HCT MVP-R Series User manual

021-MVP-R Rev C 1 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
www.enovationcontrols.com
MVP-R
Proportional Valve Ramping Controller
User Manual

021-MVP-R Rev C 2 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
Revision Record
Rev Description
Date Released
Last Updated by
Rev A Initial Revision 16-Dec-13 WB
Rev B
Upgrade to 32V and IP65 ratings 14-Oct-14 WB
Rev C
Removed 2.5A Option 15-Feb-19 CB

021-MVP-R Rev C 3 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
Contents
Revision Record...................................................................................................................................................... 2
HCT Introduction..................................................................................................................................................... 4
Product Use Limitations .......................................................................................................................................... 4
Product Application Guidelines ............................................................................................................................... 5
MVP-R Ramping Controller .................................................................................................................................... 6
Operating Specifications ................................................................................................................................. 6
Physical Description........................................................................................................................................ 7
User Interface ................................................................................................................................................. 7
Configuration................................................................................................................................................... 8
Parameter List............................................................................................................................................... 11
Wiring ............................................................................................................................................................ 13
Order Information .................................................................................................................................................. 13
Application Examples............................................................................................................................................ 14
Single Solenoid Control ................................................................................................................................ 14

021-MVP-R Rev C 4 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
HCT Introduction
Welcome to High Country Tek Inc. HCT is North America’s foremost independent designer and producer of
modular, ruggedized digital and analog electronic controllers for the fluid power industry.
From our factory in California, we manufacture ‘specialty’ controllers for specific functions and the user
programmable ‘DVC family’ to enable large area networked system solutions.
The modules are used in mobile, industrial and marine applications. They are also applied successfully in other
industry segments.
HCT products are encapsulated in solid flame resistant material for maximum durability, electrical integrity and
complete environmental security.
HCT is a market leader in many application arenas, including hydraulic generator, e-Fan and hydraulic fan system
controls. These controllers facilitate significant fuel, emission and operational savings.
HCT’s market neutrality offers integration with any hydraulic OEM valves, pumps, sub-systems or systems.
For more information, please visit us at: www.enovationcontrols.com.
Product Use Limitations
HCT products may not be suited for any of the following applications:
•Any product which comes under the Federal Highway Safety Act, namely steering or braking systems for
passenger-carrying vehicles or on-highway trucks.
•Aircraft or space vehicles.
•Ordinance or military equipment.
•Life support equipment.
•Any end product which, when sold, comes under U.S. Nuclear Regulatory Commission rules and regulations.
HCT does not have any performance assurance programs for testing their products for the above applications.
HCT's products are not designed for these applications and HCT does not warrant, recommend, or specifically
approve its products for these applications.
The user shall be solely responsible for any loss or damages occasioned by breach of the provisions of this
paragraph and shall carry product liability and liability insurance to insure against such loss or damages.

021-MVP-R Rev C 5 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
Cautions
Changing setup values or operating modes while a machine is running may cause unintended machine movement.
It could lead to possible injury or death. Any moving parts should be disabled prior to changing setup values or
operating modes. In every case, exercise caution and work should be completed only by qualified personnel.
Product Application Guidelines
ALWAYS do the following
•FULLY read this manual and accompanying data sheets BEFORE starting.
•Isolate this unit from all other equipment BEFORE any form of welding.
•Isolate the controller from ANY form of battery charging or battery boosting.
•Be aware of the electrical & mechanical connections, and the expected reactions of the equipment.
•Operate the units within the temperature range.
•Use the correct tools to do the job (i.e. P.C., software) etc.
•Separate High Voltage AC cables from Low Voltage DC signal and supply cables.
•Make sure power supply is CORRECT, ELECTRICALLY CLEAN, STABLE, and rated for the full load.
•Make sure the controller output voltage & current is compatible with the equipment.
•All unused wires / terminals should be terminated safely.
•Ensure ALL connectors have no unintended SHORT or OPEN circuits.
•Ensure ALL connectors are wired correctly, secure, locked in place and fully connected.
•Disconnect or connect wires to or from this unit only when the power supply is disconnected.
•Use adequate screening in areas of intense Radio Frequency fields.
•Ensure ALL work areas are clear of personnel before operating the controller.
•Follow and abide by local and country health & safety standards.

021-MVP-R Rev C 6 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
MVP-R Ramping Controller
The MVP-R controller drives proportional solenoid valves with adjustable ramp times.
Once configured, the settings are permanently stored in the controller memory.
MVP-R Features
Easily configured using HCT Graphical User Interface (GUI) or HCT Hand Held Interface (HHI)
LED indication of power, output current and fault status
Permanently sealed, standard DIN 43650 Form A connector body with pre-wired 18AWG PVC cable
Single coil applications, programmable enable input
Output limits are independently adjustable
Adjustable output with short circuit protection
Adjustable ramp up and ramp down times (RP1 has ramp up only)
Operating Specifications
Supply Voltage 9 to 32VDC
Supply Current Valve current + 20mA (Quiescent Max)
Output Current -06A: 600mA MAX -12A: 1.2A MAX -25A: 2.5A MAX
Coil Resistance 2Ω MIN.
Dither Frequency 80, 100, 120, 140, 160, 180, 200, 220, 240, 260, 280, 300.
(Select OFF for 1000Hz)
Ramp Functions -RP1: ramp up only -RP2: ramp up and down
Enable Input Voltage (RP2) 9 to 32VDC
Operating Temperature Range -40º to 85º C (operating); -60º to 90º C (storage)
Enclosure 33% glass reinforced, heat stabilized, black polyamide 66
Dimensions Inch: 2.4 L x 1.2 W x 0.75 H; Mm: 60 L x 30 W x 19 H
NEMA/IP Rating NEMA 4 / IP67

021-MVP-R Rev C 7 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
Physical Description
There are two indicator LEDs: STATUS and OUTPUT. The STATUS LED is green when the applied voltage is
within the operating range.
The OUTPUT LED is yellow and the brightness will vary with the output current.
In the case of a fault the STATUS LED will flash red with a flash code. See Fault Status for details.
The MVP communicates with the Graphical User Interface through an infrared interface port to RS232. The infrared
adapter clips onto the MVP-R aligning with the notches in the sides. It must be powered when configuring the
settings.
User Interface
The MVP has a number of internal settings.
Users can open the Graphical User Interface to view, make changes and save the settings in a data file, which can
be uploaded to any MVP controller.
30mm
60mm
19mm
DIN
43650
Form A
+
-

021-MVP-R Rev C 8 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
The users can use the Hand Held Interface to view and make changes, but can not save the settings in a data file.
The programmer, cable and adapter are self-contained which makes HHI a viable alternative for field work.
Configuration
The GUI has 4 buttons: Lock, Unlock, Up, and Down. There are short-cut keys: ‘/’(lock), ‘*’(unlock), ‘+’(up), and ‘-
‘(down).
The HCT Hand Held Interface has the same 4 buttons and a 2-line LCD display.
Use the up and down arrows to navigate through the parameter list. The display will show the next parameter in the
list when pressed. The parameter name is on the first line and the value is on the second line. The list scrolls,
stepping down from the last parameter to the first and vice-versa.
There are three types of parameters: fixed; monitor; and variable. Fixed parameters show the module’s firmware
version, etc. Monitor parameters display output current and system voltage. Use variable parameters to configure
the controller, such as maximum output current, operating mode, etc. Some parameters combine variable and
monitor in one line. Use it to set a variable according to the current monitor value.
Press the unlock button to enter the edit mode. An asterisk (*) will appear at the beginning of the second line. Use
the up and down buttons to change the value. For parameters containing both variable and monitor, the monitor
data is in square brackets.
Press the lock button to save the parameters and end edit mode.

021-MVP-R Rev C 9 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
When the lock button is pressed, the changes take effect immediately. Change values only when the machine is
NOT running.
“Read settings from controller” displays a static table of values from non-volatile memory. The changes made to the
settings by selecting “lock” are not updated in the table unless “read settings from controller” is selected again.
To save the settings into a file for future use, click “read settings from controller” before clicking “save settings to
file”.

021-MVP-R Rev C 10 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
When uploading settings from a data file, the static table shows the settings from the data file, but they are not in
the controller yet.
Click “write settings to controller” before clicking “read settings from controller”. After this step, the static table will
display the MVP settings from the data file.

021-MVP-R Rev C 11 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
Parameter List
The following table outlines the MVP-R parameters as well as the limits and units of measure for each parameter.
Parameter Limits Units
MVP-RPx-xxx Version #
Ramp time factor X1, /10 Mode #
Ramp up time 0.0 to 120.0 Seconds
Ramp down time*0.0 to 120.0 Seconds
Minimum output 0 to 600** mA
Maximum output 0 to 600** mA
Dither frequency 80 to 300,
(select OFF for 1000Hz)
Hz.
Output current mA
Supply voltage Volts
Fault status Fault
*RP2 only
**0 to 1.2A for –12A version, 0 to 2.5A for –25A version

021-MVP-R Rev C 12 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
MVP-RPx-xxx The title parameter is fixed. It displays the model number and the firmware version.
RAMP TIME FACTOR Sets the rate of change for the output current. If the Ramp Time Factor is x1, the ramp
time will match the ramp time settings. If it is set to 1/10, the ramp time will be 1/10 of
the ramp time setting.
RAMP UP/DOWN TIME Sets the rate of change for Output current.
For RP1, the output current increases from Minimum to Maximum.
For RP2, the output current is initially set to the Minimum.
•The output current increases from Minimum to Maximum within the Ramp Up time
when switching ON “ENABLE” switch.
•The output current decreases from Maximum to Minimum within the Ramp Down
time when switching OFF “ENABLE” switch.
MIN OUTPUT Sets the minimum output current (milliamps, amps for -12A,-25A). The value in the
brackets is the present output current.
MAX OUTPUT Sets the maximum output current (milliamps, amps for -12A,-25A). The value in the
brackets is the present output current.
DITHER FREQ. Options: 80, 100, 120, 140, 160, 180, 200, 220, 240, 260, 280, 300, (Select OFF for
1000Hz). Set the PWM or dither frequency according to the valve specifications. This
parameter is variable.
OUTPUT CURRENT Displays the present output current. This parameter is a monitor type.
SUPPLY VOLTAGE Displays the module’s power supply voltage. It is helpful for troubleshooting. This
parameter is a monitor type.
FAULT STATUS The STATUS LED will flash red 2 times for Coil Open and 3 times for Coil Short.

021-MVP-R Rev C 13 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
Wiring
Order Information
For the Hand Held Interface Device: P/N: CBL-IRA
For the PC software SAM: PN: CBL-IRMU
MVP-RP2 Wiring
Terminal
Function
Brown
PWR
Blue
PWR GND
Black
Enable Input
White
Not Used
Red
Not Used
GRN/YEL
Connector GND
MVP-RP1 Wiring
Terminal
Function
Brown
PWR
Blue
PWR GND
GRN/YEL
Connector GND
MVP-RP1-06A-10F
10F = 10ft cable
20F & 30F standards
06A = 600mA output
12A = 1200mA output
25A = 2500mA output
RP1 = Ramp up only
RP2 = Ramp up/down

021-MVP-R Rev C 14 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
Application Examples
Single Solenoid Control
The MVP can drive a single solenoid.
Set the dither and output settings according to the valve specifications.
Ramp up
time
Min
Max
Output Current
Seconds
Enable
/ON
Ramp up
time
Min
Max
Output Current
Seconds
Enable
/OFF
Ramp down
time
FUSE
+V Power Input
9 - 32VDC
+V = Enabled
Brown PWR +
MVP-RP2
Electronic Valve
Controller
BLK Enable
GRN/YEL
Prop. PWM (Sourcing)
Red
White
Blue GND
Connector GND
Screen
FUSE
+V Power Input
9 - 32VDC
Brown PWR +
MVP-RP1
Electronic Valve
Controller GRN/YEL
Prop. PWM (Sourcing)
Blue GND
Connector GND
Screen

021-MVP-R Rev C 15 Copyright © High Country Tek by Enovation Controls - 2019
MVP-R
