Harman SF 250 Installation instructions

3-90-70738R9_08/13
SAFETY NOTICE
PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW ROOM HEATER. FAILURE TO
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH.
FOR USE IN THE U.S. AND CANADA. NOT SUITABLE FOR INSTALLATION IN MOBILE HOMES
IF THIS HARMAN® STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW
INSTALLATION DIRECTIONS.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
CONTACT YOUR LOCAL AUTHORITY (SUCH AS MUNICIPAL BUILDING DEPARTMENT, FIRE DEPARTMENT, FIRE
PREVENTION BUREAU, ETC.) TO DETERMINE THE NEED FOR A PERMIT.
CETTE GUIDE D’UTILISATION EST DISPONIBLE EN FRANCAIS. CHEZ VOTRE CONCESSIONNAIRE DE HARMAN®.
SAVE THESE INSTRUCTIONS.
Installation & Operating Manual
Model(s):
SF250 Coal Stove
NOTICE: SAVE THESE INSTRUCTIONS
Hot glass will cause burns.
• Donottouchglassuntilitiscooled
• NEVERallowchildrentotouchglass
• Keepchildrenaway
• CAREFULLYSUPERVISEchildreninsameroomas
stove.
• Alertchildrenandadultstohazardsofhightemperatures.
High temperatures may ignite clothing or other
ammable materials.
• Keepclothing,furniture,draperiesandotherammable
materialsaway.
HOT SURFACES!
Glassandothersurfacesarehotduring
operationandcooldown.
WARNING
!

23-90-70738R9_08/13
TABLE OF CONTENTS
= Contains updated information

SafetyConsiderations............. 3
Specications ................... 4
Assembly....................... 5
Installation...................... 6
Chimney&Venting..............7-8
OperatingInstructions............. 9
Maintenance................... 10
OptionalBentHotWaterCoil ....11-12
TestingLabel................... 13
Warranty ....................14-15
Service&MaintenanceLog........ 16
SignaturePage................. 18

33-90-70738R9_08/13
CAUTION
• Keep Children Away
• May Cause Serious Burns
• All Surfaces of stove are hot. Do not touch.
• Keep children away.
• Serious burns will result if touched.
Fuel/Firing Warnings
Danger
Do not use chemicals or uids to start or “freshen up”
a re. Severe body burns or a re in your home could
result.
Do not burn garbage, gasoline, thinners, drain oil or
engine oil, kerosene, or fuel oil, etc. An explosion, a
house re, or personal injury could result. Keep all
such liquids well away from the stove while in use.
Neverburnmaterialsotherthancoal.Achimneyreorheat
exchangerfailurecouldresult.Thisincludeslargeamounts
ofcorrugatedboxes,woodshavings,paperscraps,garbage
orotherburnablematerials.
Ifchimneypipesorconnectorsreach500degreesfahrenheit
(maximumtemperature),thestoveisbeingover-red.We
recommend the purchase of a Magnetic Temperature
Gaugetomonitorthestoveandstacktemperaturesrelative
to the amount of draft the customer permits the stove to
operate.
Ithasbeenveriedthatcreosotewilligniteat650degrees
fahrenheit. It is the owner’s responsibility to follow these
recommendations.
Thisstoveconsumesairwhenitisburning.ifyourhouse
istightlysealedandinsulated,itisadvisablethatawindow
inthevicinitybeopenedslightlywhilethestoveisburning.
Information contained in this manual is manufacturer’s
recommendations and if there is any difference between
our recommendations and local code requirements, we
suggestfollowinglocalcoderequirements.
SAFETY CONSIDERATIONS
Curing Paint
During the rst few hours of burning, a blue smoke will
be observed rising from the painted surface of the stove.
It is advisable to increase the amount of fresh air (open
window)intheroomduringthisbreaking-inperiod.Donot
bealarmed,thisisnormalanddoesnotcauseharm.
Mobile Homes
This Harman® Stove is not approved for installation in
mobile/manufacturedhomes.
SPECIAL WARNING: NEVER OPERATE YOUR STOVE
WITHTHEFIREORASHDOOROPEN!
Keep Ash Pan Empty
Excessive ash buildup will block the airow around the
grates.This,andonlythis,willcausethegratestowarpand
sag.Neglectisnotcoveredbyyourstove’swarranty.

43-90-70738R9_08/13
7/8
35 3/4
5 13/16
32 5/8
36 11/16 42 15/16
20 1/2
42 15/16
SPECIFICATIONS

53-90-70738R9_08/13
ASSEMBLY
Firebrick Diagram
Blower
The blower slides into the channel bracket on the rear of
thestoveasshownatright.Plugtheblowerintoaproperly
groundedreceptacle.
Shaker Handle
The shaker handle installs onto the shaker handle mount
usingthetwohex-boltsandwashersprovided.
Firebricks
TheSF250uses14“standard”rebricks,asshownbelow.
Thesestandardrebricksmeasure9”X 4½” X1¼”each.
Therebricksarealreadyinstalledinthestovebutcanbe
removedtolightenthestoveformoving.Thedoorscanalso
beremovedbysimplyliftingthemoffofthehinges.

63-90-70738R9_08/13
INSTALLATION
WARNING:Thisstovemustbeinstalledinaccordancewith
allstateandlocalbuildingcoderequirements.
Locating the stove
Locatethestoveasclosetothechimneyorueaspossible,
whilestillmaintainingtheclearancestocombustibles.
Locate the stove where there is sufcient air supply for
ventilationandpropercombustion.
Clearance to Combustibles
Safestoveclearancetocombustiblewallsis24”totherear
and36”tothesidesandfront.Donotplacefurnitureandthe
likedirectlyinfrontofthestove.
Floor Protection
Floorprotectionforacombustibleoorshouldconsistof3/8”
millboardorastoveboardprovidingequalprotection(k=.84,
R=.45).Theoorprotectionshouldextend8”totherearand
eithersideand16”infrontofthestove.Theoorprotection
shouldalsoextend2”toeithersideofthechimneyconnector,
tothewallwheretheconnectorenterstheue.
Adjustable Leveling Feet
To accomodate an un-even hearth surface, the SF250 is
equipped with adjustable leveling feet. Each foot can be
turnedin or outof theleg to loweror raisethat corner of
thestove.
Turntheroundfootinorout
toleveleachcornerofthe
stove.
It is recommended that you have your unit installed and
servicedbyprofessionalswhoarecertiedbytheNational
FirplaceInstitute(NFI)asNFISpecialists.
Floor Protection
Floor Protection
36”
8”
8”
16”
24”
Alternate oor protector dimension may be used as long as they satisfy
the measurement requirements shown below.
Minumum size oor protection for a corner installation hearth pad is
54" x 54" (USA ONLY).
54"
54"

73-90-70738R9_08/13
CHIMNEY & VENTING
Types Of Chimneys
The chimney is one of the most important, yet most
neglected and misunderstood portions of any solid fuel
burning stove installation. Do not connect this stove to a
chimneyueservinganotherheatingdevice.
THE STOVE MUST BE CONNECTED TO ITS OWN
TILE-LINEDFLUE.AMINIMUMFLUESIZEOF8”X8”IS
NECESSARYFORPROPEROPERATION.
UNDER NO CIRCUMSTANCES SHOULD A MANUAL
FLUE DAMPER BE INSTALLED IN THE SMOKE PIPE
BETWEENTHESTOVEANDTHECHIMNEY.
NO DAMPER, HEAT SAVER OR AUTOMATIC VENT
DAMPER DEVICE SHOULD BE INSTALLED IN OR ON
THESMOKEPIPE.
CAUTION: THE CHIMNEY MUST BE A CLASS “A”
CHIMNEY, IN GOOD OPERATING AND CLEAN
CONDITION.
NOTE: THE USE OFALUMINUM TYPE “B” GAS VENT
FOR SOLID FUELS IS UNSAFE AND PROHIBITED BY
THENATIONALFIREPROTECTIONAGENCYCODE.
There are three types of class “A” chimneys:
1. Masonrywithtileliner,toincludebrickorstone.Itmust
besupportedongradelevelfoundation.
2. Insulated,manufacturedchimney,listedorcertiedbya
nationaltestagency.
3. Triple-wallmetalclass“A”chimney,listedorcertiedby
anationaltestagency.
Ifyourmasonrychimneyhasnotbeenusedforsometime,
haveitinspectedbyaqualiedperson.Ifalistedorcertied
manufactured chimney is to be used, make certain it is
installedinaccordancewiththemanufacturer’sinstructions
andalllocalandstatecodes.
Theminimumrecommendedheightforsolidfuelchimneys
is16feetfromthestovecollar.Thechimneymustbetwo
feethigherthananythingwithintenfeet.Italsomustextend
three feet above the point where it intersects or exits the
roofline.
In order to have a properly operating solid fuel heating
system, the chimney must be capable of providing the
necessarydraft.Theminimumrequireddraftis.06inchesof
watercolumn(W.C.).Thismustbemeasuredusingadraft
gauge.Ifthechimneycannotsupplythisconstantdraft,the
stovewill not operate properly.A barometric damper may
beusedandproperlyadjustedtocompensateforexcessive
draftonly.
IMPORTANT: When you measure the the draft, the stove
must be operating with sufcient time given for the stove
andchimneytowarm.Burnforatleastthirtyminutes.The
draftreadingisbesttaken18”upfromthecenteroftheue
outlet,intheconnectorpipe.Drillaholeinthepipeforthe
meter tube, and ll it with a screw or silicone when done
withthetest.
IMPORTANT: The connector pipe must be 24 gauge or
thicker.
Whenconnectingtheuepipetothestove,therstsection
should be installed inside the stove collar. It should be
securedtothecollarwith,atleast,threescrewsorrivets.
Do not pass the connector pipe through a wall or ceiling
withoutrstcheckingwithyourlocalcodes.Ifallowed,use
onlyapprovedpass-thrumethods.
NOTE:Allhorizontalrunsofventingshouldhavea1/4inch
ofriseperfootoflength.
Use no more than two 90° elbows in the connector. If a
barometricdamperisneeded,tocompensateforexcessive
draft,installitonlyinaverticalsectionofventpipe.
Thethreefoot,twofoot,tenfootrule
More than 10 Ft. (3 m)
10 Ft. (3 m)
2 Ft. (.6 m) Min
Height necessary
above any roof surface
within 10 Ft. (3 m)
3 Ft. (.9 m) minimum
above exit point
Ridge
Chimney

83-90-70738R9_08/13
CHIMNEY & VENTING
Possible causes of insufcient draft;
A. Chimney Leaks - Air leaking in around a loose tting
cleanout door, ue pipe joints and/or seams not secured,
improperplugopeningsordefectivemasonry.
B.ChimneyTooShort-Thegeneralruleforchimneys;16
feettall,threefeetabove the roofexit,andtwo feet taller
thananythingwithintenfeet.
C. Blocked Chimney - Have the chimney cleaned and
inspected prior to installation and before each heating
season.
D.TreesOrOtherTopographicalBarriers-Impedingonthe
chimney’soperationorcausingadowndraftsituation.This
canalso be caused by adjacentbuildings or another roof
ofthesamestructuregivingaircurrentsadownwardswirl.
NOTE:Thechimneyontheillustratedhouseistoolow,it
shouldberaisedtocompensatefordowndraftpotential.
Wind direction
Themostcommoncauseofpoordraftisanimproperlysized
ueliner.Itisrecommendedthattheinsidedimensionsof
the liner be at least as large as the appliance ue outlet
andnolargerthan125%ofthecollarforaroundue.An
example, a 8” ue collar is 50 square inches. Increased
by25%wouldbe63squareinches,orapproximatelya9”
roundue.In generalfor round liners,it isrecommended
thattheynotbeincreasedbymorethanoneinchfromthat
ofthestovecollar.Thiswillhelpensureproperdraftwiththe
loweruetemperatures.
REMEMBER; A solid fuelburningstovecanonlyperform
aswellasitsventingsystemwillallowitto.
THEMOSTIMPORTANTTHINGTOREMEMBERABOUT
CHIMNEYS IS THEIR NEED FOR MAINTENANCE
AND CLEANING. IFA CHIMNEY IS NOT CLEANED ON
A FREQUENT BASIS, IT WILL AFFECT THE DRAFT
AS WELL AS BEING A CONTRIBUTING CAUSE TO A
POSSIBLECHIMNEYFIRE.
IF YOU HAVE A CHIMNEY FIRE:
1. GETEVERYONEOUTOFTHEHOUSE.
2. CALLTHEFIREDEPARTMENT.
3. CLOSE THE DRAFT CONTROL KNOBS ON THE
STOVE.
DO NOT USE THE CHIMNEY UNTIL IT HAS BEEN
THOROUGHLY CLEANED AND INSPECTED BY A
QUALIFIEDPERSON.
E.ChimneySize-Thechimneycannotbesmallerthanthe
ueexitfromtheappliance.Toolargeofachimneycould
staytoocooltopromoteadequatedraft.
F. Chimney Offsets - Offset chimneys should be avoided.
Theoffsetareacancollectdebrisandcauseablockage.
G.Elbowrestrictions-Thereshouldbenomorethantwo
90°elbowsortheequivalentusedinconnectingthestove
tothechimneyue.
H.SharedFlue-Nomorethanoneapplianceshallventinto
asingleue.

93-90-70738R9_08/13
OPERATING INSTRUCTIONS
The SF250 is approved for use with coal only. Burning
wood or other such fuels in this stove, except for the
purpose of igniting a coal re, is prohibited.
Starting A Fire
Beginbyopeningthedraftcontrolknobsonboththeload
doorandtheashdoor.Openbothdoors.Besureallitems
havebeenremovedfromtheashpan(i.e.touch-uppaint,
warrantyregistration,etc...)
Place aproximately eight sheets of newspaper, crumbled,
on top of the grates. Lay some kindling on top of the
crumbledpaper.Thiskindlingshouldbedryandnolarger
than3/4in.diameter.Itshouldbelayeredinacriss-cross
fashion to allow good air ow. Now place some slightly
larger pieces of wood (about 2” diameter) on top of the
kindling. Using a match or grill lighter, ignite the paper at
thebottomjustinsidethedoor.Closebothdoorsandallow
thekindlingandlargerwoodtocatchre.Afteraroundve
minutes,opentheloaddoorslightly,forafewsecondsand
thenopencompletely.Thisisagoodpracticetogetintoas
itwill allow any smoke andgases to clear away fromthe
dooropening.Addsmallcompactpiecesofwoodwhenthe
kindlingisburninghot.Whenasubstantialbedofhotwood
coalsisestablished,startaddingcoalinsmallamountsat
a time.Allow a few minutes between coal loadings to be
surethat what you’ve added isignited.Youcan keepthe
ash door open through this process, but NEVER LEAVE
THESTOVEUNATTENDEDWITHADOOROPEN.Once
youhaveabedofburningcoal,youcanloadcoalintothe
stovetothetopoftherebricks.Alwaysmakesurethereis
someameshowingthroughthecoal.Thiswillensurethe
gasesarebeingburnedandnotaccumulatingintherebox.
Afteragoodcoalignition,setthedraftcontrolsontheload
doorto about 1/4 turn open.The draft control on the ash
doorisusedtocontroltherateofburn.Afterstartingare,
keepitabout2fullturnsopenforabout30minutes.Then,
adjust further closed to the proper output level. Normal
operationwillbebetweencrackedandoneturnopen.Since
coalrespondsslowlytodraftadjustments,makeonlysmall
adjustmentsandallowtimeinbetween.
Loading
Coalshouldonlybeaddedwhenthereisareasonablyhot
re.Thecoalbedshouldbebrightandvigorous.Ifthereis
burninghotandthereisadeepbedofcoals,fullloadscan
beadded.Ifitisnotasdescribed,addcoalinsmallbatches
only.
Increasing Heat From A Low Fire
Everyeffortshould bemade not toleta coal reburn so
longthatithasstartedtodie.Thiswillcausethereloading
processtobemuchlonger,andthereisagoodposibilityof
losingthere.
Donotshakeorstiralowre.
Openthedraftcontrolallthewayuntiltheregetsashotas
possible.Startaddingsmallbatchesofcoalandfollowthe
instructionsforstartingare.
Oncethereisagoodbedofburningcoals,thegratesmay
beshakentoremoveashes.
Shaking Ashes
Shaking should be done only when there is a hot re
burning. The frequency of shaking will depend on the
degreeof burning. Shaking should bedone at least once
perday,preferablytwice.
Thebestresultsfromshakingwilloccurwhenshortchoppy
strokesareused,ratherthanlong,evenstrokes.Graspthe
shakerhandlewithonehandandshakeit,onlymovingthe
actualhandle1/2inchorless.Dothisuntilyoustarttosee
hotcoalsfallingintotheashpan,thenstop.Donotrockthe
grates, as this will allow burning coal to fall through, and
you’lllosethere.
Ashes
The ashes should never be allowed to accumulate in the
ashpan.Excessashwillblocktherequiredairowthrough
thegratesandcausethemtowarpandsag.Neglectisnot
coveredbyyourstove’swarranty.
Ashes should be placed in a metal container with a
tight tting lid. This closed container of ashes should
be placed on a noncombustible oor or on the ground,
well away from any combustible materials, pending
nal disposal. If the ashes are disposed of by burial
in soil, or otherwise locally dispersed, they should be
retained in the closed container until all cinders have
thoroughly cooled.
Fuel
The SF250 is approved for burning anthracite coal. Pea,
Nut,andStovesizedcoalareallsuitable.
Grates
Thefunctionsofagratesystemaretosupportthefuelload,
while allowing air ow to the re in a balanced amount.
Anotherfunctionistoallowforashremovalwithoutlosing
there.TheSF250gratesystemprovidesforallofthisand
canberemovedwithnotoolsrequired.

10 3-90-70738R9_08/13
MAINTENANCE
GRATE LINK
GRATES
SHAKER
BAR
SHAKER
HANDLE
(external)
Close-up view of grate system components
Periodic and Normal Everyday Maintenance
BlowerMotor-Cleanperiodicallytoremovepethairandlint
fromtheintakeandfan.
Grates-Keepashpanempty.
CAUTION: BEFORE CLEANING THE CHIMNEY AND
SMOKE PIPE, BE SURE THE FIRE IS OUT AND THE
STOVEISCOOL.
Avoid Chimney Fires. On a regular schedule, check for
creosoteandsootbuildupinthechimney,smokepipe,and
spiral chamber. These areas must be kept clean. Keep a
professionalchimneysweepinmind.
Steel brushes are the safest for cleaning metal surfaces.
Salt solutions and some chemical cleaners may damage
theueliner.
Tocleanthechimney,obtainastiffbrushwithanextendable
handle. Insert the brush  into the chimney from the top.
Continuebrushingandsweepingdownwarduntiltheentire
lengthofthechimneyiscleaned.
Aftercleaningthechimney,anydebriswillbeatthebottom
bytheclean-outdoor.Opentheclean-outandvacuumthe
loosedebris.
Cleanthesmokepipe,fromthechimneytothestove,using
ametalbrush.
Cleaning of the spiral chamber - Remove clean-out plate
fromthefrontofthestove.Usinga3/4”wrench,loosenthe
clean-out bolt approximately 2 turns. Slide the clean-out
platetoonesideandremoveitfromtheopening.Scrape
the spiral chamber with a putty knife or similar tool. The
residuewillfalldowntothebottomofthechamberandcan
be removed through the ue opening on the back of the
stovebymeansofavacuumcleanerorasmallscoop.
In the rebox, remove all ashes and vacuum the entire
rebox.Inspect and replaceany cracked rebricks.Since
coal and coal ashes will draw moisture, it is important
to thoroughly clean the rebox at the end of the heating
season.Someusersapplyathincoatingofoilorotherrust
inhibitortotheinsideworkings,overthesummer.Themain
thingisthatyouremovealloftheash.
Spiral Chamber Cleanout
Cleanout Plate Removed

11 3-90-70738R9_08/13
Example 1:Thermo-siphonMethod.Thisisthesimplestandmosteconomicalmethod,providingtheexistingwaterheater
(storagetank)iswithin10feetofthestove.Thewaterinlet,wheretheTemp/Pressurereliefvalveislocated,mustbehigher
thanthetoplegofthewatercoil.Thestoragetankshouldbeelevated,ifnecessary,toallowforproperthermo-siphonaction.
1. Turnoffthewaterheaterandthewatersupplytoit.Drainthetankcompletely.
2. RemovetheTemp/Pressurereliefvalveanddiscard.Installashort¾”nippleandtee(1)alongwithanewTemp/Pressure
reliefvalve.
3. Run¾”coppertubing,alongwiththenecessaryttings,betweenthestoragetankandthetoplegofthecoil.Installa
¾”ventelbowandautomatic“oattype”airvent(2)inthehighpointoftheline.Withintwofeetofthetoplegofthecoil,
installa150lb.pressurereliefvalve(7).Run¾”tubingfromthereleaseexitofbothreliefvalves,downward(3)sothat
thehotwatermayescapeintheeventofover-heating.
4. Removethedrainvalve,atthebottomofthestoragetank.Installa¾”nippleandtee,andreinstallthedrainvalvetothe
tee(4).Run¾”coppertubing,withthenecessaryttings,betweenthedrain/teecombinationandthelowerlegofthecoil.
Afteralloftheconnectionsarecompleted,youcanrellthetank.RestorepowertothewaterheaterONLYafterthetank
hasbeencompletelyrelled.
OPTIONAL BENT HOT WATER COIL
Optional Bent Hot Water Coil - Part #3-10-49202
Useaholesawandthetemplatesuppliedwiththecoilto
make two holes through the side wall of the stove. Keep
thecoilholesabovetherebrickandawayfromtheloading
door.Placeoneofthesuppliednutsoneachlegofthecoil.
Place the coil through the holes in the stove, and adjust
thenutssothatthepipesstickoutabout1¼”to1½”from
thesidewallofthestove.Putatwashersandnutsonthe
outside,andtightenwithin¼inch.Placeberglassgasket
aroundeachpipeatthewashersandtightensecurely.You
arenowreadytorunpipesaccordingtooneofthefollowing
examples.
EXAMPLE 1: Thermo-siphon Method.
(less than 10 feet.)
Outside Nut
Washer
Outside Nut
Packing Stove Side

12 3-90-70738R9_08/13
WATER COIL OPTION
Example 2:Circulatingpumpmethod.Usedwhenthedistanceismorethantenfeetorwhenthestoveisonahigherlevel
thantheexistingwaterheater.Inadditiontoacirculator,youmaywanttoaddaaquastattocontrolthepumpaccordingto
watertemperature.Thisisnotnecessaryifthecirculatorisleftruncontinuously.Anotheroptionisagatevalveplacednear
thecirculatortocontroltherateofow.
1. Turnoffthewaterheaterandthewatersupplytoit.Drainthetankcompletely.
2. RemovetheTemp/Pressurereliefvalveanddiscard.Installashort¾”nippleandtee(1)alongwithanewTemp/Pressure
reliefvalve.
3. Removethedrainvalve,atthebottomofthestoragetank.Installa¾”nippleandtee,andreinstallthedrainvalvetothe
tee(4).
4. Installacirculatingpump(6)asshown.Run¾”coppertubingfromthecirculatortothelowerlegofthecoil.Thisiswhere
theoptionalgatevalve(5)canbeinstalled.
5. Installa¾”teeanda150lb.pressurereliefvalve(7)inthetoplegwithin2feetofthetopoutletofthewatercoil.
6. Completethecopperlinebyrunningitbacktotheteeatthetopofthewatertank,makingsuretoinstallaventelbow
andautomaticairvent(2)atthehighpointoftheline.Theoptionalaquastatcanbeinstalledinthislineamaximumof
sixfeetfromthestove.Theaquastatmustbea“closeontemperaturerise”typeandmustbewiredandsettoturnonthe
circulatorwhenthewatertemperaturereaches120˚Farenheit.
ThesystemisnowreadytoberelledandpowerrestoredtothewaterheaterONLYafterthetankislled.
EXAMPLE 2: Circulator Method.
(more than 10 feet.)

3-90-70738R9_08/13
TESTING LABEL
*Thisapplianceisalsoapprovedforinstallationintoashop
SAMPLE

3-90-70738R9_08/13
14
4021-645F02-18-13
Page1of2
Hearth & Home Technologies
LIMITED LIFETIME WARRANTY
Hearth&HomeTechnologies,onbehalfofitshearthbrands(”HHT”),extendsthefollowingwarrantyforHHT
gas,wood,pellet,coalandelectrichearthappliancesthatarepurchasedfromanHHTauthorizeddealer.
WARRANTY COVERAGE:
HHTwarrantstotheoriginalowneroftheHHTapplianceatthesiteofinstallation,andtoanytransfereetakingownership
oftheapplianceatthesiteofinstallationwithintwoyearsfollowingthedateoforiginalpurchase,thattheHHTappliance
willbefreefromdefectsinmaterialsandworkmanshipatthetimeofmanufacture.Afterinstallation,ifcoveredcompo-
nentsmanufacturedbyHHTarefoundtobedefectiveinmaterialsorworkmanshipduringtheapplicablewarrantyperiod,
HHTwill,atitsoption,repairorreplacethecoveredcomponents.HHT,atitsowndiscretion,mayfullydischargeallofits
obligationsundersuchwarrantiesbyreplacingtheproductitselforrefundingtheverifiedpurchasepriceoftheproduct
itself.Themaximumamountrecoverableunderthiswarrantyislimitedtothepurchasepriceoftheproduct.Thiswarranty
issubjecttoconditions,exclusionsandlimitationsasdescribedbelow.
WARRANTY PERIOD:
Warrantycoveragebeginsonthedateoforiginalpurchase.Inthecaseofnewhomeconstruction,warrantycoverage
beginsonthedateoffirstoccupancyofthedwellingorsixmonthsafterthesaleoftheproductbyanindependent,
authorizedHHTdealer/distributor,whicheveroccursearlier.Thewarrantyshallcommencenolaterthan24months
followingthedateofproductshipmentfromHHT,regardlessoftheinstallationoroccupancydate.Thewarrantyperiodfor
partsandlaborforcoveredcomponentsisproducedinthefollowingtable.
Theterm“LimitedLifetime”inthetablebelowisdefinedas:20yearsfromthebeginningdateofwarrantycoveragefor
gasappliances,and10yearsfromthebeginningdateofwarrantycoverageforwood,pellet,andcoalappliances.These
timeperiodsreflecttheminimumexpectedusefullivesofthedesignatedcomponentsundernormaloperatingconditions.
Seeconditions,exclusions,andlimitationsonnextpage.
Parts Labor Gas Wood Pellet EPA
Wood
Coal Electric Venting
XXXXXXX
Allpartsandmaterialexceptas
coveredbyConditions,
Exclusions,andLimitations
listed
XXX
Igniters,electroniccomponents,
andglass
X X X X X Factory-installedblowers
X Moldedrefractorypanels
X Firepotsandburnpots
5years 1year X X Castingsandbaffles
7years 3years X X X Manifoldtubes,
HHTchimneyandtermination
10
years
1year X Burners,logsandrefractory
Limited
Lifetime
3years X X X X X Fireboxandheatexchanger
XXXXXXX Allreplacementparts
beyondwarrantyperiod
WarrantyPeriod HHTManufacturedAppliancesandVenting
1Year
ComponentsCovered
3years
2years
90Days

3-90-70738R9_08/13
15
4021-645F02-18-13 Page2of2
WARRANTY CONDITIONS:
• ThiswarrantyonlycoversHHTappliancesthatarepurchasedthroughanHHTauthorizeddealerordistributor.Alistof
HHTauthorizeddealersisavailableontheHHTbrandedwebsites.
• ThiswarrantyisonlyvalidwhiletheHHTapplianceremainsatthesiteoforiginalinstallation.
•ThiswarrantyisonlyvalidinthecountryinwhichtheHHTauthorizeddealerordistributorthatsoldtheappliance
resides.
• Contactyourinstallingdealerforwarrantyservice.Iftheinstallingdealerisunabletoprovidenecessaryparts,contact
thenearestHHTauthorizeddealerorsupplier.Additionalservicefeesmayapplyifyouareseekingwarrantyservice
fromadealerotherthanthedealerfromwhomyouoriginallypurchasedtheproduct.
• Checkwithyourdealerinadvanceforanycoststoyouwhenarrangingawarrantycall.Travelandshippingcharges
forpartsarenotcoveredbythiswarranty.
This warranty is void if:
• Theappliancehasbeenover-firedoroperatedinatmospherescontaminatedbychlorine,fluorine,orotherdamaging
chemicals.Over-firingcanbeidentifiedby,butnotlimitedto,warpedplatesortubes,rustcoloredcastiron,bubbling,
crackinganddiscolorationofsteelorenamelfinishes.
• Theapplianceissubjectedtoprolongedperiodsofdampnessorcondensation.
• Thereisanydamagetotheapplianceorothercomponentsduetowaterorweatherdamagewhichistheresultof,but
notlimitedto,improperchimneyorventinginstallation.
LIMITATIONS OF LIABILITY:
• Theowner’sexclusiveremedyandHHT’ssoleobligationunderthiswarranty,underanyotherwarranty,expressor
implied,orincontract,tortorotherwise,shallbelimitedtoreplacement,repair,orrefund,asspecifiedabove.Inno
eventwillHHTbeliableforanyincidentalorconsequentialdamagescausedbydefectsintheappliance.Somestates
donotallowexclusionsorlimitationofincidentalorconsequentialdamages,sotheselimitationsmaynotapplytoyou.
Thiswarrantygivesyouspecificrights;youmayalsohaveotherrights,whichvaryfromstatetostate.EXCEPTTO
THEEXTENTPROVIDEDBYLAW,HHTMAKESNOEXPRESSWARRANTIESOTHERTHANTHEWARRANTY
SPECIFIEDHEREIN.THEDURATIONOFANYIMPLIEDWARRANTYISLIMITEDTODURATIONOFTHE
EXPRESSEDWARRANTYSPECIFIEDABOVE.
WARRANTY EXCLUSIONS:
Thiswarrantydoesnotcoverthefollowing:
• Changesinsurfacefinishesasaresultofnormaluse.Asaheatingappliance,somechangesincolorofinteriorand
exteriorsurfacefinishesmayoccur.Thisisnotaflawandisnotcoveredunderwarranty.
• Damagetoprinted,plated,orenameledsurfacescausedbyfingerprints,accidents,misuse,scratches,melteditems,
orotherexternalsourcesandresiduesleftontheplatedsurfacesfromtheuseofabrasivecleanersorpolishes.
• Repairorreplacementofpartsthataresubjecttonormalwearandtearduringthewarrantyperiod.Theseparts
include:paint,wood,pelletandcoalgaskets,firebricks,grates,flameguides,batteriesandthediscolorationofglass.
• Minorexpansion,contraction,ormovementofcertainpartscausingnoise.Theseconditionsarenormalandcom-
plaintsrelatedtothisnoisearenotcoveredbythiswarranty.
• Damagesresultingfrom:(1)failuretoinstall,operate,ormaintaintheapplianceinaccordancewiththeinstallation
instructions,operatinginstructions,andlistingagentidentificationlabelfurnishedwiththeappliance;(2)failureto
installtheapplianceinaccordancewithlocalbuildingcodes;(3)shippingorimproperhandling;(4)improperopera-
tion,abuse,misuse,continuedoperationwithdamaged,corrodedorfailedcomponents,accident,orimproperly/
incorrectlyperformedrepairs;(5)environmentalconditions,inadequateventilation,negativepressure,ordrafting
causedbytightlysealedconstructions,insufficientmake-upairsupply,orhandlingdevicessuchasexhaustfansor
forcedairfurnacesorothersuchcauses;(6)useoffuelsotherthanthosespecifiedintheoperatinginstructions;(7)
installationoruseofcomponentsnotsuppliedwiththeapplianceoranyothercomponentsnotexpresslyauthorized
andapprovedbyHHT;(8)modificationoftheappliancenotexpresslyauthorizedandapprovedbyHHTinwriting;
and/or(9)interruptionsorfluctuationsofelectricalpowersupplytotheappliance.
• Non-HHTventingcomponents,hearthcomponentsorotheraccessoriesusedinconjunctionwiththeappliance.
• Anypartofapre-existingfireplacesysteminwhichaninsertoradecorativegasapplianceisinstalled.
• HHT’sobligationunderthiswarrantydoesnotextendtotheappliance’scapabilitytoheatthedesiredspace.Informa-
tionisprovidedtoassisttheconsumerandthedealerinselectingtheproperappliancefortheapplication.Consider-
ationmustbegiventoappliancelocationandconfiguration,environmentalconditions,insulationandairtightnessof
thestructure.

16 3-90-70738R9_08/13
Date Of Service Performed By Description Of Service
Service & Maintenance Log

17 3-90-70738R9_08/13
NOTES

Proudly Printed On 100% Recycled Paper
At Harman®, we build each product to a standard, not a price.
(Signature of Boxer)
Your premium quality hearth product designed and assembled by the
experienced and skilled members at Harman® in Halifax, PA, USA.
