Hatco ATMOSPHERIC AWD-12 Series Application guide

Atmospheric Hot Water
Dispenser
RREEPPLLAACCEEMMEENNTT
PPAARRTTSSLLIISSTT
AWD-12
AWD Series

HATCO AWD SERIES ATMOSPHERIC HOT WATER DISPENSER
31
33
34 11
28
2
41
22
32
18
30
27
26
4
16
3
45
40
7
17
43
10
36
46
20
24
15
39
42
8
44
37
9
Model Designation
AWD-12 =Atmospheric
=Water =Dispenser =Gallons
Form No. AWDRP - 0405 2 Printed in U.S.A.
CAUTION - Use of replacement parts
other than those supplied by Hatco Corporation may result in damage to the unit or injury to personnel.
38
19
23
30
29
30
12
6
1
47
21 25
14
13
5
50
35
48
30
A W D 12
24 Hour 7 Day Parts & Service Assistance available in the United States and Canada By calling [phone].
49

PARTS SPECIFIC TO MODEL AWD-12
Form No. 3CSRP - 0401 3 Printed in U.S.A.
50 Heating Element 1625W R02.06.501.00
230-240V CE
Single Phase
50 Hz
220-230V CE
Single Phase
50 Hz
240V
60 Hz
208V
60 Hz 480V
60 Hz
ITEM DESCRIPTION
R02.06.500.00 ---
Shaded area in parts lists on the following pages reflects export models only.
Form No. AWDRP - 0405 3 Printed in U.S.A.
1 Contactor 50A, 24 VAC 02.01.167.00 1 2 Power Cord Assembly-
30A, 250 Volt 02.18.122.00 1
3 Cord Grip 02.20.259.00 1 4 Fill Solenoid Valve R03.02.040.00 1 5 Water Fill Tube 03.40.081.00 2' 6 Tank Inlet Tube 03.40.081.00 2' 7 Bulkhead Union Fitting 03.40.085.00 1 8 Base, Warm Red 04.36.007.00 1 9 Screw, Drip Pan 05.04.149.00 3
10 Leg, 4" (102 mm) 05.30.065.00 4
11 Water Conditioning Magnet 05.30.087.00 1
12 Thermistor Probe-
Temperature-Upper 02.01.203.00 1
13 Thermistor Probe
Temperature/Level-Lower 02.01.204.00 1
14 High Limit-Surface Mount 02.16.121.00 1 15 Probe with bend-LWCO 02.40.045.00 1 16 Value Extension 2" ( 51 mm) 03.02.029.00 1 17 Ball Valve-Stainless Steel 03.02.038.00 1 18 Inlet Tube 03.40.086.00 1 19 Water Tank Assembly 04.36.005.00 1 20 Tank Lid 04.36.006.00 1 21 Gasket, Heating Element 05.06.005.00 3 22 Gasket, Tank Lid 05.06.076.00 1 23 Terminal Block-2 Pole 02.15.050.00 1 24 Transformer
208/240 Volt-24 Volt 02.17.046.00 1
PARTS COMMON TO ALL AWD MODELS
25 Dispense Valve 03.02.032.00 1 26 Handle for Ball Valve 03.02.038.00 1 27 Brass Hose Connector
w/Shoulder 03.05.058.00 1
28 Hose, Delimer 03.40.089.00 1' 29 Hose, Dispense 03.40.089.00 1' 30 Hose Clamp 03.40.080.00 4 31 Jacket, White Granite 04.36.009.00 1 32 Valve extension 5.125" (130 mm) 04.36.017.00 1 33 Insulation, Tank 05.05.034.00 1 34 Fill Cup with Cover Assembly R05.30.050.00 1 35 Brass Elbow 3/4" (19 mm) 03.08.012.00 1 36 Water Level Control Board 02.01.189.00 1 37 On/Off Rocker Switch 02.19.081.00 1 38 Outlet Tube 03.40.081.00 2' 39 Front Housing, White Granite 04.36.013.00 1 40 Decal Overlay 07.03.430.00 1 41 Flare Connection 03.40.078.00 1 42 Stem Adapter Fitting 03.40.084.00 1 43 Drip Tray 04.36.008.00 1 44 Top Cover, Warm Red 04.36.011.00 1
45 Front Cover, White Granite 04.36.012.00 1
46 Rubber Channel Gasket 05.06.002.00 1 47 Grommet, Rubber 05.06.075.00 1
48 Isulation, Top 05.05.059.00 1 49 Nipple, Push-On 03.40.083.00 1
ITEM DESCRIPTION PART NO. QTY. ITEM DESCRIPTION PART NO. QTY.
---
---
