MP85A(DP) FASTpress
MP85A(DP)-S EASYswitch
Quick Start Guide
Kurzanleitung
Guide rapide
with PME-Assistant
mit PME-Assistent
avec PME-Assistent

English Page 3 −25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deutsch Seite 26 −49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Français Page 50 −73. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
Contents Page
Safety information 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Connecting MP85A modules to a PC with an Ethernet interface 5. .
2 Connecting the sensors 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Installing the PME Setup Assistant 9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Preparing for measurement / Setting up mode 10. . . . . . . . . . . . . . . . . .
5 Specifying the evaluation criteria 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Measuring and displaying (continuous production) 17. . . . . . . . . . . . .
7 Results of the last measurement 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Displaying saved processes / Report printout 19. . . . . . . . . . . . . . . . . .
9 Error messages/operating state (LED display) 22. . . . . . . . . . . . . . . . . .
10 Technical support 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
4
A2073-5.0 en/de/fr
Safety information
Observe the safety information described in the twin-channel amplifier,
module MP85A(DP) FASTpress, MP85A(DP)-S EASYswitch operating in-
structions.
This Quick Start Guide will enable you to rapidly and easily produce measure-
ment results with the MP85A(-S) or MP85ADP(-S). The designation MP85A
process controller will be used for all devices in this manual. If text/data refers
only to specific modules, this will be clearly indicated in the text and one of the
above designations used.
The MP85A process controller is set up with the “PME Assistant” setup soft-
ware, which is on the CD-ROM (PME System CD) that accompanies the de-
vice, or available as freeware from
http://www.hbm.de > Support > Download > Software
Further, more detailed information is available in the:
−PME Assistant program Help with FAQs (PME Assistant must be installed)
−Twin-channel amplifier, module MP85A(DP) FASTpress, MP85A(DP)-S EA-
SYswitch operating instructions.
−MP85A(DP) FASTpress, MP85A(DP)-S EASYswitch CAN/PROFIBUS/
Ethernet interface description.

5
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
1 Connecting MP85A modules to a PC with an Ethernet
interface
•Connect external DC voltage to terminal 1 or 2
•Use an Ethernet crossover cable to connect a PC or Laptop to terminal 7
0V SYNC
Screw terminal 3
(control inputs/outputs)
LH
Screw terminal 1
(CAN bus voltage supply,
synchronization)
Connecting the power
supply: The MP85A/MP85ADP module must be connected to an
external supply voltage of 18 −30 V (24 Vnom).
DAttach wire end sleeves to the voltage supply wire ends.
DScrew the wire ends to screw terminal 1.
DInsert the screw terminal into the top socket.
DSwitch on the voltage supply.
IN = digital input OUT = digital output
24V
Labeling
Screw terminal 2
CAN
(CAN adapter; assignment as for
screw terminal 1)
Screw terminal 4 (MP85A only)
(control inputs/outputs)
Out 1
Out 2
Out 3
Out 4
0 V
24 V
IN 1
Out 5
Out 6
Out 7
Out 8
IN 2
IN 3
IN 4
IN 5
IN
1
2
OUT
3
4
0V
24V
IN
1
5
6
OUT
7
8
2
3
IN
5
4
Screw terminal 5
(sensor channel x)
Screw terminal 6
(sensor channel y)
CAUTION
RJ45 Ethernet connection
Terminal 7

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
6
A2073-5.0 en/de/fr
System configuration with
the MP85A
Sensors
External
display
terminal
(option)
Please note, for trouble-free operation:
CAUTION
Please note, for trouble-free operation:
−Do not use USB connections designed for use in office environments, e.g.
such as the USB to CAN adapter from HBM, for industrial environments.
−Only use high-quality cables and devices, e.g. managed switches, for the
network components. Interferences caused by low-quality network compo-
nents can only be detected with great expense and therefore result in exces-
sively high costs during troubleshooting.
−Ensure that the hardware used meets the minimum requirements of the re-
spective software. The faster the processes being monitored and the more
data, e.g. process data and curves, needs to be saved, the faster the PC must
be capable of being able to process them.
−Ensure that the PC is sufficiently ventilated and cooled, even under unfavor-
able conditions (hot days).
−Ensure that regular backups are implemented for important data.

7
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
2 Connecting the sensors
2 sensors (transducers) can be independently connected to screw terminals 5
and 6 (e.g. channel 1 displacement and channel 2 force). HBM transducer
cables or other shielded, low capacitance measurement cables should be
used. The shield of the transducer cable must be connected as closely as
possible (< 5 cm) to the flat plug (4.8 mm).
MP85A(-S)
Screw terminals 5 and 6
for transducer connection
MP85ADP(-S)
SENSOR X
18
SENSOR Y
18
Flat plug for the transducer cable shield
ye
SG and inductive full bridges,
piezoresistive transducers
1
2
4
6
Hsg.
5
3
wh
bk
rd
bu
gn
gy
ye
Cable color code:
wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
1
2
4
5
3
1
2
3
Potentiometric transducer
1
2
4
6
Sense lead (−)
Cable shield
1
2
4
5
3
wh
bk
bu
gn
gy
Sense lead (−)
Sense lead (+)
Cable shield
SG and inductive half bridges
LVDT transducer
Measurement signal (+) Measurement
signal (+)
Bridge excitation
voltage (−)Bridge excitation
voltage (−)
Bridge excitation
voltage (+)
Measurement signal (−)
Sense lead (+)
Hsg.
5
3
Hsg.
Hsg.
Bridge excitation
voltage (+)
Sense lead (−)
Cable shield
Measurement
signal (+)
Bridge excitation
voltage (−)
Bridge excitation
voltage (+)
Sense lead (+)
Sense lead (−)
Cable shield
Measurement
signal (+)
Bridge excitation
voltage (−)
Bridge excitation
voltage (+)
Sense lead (+)
Measurement
signal (−)
(half bridge function)
To connect other sensors,refer to the Online help or the operating instructions.

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
8
A2073-5.0 en/de/fr
NOTE
When connecting transducers in 4-wire circuits, the sense leads must be
bridged with the appropriate excitation voltage (Pin 3 with Pin 2 and Pin 5 with
Pin 4).
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
1
2
4
6
Hsg.
5
3
wh
bk
rd
bu
ye
Feedback bridges for four-wire circuitry
4-wire circuit: Full bridge
1
2
4
6
Hsg.
5
3
wh
bk
gn
bu
ye
4-wire circuit: Half bridge
gy

9
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
3 Installing the PME Setup Assistant
•Insert the CD into the drive
Installation starts automatically or can be called up from the “Setup.exe” file.
Alternatively, the current Assistant can be downloaded from the HBM website
http://www.hbm.de > Support > Download > Software.
After installation, an icon is generated in the Windows
Start menu, with which the Assistant can be launched.
The Assistant initially displays the Setup window where the MP85A process
controller connection settings must be specified.
Factory settings
for the interface
Scanning the bus
for connected PME
modules
Opens the
Setup window
Interface
type 192 168 169 10
IMPORTANT
The network segment of the MP85A process controller (factory settings:
192.169.169.10) must also be set in the network settings of the PC (no auto-
matic address assignment via DHCP). The PC address may only differ in the
last group from the address of the MP85A process controller:
IP address example: 192.168.169.11
Subnet mask example 255.255.255.0
Further information and tips can be called up by clicking on the Help button.

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
10
A2073-5.0 en/de/fr
4 Preparing for measurement / Setting up mode
When it is switched on, the two-line display on the front of the MP85A process
controller shows the measured value and another line with status information.
If the device detects an error, this will also be shown on the display (for a de-
scription, see the Chapter “Error messages” and Chapter 9 in the MP85A pro-
cess controller operating manual).
Further device configuration is then implemented with the “PME Assistant”.
The individual masks are called up by clicking on the folder in the tree struc-
ture.
To close the window, click on the button at the top right of the window as is
the rule in Windows. The settings made in that window will then also be ap-
plied!
TIP
In order not to invalidate subsequent statistics while in set up mode, the PME
Assistance (menu: data backup) can be used to switch off the statistics proc-
essing.
Sensor settings:
The relevant characteristic transducer values must be entered with the PME
Assistant before measurements can be made.
1. Sensors with TEDS (electronic data sheet)
If the MP85A process controller is working with sensors that have TEDS, the
sensor settings can be transferred to the amplifier by clicking in the window
TEDS (Preparing for measurement −> Amplifier −> TEDS menu). Then all
that is needed is a zero balance.

11
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
TIP
To ensure that the TEDS function is automatically available after a power fail-
ure and also during measurement itself, select the relevant options in the
TEDS window and save them in the current parameter set (window: Save/
load parameters)
Sensors without TEDS (electronic data sheet)
Should you be using sensors without TEDS, the relevant sensor data must be
entered via the PME Assistant.
This includes:
1. Transducer type
2. Transducer characteristic curve (2 points). Subsequently,
3. A zero balance must be performed.

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
12
A2073-5.0 en/de/fr
In this example, a displacement transducer is connected to channel x and a
force transducer to channel y.
Step 1 (transducer window):
The displacement transducer works as a half bridge with an 80 mV/V mea-
suring range (the next highest with 100 mV/V was selected).
The force transducer works as a full bridge with an 2 mV/V measuring range
(the next highest with 4 mV/V was selected).
It is helpful to set the units at the same time (here: mm and kN).
Step 2 (enter characteristic curve window):
Two methods are available:
−Enter characteristic curve using the data sheet data
−Alternatively: Calibrate characteristic curve, specifying two points per sen-
sor

13
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
Simplest way:
Enter the values for the zero point and the full scale from the sensor data
sheet in the Enter characteristic curve window.
(e.g. Zero point: 0 mV/V corresponding to 0 kN
Span: 2 mV/V corresponding to 10 kN)
Alternatively: (Calibrate characteristic curve window) measure two points
per sensor
To keep measurement error as small as possible, the points used should lie at
the limits of the subsequently used measurement range.
Procedure:
1. Approach the first characteristic curve point , e.g. move displacement
transducer to the starting position, for force (and zero point as the selected
point), relieve the transducer.
2. Enter corresponding physical value in “Physical point 1”, e.g. 0 mm.
3. Click on “Measure point 1”. The value measured by the MP85A process
controller appears under “Electrical point 1”.
4. Move to second characteristic curve point, e.g. set path using gauge block,
set force value with weights or with reference transducer, etc.
5. Enter the value of quantity set under “Physical point 2”, e. g. 40 kN or
60 mm.
6. Click on “Measure point 2”. The value measured by the MP85A process
controller appears under “Electrical point 2”.
Apply the same procedure to the second sensor.
Step 3 (zero balance, signal conditioning), needed for sensors both with
and without TEDS:
The sensors are now connected and the system is in the starting position.
Carry out a zero balance for each sensor with the “Zero balance” button.
The sensor technology and the amplifier are now perfectly coordinated.
TIP
To store all the settings safe from power failure, these should now be saved in
the Save/load parameters window in the internal MP85A process controller
memory (menu: Save to Flash) as well as on the PC (menu: Save to PC)!
Further information and tips can be called up by clicking on the Help button.

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
14
A2073-5.0 en/de/fr
5 Specifying the evaluation criteria
This menu (Evaluation parameter settings) is used to specify the criteria to
later evaluate the process response as OK (OK) or not OK (NOK).
This is implemented by means of a curve trace, e.g. force-displacement dur-
ing a press-fit process, travelling through various windows (tolerance win-
dows). If the trace misses these windows or leaves the windows at the wrong
place, the press-fit process is evaluated as not OK (NOK) and displayed.
The Evaluation parameter menu allows measurements to be started and
stopped manually, i.e. using the mouse. The process curves measured in this
way can be used for better positioning of the tolerance windows.
The positioning of the individual windows is also implemented by using the
mouse. Once the windows are created, they can be moved around with the
“Drag and Drop” function or changed in size, as required. A maximum of 9 tol-
erance windows are available.
Alternatively, the evaluation can be implemented via an envelope curve or tol-
erance band (see MP85A online help).
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Status line
In this example, 4 windows are positioned at the characteristic points of the
press-fit process.

15
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
Step 1:
Call up the Evaluation parameter settings window
Step 2 (control settings):
The essential setting here:
−How will the measurement function be started/ended later in the process?
This is important as in the factory setting, evaluation with the OK/NOK deci-
sion is only implemented after measurement is completed!
It makes sense, when measuring force/displacement, for the Start setting to
be: “Channel x setpoint exceeded” (here displacement) and the Stop setting
to be: “Channel x return” (here displacement).
The standard end condition set is:
End: at external signal or when exiting start conditions
If the stop signal must come from an external controller, the stop condition
“External stop” should be selected. The “Start/Stop process” function can be
assigned to a digital input. This must be set in the menu “Digital inputs”.
Status bar:
Information about the measurement process will be displayed here and also
later in measuring mode:
−Measurement sequence (e.g. running or finished)
−Reasons for an alarm (e.g. values outside the alarm window/machine pro-
tection)
−Reason for end of measurement (e.g. external stop)

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
16
A2073-5.0 en/de/fr
Step 3 (Alarm range window):
Call the Alarm window window and press the “Automatically adjust alarm
and range window” button. This will automatically adapt the display and con-
trol area to the measuring range of the connected sensors.
Step 4 (tolerance window):
Use the left mouse button to move the tolerance windows to the decisive posi-
tions for the process.
To do this:
•Keep the left mouse button pressed down
•Pull window
•Select: “New window”
(In this case: Window 1 for the thread-in process, window 2 for the fitting pro-
cess and window 3 as the end window to display the block force).
NOTE
All tolerance windows must lie within the range window marked in green. The
blue alarm window must be at least as big as the range window – the size can
be changed with the mouse.
Step 5:
To set up further evaluation criteria for the tolerance windows, click on the re-
quired window which will then appear in blue.
Clicking on the button opens another window where you can e.g. se-
lect the entry and exit sides.
Step 6:
In setting up mode, use the button to start a measurement “manually”,
run the process through and then stop again manually with the button.
If necessary, repeat this process several times to obtain an accurate curve
family. To do this, click on the “Curve history” item in the “Graphics” menu first.

17
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
TIP
To store all the settings safe from power failure, these should now be saved in
the Save/load parameters window in the internal MP85A process controller
memory (Flash) and in the PC!
Select the memory directory under “File −> Specify memory directory”.
Further information and tips can be called up by clicking on the Help button.
6 Measuring and displaying (continuous production)
The graphic display of the test process during continuous production, with all
tolerance windows, is implemented in the Measurement curve window. By
default, the last measurement curve is always shown. It is also possible, in the
“Graphics” menu, to select the display of several curves: “Curve history”.
Measurement curve
Results of last measurement
Status line
This window also has a status bar at the lower end. It shows:
−The progress of the measurement, then after the evaluation the OK or NOK
decision
−Reasons for an alarm
−Reasons for the end of measurement

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
18
A2073-5.0 en/de/fr
7 Results of the last measurement
The evaluation of the last process can be shown as a table, with all important
information (window: Results of last measurement). The minimum and max-
imum values of the process are also displayed here.
The switching results and haptic measured values are also displayed in a ta-
ble when the MP85A(DP)-EASYswitch is used.

19
MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
A2073-5.0 en/de/fr
8 Displaying saved processes / Report printout
(Data storage window)
To ensure optimum traceability for the production process, the curves, results
and statistical evaluations of all measured processes can be saved and dis-
played on the screen. This does not occur automatically with the “Save pa-
rameters” function, you must set the save procedure in the Data storage win-
dow.
TIP
Select the memory directory under “File −> Specify memory directory”.
The saved data can then be displayed by the PME Assistant or imported into
other programs (e.g. Excel).
Step 1
Step 2
Step 3
Step 1 (storage target):
To save data to the PC, select the storage target “External via CAN/Ethernet”.
Step 2 (results):
Specify here which results should be saved (OK, NOK, all, none).
Step 3 (curves):
Specify here which curves should be saved (OK, NOK, all, none).
Calling up saved data / Report printout:
(Display saved data window)

MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
20
A2073-5.0 en/de/fr
After opening this window, previously saved measurement curves and overall
results (process data and OK/NOK evaluation) can be loaded and displayed
in the empty diagram.
Curves
Step 3
Process data
Step 2
Step 1
Result
Step 1:
Click on the directory symbol to open a search mask where the required
process and result data can be selected.
Step 2:
Various search criteria can be entered, as well as the directory on the PC.
Click on the “Find” button to display the selection of items found. A new
search can be made at any time.
Step 3:
Click on the required file in the search field to automatically transfer it to the
graphic window for display (Result).
