Haztec 7-1160-S User manual

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
7-1160-S
LED Worklight
M327.1.1 - 1 - April 2022
Thank you for purchasing this Haztec product. Before proceeding with installation, it is essential to
read and understand this instruction booklet
▪This product must be installed by persons competent in vehicle electrical installations
▪Care should be taken to ensure that water ingress cannot occur through mounting or wiring
holes
▪Regularly inspect the product to confirm correct operation
▪DO NOT stare directly into the light it produces as permanent damage to the eyes may
result
▪Use only a mixture of soap and water to clean this product
▪This light becomes hot under continuous use. DO NOT attempt to touch or remove it for at
least 30 minutes after switching off
▪Keep the heatsink vanes clean and free of debris to maintain air flow
Basic Operating Specifications:
Supply voltage range:
9-32VDC
Current draw:
5.4A @ 12VDC / 2.5A @ 24VDC
LED power:
6 x 10W Cree LEDs
Operating temperature range:
-40OC to +60OC
Colour temperature:
6500K
Dimensions (mm):
135 (W) x 160 (H) x 124 (D)
Connection Instructions:
Wire
Connect to
Function
Red
Positive [+] via switch and fuse
Main feed
Black
Permanent negative [-]
Earth/ground
▪Heavy duty worklight
▪60 Watts
▪5400 lumens
▪10-degree spot beam
▪IP67
▪2 year warranty

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
7-1160-S
LED Worklight
M327.1.1 - 2 - April 2022
Beam Spread:
Installation Instructions:
▪Before commencing installation make sure to disconnect the vehicle battery
▪Inspect and check the operation of the worklight to ensure correct functionality before
installation
▪Select a suitable location to mount the worklight, preferably on a flat and solid metal
surface capable of supporting the weight of the light
▪Use a suitably sized drill bit to make a hole in the surface to allow the mounting bolt
to pass through
▪Always ensure there are no obstructions behind the surface being drilled
▪Place the mounting bracket on the surface and secure the light using the nyloc nut
provided
▪Position the light onto the bracket and insert the two retaining screws
▪Connect the power loom to a 9-32VDC supply ensuring the correct polarity, as per
connection instructions
▪It is recommended to use weather proof connectors located in a protected area away
from direct exposure to the elements
▪Power up the worklight and adjust the beam coverage to the required angle
▪Tighten all fixings to secure the light in position
