HDanywhere XTND2K30 User manual

XTND 2K (30m) Extender Manual
Product Code: XTND2K30
EQ HDMI OUT IR (IN)
DC5VIR (IN)
CAT
CAT
SOURCE INPUT EDID HDMI OUT

XTND 2K (30m) Extender Manual
2
CONTENTS
Contents, introduction and box contents
5 minute quick setup guide and system features
Transmitter, receiver and setting up IR control
Standard wiring diagram
Edid management and short-run adjust

Guarantee, warranty information and contacting
customer support
2
3
4
5
6
7

YOUR
EXTENDERS
Use an XTND 2K (30m) to extend
your favourite HDMI media device
(DVD/Blu-Ray player, Xbox, Apple
TV etc) to a HDTV located up to 30m
away.
XTND 2K (30m) requires Cat cabling
to be run from the transmitter to
the display receiver, which you can
run yourself if capable or choose to
have professionally installed. XTND
2K (30m) has a built-in HDMI splitter
that lets you share one media device
between a ‘local’ or nearby display as
well as a ‘remote’ display up to 30m
away. With IR passback, you can also
control your media device.
1. x1 XTND 2K (30m) Transmitter
2. x1 XTND 2K (30m) Receiver
3. x1 5V / 1A DC PSU
4. x1 IR transmitters (TX)
5. x1 IR receivers (RX)
IN THE BOX

XTND 2K (30m) Extender Manual
3
QUICK SETUP
SYSTEM FEATURES
This quick setup guide will get your extender up and working in less than 5 minutes.
If you need to integrate IR control then please continue on to page 4.
1. 
device.
2. Connect the HDMI source to the Source Input
port on the XTND 2K (30m) Transmitter using
an appropriate HDMI cable.
3. Connect a display such as a HDTV or HD
Projector to the HDMI out port on the XTND
2K (30m) receiver using an appropriate HDMI
cable. We recommend that you use high-
speed HDMI cables no longer than 5 meters in
length.
4. Now connect a single Cat5e/6 cable up to
164ft/30m in length between the Cat output
port of the XTND 2K (30m) transmitter and the
Cat input port on the XTND 2K (30m) receiver.
1. Delivers uncompressed video and audio over
network cable
2. Supports the following resolutions:
a. 1080p/1080i/720p/576p/480p/576i/480i
b. Up to 24-Bit Deep Colour
3. HDMI loop out for a local display
4. Enables HD viewing in one additional room
5. If you are connecting a nearby or “local”
display use the HDMI loop out port. Connect
your TV to this port with an appropriate HDMI
cable.
6. Plug in the power supply for the Transmitter.
7. Power on your HDMI source device, then
power on connected displays.
8. At this point the display should show the
video and audio of the HDMI source device
that is connected to the extender.
5. Stereo or multichannel audio including:
a. LPCM 7.1CH
b. Dolby True HD
c. DTS-HD Master Audio
d. Dolby Atmos
6. EDID management
7. One-way IR

XTND 2K (30m) Extender Manual
4
TRANSMITTER AND RECEIVER (x1)
1. HDMI source input port: Connect HDMI source
e.g. BluRay player, with HDMI cable
2. EDID switch: See page 6
3. HDMI out port: Connect a local display or an
AVR to this port using appropriate HDMI cabling
4. IR (OUT): Plug the supplied IR TX into this port
5. CAT 5e/6 output: Connect the CAT 5e/6 cabling
run from the receiver to this port
SETTING UP
IR CONTROL
This will enable backwards IR
control (the most common form of
IR control) where IR signals from
a remote in your distant zone is
sent back to the extender and sent
to your source device to make it
appear as though it is in the same
room as you.
6. DC input: Plug the 5V / 1A DC power supply into the
unit
7. Short run adjust: See page 6
8. HDMI out: Connect a local display or an AVR to this
port using appropriate HDMI cabling
9. IR IN: Plug the supplied IR RX into this port
10. CAT 5e/6 input: Connect the CAT 5e/6 cabling run
from the transmitter to this port
SOURCE CONTROL VIA IR (BACKWARDS IR)
1. Plug IR transmitter (TX) into the 3.5mm jack port labelled IR (OUT)
on the XTND 2K (30m) transmitter.
2. Place IR transmitter (TX) bud (small circular part) in front of the IR
eye of the source (where you would normally point the remote to
control the HDMI source device).
3. Plug IR receiver (RX) into the 3.5mm jack port labelled IR (IN) on
the XTND 2K (30m) receiver.
4. Place IR receiver (RX) at or near the display (position it close to
where you would usually point your remote to turn your TV on or

7 8 9 10
1 2 3 4 5 6
EQ HDMI OUT IR (IN)
DC5VIR (IN)
CAT
CAT
SOURCE INPUT EDID HDMI OUT

XTND 2K (30m) Extender Manual
5
STANDARD WIRING DIAGRAM
This is a typical wiring diagram that shows how we would expect an XTND 2K (30m) Extender set up to look
once installed. This diagram features a single HDMI source device (a BluRay player) being sent to 1 room, with a
display located up to 30 metres away, and with IR controlling the source device via backwards IR.
IR cable
HDMI cable - 25m / 82ft Max
HDMI over cat cable - 50m / 164ft Max
Connection
Direction
IR Transmitter
IR Receiver
Key
DC5V

XTND 2K (30m) Extender Manual
6
EDID MANAGEMENT

sent by a display to describe its capabilities to a
HDMI source. For example, it’s what enables a
modern computer to know what kinds of monitors
are connected to it.
The XTND 2K (30m) can copy EDID data from both
the local display or the remote display. If the EDID
switch is in the ‘right’ position it will copy EDID
data from the local display. In the ‘left’ position it
will copy EDID data from the remote display.
SHORT RUN ADJUST

settings to improve the picture. You can typically assume the correct position of the switches based on the
distances shown below.
RECOMMENDED EQ SETTINGS
Position Cable Length
0 1
Under 15m (49.5ft)
0 1

0 1
30-40m (99ft - 132ft)
0 1
40-50m (132ft - 164ft)

XTND 2K (30m) Extender Manual
7
SPECIFICATION
Frequency bandwidth
4.95 Gbps
Transmitter input/output ports
x1 HDMI input
x1 Local HDMI output
x1 Cat 5e/6
x1 IR Transmitter
Receiver input/output ports
x1 HDMI
x1 Cat 5e/6
x1 IR Receiver
Power supply
1x DC 5V 1A
ESD Protection Human Body Model
± 8kV (air-gap discharge) ± 4kV (contact discharge)
Dimensions (mm) (Width x Depth x Height)
Display receiver (49 x 81 x 25)
Weight (g)
Display receiver (140g) x2
Operating temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative humidity
20 ~ 90% RH (Non-condensing)
Maximum power consumption
Display receiver (1.5W) x2

XTND 2K (30m) Extender Manual
8
TWO-YEAR REPLACEMENT WARRANTY &
GUARANTEE
A one-year worldwide replacement guarantee covering HDanywhere™ electronic devices is provided by HD
Connectivity Ltd. . If you need to use this guarantee, please contact HDanywhere Customer Services: support@

Hereby, HDanywhere™ declares that this HDMI connectivity device is in compliance with the essential require-
ments and other relevant provisions of the following Directives: 2006/95/EC (LVD Directive); 2004/108/EC (EMC
Directive); 999/5/EC (R&TTE Directive).
www.hdanywhere.co.uk
