NORMAL OPERATION
Arm Alarm Disarm alarm
Mute alarm
Remote start
ARMING THE ALARM SYSTEM
NORMAL ARMING MODE
To arm the alarm system, turn the ignition switch OFF, press the button, indicators will
flash once; with single audible bleep LED starts to flash the alarm system will enter into
the arming status after 5 seconds. If motorcycle is slightly moved, the alarm will chirp and
the indicator will flash lights 5 times, if it’s moved hard then full reaction will occur and
sound for 30 seconds. Engine will be completely immobilised and can not be driven away.
(if immobiliser installed).
AUTOMATIC ARMING
In any case, the alarm system will arm itself automatically 60 seconds after the ignition
has been switched OFF.
To disable the function of automatic arming, press button and button simultaneously,
indicator light will flash 4 times, auto-arming function is disabled. To enable this function,
press button and button again at the same time, siren sound 4 times, indicator light
flash 4 times, auto-arming function is enabled.
DISARMING THE ALARM SYSTEM
T
CHANGE SIREN TONE (default single tone)
Press + buttons simultaneously indicator lights flash 2 times, siren sound 2 times
for 6 tone. For single tone follow above procedure, indicator lights flash 2 times.
o disarm the alarm system, press the button, indicators flash twice with two audible
bleeps. If the system was triggered during arming, indicator LED light will flash quickly
after disarming. The LED will also flash quickly when the system is alarming.
1
21
CONNECTING THE ALARM WITH SPECIFIC T HARNESS
(OPTIONAL EXTRAS)

SILENT ARMING/DISARMING
Press the button, the lights will flash once and the system will be armed. If the motion
detection sensor is triggered in silent arming mode for first time, indicator lights flashes
slowly. System will revert to normal arming mode automatically, when shaken again.
To disarm in silent arming mode press the button. Press the button to quit silent
arming and back to normal arming mode.
ARMING IN TRANSPORT MODE (Temporary Sensor By pass)
A
PERMEANT MUTE ARMING AND DISARMING
Press + buttons simultaneously, indicator lights flash 2 times for mute mode. To
disable permeant mute arming and disarming follow the above procedure, indicator lights
flash 2 times, siren sound 2 times.
fter pressing button to arm the system, press again once within 3 seconds,
indicator light flash once, indicating shock sensor and auxiliary sensor are both bypassed;
now the motorbike can be transported freely.
To turn on the shock sensor and auxiliary sensor, press again, the bike will be back to
normal arming status.
ENERGY SAVING MODE:
The HAWK incorporates Energy Saving Mode in order to conserve motorcycle battery charge.
Energy Saving Mode as follows:
Automatically
When alarm is armed after 2 days the alarm will enter automatically into sleep mode. The
remote control fobs will not work or LED will not flash until system is awakened (see Exit
Sleep Mode).
Manually
To cancel energy saving mode:
Disarm the alarm, press and hold button for 2 seconds. Siren will chirp once. Continue
to hold Siren will chirp once and indicator will flash once.
To enable energy saving mode:
Disarm the alarm press and hold button for 2 seconds. Siren will chirp twice and
indicator will flash twice.
Alarm Reaction in sleep mode
Turn ignition ON, the system will be awaken and alarm will sound constantly •
until the ignition is switch OFF. System will enter into normal mode after 5 seconds.
Shock sensor activated, alarm will activate for 30 seconds (shock sensor activated •
1 stage, system will chirp 5 times and indicator light will flash 5 times). The
st
system will enter into normal mode after 5 seconds after alarm reaction finished.
2
21
CONNECTING THE ALARM WITH SPECIFIC T HARNESS
(OPTIONAL EXTRAS)

EXIT SLEEP MODE:
Shake the bike to awaken the alarm system and press any button on remote control fob
within 5 seconds, or enter into emergency pin override mode. The system will exit the
sleep mode.
EMERGENCY PIN CODE RESET:
If you cannot disarm the system from the remote transmitter, you will be able to disarm
the system by using the Personal Identification Number (PIN).
The HAWK system leaves the factory with no PIN override in its memory. We feel it is
easier for you, the rider, to enter a number which means something to you and can easily
be remembered. You should never need to use the PIN override, but if you do have to use
it then this system just might make life a bit easier!
TO ENTER THE INITIAL PIN
Step 1
Disarm the system.
Step 2
Turn Ignition ON/OFF 5 times and stopping at ON position at the last time. LED light will
illuminate for 4 seconds.
Step 3
When
pin code mode.
LED Light is illuminated press the button once then turn ignition off to enter
You can now enter the pin of your choice; ie. say 4 digits - 1234
Ignition on, count LED 1 flash ignition off 1
Ignition on, count LED 2 flash ignition off 2
Ignition on, count LED 3 flash ignition off 3
Ignition on, count LED 4 flash ignition off 4
You will get one chirp, and you will need to confirm the PIN
Ignition on, count LED 1 flash ignition off 1
Ignition on, count LED 2 flash ignition off 2
Ignition on, count LED 3 flash ignition off 3
Ignition on, count LED 4 flash ignition off 4
You will get 2 chirps to confirm the PIN has been entered successfully.
(3 chirps means that first and second entry of the PIN did not match- try again!
Go to Step 1)
IF YOU GET IT WRONG
Should you get it wrong or distracted at any point in this process, and you want to start the
process again, simply disarm the alarm with the transmitter.
3

DISARMING THE SYSTEM USING THE PIN OVERRIDE
If the system is armed and you cannot disarm it from the transmitter, disarm using the PIN
Override (in this example the PIN is set to 1234)
1. Turn Ignition ON/OFF 5 times and stopping at ON position at the last time after 2
seconds LED light will illuminate for 4 seconds and during this time switch the ignition
OFF. Every pin code must be inputted within 4 seconds period.
DURING THIS 4 SECOND PERIOD
Ignition on, count LED 1 flash ignition off 1
Ignition on, count LED 2 flash ignition off 2
Ignition on, count LED 3 flash ignition off 3
Ignition on, count LED 4 flash ignition off 4
The system will now disarm - 4 chirps will sound, you now have 30 seconds to start the
motorcycle or the HAWK will arm again.
*KEEP PIN NUMBER SAFE*
Write your pin code here and keep in safe place.
4 Pin code:
BIKE FINDER/PANIC
Press button and button simultaneously with the ignition in OFF position and
the indicator lights will flash 8 times and siren will chirp 8 times. If alarm armed in silent
mode only the indicator lights will flash 8 times.
4

REMOTE START
Read Warning! Safety First
Press the button twice within two seconds and hold, engine will start automatically,
and used for non-key driving and warm-up. Repeat the above operation if the engine does
not function due to cold weather or due to slow rotation of engine.
NOTE: when using the remote start up, the switch key of the motorcycle cannot be
pressed at the same time, otherwise the fuse will blow.
How to turn off the remote start function: press the
Disable Remote Engine Start (default on)
Long press button, indicator lights flash 2 times. To enable remote engine start follow
above procedure, indicator lights flash 2 times, siren sounds 2 times.
button once then engine will stop.
Warning! Safety first
When properly installed, this system can start the bike via a command signal from the
remote control transmitter.
Therefore, never operate the system in an enclosed area or partially enclosed area without
ventilation (such as a garage). It is the user’s sole responsibility to properly handle and
keep out of reach from children all remote control transmitters to assure that the system
does not unintentionally remote start the bike. THE USER MUST INSTALL A CARBON
MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE
VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE
ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE AREA MUST AT
ALL TIMES REMAIN CLOSED. These precautions are the sole responsibility of the user.
Use of this product in a manner contrary to its intended mode of operation may result in
property damage, personal injury, or death. (1) Never remotely start the bike with the bike
in gear, and (2) Never remotely start the bike with the keys in the ignition. The user must
also have the neutral Safety feature of the bike periodically checked, wherein the bike
must not remotely start while the bike is in gear. If the bike starts in gear, cease remote
start operation immediately and consult with the authorized dealer to fix the problem.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERATING
THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT
IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY
CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN
AUTHORIZED DEALER TO REPAIR OR DISCONNECT THE INSTALLED REMOTE
START MODULE. HAWK CAR ALARM WILL NOT BE HELD RESPONSIBLE OR
PAY FOR INSTALLATION OR REINSTALLATION COSTS.
5
21
CONNECTING THE ALARM WITH SPECIFIC T HARNESS
(OPTIONAL EXTRAS)

ANTI HOTWIRE
When system in armed mode if system detects the ignition is forcibly switched on
(hotwired) siren will activate and indicator lights will remain solid, the engine is
automatically immobilised and motorcycle cannot be started up. The siren will sound for
30 second if the ignition is switched off, otherwise it will sound continuously.
ANTI HIJACK
Press the button and button at the same time when ignition is on engine will
immobilise immediately, siren will sound continuously and indicator lights will flash
continuously. Press the button to de-activate anti hijack mode.
VALET MODE
In disarming mode, IGNITION OFF position, turn IGNITION ON/OFF 6 times and
stopped at ON at the last time, then press button within 5 seconds. LED will be on
constantly, indicating system entered into Valet Mode. In this mode, all alarming function
disabled. Only remote engine start and bike finding function. Follow the same procedures
to exit Valet Mode.
FOUR-SELECTION SENSITIVITY SET: (Disable built in Shock sensor)
When alarm disarmed Press the button and the button at the same time, the siren
will chirp three times and indicator lights flash three times. System is set for sensitivity
adjustment mode.
Press the button sensitivity increase and press the button sensitivity decrease.Level
of sensitivity indicated by number of siren chirps, there are 4 levels of sensitivity. If in
level 1, the shock sensor is disabled. To exit from sensitivity adjustment mode press the
button.
6

ALARM MEMORY:
When the motorcycle is set into arming normal or silent mode, press the button, if the
LED flashes continuously then motorcycle was tampered. To turn off alarm memory turn
ON ignition key.
MEMORY FUNCTION
During the alert state, if the alarm is detached from the cable harness, when restored it will
“remember” the state in which was, preventing in this way every attempt of tampering.
LEARNING TRANSMITTER CODES: (We have already done this for you!!!)
This alarm system can support up to 4 remote controls. The included transmitter is pre
programmed into the systems memory at the factory. Follow the below steps to add or
delete a new transmitter.
1. In disarming mode, Ignition OFF position. Turn the Ignition ON/OFF 8 times, stopped
at ON at the last time, indicator light will flash twice, indicating the bike enters into code
learning mode.
2. Press and hold a button on the first remote for 1 second, indicator light flash once. The
first remote is learned.
3. Press and hold a button on the second remote for 1 second, indicator light flash twice,
indicating the second remote learned.
4. Follow the above procedures, the times the indicator light flash indicate the sequence of
the remote learned.
5. Altogether 4 remotes can be learned. If the 5th remote learned, it will automatically
replace the first one.
After all remotes are learned, turn Ignition OFF, indicator light will flash twice, the alarm
exits code learning mode. Verify the correct operation of each remote control.
Warning: After entering into code-learning mode, the previous remote codes
will not be cleared. To clear the previous remote codes (In case remotes were lost), learn a
new remote for at least 4 times, it will automatically replace all other remotes.
7
21
CONNECTING THE ALARM WITH SPECIFIC T HARNESS
(OPTIONAL EXTRAS)

Consumer Warranty
8
Commercial Electronics Co. Ltd (“HAWK®”) promises to the original purchaser to repair or replace
with a comparable reconditioned model any HAWK unit (hereafter the “unit”), excluding without
limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to
be defective in workmanship or material under reasonable use during one year from date of purchase.
provided the following conditions are met: the unit was professionally installed and serviced by an
authorized HAWK dealer; the unit will be professionally reinstalled in the vehicle in which it was
originally installed by an authorized HAWK dealer; and the unit is returned to HAWK, shipping
prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing the following
information: consumerʼs name, telephone number and address; the authorized dealers name,
telephone number and address; complete product description, including accessories; the year, make
and model of the vehicle; vehicle license number and vehicle identification number. All components
other than the unit, including without limitation the siren, the remote transmitters and the associated
sensors and accessories, carry a one-year warranty from the date of purchase of the same. This
warranty is non-transferable altered, the unit has been modified or used in a manner contrary to its
intended purpose; the unit has been damaged by accident, unreasonable use, neglect, improper
service, installation or other causes not arising out of defects in materials or construction. The
warranty does not cover damage to the unit caused by installation or removal of the unit. HAWK, in
its sole discretion, will determine what constitutes excessive damage and may refuse the return of any
unit with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WAR-
RANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WAR-
RANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE
EXPRESSLY EXCLUDED; AND HAWK NEITHER ASSUMES NOR AUTHORIZES ANY
PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN
CONNECTION WITH ITS PRODUCTS. HAWK DISCLAIMS AND HAS ABSOLUTELY NO
LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED
DEALERS OR INSTALLERS. HAWK SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE
DETERRENTS AGAINST POSSIBLE THEFT. HAWK IS NOT OFFERING A GUARANTEE OR
INSURANCE AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS
PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSO-
EVER, INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR
VANDALISM. THIS WARRANTY DOES NOT COVER LABOUR COSTS FOR MAINTE-
NANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL
DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING HAWK
OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE ENGLAND & WALES . THE MAXI-
MUM RECOVERY UNDER ANY CLAIM AGAINST HAWK SHALL BE STRICTLY LIMITED
TO THE AUTHORIZED HAWK DEALERʼS PURCHASE PRICE OF THE UNIT. HAWK SHALL
NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT
LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES
FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF
ECONOMIC OPPORTUNITY AND THE LIKE. NOT WITH STANDING THE ABOVE, THE
MANUFACTURER DOES OFFER A LIMITED ONE YEAR WARRANTY TO REPLACE OR
REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.
21
CONNECTING THE ALARM WITH SPECIFIC T HARNESS
(OPTIONAL EXTRAS)

NOTES
9
21
CONNECTING THE ALARM WITH SPECIFIC T HARNESS
(OPTIONAL EXTRAS)

Commercial
electronics®
Co. Ltd.
Commercial
electronics®
264 Haydon’s Road
Wimbledon
London SW19 8TT
Telephone: [phone]
Web: www.hawkcaralarm.com
E-mail: [e-mail]
Est.1987
MANUFACTURER & EXPORTER
24
Manufactured By Commercial Electronics . Great Britain . © Commercial Electronics 2011
www.hawkcaralarm.com
[e-mail]
Manufacturered by Commercial Electronics Co. Ltd • Great Britain • © Commercial Electronics 2020
