeting participants gather in a conference room that
features a large BenQ touchscreen display. In this scenario a participant running a video conferencing
app can connect an already paired Button to his or her notebook PC and begin a presentation to
share the video conference with all other participants in the room. Once presenting, the user can
then switch the video input for the app over to the display’s external webcam and both the audio
input and output to the microphone and speakers of the display respectively.
This setup allows the video conferencing app to capture views and voices from of all the participants
in the conference room as well as broadcast the audio on the display’s more powerful speakers so
that the whole room is able to hear, thereby removing the need for each particpant to individually log
into the video conference themselves.
External Webcam

18 Using InstaShare Wireless Solution
Storing Buttons in the InstaShare Dock
You can store up to four Buttons in the InstaShare Dock along with additional accessories such as
touch styluses and/or a remote control.
Up to 4 Buttons

PN: 4J.F7W02.001
10/28/2021
Regulatory Statements
CE DOC
DECLARATION OF CONFORMITY
The device complies with the requirements set out in the Council Directives relevant Union
harmonisation legislation:
RED Directive (2014/53/EU)
Laws of the Member States relating Electromagnetic Compatibility (2014/30/EU)
LowVoltage Directive (2014/35/EU)
RoHS Directive 2011/65/EU & (EU) 2015/863
DÉCLARATION DE CONFORMITÉ
L'appareil est conforme aux exigences dénies dans les directives du Conseil relatives à la législation
d'harmonisation de l'Union :
Directive RED (2014/53/UE)
Lois des États membres relatives à la compatibilité électromagnétique (2014/30/UE)
Directive Basse tension (2014/35/UE)
Directive RoHS 2011/65/UE et (UE) 2015/863
DECLARACIÓN DE CONFORMIDAD
El dispositivo cumple los requisitos impuestos en las directivas del Consejo relativas a la legislación de
armonización de la Unión Europea:
Directiva sobre equipos radioeléctricos (2014/53/UE)
Legislaciones de los Estados miembros en materia de compatibilidad electromagnética (2014/30/UE)
Directiva de bajo voltaje (2014/35/UE)
Directiva sobre sustancias peligrosas 2011/65/UE y (UE) 2015/863
DECLARAÇÃO DE CONFORMIDADE
O dispositivo está conforme aos requisitos das Diretivas do Conselho e relevante legislação de
harmonização da União Europeia:
Diretiva RED (2014/53/UE)
Leis dos Estados-Membros relativamente à Compatibilidade Eletromagnética (2014/30/UE)
Directiva de BaixaVoltagem (2014/35/UE)
Diretiva RoHS 2011/65/UE & (UE) 2015/863
DICHIARAZIONE DI CONFORMITÀ
Il dispositivo è conforme con i requisiti deniti nelle Direttive del Consiglio relative alla Norma
sull'armonizzazione dell'Unione:
Direttiva RED (2014/53/UE)
Leggi degli Stati Membri in relazione alla Compatibilità Elettromagnetica (2014/30/UE)
Direttiva BassoVoltaggio (2014/35/UE)
Direttiva RoHS 2011/65/UE e (UE) 2015/863
KONFORMITÄTSERKLÄRUNG
Das Gerät entspricht den Anforderungen der entsprechenden EU-Harmonisierungsrichtlinien des
Rates:
RED-Richtlinie (2014/53/EU)
Gesetze der Mitgliedsstaaten zur elektromagnetischenVerträglichkeit (2014/30/EU)
Niederspannungsrichtlinie (2014/35/EU)
RoHS-Richtlinie 2011/65/EU & (EU) 2015/863
ЗАЯВЛЕНИЕ О СООТВЕТСТВИИ
Это устройство отвечает требованиям, изложенным в Директивах Совета о
гармонизации соответствующих законов государств, входящих в состав Европейского
союза (EU):
Директива о радиооборудовании (2014/53/EU)
Законы стран-участниц, касающиеся электромагнитной совместимости (2014/30/EU)
EN
FR
ES
PT
IT
DE
RU

Директива в отношении низковольтного оборудования (2014/35/EU)
Директива 2011/65/EU и (EU) 2015/863 об ограничении использования определенных
видов опасных веществ в электрическом и электронном оборудовании (RoHS)
Oświadczenie zgodności
Urządzenie jest zgodne z wymaganiami określonymi w odpowiednich unijnych Dyrektywach
harmonizacyjnych Rady:
Dyrektywa RED (2014/53/UE)
Przepisy państw członkowskich dotyczące kompatybilności elektromagnetycznej (2014/30/
UE)
Dyrektywa niskonapięciowa (2014/35/UE)
Dyrektywa RoHS 2011/65/UE i (UE) 2015/863
UYUM BEYANI
Aygıt, Konsey Yönergeleri ile ilgili Birlik uyum mevzuatında belirtilen şartlara uygundur:
RED Yönergesi (2014/53/EU)
Üye Devletlerin Elektromanyetik Uyumluluğa İlişkin Kanunları (2014/30/EU)
Alçak Gerilim Yönergesi (2014/35/EU)
RoHS Yönergesi 2011/65/EU & (EU) 2015/863
OVERENSSTEMMELSESERKLÆRING
Enheden er i overensstemmelse med kravene i Rådets direktiv,relevant til EU's lovgivning om
harmonisering:
RED-direktiv (2014/53/EU)
Medlemsstaternes lovgivning om elektromagnetisk kompatibilitet (2014/30/EU)
Direktiv om lavspænding (2014/35/EU)
RoHS-direktiv 2011/65/EU og (EU) 2015/863
VAATIMUSTENMUKAISUUSVAKUUTUS
Laite on Euroopan neuvoston direktiivien olennaisen unionin harmonisointilainsäädännön vaatimusten
mukainen:
RED-direktiivi (2014/53/EU)
Jäsenvaltioiden lait liittyen sähkömagneettiseen yhteensopivuuteen (2014/30/EU)
Matalajännitedirektiivi (2014/35/EU)
RoHS-direktiivi 2011/65/EU & (EU) 2015/863
SAMSVARSERKLÆRING
Enheten overholder kravene i EU-rådets harmoniseringsdirektiver:
RED-direktiv (2014/53/EU)
Medlemsstaternes lovgivning om elektromagnetisk kompatibilitet (2014/30/EU)
Lavspenningsdirektiv (2014/35/EU)
RoHS-direktiv 2011/65/EU & (EU) 2015/863
KONFORMITETSDEKLARATION
Enheten uppfyller kraven som anges i Rådets direktivs relevanta harmoniseringslagstiftning för
Europeiska unionen:
RED-direktivet (2014/53/EU)
Medlemsstaternas lagar om elektromagnetisk kompatibilitet (2014/30/EU)
Lågspänningsdirektivet (2014/35/EU)
RoHS-direktiv 2011/65/EU & (EU) 2015/863
DECLARAŢIE DE CONFORMITATE
Dispozitivul respectă cerinţele menţionate în Directivele Consiliului şi în legislaţia armonizată
relevantă la nivelul Uniunii:
Directiva privind echipamentele radio (2014/53/UE)
Legislaţiile Statelor Membre privind Compatibilitatea electromagnetică (2014/30/UE)
Directiva privind tensiunea joasă (2014/35/UE)
Directiva RoHS 2011/65/UE şi (UE) 2015/863
PL
TR
DA
FI
NB
SV
RO
