Faithfull FPPSLFF10WR User manual

FAITHFULL TOOLS
Phoenix House, 3 White Lodge Business Estate,
Hall Road, Norwich, Norfolk, NR4 6DG, United Kingdom.
E-mail: [email protected]
www.faithfulltools.com
Care and Maintenance
Storage
Store the Work Light and charging adapters
in a clean and dry area. This lamp may be
recharged using any standard USB 5V 1A
charger with a micro USB (B class) plug.
Using a non compatible charger could cause
damage to the Work Light or personal injury.
The Work Light may also be stored in a
vehicle for use in roadside emergencies.
If kept in a vehicle, it is recommended that
the battery be recharged periodically to ensure
maximum performance in an emergency.
To prevent the light and any of the
accessories being damaged,
please ensure that it is properly secured
and in a safe place inside the vehicle.
Cleaning
All exterior surfaces of the Work Light can be
wiped clean with a soft cloth dampened with
a soap and water solution. Do not immerse or
submerge any part of the light in water or any
other solvent. Never use solvents or cleaning
agents containing petroleum (petrol, kerosene,
oil), paint thinner, turpentine, alcohol,
or ammonia. Harsh materials like
these can damage surfaces.
Maintenance
All repairs should only be carried out by
qualied service personnel. Do not open
exterior casing of the Work Light, as there are
no user serviceable parts inside. Opening or
visible attempts to open or repair a Work Light
may void any guarantee and/or cause damage
to the product or personal injury.
Never attempt to open the
battery pack, under abusive conditions
liquid may be ejected from the battery,
if accidental contact occurs ush the
affected area with water. If the liquid
comes into contact with the eyes ush
with water and seek medical help.
Liquid ejected from batteries may
cause irritation or burns.
This product contains an internal Li-ion
battery pack formulated from
environmentally sensitive materials.
This product must be disposed of
properly with due care for the
environment. Please return this product
to your local dealer or to your local
recycling station where batteries will be
recycled or disposed of properly.
Never attempt to incinerate
batteries as they may leak or explode.
FAITHFULL TOOLS
Phoenix House, 3 White Lodge Business Estate,
Hall Road, Norwich, Norfolk, NR4 6DG, United Kingdom.
E-mail: [email protected]
www.faithfulltools.com
General Safety Precautions
• Store in dry location and do not allow the charging adapters to come in contact with water, rain or snow.
• If a charging adapter comes into contact with water, place in a dry location at room temperature,
on a soft absorbent towel and allow to dry thoroughly.
• Do not operate the unit until it is completely free of moisture.
• If an adaptor becomes submerged in water, discontinue its use immediately and contact your local
Faithfull retailer for a replacement charger unit.
• Do not store charging adapters where temperatures may exceed 122°F (50°C).
• Do not use an adaptor or charging cable if there is any sign of damage, these are not user serviceable
parts and should be replaced.
• Do not attempt to charge this light with a charge other than a USB specication product as this could
result in a re, damage to the light or personal injury.
IMPORTANT: Read these instructions fully before using
the Work Light. Retain these instructions for future reference.
FPP SLFF10WR
Instruction Manual
LED Work Light
10 Watt
Rechargeable

Charging the LED Work Light
The Work Light must be fully charged before being used for the rst time.
This will ensure that the battery gives its best performance now and on future recharging cycles.
The AC and DC charging adapters are for recharging the battery only.
USB Power Bank
The battery in this product also functions as a ‘Power Bank’ using the USB output socket (C).
Most small electronic devices such as mobile phones, MP3 players or tablets are now supplied
with USB changing leads which can be connected to the lamps USB output and used to recharge
the device. Always use the USB lead supplied by the manufacturer of your device to ensure
compatibility with your product. The amount of charge available will be determined by the state
of charge of the Work Lights internal battery.
NB. Some manufacturers incorporate authentication chips in their products to prevent the use of
third party charges and this may prevent the use of the Power Bank function on this product.
Faithfull cannot be held responsible for any damage caused to any
device that is charged using the Power Bank function.
Using the DC Charging Adapter
1) Recharge the lamp when the battery indicator
lamp (D) shows one green bar ashing.
2) Plug the charging cables micro USB plug
into the charging socket (B) of the Work Light
located under the plastic cover.
3) Plug the adapter into the vehicles 12V DC
cigarette lighter or accessory power socket.
4) The battery indicator lamp (D) will display up
to four green bars, which indicates the state of
charge of the battery. When charging the battery
the indicator lamp will ash and the bars will
cycle up until all four bars are a solid green, this
indicates that the battery is fully charged.
5) The battery will be fully charged after
approximately 5 hours or when all four green
bars are a solid green and are no longer
ashing. Disconnect the USB plug from the
Work Light and remove the adapter from 12V
power socket.
Safety Precautions DC
• The DC charging adapter can be used in
vehicles by plugging into the 12V DC cigarette
lighter or accessory power socket
• Consult your vehicle owner’s manual for further
information on operating 12V DC accessories.
• Do not drive the vehicle while charging as an
unsecured light may be a hazard during certain
driving manoeuvres
• Do not attempt to charge the light with an
adapter that is not compatible as this could result
in a re, damage to the torch or personal injury.
Using the AC Charging Adapter
1)Recharge the lamp when the battery indicator
lamp (D) shows one green bar ashing.
2)Plug the charging cables micro USB plug into
the charging socket (B) of the Work Light
located under the plastic cover.
3)Plug the adapter into a 240V socket and
switch the socket on (if applicable).
4)The battery indicator lamp (D) will display up to
four green bars, which indicates the state of
charge of the battery. When charging the battery
the indicator lamp will ash and the bars will cycle
up until all four bars are a solid green, this indicates
that the battery is fully charged.
5)The battery will be fully charged after
approximately 5 hours or when all four green
bars are a solid green and are no longer ashing.
Disconnect the USB plug from the Work Light
remove the adapter from the wall socket
or switch off.
NB. This lamp may be recharged using any standard
USB 5V 1A charger with a micro USB (B class) plug.
Safety Precautions AC
• Use 240V AC charging adapter indoors in a dry
location only.
• Exposure to damp or wet conditions could cause
electrocution or damage to adapter.
• Do not use the charger in the vicinity of
ammable liquids or materials.
• Do not use the charging adapter in combination
with electrical generators or step-up transformers.
• Always plug the adapter directly into a 240V
outlet in a suitable location.
An energy efcient and incredibly robust LED Work Light producing 800 lumens of 6500K light.
Its compact size and heavy-duty casing makes the unit ideal for most working environments,
while its slim prole and fold away handle allows for easy space saving storage.
The Faithfull Rechargeable LED Work Light
Setting up the Work Light
The Work Light has a ratcheting leg stand
system that allows the lamp to be folded at
for storage and opened out for use.
Work Light Operation
To switch on:
Press the red ON/OFF (A) button.
To change mode:
Press the red on button through
the two modes: 100%, and 50%
Magnetic Base Attachment
The magnetic base allows the Work Light
to be attached to metal surfaces.
Open the clips on the top of the
magnetic base then place
the handle of the Work Light into
the opening (Fig1) then close the
clips rmly ensuring they have
‘clicked’ into place (Fig2).
Running Times
The operating times of this Work Light may
vary depending on the working conditions
and the amount of charge in the battery
at the time of use. The approximate
running times for this Work Light when
fully charged are as follows:
100% - 3 hours
50% - 6 hours
Battery Warning Indicator:
The charging indicator lamp will ash green
when the batteries level of charge has
become low, indicating that the
Work Light should be recharged.
Safety Warning
When in use the lens will
become hot. Take care
when touching the lens
of the light after prolonged
periods of use.
Specifications
LED power: 10 Watt
Brightness: 800 Lumens
Beam angle: 120O
Colour temp: 6500K
IP rating: IP54
Type: COB
Battery: Lithium-ion 3.7V 4400mAh
Charge time: 5 hours
Run time: 100% - 3 hours, 50% - 6
hours
*230V AC/DC Mains charger
(5V 1A)
*12V DC USB Car charger
(5V 1A)
(Fig1)
(Fig2)
D: Battery
indicator lamp
A: ON/OFF and
mode switch
B: DC Micro
USB (Charging
the battery)
C: USB
output socket
(Charging
devices)
*Chargers may vary from that shown.
*USB to micro USB lead
