Harmar Mobility AL001 Installation instructions

your
AL001

AL001 Users Manual
Harmar Mobility
Rev.1 June 2008
Please read the manual before using.
WARNING!
A"warning"indicates"a"potentially"dangerous
situation,"which"if"not"avoided,"could"result"in"death
or"serious"injury.
1. Read all instructions and save them for future
reference.
2. Follow all warnings and instructions marked on the
product.
3. Do not ride any vehicle while loading onto the carrier.
4. Do not stand on the carrier.
5. Never exceed vehicle tongue weight ratings.
6. Always store the carrier in a safe place.
7. Only use the carrier with Class 2, 3 or larger hitch.
8. Improper use, storage or installation of carrier could
result in death or serious injury.

9. Do not put the product on any kinds of trailers.
10. Carrying capacity is limited to 500 lbs. max.
Assembly Instructions
Tools Need:
5/8” wrench
1/2” wrench
3/4” wrench
9/16” wrench
Phillips screwdriver
Step.1
Insert the hitch into the carrier rack. See the figure
Step.2
Insert four 3/8”x7/8” bolts on the bottom of your carrier tube.
Tighten bolts firm with a wrench. See the figure.

Step.3
Screw spring pull pin into carrier. Add reflectors. See the figure.
Step.4
Screw spring pull pin into jam nut. Screw spring pull pin into ramp
bracket. Bolt bracket to frame. Secure with nuts and lock washers.
See the figure.
NOTE! To prevent loosening of the spring pull pin, torque the jam
nut tightly against the ramp bracket.
When in use:
Use safety pin to adjust the hitch. See the figure.

Insert the spring pull pin into the hole on the ramp when you stand
the ramp. See the figure.
ATTENTION!
For the first installation of the anti-tilt lock bracket insert the
carrier into the hitch receiver. Do not insert the hitch pin at this
point. Now slide the carrier toward the vehicle until it holds the anti-
tilt lock bracket while an additional person holds the carrier
securely against the hitch receiver.
BE SURE TO TORQUE THE BOLTS TO 35-40FT
LBS.

Next loosen the bolts on the anti-tilt lock bracket. (There
should be grooves where the bolts were tightened against the hitch
receiver)
This procedure is required only during the initial installation of
the anti-tilt lock bracket as for the grooves will ensure repeated
relocating of the anti-tilt lock bracket. Now pull the carrier out to its
final location and install the hitch pin. Return the anti-tilt lock
bracket to the location securely against the hitch receiver and
torque the bolts.
THE BOLTS SHOULD FALL INTO THE
GROOVES CREATED EARLIER IN THIS
PROCEDURE.

ATTENTION:
Large chain loops on trailer hitches will not accept the anti-tilt
locking device. In this case you will be unable to use the
supplied anti-tilt locking devise.

Assembly

Parts List
Index
Description
Quantity
1
ramp
1
2
ramp bolt sets
2
3
Carriage bolt sets
2
4
Ramp bracket
1
5
Spring pull pin
2
6
reflector
2
7
carrier tray
1
8
gear
1
9
hitch pin
1
10
M12x70 bolt
1
11
adjust bolt
1
12
M10x30 bolt
3
13
anti tilt lock bracket
1
14
lock bolt
4

YOU MUST HAND WASH
OR USE A TOUCHLESS
AUTOMATIC CAR WASH
TO PREVENT LIFT DAMAGE.
IF YOU HAVE ANY QUESTIONS REGARDING
WASHING A CAR EQUIPPED WITH A HARMAR
LIFT PLEASE CALL THE HARMAR TECHNINCAL
SERVICES DEPARTMENT
