Haztec 7-1418-F User manual

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
7-1418-F LED Worklight
M109 Issue 1.0 Created by: Technical - 1 - July 2019
Thank you for purchasing this Haztec product. Before proceeding with installation it is essential
to read and understand this instruction booklet.
Warning!
This product must be installed by persons competent in vehicle electrical installations
Improper installation of this product will void all warranties
Care should be taken to ensure that water ingress cannot occur through mounting or
wiring holes
Regularly inspect the product to confirm correct operation
DO NOT stare directly into the light it produces as permanent damage to the eyes may
result
Use only a mixture of soap and water to clean this product
DO NOT allow solvents; fuels; acetone-based cleaners etc. to contact this product
This product becomes hot under continuous use
DO NOT remove or touch the light for at least 30 minutes after switching off
Keep heatsink fins clean and free of debris to maintain airflow and heat dissipation
Basic Operating Specifications:
Supply voltage range:
9-32VDC
Maximum current draw:
1.1A @ 12V / 0.6A @ 24V
Fuse Rating:
1.5A
LED power:
18W
Beam Angle:
60OFlood Beam
Operating temperature range:
-40OC ~ 85OC
IP Rating:
IP68
Dimensions:
150mm x 52.5mm x 56mm
Connection Instructions:
Wire
Connect to
Function
Red
Positive [+] via switch & fuse
Main feed
Black
Permanent negative [-]
Earth/Ground
Flood beam
18 Watts
1440 Lumens
Powder coated
IP68 rated

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
7-1418-F LED Worklight
M109 Issue 1.0 Created by: Technical - 2 - July 2019
Installation:
Use the included ¾” socket screws to attach the mounting brackets to each end of the
Worklight and tighten using a 5mm Allen or Hex key
Locate the area where the Worklight is to be installed and use the ¼” bolt, washer and
nut to securely mount the lamp to the vehicle
Before power installation, ensure that the vehicle battery is disconnected
If the Worklight is to be directly connected to a battery, a toggle switch is needed to turn
the light on/off
An in-line fuse must be fitted within 12 inches of the power source
Ensure the toggle switch is rated for the correct amperage
Where cables are extended, it is highly recommended to solder the connections and then
insulate using heatshrink
Inspect and check operation of the Worklight to ensure it is functioning correctly
Connect the red power wire to the output terminal of the toggle switch and run the
appropriate gauge wire from the input terminal to the positive [+] terminal of the battery
Connect the black wire to the negative [-] terminal of the battery or any other good bare
metal ground source
Test the Worklight by operating the toggle switch to ‘ON’
