HART HLBL02VNM User manual

HLBL02VNM 40V
Blower
Soufflante
Sopladora
OPERATOR’S MANUAL
Important Safety Instructions 2-3
Symbols 4-5
Features 5
 Assembly 5-6
 Operation 6-7
Maintenance 8
 Parts/Service
Back page
MANUEL D’UTILISATION
Instructions importantes 2-3
concernant la sécurité
Symboles 4-5
Caractéristiques 5
 Assemblage 5-6
 Utilisation 6-7
Entretien 8
 Commandedepiècesetdépannage
  Pagearrière
MANUAL DEL OPERADOR
 Instruccionesdeseguridad 2-3
importantes
Símbolos 4-5
Características 5
 Armado 5-6
 Funcionamiento 6-7
Mantenimiento 8
 Pedidosdepiezasyservicio
  Pág.posterior
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
WARNING: To
reduce the risk of injury, the user must read
and understand the operator’s manual before
using this product.
CE LIVRET D’INSTRUCTIONS CONTIENT DES
CONSIGNES DE SÉCURITÉ IMPORTANTES.
VEUILLEZ LE LIRE ET LE CONSERVER POUR
TOUTE RÉFÉRENCE FUTURE.
AVERTISSEMENT:
Pour réduire les risques de blessures,
l’utilisateur doit lire et veiller à bien comprendre
le manuel d’utilisation avant d’employer ce
produit.
ESTE FOLLETO DE INSTRUCCIONES CONTIENE
INFORMACIÓN DE SEGURIDAD IMPORTANTE.
LÉALO Y CONSÉRVELO PARA REFERENCIA
FUTURA.
ADVERTENCIA:
Para reducir el riesgo de lesiones, el usuario
debe leer y comprender el manual del operador
antes de usar este producto.

ii
A - Blower tube (tube de soufflante, tubo de la sopladora)
B - Blower housing outlet (prise de boîtier de soufflante, salida del alojamiento de la sopladora)
C - Switch trigger (gâchette, gatillo)
See this fold-out section for all of the figures
referenced in the operator’s manual.
Consulter l’encart à volets afin d’examiner toutes les figures
mentionnées dans le manuel d’utilisation.
Consulte esta sección desplegable para ver todas las figuras
a las que se hace referencia en el manual del operador.
A
B
C
FIG. 1

iii
A - Switch trigger (gâchette, gatillo)
A - Tab (languette, orejeta)
B - Blower housing outlet (prise de boîtier
de soufflante, salida del alojamiento de la
sopladora)
C - Blower tube (tube de soufflante, tubo de la
aspiradora)
D - Slot (fente, ranura)
A
A
C
B
A - Battery pack (bloc-piles, paquete de baterías)
B - Battery port (logement de batteries, receptáculo para baterías)
C - Latch (loquet, pestillo)
D - Raised rib (épaulements surélevés, costillas realzadas)
B
PROPER OPERATING POSITION
BONNE POSITION DE TRAVAIL
POSICIÓN CORRECTA PARA EL MANEJO
DE LA HERRAMIENTA
D
A
C
D
FIG. 2 FIG. 4
FIG. 5
FIG. 3

2 – English
Whenusinganelectricalappliance,basicprecautionsshould
alwaysbefollowed,includingthefollowing:
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
BEFORE USING THIS BLOWER. Toreducetherisk
ofelectricshock,fireand/orseriouspersonalinjury.
Know your power blower. Read operator’s manual
carefully. Learn its applications and limitations, as
well as the specific potential hazards related to this
blower. Followingthisrulewillreducetheriskofelectric
shock,fire,orseriousinjury.
Do not permit children to use blower.Itisnotatoy.
Closeattentionisnecessarywhenusednearchildren.
Use only accessories that are recommended by the
manufacturer for your model described in this manual.
Accessories that may be suitable for one blower may
createariskofinjurywhenusedonanotherblower.Use
onlyasdescribedinthismanual.
Do not handle charger, including charger plug, and
charger terminals with wet hands.
Do not put any object into openings. Do not use with
any opening blocked; keep free of dust, lint, hair, and
anything that may reduce air flow.
Do not charge the unit outdoors.
Keep hair, loose clothing, fingers, and all parts of body
away from openings and moving parts.
Turn off all controls before removing battery.
Use extra care when cleaning on stairs or steps.
Do not operate blowers in explosive atmospheres,
such as in the presence of flammable liquids, gases,
or dust.Blowerscreatesparkswhichmayignitethedust
orfumes.
Keep your work area clean and well lit. Cluttered
benchesanddarkareasinviteaccidents.
Keep bystanders, children, and visitors at least 50 ft.
away while operating a blower. Distractions can cause
youtolosecontrol.
A battery operated blower with integral batteries or
a separate battery pack must be recharged only with
the specified charger for the battery. Achargerthat
may be suitable for one type of battery may create a risk
offirewhenusedwithanotherbattery.
Use battery operated blower only with specifically
designated battery pack. Use of any other batteries may
createariskoffire.
Use this product only with batteries and chargers
listed in tool/appliance/battery pack/charger correla-
tion supplement 995000885.
Do not operate charger with a damaged cord or plug,
which could cause shorting and electric shock.Ifdam-
aged,havethechargerreplacedbyanauthorizedservice
center.
Do not modify or attempt to repair the appliance or the
battery pack except as indicated in the instructions
for use and care.
If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into
water, return it to a service center.
Stay alert, watch what you are doing and use
common sense when operating a power blower. Do
not use blower while tired, upset, or under the influ-
ence of drugs, alcohol, or medication.Amomentof
inattention while operating blowers may result in serious
personalinjury.
Secure long hair above shoulder level to prevent en-
tanglement in moving parts.
Avoid accidental starting. Be sure switch is in the
locked or off position before inserting battery pack.
Carrying blowers with your finger on the switch or in-
serting the battery pack into a blower with the switch on
invitesaccidents.
Use safety equipment. Always wear eye protection.
Dustmask,non-skidsafetyshoes,hardhat,orhearing
protectionmustbeusedforappropriateconditions.
Do not wear loose clothing or jewelry. Contain long
hair. Looseclothes,jewelry,orlonghaircanbedrawn
intoairvents.
Do not use on a ladder, rooftop, tree, or other unstable
support. Stablefootingonasolidsurfaceenablesbetter
controloftheblowerinunexpectedsituations.
Do not use blower if switch does not turn it on or off.
A blower that cannot be controlled with the switch is
dangerousandmustberepaired.
Disconnect battery pack from blower or place the
switch in the locked or off position before making
any adjustments, changing accessories, or storing
the blower.Suchpreventivesafetymeasuresreducethe
riskofstartingthebloweraccidentally.
When battery pack is not in use, keep it away from
other metal objects like: paper clips, coins, keys, nails,
screws, or other small metal objects that can make
a connection from one terminal to another. Shorting
the battery terminals together may cause sparks, burns,
orafire.
Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the blower’s operation. If damaged, have the
blower serviced before using. Many accidents are
causedbypoorlymaintainedblowers.
IMPORTANT SAFETY INSTRUCTIONS

3 – English
Keep the blower and its handle dry, clean and free
from oil and grease. Always use a clean cloth when
cleaning. Never use brake fluids, gasoline, petroleum-
based products, or any strong solvents to clean your
blower.Followingthisrulewillreducetheriskoflossof
controlanddeteriorationoftheenclosureplastic.
Always wear safety glasses with side shields.
Everydayglasseshaveonlyimpactresistantlenses.They
areNOTsafetyglasses.Followingthisrulewillreduce
theriskofeyeinjury.
Always wear eye protection with side shields marked
to comply with ANSI Z87.1 along with hearing protec-
tion when operating this equipment.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Followingthis rule willreducethe
riskofseriouspersonalinjury.
Protect your hearing. Wear hearing protection during
extended periods of operation. Following this rule will
reducetheriskofseriouspersonalinjury.
Battery blowers do not have to be plugged into an
electrical outlet; therefore, they are always in operat-
ing condition. Be aware of possible hazards when not
using your battery powered blower or when changing
accessories. Followingthisrulewillreducetheriskof
electricshock,fire,orseriouspersonalinjury.
Do not place battery powered blowers or their batter-
ies near fire or heat. Thiswillreducetheriskofexplosion
andpossiblyinjury.
Don’t expose blowers to rain or wet conditions. Water
enteringablowerwillincreasetheriskofelectricshock.
Wear heavy long pants, long sleeves, boots, and
gloves.Avoidloosegarmentsorjewelrythatcouldget
caughtinmovingpartsofthemachineoritsmotor.
Do not operate the equipment while barefoot or when
wearing sandals or similar lightweight footwear.Wear
protectivefootwearthatwillprotectyourfeetandimprove
yourfootingonslipperysurfaces.
Keep firm footing and balance. Do not overreach.
Overreachingcanresultinlossofbalance.
Check the work area before each use. Remove all
objects such as rocks, broken glass, nails, wire, or
stringwhichcanbethrownorbecomeentangledinthe
machine.
Do not point the blower nozzle in the direction of
people or pets.
Never run the unit without the proper equipment at-
tached. Alwaysensuretheblowertubesareinstalled.
When not in use, blower should be stored indoors in
a dry, locked up place—out of the reach of children.
Do not hang unit so that the switch trigger is de-
pressed.
Keep all bystanders, children, and pets at least 50 ft.
away.
Do not dispose of a severely damaged or worn out
battery pack or this blower by incinerating. The battery
canexplodeinfire.
Blower service must be performed only by qualified
repair personnel.Serviceormaintenanceperformedby
unqualifiedpersonnelmayresultinariskofinjury.
When servicing a blower, use only identical replace-
ment parts. Follow instructions in the Maintenance sec-
tionofthismanual.Useofunauthorizedpartsorfailure
to follow Maintenance Instructions may create a risk of
shockorinjury.
Never use blower near fires, fireplaces, hot ashes,
barbecue pits, etc. Usenearfiresorashescanspread
firesandresultinseriousinjuryand/orpropertydamage.
Never use blower to spread chemicals, fertilizers,
or any other toxic substances.Spreadingthesesub-
stancescouldresultinseriousinjurytotheoperatoror
bystanders.
Never place blower on any surface, except a hard,
clean surface when motor is running. Gravel, sand,
andotherdebriscanbepickedupbytheairinletand
thrownattheoperatororbystanders,causingpossible
seriousinjuries.
Stop the motor, wait until all moving parts come to a
completestop,anddisconnectfromthepowersupply
beforecleaningorperforminganymaintenance.
Never use water or any liquids to clean or rinse off
your product and do not expose the product to rain or
wet conditions. Store indoors in a dry area.Corrosive
liquids, water, and chemicals can enter the product’s
electroniccomponentsand causedamage,which can
resultinashortcircuit,increasedriskoffire,andserious
personalinjury.Removeanybuildupofdirtanddebrisby
wipingtheproductcleanwithadryclothoccasionally.
For household use only.
Save these instructions.Refertothemfrequentlyand
usethemtoinstructotherswhomayusethistool.Ifyou
loansomeonethistool,loanthemtheseinstructionsalso.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS

4 – English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicatesapotentialpersonalinjuryhazard.
Read
Operator’s
Manual
Toreducetheriskofinjury,usermustreadandunderstandoperator’smanual
beforeusingthisproduct.
Eye and Hearing
Protection
AlwaysweareyeprotectionwithsideshieldsmarkedtocomplywithANSIZ87.1
alongwithhearingprotectionwhenoperatingthisequipment.
Impeller Blades Rotatingimpellerbladescancausesevereinjury.
Wet
Conditions Alert
Do not expose battery, battery compartment, or electronic components to rain,
water, or liquids. Do not charge battery or expose product to rain or damp
locations.
Keep Bystanders
Away Keepallbystandersatleast50ft.away.
Long Hair Failuretokeeplonghairawayfromtheairinletcouldresultinpersonalinjury.
Blower Tubes Donotoperatewithouttubesinplace.
Loose Clothing Failuretokeeplooseclothingfrombeingdrawnintoairintakecouldresultin
personalinjury.
Ricochet Thrownobjectscanricochetandresultinpersonalinjuryorpropertydamage.
Recycle Symbol
Thisproductuseslithium-ion(Li-ion)batteries.Local,state,orfederallawsmay
prohibitdisposalofbatteriesinordinarytrash.Consult your local waste authority
forinformationregardingavailablerecyclingand/ordisposaloptions.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicatesahazardoussituation,which,ifnotavoided,willresultindeathorseriousinjury.
WARNING: Indicatesahazardoussituation,which,ifnotavoided,couldresultindeathorseriousinjury.
CAUTION: Indicatesahazardoussituation,that,ifnotavoided,mayresultinminorormoderateinjury.
NOTICE: (WithoutSafetyAlertSymbol)Indicatesinformationconsideredimportant,butnotrelated
toapotentialinjury(e.g.messagesrelatingtopropertydamage).
SYMBOLS

5 – English
PRODUCT SPECIFICATIONS
Motor.....................................................................................................................................................................40VoltsDC
AirVelocity:
 MPH................................................................................................................................................................................120
CFM................................................................................................................................................................................280
KNOW YOUR BLOWER
See Figure 1.
Thesafeuseofthisproductrequiresanunderstandingof
theinformationonthetoolandinthisoperator’smanualas
wellasaknowledgeoftheprojectyouareattempting.Before
use of this product, familiarize yourself with all operating
featuresandsafetyrules.
BLOWER TUBE
The blower tube can be installed on the blower without
usinganytools.
OVERMOLD HANDLE
Ergonomichandlewithovermoldimprovescomfortandgrip.
UNPACKING
Thisproductrequiresassembly.
 Carefullyremovetheproductandanyaccessoriesfrom
thebox.MakesurethatallitemslistedinthePacking
List areincluded.
WARNING:
Do not use this product if any parts in the Packing
Listarealreadyassembledtoyourproductwhenyou
unpackit.Partsonthislistarenotassembledtothe
product by the manufacturer and require customer
installation. Use of a product that may have been
improperlyassembledcouldresultinseriouspersonal
injury.
 Inspecttheproductcarefullytomakesurenobreakage
ordamageoccurredduringshipping.
 Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
 If any parts are damaged or missing, please call
1-800-776-5191forassistance.
PACKING LIST
Blower
Blower Tube
Operator’sManual
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
VVolts Voltage
min Minutes Time
Direct Current Type or a characteristic of current
n
o
No Load Speed Rotationalspeed,atnoload
.../min Per Minute Revolutions,strokes,surfacespeed,orbitsetc.,perminute
SYMBOLS
FEATURES
ASSEMBLY

6 – English
WARNING:
Ifanypartsaredamagedor missingdo notoperate
thisproductuntilthepartsarereplaced.Useofthis
productwithdamagedormissingpartscouldresultin
seriouspersonalinjury.
WARNING:
Do not attempt to modify this product or create
accessoriesnotrecommendedforusewiththisblower.
Anysuchalterationormodificationismisuseandcould
result in a hazardous condition leading to possible
seriouspersonalinjury.
WARNING:
Topreventaccidentalstartingthatcouldcauseserious
personalinjury,alwaysremovethebatterypackfrom
thetoolwhenassemblingparts.
WARNING:
Thisproductisintendedforbloweruseonlyandisnot
designedforvacuumuse.Donotattempttoremove
the main reducer housing that covers the impellers.
Removal of the main reducer housing will expose
themovingimpellersandcontactwiththeseimpeller
bladescanresultinseriouspersonalinjury.
ASSEMBLING THE BLOWER TUBE
See Figure 2.
 Withthelogoareafacingup,slidetheblowertubeover
theoutletontheblowerhousing.
 Pressdownonthetabontheblowerhousingoutlet.
 Pushtubeontheblowerhousingoutletuntiltablocks
intoplacethroughtheslotintheblowertube.
 Toremovetheblowertube,pushtabdownandslidetube
off.
WARNING:
Do not allow familiarity with products to make you
careless.Rememberthatacarelessfractionofasecondis
sufficienttoinflictseriousinjury.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1,alongwithhearingprotection.
Failuretodosocouldresultinobjectsbeingthrowninto
youreyesresultinginpossibleseriousinjury.
WARNING:
Do not use any attachments or accessories not
recommendedbythemanufacturerofthisproduct.The
useofattachmentsoraccessoriesnotrecommended
canresultinseriouspersonalinjury.
WARNING:
Verifythatallguardsandtubesareinplacepriortouse.
Iftheblowerisdropped,stopblowerandverifythat
nodamagehasoccurred.Ifanyguard,part,ortube
isdamagedormissing,donotusebloweruntilithas
beenrepairedorreplacedbyaqualifiedservicecenter.
Useofblowerwithdamagedormissingguards,parts,
ortubescanresultinseriouspersonalinjuryorfurther
damagetotheblower.
ASSEMBLY
OPERATION

7 – English
To remove:
Locatethelatchanddepresstoreleasethebatterypack
fromtheblower.
WARNING:
Battery tools are always in operating condition.
Therefore,switchshouldalwaysbeintheOFFposition
when not in use or carrying at your side. Remove
battery pack when transporting or carrying blower to
avoidaccidentalstarting,whichcouldresultinserious
injury.
For complete charging instructions, see the operator’s
manualsforyourbatterypackandcharger.
STARTING/STOPPING THE BLOWER
See Figure 4.
 Tostarttheblower,depresstheswitchtrigger.
 Tostoptheblower,releasetheswitchtrigger.
OPERATING THE BLOWER
See Figure 5.
 Tokeepfromscatteringdebris,blowaroundtheouter
edgesofadebrispile.Neverblowdirectlyintothecenter
ofapile.
 To reduce sound levels, limit the number ofpieces of
equipmentusedatanyonetime.
 Userakesandbroomstoloosendebrisbeforeblowing.
Industyconditions,slightlydampensurfaceswhenwater
isavailable.
 Conservewaterbyusingpowerblowersinsteadofhosesfor
manylawnandgardenapplications,includingareassuch
asgutters,screens,patios,grills,porches,andgardens.
 Watchoutforchildren,pets,openwindows,orfreshly
washedcars,andblowdebrissafelyaway.
 After using blowers or other equipment, CLEAN UP!
Disposeofdebrisproperly.
WARNING:
Battery tools are always in operating condition.
Therefore,switchshouldalwaysbeintheOFFposition
whennotinuseorcarryingatyourside.
NOTICE:
Before each use, inspect the entire product for
damaged,missing,orloosepartssuchasscrews,nuts,
bolts,caps,etc.Tightensecurelyallfastenersandcaps
and do not operate this product until all missing or
damagedpartsarereplaced.Pleasecontactcustomer
serviceoranauthorizedservicecenterforassistance.
APPLICATIONS
Youmayusethisproductforthepurposeslistedbelow:
Clearingleavesandotherdebrisfromyourlawn
Keepingdecksanddrivewaysfreefromgrassclippings,
leaves,pineneedles,andotherdebris
INSTALLING/REMOVING BATTERY PACK
See Figure 3.
WARNING:
Alwaysremovebatterypackfromyourtoolwhenyou
areassemblingparts,makingadjustments,cleaning,
orwhennotinuse.Removingbatterypackwillprevent
accidentalstartingthatcouldcauseseriouspersonal
injury.
To install:
Placethebatterypackintheblower.Aligntheraisedrib
onthebatterypackwithgrooveintheblower’sbattery
port.
WARNING:
Make sure the latch on the bottom of the battery pack
snaps in place and the battery pack is fully seated
andsecureintheblowerbatteryportbeforebeginning
operation. Failure to securely seat the battery pack
couldcause the battery packto fall out,resultingin
seriouspersonalinjury.
NOTICE:
Whenplacingbatterypackinthetool,besureraised
rib on battery pack aligns with the bottom of the tool
andlatchesintoplaceproperly.Improperinstallation
of the battery pack can cause damage to internal
components.
OPERATION

8 – English
WARNING:
To avoid serious personal injury, always remove the
battery pack from the product when cleaning or
performinganymaintenance.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1,alongwithhearingprotection.
Failuretodosocouldresultinobjectsbeingthrowninto
youreyesresultinginpossibleseriousinjury.
WARNING:
Whenservicing,useonlyidenticalreplacementparts.
Useofanyotherpartscancreateahazardorcause
productdamage.
WARNING:
Never use water or any liquids to clean or rinse
off your product and do not expose the product to
rain or wet conditions. Store indoors in a dry area.
Corrosive liquids, water, and chemicals can enter
the product’s electronic components and/or battery
compartment and damage electronic components
and/or the battery pack, which can result in a short
circuit,increasedriskoffire,andseriouspersonalinjury.
Removeanybuildupofdirtanddebrisbywipingthe
productcleanwithadryclothoccasionally.
MAINTENANCE
NOTICE:
Periodicallyinspect the entireproductfordamaged,
missing, or loose parts such as screws, nuts, bolts,
caps,etc.Tightensecurelyallfastenersandcapsand
donotoperatethisproductuntilallmissingordamaged
partsarereplaced.Pleasecontactcustomerserviceor
anauthorizedservicecenterforassistance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plasticsaresusceptibletodamagefromvarious typesof
commercialsolventsandmaybedamagedbytheiruse.Use
cleanclothstoremovedirt,dust,oil,grease,etc.
WARNING:
Donotatanytimeletbrakefluids,gasoline,petroleum-
basedproducts,penetratingoils,etc.,comeincontact
withplasticparts.Chemicalscandamage,weakenor
destroy plastic which can result in serious personal
injury.
STORAGE
 Cleanallforeignmaterialfromtheblower.
 Storeindoors ina secure placethat is inaccessibleto
children. Keep away from corrosive agents such as
gardenchemicalsandde-icingsalts.
 Donothangunitsothattheswitchtriggerisdepressed.
