Harvest Healthcare COMMUNITY Series Installation and operating manual

[e-mail] www.harvesthealthcare.co.uk 1
General User/Safety Guide
HARVEST STATIC
MATTRESS
RANGE
STATIC MATTRESSES
www.harvesthealthcare.co.uk

T+44 (0)1709 377172 F+44 (0)1709 377173
2

E[email protected] www.harvesthealthcare.co.uk 3
CONTENTS
WARNINGS & CAUTIONSWARNINGS & CAUTIONS
OVERVIEWOVERVIEW
GENERAL INFORMATIONGENERAL INFORMATION
CLEANING & CARECLEANING & CARE
GUARANTEES & WARRANTIESGUARANTEES & WARRANTIES
DECLARATION OF CONFORMITYDECLARATION OF CONFORMITY
4
5
6-7
8
9
10

T+44 (0)1709 377172 F+44 (0)1709 377173
4
READ THIS INSTRUCTION MANUAL CAREFULLY. PLEASE NOTE
IN PARTICULAR THAT THE SAFETY INSTRUCTIONS MUST BE
OBSERVED.
WARNING
Please ensure that this booklet is read prior to rst use.
Please refer to the information in this booklet as a guideline only.
Harvest Healthcare Ltd recommend that prior to using this product, a full risk assessment must be
completed by a qualied professional, in order to determine that the correct product is suitable for each individual.
Do not allow sharp objects to penetrate the cover material.
Do not use this product for/whilst lifting the patient. This will damage the product and could put the patient at risk.
Ensure that this product is used the correct way up if not reversible.
Do not expose this product to open ames. We advise the user not smoke when using this product.
Facial contact with the cover may cause suffocation.
WARNINGS &
CAUTIONS
WASH at
80°C
TUMBLE DRY
ON LOW
DO NOT
DRY CLEAN
DO NOT
BLEACH
DO NOT IRON CE MARK NO
SMOKING
PHENOLS
DO NOT USE
PHENOLS
SYMBOLS USED
This symbol indicates general hazards. There is a danger to life and health.

E[email protected] www.harvesthealthcare.co.uk 5
WIDTH (MM)
MAX PATIENT WEIGHT (KG) RISK LEVEL
COMMUNITY
MATTRESS
900/1200/
1400 125 159 Medium
LENGTH (MM) THICKNESS (MM)
FIRE-TECH 7
VANDAL PROOF
900/1200/
1400 150 190 High
FIRE-TECH 7
COMFORT
900/1200/
1400 150 190 High
PRIME COMFORT 150 177 High
COMMUNITY PLUS
MATTRESS 150 190 High
PRIME
COMFORT PLUS
900/1200/
1400 140 247 High
REFLECT
2
900/1200/
1370 2000 165 247 High
REFLECT 2
PLUS SIZED > 45
1200/
1400 2000 180 285 High
REFLECT 2
PLUS SIZED > 60
1200/
1400 2000 180 381 High
KINETIC
AIR 900 2000 150 247 High
OVERVIEW
MATTRESS RANGE OVERVIEW/PERFORMANCE CHARACTERISTICS
900/1200/
1400
2000/
1900
900/1200
1400
MODULAR
REPLACEMENT 900 160 127 Medium
MODULAR
REPLACEMENT
PLUS SIZED
1200 160 190 Medium
2000
2000
2000/
1900
2000/
1900
2000/
1900
2000/
1900
2000/
1900

T+44 (0)1709 377172 F+44 (0)1709 377173
6
GENERAL USE
INSTRUCTIONS FOR USE
Check whether the mattress is a replacement or an overlay.
- If it is a replacement mattress it should be placed directly on to the bed frame
- If it is a mattress overlay it should be placed on top of the existing mattress.
Check that the safe working load of the mattress is suitable for the intended user.
Do not exceed the max patient weight of the mattress (see page 5).
Ensure that the Risk Factor is suitable for the intended user. To help prevent pressure damage
it is important that patients reposition themselves, or are repositioned regularly.
Mattresses are delivered in plastic covers for protection; these covers must be removed
before use.
With the exception of bed sheets avoid using any additional covers/padding between the
patient and the support surface, as this may affect its pressure reducing qualities.
INTENDED PURPOSE
Harvest Healthcare static mattresses are designed for patients at risk of pressure injury,
or who have already developed pressure injuries. The foam surface redistributes pressure,
aiming to reduce capillary closure in high risk areas such as the heels and sacrum. The
mattress range overview (see page 3) supports identifying the most appropriate Harvest
Healthcare static mattress for an individual patient, giving ranges for patient risk levels and
maximum patient weights. These are provided as a guide to support appropriate mattress
choice, but all individuals should be risk assessed by a trained professional as individual
circumstances may alter mattress choices.
Never use a mattress with a lower risk category than that assigned to the service user by a
trained professional.
Never exceed the maximum patient weight for a mattress.
Misuse of the mattress could lead to the development of pressure injury.
PERFORMANCE CHARACTERISTICS/MATTRESS INSPECTION
RECOMMENDATIONS
Mattresses should be checked regularly to ensure they remain ‘t for purpose’, clinically
effective and pose no risk of infection to either the patient or the carer.
Harvest Healthcare Ltd recommend that a thorough inspection of both the interior (foamcore)
and exterior (cover) of the mattress is carried out weekly, or each time a new patient is placed
on the mattress. Visual checks should be carried out daily to identify any signicant signs of
damage or infection risk.
If any signs of contamination are identied on the cover, the mattress should be withdrawn
from use immediately and the cover replaced. If the foam and/or the cover are showing signs
of contamination or excessive wear the mattress should be removed from use immediately
and the entire mattress replaced. Signs of excessive wear may include, but are not restricted
to, thinning, discolouration, tearing, fraying, misshaping and uid ingress.
Facial contact with any covering material such as that used on this
product can cause suffocation and a Risk Assessment should be
done prior to the use of this product.

E[email protected] www.harvesthealthcare.co.uk 7
GENERAL USE
MATTRESS CLEANING AND CARE
Mattresses are fully encased in a protective waterproof, multi-stretch PU cover to prevent
uid ingress from damaging the foam core. The mattress cover should be cleaned regularly in
accordance with your organisation’s disinfection protocol.
For full cleaning procedures for our mattresses see page 8.
MOVING, HANDLING AND STORAGE
Where possible, mattresses should be stacked at and transported on a bed base.
Mattresses should be handled by two people, one at either end of the mattress.
Store mattresses in a temperate, dry environment. Do not expose to high humidity or heat.
Do not drag or pull mattresses by the cover.
SAFE USE
The length, width and height of the mattress should be checked to ensure that these
dimensions are within the limits specied by the bed manufacturer and do not introduce gaps
that could increase the risk of entrapment.
Before and during use of mattress overlays with bed rails, consider the reduction in the
effective height of the bed rail relative to the top of the mattress may allow the occupant to
roll over the top of it; extra height bed rails may be required. The hazard of entrapment in the
vertical gap between the side of the mattress and the bed rail may be exacerbated due to the
soft, easily compressible nature of the overlay and/or mattress edge. If the standard mattress
is replaced with a lightweight foam mattress, third party bed rail assemblies (including the
mattress and bed occupant) can tip off the bed when the bed occupant rolls against the bed
rail. This is because many third-party bed rails rely on the weight of a standard mattress to
hold the assembly in place.
If the mattress is on a bed which is proled it may not be a suitable surface for CPR. In this
case, put the service user on the oor to perform CPR.
WARRANTY
Foam Inner
All Harvest Healthcare static foam mattresses are covered by warranty for a period of 3 years.
Damage through incorrect use will invalidate this warranty.
Mattress Cover
All Harvest Healthcare mattress covers are covered by warranty for a period of 12 months.
Damage through incorrect use and penetration by sharp instruments will invalidate this
warranty.
GUARANTEE
Harvest Healthcare Ltd guarantees to repair or replace all goods issued to its customers
which are found to be defective whilst still under their applicable warranty period. All
warranties are subject to our standard terms and conditions of sale which can be found on
our website or by request to Harvest Healthcare Ltd.

T+44 (0)1709 377172 F+44 (0)1709 377173
8
CLEANING & CARE
MATTRESS COVER
During general use the mattress can be cleaned by wiping with a mild detergent solution.
Where necessary the mattress cover can be removed for laundering or sterilisation. Where
there is staining or body uids on the mattress, wash thoroughly with soap and water, then
wipe with a sodium hypochlorite solution diluted to 1000ppm before laundering.
Mattress covers may be laundered as follows:
1Pre wash cold 10 minutes
2Main wash 80°C 10 minutes
3Followed by cold rinses and extraction.
WARNING
Eye protection, gloves and protective clothing should be worn when carrying out cleaning
and disinfection procedures.
When disinfecting the system, Harvest Healthcare recommends the following guidelines
which have been developed to comply with recognised infection control procedures.
These procedures are also to be used to prevent cross infection when transferring the
system between patients.
Do not use abrasive cleaners, phenol disinfectants, solvents or alcohol-based
cleansers, e.g. Dettol, Phenicol, Hibiscrub, Clearsol, Stericol, Hycoline, as these
will damage the cover materials.
Do not iron.
Ensure that the mattress is thoroughly dried before remaking the bed or placing
in storage.
HYPERCARBONATE AND PHENOL-BASED SOLUTIONS SHOULD NOT
BE USED AS THESE WILL DAMAGE THE MATTRESS COVER
DISPOSAL
If contaminated, please dispose of as clinical waste.
If not contaminated dispose of as household waste at your local approved facility.
Note:
Please report any serious incident related to this device to Harvest Healthcare.
Full contact details can be found at the end of this document.

E[email protected] www.harvesthealthcare.co.uk 9
TECHNICAL
SPECIFICATION
FIRE TESTING (FOAM)
PRODUCT WEIGHT (KG)
FOAM TYPE
BS 7177
Crib 5 8 kg
PU High
Density
BS 7177
Crib 7 13 kg
PU -
Welded/Zipped
High
Density
BS 7177
Crib 7 13 kg
PU -
Welded/Zipped
High
Density
BS 7177
Crib 5 12 kg
PU -
Welded
High Density-
Castellated
11 kg
PU High
Density
BS 7177
Crib 5 15 kg
PU -
Welded
Multizone
Castellated
BS 7177
Crib 5 12 kg
PU -
Welded
Multizone
Visco
BS 7177
Crib 5 18 kg
PU -
Welded
Multizone
Visco
BS 7177
Crib 5 18 kg
PU -
Welded
Multizone
Visco
16 kg
PU -
Welded
Multizone
Castellated
MATTRESS RANGE TECHNICAL SPECIFICATION
COMMUNITY
MATTRESS
FIRE-TECH 7
VANDAL PROOF
FIRE-TECH 7
COMFORT
PRIME
COMFORT
COMMUNITY PLUS
MATTRESS
PRIME
COMFORT PLUS
REFLECT
2
REFLECT 2
PLUS SIZED > 45
REFLECT 2
PLUS SIZED > 60
KINETIC
AIR
BS 7177
Crib 5
BS 7177
Crib 5
MODULAR
REPLACEMENT
BS 7177
Crib 5
COVER MATERIAL
PU Castellated 12 kg
MODULAR
REPLACEMENT
PLUS SIZED
BS 7177
Crib 5
PU Castellated 22 kg

T+44 (0)1709 377172 F+44 (0)1709 377173
10
DECLARARTION
OF CONFORMITY
DECLARATION OF CONFORMITY
Declaration of Conformity Annex VII EU Directive 93/42/EEC
We, as company: Harvest Healthcare Ltd
Sheaf House
Bradmarsh Way
Bradmarsh Business Park
Rotherham, S60 IBW
Product Development and Quality Manager
Rotherham, 07.04.2020
Confirm on our own behalf that the medical product:
Please see the Static Mattresses list on the next page.
Risk Class: I
SRN: TBC
complies with all applicable requirements in Appendix I of the EU directive 93/42E EC
The following compliance evaluation process was applied: Annex VII
EU legislation for this type of product covers all safety, health and environmental requirements.
Modifying this product without consultation with Harvest Healthcare Ltd will invalidate this declaration
of conformity.
This declaration of conformity is issued under the sole responsibility of Harvest Healthcare.
Notified Body: TBC
This document is valid for 4 years after the date of the signature.
Authorised Representative: TBC
SRN: TBC

E[email protected] www.harvesthealthcare.co.uk 11
NOTES
Community-900mm wide
Community-1200mm wide
Community Plus-900mm wide
Community Plus-1200mm wide
Community Plus-1400mm wide
Fire-Tech 7 Comfort-Zipped
Fire-Tech 7 Comfort- Welded
Prime Comfort-900mm wide
Prime Comfort Plus-900mm wide
Prime Comfort Plus-1200mm wide
Reflect 2-900mm wide
Reflect 2-1200mm wide
Reflect 2-1370mm wide
Reflect 2 Plus Sized >45-1200mm wide
Reflect 2 Plus Sized >45-1400mm wide
Reflect 2 Plus Sized >60-1200mm wide
Reflect 2 Plus Sized >60-1400mm wide
Kinetic Air Hybrid Mattress
Modular Replacement
Modular Replacement Plus Sized
Fire-Tech 7 Vandal Proof
Prime Comfort-1200mm wide
Prime Comfort-1400mm wide
Here is the listof the Static Mattresses.
HSMCOM
HSMCOM.12
HSMCOMP
HSMCOMP.12
HSMCOMP.CAS2.14
HSMFIRET.CFT
HSMFIRET.CFT.W
HSMFIRET.VP
HSMPRIM
HSMPRIM.DV12
HSMPRIM.14
HSMPRIMP
HSMPRIMP.12
HFR147
HFR147.12
HFR147.1370
HFR227
HFR227.14
HFR227.60
HFR.1400.60
HK100
HFR114
HFR105.120
UDI: 5060517530181
UDI: 5060517532109
UDI: 5060517530198
UDI: 5060517532185
UDI: 5060517532383
UDI: 5060517532390
UDI: 5060517530235
UDI: 5060517532338
UDI: 5060517530204
UDI: 5060517531935
UDI: 5060517532222
UDI: 5060517530211
UDI: 5060517532123
UDI: 5060517530228
UDI: 5060517532161
UDI: 5060517532277
UDI:5060517532376
UDI: 5060517532130
UDI: 5060517533229
UDI: 5060517531928
UDI: 5060517530143
UDI: 5060517531584
UDI: 5060517532079
DECLARATION OF CONFORMITY
Declaration of Conformity Annex VII EU Directive 93/42/EEC

T+44 (0)1709 377172 F+44 (0)1709 377173
12
Harvest Healthcare Limited. Company No: 07210261
Sheaf House, Bradmarsh Way, Bradmarsh Business Park,
Rotherham, S60 1BW
T [phone] F+44 (0)1709 377 173
E[email protected] www.harvesthealthcare.co.uk
© Copyright Harvest Healthcare
Our Full Terms & Conditions are available by request or can be found on our Website.
Harvest Healthcare reserves the right to alter or amend this document without notice.
Serial No:
DOCUMENT REFERENCE: STATICMAT/MANUAL04- April 2020
ALSO
AVAILABLE...
STATIC MATTRESS LENGTH EXTENSIONS
The Static Mattress Length Extensions have been designed for use with our Static Mattress
range.
Ideal for use with existing mattresses, the piece will add a further 150mm or 200mm* and
close any gaps between the mattress and bed frame.
Once in place, the kit continues to provide pressure relief around the heels and zonal areas.
*Used in conjunction with the
bed extensions.
PRODUCT CODE SIZE
HFIM1515 900mm x 150mm x 150mm
HFIM2013 900mm x 200mm x 130mm
HFIM2016 900mm x 200mm x 160mm
HFIM2020 900mm x 200mm x 200mm
HFIM2016.12 1200mm x 200mm x 160mm
HFIM2016.14 1400mm x 200mm x 160mm
