Model 7501 Portable Eyewash
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS®warrants that all of its products are guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing
to company within a reasonable period after receipt of the product. Where claims for
defects are made, the defective part or parts shall be delivered to the Company, prepaid,
for inspection. HAWS will not be liable for the cost of repairs, alterations or replacements,
or for any expense connected therewith made by the owner or his agents, except upon
written authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages
caused by defective materials or poor workmanship, except for replacements, as provided
above. Buyer agrees that Haws has made no other warranties either expressed or implied
in addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for
the purpose, which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions HAWS cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL, PLEASE CALL: 1-800-766-5612
FOR PARTS CALL: 1-800-758-9378
(U.S.A. AND CANADA ONLY) MONDAY-THURSDAY: 6:00 A.M. – 4:00 P.M. PST
FRIDAY: 6:00 A.M – 1:00 P.M. PST

12/06 Model 7501 Page 2 of 5
RECOMMENDED TOOLS: Two 1/4" diameter anchors suitable for supporting filled eyewash
(approximately 80 pounds) and tools needed to install these anchors.
LOCATION OF UNIT: The Model 7501 Portable Eyewash should be installed in close
proximity to potential accident areas. It should be clearly identified, free from obstructions and
easily accessible.
INSTALLATION INSTRUCTIONS
Step 1: Wall mount with “J” Bracket (see Installation Drawing). Eyewash nozzles should
be between 33 inches (83.8 cm) and 45 inches (114.3 cm) above the floor when
eye wash arm is in the active (lowered) position.
IMPORTANT:
Filled eyewash unit is heavy (approximately 80 pounds). Wall bracket anchors or
shelf must be strong enough to support the filled eyewash and the weight of a
worker leaning on eyewash.
Step 2: Fill up to fill line and place on level surface if possible. If installed as indicated,
eyewash unit will provide 15-minute duration of flow.
Step 3: Take proper precautions to help prevent the growth of potentially harmful
bacteria in eyewash tanks. (Refer to Maintenance Instruction).
OPERATING INSTRUCTIONS
Instruct all employees in the use of this Emergency Eyewash. Personnel should be assigned
to check eyewash liquid level daily.
Step 1: Lead patient to nearest eyewash station. Seconds can make the difference in
preventing serious eye injury.
Step 2: Pull yellow eyewash arm firmly. Eyewash arm will drop to activate eyewash.
Step 3: Lower head until eyes enter eyewash stream. Use thumbs and forefingers to hold
eyelids open. Flush for 15 minutes.
Step 4: Seek qualified medical attention immediately.

12/06 Model 7501 Page 3 of 5
MAINTENANCE
Step 1: Self contained eyewash equipment shall be visually checked to determine if
flushing fluid needs to be changed or supplemented.
Step 2: Take proper precautions to help prevent the growth of potentially harmful
bacteria in eyewash tanks. We recommend either of the following procedures:
A. Use suitable Bacteriostatic Preservative to help prevent the growth of bacteria in
eyewash tank. Eyewash tank should be drained, flushed and refilled with clean
potable water and Bacteriostatic Preservative as directed by the preservative’s
manufacturer.
B. Drain, flush and refill portable units with clean potable water at least once every
week. Thoroughly cleanse tank at least once every month.
NOTE: Acanthamoeba survive mild chlorination and are commonly found in tap water.
Bacteriostatic Preservative will prevent the growth of Acanthamoeba. Hot water,
158º F (70º C) or hotter will destroy Acanthamoeba but must be allowed to cool
prior to use in eyewash units.
TROUBLESHOOTING
PROBLEM REPAIR CHECKLIST
1. No flow. 1. a. Tank empty. Refill tank.
b. Obstruction in line or fitting. Clear
obstruction.
2. Poor flow from eyewash head(s). 2. a. Tighten head assembly.
b. Check for obstructions. If necessary,
remove eyewash head(s), clean and
reassemble. To reassemble head, place
cap screw through head and thread into
head anchor two or three turns. Tilt head
assembly and work anchor legs into
eyewash armholes. Tighten assembly.
Check for leaks.
3. Water leak between joints or
fittings. 3. a. Pull hose off fitting. Smooth raised plastic edge on center of fitting. Return hose
and hose clamp to original position.
b. Tighten hose clamp(s) with pliers.
