Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2018390-044I
Installation Manual
Installation and Appliance Setup
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Model(s):
P43-C, P61-C & P68-C
Freestanding Pellet Stove
NOTICE: SAVE THESE INSTRUCTIONS
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com
Pour obtenir une traduction française de ce manuel, s’il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com
NOTE
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
ammable materials.
• Keepclothing,furniture,draperiesandotherammable
materials away.
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
WARNING
Please read this entire manual before
installation and use of this pellet fuel-
burning room heater.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
• Donotstoreorusegasolineorotherammablevapors
and liquids in the vicinity of this or any other appliance.
• Donotoverre-Ifanyexternalpartstartstoglow,you
areoverring.Reducefeedrate.Overringwillvoid
your warranty.
• Comply with all minimum clearances to combustibles
asspecied.Failuretocomplymaycausehousere.
WARNING
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Contactlocalbuildingorreo󰀩cialsaboutrestrictions
and installation inspection requirements in your area.
CAUTION

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2028390-044I
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the stove or to property.
Installation Standard Work Checklist...............3
1 Product Specic and Important Safety Information
A.ApplianceCertication .......................4
B.GlassSpecications .........................4
C. Mobile Home Approvals ......................4
D. California Safety Information ..................4
E.BTUSpecications ..........................5
F. Non-CombustibleMaterialsSpecication .........5
G.CombustibleMaterialsSpecication.............5
H. Electrical Codes ............................5
2 Getting Started
A. Design and Installation Considerations ..........6
B. Tools and Supplies Needed ...................7
C. Inspect Appliance and Components .............7
3 Framing and Clearances
A. Appliance Dimension Diagram .................8
B. Clearances to Combustibles...................9
C. Floor Protection ...........................10
D. Mobile Home Installation ....................10
4 Termination Location and Vent Information
A. Vent Termination Minimum Clearances ......... 11
B. Chimney Diagram ..........................15
C. Venting & Use of Elbows ....................16
D.OutsideAir ...............................18
E. Locating Your Appliance and Chimney ..........19
F. Draft ....................................19
G. Negative Pressure .........................19
H.AvoidingSmoke&Odors ....................20
I. Fire Safety ...............................21
J. Inspect Appliance & Components..............21
5 Appliance Setup
A. Unpacking................................22
B. Removing Rear Cover Panels ................22
C. Firebrick .................................22
D. Flame Guide ..............................22
E. Room Sensor .............................23
F. Low Draft Voltage Adjustment.................23
6 Reference Materials
A. Safety Reminders ..........................24
B. Wiring Diagram ............................25
= Contains updated information


Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2038390-044I
Installation Standard Work Checklist
ATTENTION INSTALLER:
Follow this Standard Work Checklist
This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in
this installation manual.
Customer: ________________________________ Date Installed: __________________________
Lot/Address: ________________________________ Location of Stove: __________________________
________________________________ Installer: __________________________
Model: ________________________________ Dealer/Distributer Ph #__________________________
Serial Number: __________________________
!
WARNING! Risk of Fire or Explosion! Failure to install appliance to these instructions can lead to a re
or explosion.
Appliance Install Section 3 YES IF NO, WHY?
Required non-combustible oor protection ________________________________
Veried clearances to combustible. ________________________________
Unit is Leveled and secured. ________________________________
Venting/Chimney Section 4
Venting Conguration complies to vent diagrams. ________________________________
Venting installed, sealed and secured in place with proper clearances. ________________________________
Exterior wall/roof ashing installed and sealed ________________________________
Terminations installed and sealed. ________________________________
Electrical Section 1
120 VAC unswitched power provided to the appliance. ________________________________
Check outlet with multi-meter for proper voltage. (115-120 VAC) ________________________________
Record voltage reading: ___________
Appliance Setup Section 5
All packaging and protective materials are removed ________________________________
Accessories installed properly ________________________________
Manual bag and all it’s contents are removed from inside the appliance
and given to party responsible for use and operation ________________________________
Started appliance and veried that all motors and blowers operate
as they should. ________________________________
Checked draft using a Manometer. Record readings: __________ ________________________________
Hearth and Home Technologies recommends the following:
Photographing the installation and copying this checklist for your le.
This checklist remain visible at all times on the appliance until the installation is complete.
Comments: Further description of the issues, who is responsible (Installer/Builder/Other Trades, etc.) and corrective action
needed __________________________________________________________________________________________
_________________________________________________________________________________________________
_________________________________________________________________________________________________
Comments communicated to party responsible____________________ by ________________________ on __________
(Builder / Gen Contractor) (Installer) (Date)
04/17

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2048390-044I
A. Appliance Certication B. Glass Specications
This appliance is equipped with 5mm mirrored ceramic
glass. Replace glass only with 5mm ceramic glass. Please
contact your dealer for replacement glass.
C. Mobile Home Approved
This appliance is approved for mobile home installations
when not installed in a sleeping room and when an outside
combustion air inlet is provided.
Thestructuralintegrityofthemobilehomeoor,ceiling,and
walls must be maintained. The appliance must be properly
grounded to the frame of the mobile home and use only listed
pellet vent, Class “PL” connector pipe.
A Harman®OutsideAirKitmustbeinstalledinamobilehome
installation.
NOTE: This installation must conform with local codes.
In the absence of local codes you must comply with
the ASTM E1509-2004, ULC-S627-00, ULC/ORD-C-
1482-M1990, (UM) 84-HUD
11 Product Specic and Important Safety Information
MODEL: P43-CPelletStove
LABORATORY: OMNITestLaboratories,Inc
REPORT NO. 0135PS023E / 0135PS023S
TYPE: Pellet Fueled/Supplementary For
Residential Use
STANDARD(s): ASTME1509-04,ULC-S627-00,
ASTME2515-11,ASTME2779-10
MODEL: P61-CPelletStove
LABORATORY: OMNITestLaboratories,Inc
REPORT NO. 0135PS022E / 0135PS022S
TYPE: Pellet Fueled/Supplementary For
Residential Use
STANDARD(s): ASTME1509-04,ULC-S627-00,
ASTME2515-11,ASTME2779-10
MODEL: P68-CPelletStove
LABORATORY: OMNITestLaboratories,Inc
REPORT NO. 0135PS013E / 0135PS013S
TYPE: Pellet Fueled/Supplementary For
Residential Use
STANDARD(s): ASTME1509-04,ULC-S627-00,
ASTME2515-11,ASTME2779-10
THE STRUCTURAL INTEGRITY OF THE
MANUFACTURED HOME FLOOR, WALL, AND
CEILING/ROOF MUST BE MAINTAINED.
DO NOT INSTALL IN SLEEPING ROOM.
WARNING
!WARNING
This product and the fuels used to operate this product
(wood), and the products of combustion of such fuels, can
expose you to chemicals including carbon black, which
is known to the State of California to cause cancer, and
carbonmonoxide,whichisknowtotheStateofCalifornia
to cause birth defects or other reproductive harm. For
more information go to: www.P65Warnings.ca.gov
D. California Safety Information
The P43-C, P61-C and P68-C is Certied
to comply with 2020 particulate emission
standards.

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2058390-044I
NOTE: Hearth & Home Technologies, manufacturer of
this appliance, reserves the right to alter its products, their
specicationsand/orpricewithoutnotice.
Harman®is a registered trademark of Hearth & Home
Technologies.
F. Non-Combustible Materials Specication
Material which will not ignite and burn. Such materials are
those consisting entirely of steel, iron, brick, tile, concrete,
slate, glass or plasters, or any combination thereof.
Materials that are reported as passing ASTM E 136,
Standard Test Method for Behavior of Materials in
a Vertical Tube Furnace at 750° C and UL763 shall be
considerednon-combustiblematerials.
G. Combustible Materials Specication
Materials made of or surfaced with wood, compressed
paper,plantbers,plastics,orothermaterialthatcanignite
andburn,whetherameproofedornot,orplasteredorun-
plastered shall be considered combustible materials.
H. Electrical Codes
120 VAC, 60 Hz, Start 4.2 Amps, Run 2.8 Amps
NOTE: Some generator or battery back-up systems may
not be compatible with the micro-processor electronics
on this appliance. Please consult the power supply
manufacturer for compatible systems.
WARNING! Risk of Fire! Hearth & Home Technologies
disclaims any responsibility for, and the warranty and agency
listing will be voided by the below actions.
DO NOT:
• Install or operate damaged appliance
• Modify appliance
• Install other than as instructed by Hearth & Home
Technologies
• Operate the appliance without fully assembling all
components
 • Overre
• Install any component not approved by Hearth &
Home Technologies
• Install parts or components not Listed or approved.
• Disable safety switches
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Forassistanceoradditionalinformation,consultaqualied
installer, service agency or your dealer.
E. BTU & E󰀩ciency Specications
*WeightedaverageLHVeciencyusingdatacollected
during EPA emissions test.
**WeightedaverageHHVeciencyusingdatacollected
during EPA emissions test.
***ArangeofBTUoutputsbasedonEPADefaultEciency
and the burn rates from the low and high EPA tests.
****Based on the maximum feed rate per hour multiplied by
approximately 8,600 BTU’s which is the average BTU’s from
a pound of pellets.
This wood heater needs periodic inspection and repair for
proper operation. It is against federal regulations to operate
this wood heater in a manner inconsistent with operating
instructions in this manual.
P43-C Freestanding Pellet Stove:
EPA Certication Number: 165-18
EPA Certied Emissions: .95 g/hr
*LHV Tested E󰀩ciency: 83.5%
**HHV Tested E󰀩ciency: 77.9%
***EPA BTU Output: 16,600-30,900
****BTU Input: 17,200-43,500
Vent Size: 3 Inch
Hopper Capacity: 50 lbs
Fuel Wood Pellet
P61-C Freestanding Pellet Stove:
EPA Certication Number: 177-19
EPA Certied Emissions: 1.5 g/hr
*LHV Tested E󰀩ciency: 85%
**HHV Tested E󰀩ciency: 79%
***EPA BTU Output: 17,100-46,800
****BTU Input: 21,400-60,700
Vent Size: 3 Inch
Hopper Capacity: 72 lbs
Fuel Wood Pellet
P68-C Freestanding Pellet Stove:
EPA Certication Number: 178-19
EPA Certied Emissions: 1.4 g/hr
*LHV Tested E󰀩ciency: 85%
**HHV Tested E󰀩ciency: 79.5%
***EPA BTU Output: 15,900-53,100
****BTU Input: 20,200-67,600
Vent Size: 3 Inch
Hopper Capacity: 76 lbs
Fuel Wood Pellet

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2068390-044I
A. Design and Installation Considerations
1. Appliance Location
NOTICE: Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult insurance carrier, local building inspector,
re o󰀩cials or authorities having jurisdiction over
restrictions, installation inspection and permits.
Itisagoodideatoplanyourinstallationonpaper,usingexact
measurementsfor clearancesand oorprotection, before
actually beginning the installation
Consideration must be given to:
• Safety,convenience,tra󰀩cow
• Placement of the chimney and chimney connector.
• If you are not using an existing chimney, place the
appliance where there will be a clear passage for a
factory-built listed chimney through the ceiling and
roof.
• Installinganoptional outside air kitwoulda󰀨ect the
location of the vent termination.
Sincepellet exhaustcancontainash,soot orsparks,you
must consider the location of:
• Windows
• Air Intakes
• Air Conditioner
• Overhang,so󰀩ts,porchroofs,adjacentwalls
• Landscaping, vegetation
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended:
Outside Air Intake
on windward side
NOT recommended:
Outside Air Intake
on leeward side
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 2.1
22 Getting Started
When locating vent and venting termination, vent above
roof line when possible.
Warning! Risk of Fire Damaged parts could impair safe
operation. Do NOT install damaged, incomplete or substitute
components.
NOTICE: Locating the appliance in a location of considerable
air movement can cause intermittent smoke spillage from
appliance. Do not locate appliance near:
• Frequently open doors
• Central heat outlets or returns
Installation and service of this appliance should be performed by
qualiedpersonnel.Hearth&HomeTechnologiesrecommends
HHTFactoryTrainedorNFIcertiedprofessionals.

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2078390-044I
Reciprocating Saw
Hammer
Phillips Screwdriver
Tape Measure
Level
Non-CombustibleSealant
Material
Gloves
Safety Glasses
Electric Drill & Bits
May also need:
Vent Support Straps
Venting Paint
Tools and building supplies normally required
for installation, unless installing into an existing
masonry replace:
B. Tools And Supplies Needed
C. Inspect Appliance and Components
• Carefully remove the appliance and components from
the packaging.
• The vent system components and decorative doors
and fronts may be shipped in separate packages.
• Report to your dealer any parts damaged in shipment,
particularly the condition of the glass.
•Read all of the instructions before starting the
installation. Follow these instructions carefully
during the installation to ensure maximum safety
and benet.
Hearth & Home Technologies disclaims any responsibility
for, and the warranty will be voided by the following actions:
• Installation and use of any damaged appliance or
vent system component.
• Modicationoftheapplianceorventsystem.
• Installation other than as instructed by Hearth &
Home Technologies.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies.
Any such action may cause a re hazard.
WARNING
Risk of Fire, Explosion or Electric Shock! DO NOT use
this appliance if any part has been under water. Call a
qualied service technician to inspect the appliance
and to replace any part of the control system which
has been under water.
INSTALL EXHAUST VENT AT CLEARANCES SPECIFIED
BY THE MANUFACTURER.
Most pellet vent pipe requires a minimum of 1" of clearance
to combustible materials although some can be installed at
1" clearance.
Follow these instructions along with all local codes regarding
installation of this appliance.
Do NOT use makeshift compromises when installing this
appliance, serious consequences may result.
WARNING
RISK OF FIRE OR EXPLOSION! Damaged parts
could impair safe operation. DO NOT install damaged,
incomplete or substitute components. Keep appliance
dry.

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2088390-044I
33 Clearances
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only.
Figure 3.1
20 3/4"
22"
10"
33 1/2"
5 1/8"
13 3/4"
28 5/16"
Outside
Air Intake
P43-C Freestanding Pellet Stove
23 1/2"
10 "
36 1/2"
5 1/8"
13 3/4”
29 3/8"
Outside
Air Intake
P61-C Freestanding Pellet Stove
10 "
37 1/2”
5 1/4"
13 3/4”
29 3/8"
23-1/2”
Outside
Air Intake
P68-C Freestanding Pellet Stove

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2098390-044I
Place the stove away from combustible walls at least as far
asshowninFigure3.2.Pleasenotethedi󰀨erenceinside
wall clearance with and without side shields.
Note that the clearances shown are minimum for safety but do
not leave much room for access when cleaning or servicing.
Please take this into account when placing the stove.
Due to high temperatures, the stove should be placed out of
tra󰀩candawayfromfurnitureanddraperies.
Children and adults should be alerted to the hazards of high
surface temperatures and should stay away to avoid burns
to skin and/or clothing.
Young children should be carefully supervised when they are
in the same room as the stove.
Clothingandotherammablematerialsshouldnotbeplaced
on or near this unit.
B. Clearances to Combustibles
When selecting a location for the appliance it is important to
consider the required clearances to walls, Figure 3.2.
CAUTION
THIS APPLIANCE MUST BE VENTED TO THE OUTSIDE.
WARNING
RISK OF FIRE OR BURNS! Provide adequate
clearance around air openings and for service
access. Due to high temperatures, the appliance should
be located out of trac and away from furniture and
draperies.
NOTICE: IllustrationsreecttypicalinstallationsandareFOR
DESIGNPURPOSESONLY.Actualinstallationmayvarydue
to individual design preference.
Figure 3.2
9"(228mm)With Side Shields
13"(330mm) Without Side Shields
9"(228mm)-
13"(330mm)
9"(228mm)- 13"(330mm)
9" (228mm) With or Without Side Shields
9"(228mm)
9"(228mm)
*10" (254mm) with
side shields
*16" (406mm)
without side shields
2" (51mm)
36" (914mm)
*10" (254mm)
*16" (406mm)
2" (51mm)
36" (914mm)
14" (355mm)
20" (508mm)
14" (355mm) with
side shields
20" (508mm)
without side shields
P43-C Freestanding Pellet StoveP61-C & P68-C Freestanding Pellet Stove

Harman® • P-Series Installation Manual_R3 • 2018 - ___ • 09/2010 8390-044I
C. Floor Protection
Parallel Installation:
Place the stove on a noncombustible type oor or oor
protectorthatextendsaminimumof6inches(152mm)to
the front of the load door opening, 6 inches (152mm) to the
sides of the door opening, and 6 inches to the rear.
TheP-SeriesdoesnotrequireRvalueoorprotection.
Theminimumoorprotectormaterialis20gaugesheetmetal.
OtheroorprotectormaterialsthatcanbeusedincludeType
I hearth pads, ceramic tile, stone, brick, etc. Figure 3.3
*Floor protection dimensions for the front and sides are
measured from the appliance door opening in The United
States. In Canada, the side dimension is measured from the
widest part of the appliance.
P43-C - Minimum size rectangular oor protection is 25-
7/16”Wideby26-3/4”Deep(646mmX680mm).
P61-C-Minimumsizerectangularoorprotectionis25-1/8”
Wideby27-3/4”Deep(638mmX705mm).
P68-C - Minimum size rectangular oor protection is 25-
3/16”Wideby27-3/4”Deep(640mmX705mm).
Venting:
US-Follow PL vent manufacturers recommendations when
conguringventpipeinstallation.
Canada-Mustextend2”(51mm)beyondeachsideofany
horizontaluepipe.
Figure 3.3
J
K
L
Floor Protector
D. Mobile Home Installation
When installing this unit in a mobile home, several
requirements must be followed:
1. Theunitmustbeboltedto the oor.Thiscanbedone
using an appropriate fastener for the application.
2. The unit must also be connected to outside air. See
“Termination Location and Vent Information” Section D.
3. Floor protection and clearances must be followed as
shown.
4. The appliance must be properly grounded to the frame of
the mobile home using a minimum of 8 AWG copper solid
or stranded, insulated or bare wire or equivalent.
Floor Protection
Requirements US Canada
JSides 6" 152mm
KFront 6” 152mm
LRear 6” 152mm
Corner Installation:
Minimumsizeoorprotectionforacornerinstallationhearth
pad is:
P43-C-Minimumsizeoorprotectionis25-7/16”Wideby
26-3/4”Deep(646mmX680mm).
P61-C- Minimumsize oorprotection is 25-1/8” Wide by
27-3/4”Deep(638mmX705mm).
P68-C-Minimumsizeoorprotectionis25-3/16”Wideby
27-3/4”Deep(640mmX705mm).
Note: Floor protector WILL NOT touch the wall using
minimum clearances.
If corner oor protection is desired to touch the wall, the
oorprotectionwillneedtobeatleast40”x40”(1016mm
x1016mm).Note: This will allow the oor protection to
touch the wall as shown. Figure 3.4.
Alternateoorprotectordimensionmaybeusedaslongas
they satisfy the measurement requirements shown below.
Figure 3.4
