Quick and easy solution to eliminate wired from your personal area network (PAN)!
The HBTC2 Bluetooth® Class 1 USB Adapter allows users to make quick and effortless connections between
notebook, mobile phones, portable and handheld devices. It transmits voice and data through radio waves at fast
Bluetooth® speeds up to 723Kbps and distances of up to 100 meters. Its low power consumption allow efficient
wireless connections, while the Bluetooth® specification ensures protection from inteference and seeks to ensures
security of data. An ultimate solution to be freed from wired and go wireless via a secure wireless Bluetooth® link.
Bluetooth Profiles Supported: Generic Access (GAP), Service Discovery Application (SDAP), Serial Port (SSP), Dial-Up
Network (DUN), FAX, File Transfer (FTP), LAN Access (LAP), Synchronization (SYNC), Object Push, (OPP), Generic
Object Exchange (GEOP), Headset (HSP), and Hardcopy Cable Replacement (HCRP), Human Interface Device (HID).
System Requirements
 Pentium 200MHz or Higher Processor
 Windows 98SE, ME, 2000, XP
 One Available USB Port
 One Available CD-Rom For Driver Installation
Class 1
USB Adapter
PACKAGE CONTENTS:
One Bluetooth®Class 1 USB Adapter
One CD (Driver/Utility/User’s Manual)
One Quick Installation Guide

HBTC2
HBTC2
READY, NETWORK AND GO!
Step 1 - Insert the Setup CD
Power on your PC and insert the setup CD into the CD-Rom Drive.
Step 2 - Install Utility and Driver
The setup CD will guide you through the installation process
Step 3 - Plug in the HBTC2 and search for bluetooth enabled devices
After you have completed the driver installation, insert the Bluetooth firmly into
the USB slot and search for bluetooth enabled devices.
NETWORK DIAGRAM
Class 1 USB Adapter
RELATED PRODUCTS:
HWUG1 Wireless-G USB Adapter
UH104 4-Port USB Hub
HBTC2
Bluetooth®Class 1 USB Adapter
1 Year Warranty
HAWKING TECHNOLOGIES, INC
USA: Irvine, California
Sales: 888.662.8828 or 949.790.0800 Fax: [phone]
Email: [email protected] Email: [email protected]
EUROPE: Rotterdam, The Netherlands
Sales: 31-10-245-1600 Fax: [phone]
Email: [email protected] Email: [email protected]
Copyright © Hawking Technologies, Inc. 2006. All rights reserved.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Hawking
Technologies is under license. Other trademarks and trade names are those of their respective owners..
SPECIFICATIONS
Standard
Bluetooth SIG 1.1 compliant
(upgradeable to Bluetooth SIG 1.2)
Bluetooth Profile
Generic Access (GAP), Service Discovery
Application (SDAP), Serial Port (SPP),
Dial-Up Network (DUN), FAX, File transfer
(FTP), LAN Access (LAP), Synchronization
(SYNC), Object Push (OPP), Generic Object
Exchange (GEOP), Headset (HSP), and
Hardcopy Cable Replacement (HCRP),
Human Interface Device (HID)
Interfaces
USB 1.1 (type A)
RF Specifications
Frequency Band: 2.400~2.4835 Ghz
unlicensed ISM band
Spectrum: Adapter Input (100~240v
50Hz-60 Hz), Adapter Output (5V 2.5A)
Modulation: GFSK
Output Power: +13dBm (typical)
Receiving Sensitivity: -82dBm (typical)
Power Class: Class 1
Range: up to 100m (limited condition)
Security
Pairing, Encryption, Authentication
Power
USB Port (directly)
Dimensions (L x W x H)
55 x 17 x 6 mm (or)
2 x 0.65 x 0.5 in
Compatible with
USB enabled PC's
and Macs.
Compatible with
USB enabled Notebooks
Tablet PC's and Laptops
Compatible with most Bluetooth®Devices
FEATURES
Create a Bluetooth personal network with other compatible bluetooth devices,
such as keyboard, mouse, PDA, headset, mobile phone and more
Supports a wide range of applications, such as Wireless File Transferring, Data
Synchronization, Gaming, Internet Access, LAN Access, printing, net meeting
With data encryption and user authentication features, exchange information
securely and confidently
The bundled utility makes wireless networking simple by automatically
detecting and displaying other BlueTooth devices within range
Range: Up to 100m (limited condition)
