Hartman ASCOT 120 CM ROUND TABLE User manual

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ATTENTION:PLEASE DO NOT TIGHTEN BOLTS UNTIL ALL BOLTS ARE INPLACE
1. Please read these instructions carefully before assembly
2. Aluminium is soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the table over and into position when
fully assembled
ASSEMBLY STEPS:
1. Place glass in safe place whilst assembling table
2. LOOSELY attach legs (C ) to table shelf (B) using bolts (G) small flat washers (F) using allen key (J) DO NOT TIGHTEN BOLTS AT
THIS STAGE
3. LOOSELY attach table legs (C) to table frame (A) using bolts (E) small flat washers (F) using allen key (J) DO NOT TIGHTEN BOLTS
AT THIS STAGE
4. Tighten all bolts using allen key (J) one by one being careful not to over tighten any as this will cause the thread to become damaged
5. Place PVC covers (H) on all visible bolts (E/G)
6. Turn table top over and place in desired position
7. Place glass (D) back on table and gently press down on suckers to ensure glass is secure
For more information regarding maintenance of your furniture please visit
http://www.hartmanuk.co.uk/after_care_videos.html
Component’s
Fixings
Parts List
Parts Picture
Descrip
tion
Q’ty
Part no
Parts
list
Parts Picture
Description
Q’ty
Part no.
A
Table
Frame
1
68283089A
E
M6*20 Bolts
4
1151162
F
Small Flat
Washers
12
1161162
B
Table
Shelf
1
68283089B
G
M6*45 Bolts
8
1181162
C
Legs
2
68283089C
H
PVC Cover
12
1171162
D
Glass
1
68283089D
J
Allen Key
1
1010162

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
ASCOT 120 CM ROUND TABLE
( )
