Harman CW-30 Assembly instructions

CW-30 “Harman E” Repair Guide 1
Disassembling Instructions and Parts Identication
There are quite a few of the CW-30 stoves still in use out there.
This guide will help you to identify parts and pieces while also providing instruction for replacing
gaskets and/or other various components.
What better way to learn about a stove than to take it apart and put it back together?

CW-30 “Harman E” Repair Guide 2
To begin dismantling the stove, remove the Harman Logo plate from the center of the top.
This will expose a nut which secures the cast iron top to the stove.
Using a ½” socket or wrench, loosen and remove the nut. Then lift the top off of the stove.

CW-30 “Harman E” Repair Guide 3
The under side of the cast iron top is gasketed, mostly to prevent rattles of metal to metal
contact. This is ⅜” low density rope gasket (3-44-00888) attached with gasket cement.
Now you’ll see the inner top, which is held down with (6) ½” nuts and washers. Remove the
nuts and washers to lift the inner top.

CW-30 “Harman E” Repair Guide 4
Looking into the top of the rebox, you’ll see the wafe as shown below. Find a bolt or
screw to t the hole size (3/8” thread) and thread it into a hole near the center of the wafe.
This will provide a handle with which to manipulate the wafe. Lift up on the wafe and tilt
it back to drop it down and out.
Ceramic Fiber Wafe
Item # 3-40-00471

CW-30 “Harman E” Repair Guide 5
With the inner top removed, you’ll now see the damper (Damper Weldment # 1-10-00465)
and the combustion package. (Ceramic Fiber Combustion Package # 3-40-00472)
Pull forward and lift the combustion package out of the top of the stove. Use extra care
when handling the combustion package, as it does become brittle after burning.

CW-30 “Harman E” Repair Guide 6
This view shows the underside of the combustion package. Note the holes and the indents
for the damper frame bolts.
With the Package removed, you’ll see the top of the Pyrolite Ignitor Tunnel. You can also
now see the top of the damper and the damper frame ller plate.
Air Flow Holes, be
sure they are not
blocked.
Indents for damper
frame bolts.

CW-30 “Harman E” Repair Guide 7
Damper Frame Filler Plate
Damper Plate
Damper Frame Mounting Bolts
Front Of Stove
Damper open
Using a ½” wrench and socket, remove the (4) bolts which hold the damper frame up in the
top of the rebox. Be sure to secure the frame from below, as it will drop upon removal of
the last bolt.

CW-30 “Harman E” Repair Guide 8
This is the damper frame assembly (# 1-10-00641) and ller plate (# 1-10-00734) as it is
removed from the rebox.
Close up view of the
damper lift arm.
Front Of Stove
To remove the damper, loosen the two bolts and clips at the ends of the damper plate. The
damper lift arm can be removed by rst removing the external brass elbow. Then pull the
damper lift arm in through the stove wall. (Damper Arm Weldment # 1-10-00638)

CW-30 “Harman E” Repair Guide 9
Damper Frame Assembly Item # 1-10-00641
and Damper Filler Plate Item # 1-10-00734
Note how the ller plate lays in the damper
frame channel, with the end tabs inside.
3/8” Rope # 3-44-00888
1/4” rope # 3-44-108636

CW-30 “Harman E” Repair Guide 10
Remove the Arch Brick (cast iron or refractory) by lifting up slightly then pull the bottom
toward the front of the stove.
Next would be the side bricks. Note the insulation panel on the back side of the side bricks.
There are two side bricks on each side of the rebox.
Arch Brick Item
# 3-40-00615
Right Support Brick
Item # 3-40-00468-2
Left Support Brick
Item # 3-40-00468-1
Ramp Brick
Item # 3-40-
00470
Side Brick (4 total)
Item # 3-40-00469
and insulation backer
